Philips TAH1205 Bedienungsanleitung

User manual

www.philips.com/support

TAH1205

Headphones

1000 Series

1 Important safety instructions 2

Hearing Safety 2

General information 2

2 Your Bluetooth on-ear

headphones 3

What's in the box 3

Other devices 3

Overview of your Bluetooth

wireless headset 4

3 Get started 5

Charge the battery 5

Pair the headphones with your

mobile phone 5

4 Use your headphones 6

Connect the headphones to a

Bluetooth device 6

Manage your calls and music 6

5 Technical data 8

6 Notice 9

Declaration of conformity 9

Disposal of your old product

and battery 9

Remove the integrated battery 9

Compliance with EMF 9

Environmental information 10

Notice of compliance 10

7 Trademarks 11

7 Frequently asked questions 12

Contents

1 Important

safety

instructions

Hearing Safety

Danger

 To avoid hearing damage, limit the time you

use headphones at high volume and set the

volume to a safe level. The louder the

volume, the shorter the safe listening time is.

Be sure to observe the following guide-

lines when using your headset.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume

continuously upwards as your

hearing adapts.

• Do not turn up the volume so high

that you can't hear what's around

you.

• You should use caution or tempo-

rarily discontinue use in potentially

hazardous situations.

• Excessive sound pressure from

earphones and headphones can

cause hearing loss.

• Using headphones with both ears

covered while driving is not recom-

mended and may be illegal in some

areas while driving.

• For your safety, avoid distractions

from music or phone calls while in

trac or other potentially dangerous

environments.

General information

To avoid damage or malfunction:

Caution

 Do not expose headphones to excessive heat

 Do not drop your headphones.

 Headphones shall not be exposed to dripping

or splashing.

 Do not allow your headphones to be

submerged in water.

 Do not use any cleaning agents containing

alcohol, ammonia, benzene, or abrasives.

 If cleaning is required use a soft cloth, if

necessary dampened with a minimum amount

of water or diluted mild soap, to clean the

product.

 The integrated battery shall not be exposed to

excessive heat such as sunshine, re or the

like.

 Danger of explosion if battery is incorrectly

replaced. Replace only with the same or

equivalent type.

About operating and storage

temperatures and humidity

• Operate or store in a place where

temperature is between -10°C

(14°F) and 60°C (140 °F) (up to 90%

relative humidity.

• Battery life may be shorter in high

or low temperature conditions.

2 Your

Bluetooth

on-ear

headphones

What's in the box

Philips Bluetooth on-ear headphones

Philips TAH1205

Quick start guide

Other devices

A mobile phone or device (e.g. note-

book, PAD, Bluetooth adapters, MP3

players etc) which supports Bluetooth

and is compatible to the headset (see

'Technical data' ).

Congratulations on your purchase, and

welcome to Philips! To fully benet

from the support that Philips oers,

www.philips.com/welcome.

With this Philips on-ear headphones,

you can:

• enjoy convenient wireless

handsfree calls;

• enjoy and control wireless music;

• switch between calls and music.

USB charging cable (for charging only)

Global Warranty

Safety leaet

Overview of your

Bluetooth wireless

headset

Volume + / Next track

Music/call control

Volume - / Previous track.

LED indicator

Micro USB C charging slot

Microphone

(Power on / o / Pairing)















3 Get started

Charge the battery

Note

 Before you use your headset for the rst time,

place the headsets in the charging case and

charge the battery for 2 hours for optimum

battery capacity and lifetime.

 Use only the original USB charging cable to

avoid any damage.

 Finish your call before charging the headset,

as connecting the headset for charging will

power the headset o.

Connect the supplied USB charging

cable to:

• The Micro USB charging slot on the

headphones and;

• The charger/USB port of a computer.

Tip

 Normally, a full charge takes 2 hours.

Pair the headphones with

your mobile phone

Make sure that the headphones are

fully charged and turned o.

Make sure that the mobile phone is

turned on and its Bluetooth feature

is activated.

The headphone remain in

pairing mode for 5 minutes.

Before you use the headphones with

your mobile phone for the rst time, pair

it with a mobile phone. A successful

pairing establishes a unique encrypted

link between the headphones and

mobile phone. The headphones store

the last 8 devices in the memory. If you

try to pair more than 8 devices, the

earliest paired device is replaced by the

new one.

The following example shows you how

to pair the headphones with your mobile

phone.

LED turns white during charging and

turns o when the headphones in

fully charged.

Press and hold for 4 seconds

until the blue and white LED ashes

alternately.

Philips TAH1205

Pair the headphones with the

mobile phone. For detailed infor-

mation, refer to the user manual of

your mobile phone.

Activate the Bluetooth feature of your

mobile phone, select Philips TAH1205

4 Use your

headset

Connect the headset to

your Bluetooth device

Turn on your mobile phone/

Bluetooth device.

Press and hold the on/o button for

2 seconds to turn heaphones on.

The blue LED will turn on .

The headphones are recon-

nected to the last connected

mobile phone/ Bluetooth

device automatically.

Tip

 If you turn on the mobile phone/Bluetooth

device or activate the Bluetooth feature after

turning on the headphones, you have to

reconnect the headphones and mobile

phone/ Bluetooth device manually.

 If the headphone has no any connection

history and doesn’t connect any Bluetooth

device whith 5 minutes, it will switch o

automatically.

 If the headphones fail to connect to last

connected Bluetooth device within range in 5

minutes, it will switch o automatically.

Note

Manage your calls and

music

On/o

Task Button Operation

Turn the

head-

phones on.

On/o Press and hold

for

2 seconds.

Turn the

head-

phones o.

On/o Press and hold

for 4 seconds.

The Blue

LED is on

and fades

out.

Music control

Task Button Operation

music/call

control

Play or

pause music.

Press once.

Press to +/-

Press to +

Adjust volume.

Next track.

Previous track.

Call control

Task Button Operation

Pick up/

hang up a

call.

Switch

caller

during a

call.

music/

call control

music/-

call

control

Press once.

twice.

Press to -

twice.

Press and

hold(>2s)

Other headphones indicator status

Headphones status Indicator

The headphones

are connected

to a Bluetooth

device, while the

headphones in

standby mode

or while you are

listening to music.

The blue LED will

ash every 5s.

The headphones

are ready for

pairing.

The LED ashes

blue and white

alternately.

The headphones

are on but not

connected to a

Bluetooth device.

The Blue LED

ashes every 10

seconds. If no

connection

can be made, the

headphones will

turn itself o within

5 minutes.

Low battery level. The white LED

ash 3 times,

trigger once in one

minute

Battery is fully

charged.

White LED is o.

5 Technical data

Note

 Specications are subject to change without

notice.

Headset

Music time: 15 hours

Talk time: 15 hours

Standby time: 240 hours

Charging time: 2 hours

Rechargeable lithium polymer

battery (240 mAh)

Bluetooth version: 5.1

Compatible Bluetooth proles:

• HFP (Hands-Free Prole)

• A2DP (Advanced Audio Distri-

bution Prole)

• AVRCP (Audio Video Remote

Control Prole)

Supported audio codec: SBC

Frequency range: 2.402-2.480 GHz

Transmitter power: < 10 dBm

Operating range: Up to 10 meters (33

feet)

Digital echo & noise reduction

Auto power o

Micro USB port for charging

Remove the integrated battery

6 Notice

Hereby, MMD Hong Kong Holding Limited

declares that this product is in compli-

ance with the essential requirements and

other relevant provisions of Directive

2014/53/EU. You can nd the Declaration

of Conformity on www.p4c.philips.com.

Declaration of conformity

Disposal of your old

product and battery

Your product is designed and manufac-

tured with high quality materials and

components, which can be recycled and

reused.

This symbol on a product means that

the product is covered by European

Directive 2012/19/EU.

This symbol means that the product

contains a built-in rechargeable battery

covered by European Directive

2013/56/EU which cannot be disposed

of with normal household waste. We

strongly advise you to take your product

to an ocial collection point or a Philips

service centre to have a professional

remove the rechargeable battery.

Inform yourself about the local separate

collection system for electrical and

electronic products and rechargeable

batteries. Follow local rules and never

dispose of the product and rechargeable

batteries with normal household waste.

Correct disposal of old products and

rechargeable batteries helps prevent

negative consequences for the environ-

ment and human health.

If there is no collection/recycling system

for electronic products in your country,

you can protect the environment by

removing and recycling the battery

before disposing the headphones.

• Make sure the headset is discon-

nected from the charging case

before removing the battery.

Compliance with EMF

This product complies with all applica-

ble standards and regulations regarding

exposure to electromagnetic elds.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips Kopfhörer Handbücher

Philips

Philips SHG8015 Bedienungsanleitung

Philips

Philips SHB3080 Bedienungsanleitung

Philips

Philips Over Ear PH802 Bedienungsanleitung

Philips

Philips TAT2206WT/00 Bedienungsanleitung

Philips

Philips TAN4207 Bedienungsanleitung

Philips

Philips SHB9250/00 Bedienungsanleitung

Philips

Philips TAT1108 Bedienungsanleitung

Philips

Philips SHK3020 Bedienungsanleitung

Philips

Philips SHN2600/28 Bedienungsanleitung

Philips

Philips SHN9500 Bedienungsanleitung

Philips

Philips SHB9250 Bedienungsanleitung

Philips

Philips SBC HS500 Bedienungsanleitung

Philips

Philips SHN6000 Bedienungsanleitung

Philips

Philips SHB5950BK/00 Bedienungsanleitung

Philips

Philips SHS4701 Bedienungsanleitung

Philips

Philips SBCHP430 Bedienungsanleitung

Philips

Philips SHJ026 Bedienungsanleitung

Philips

Philips SHS4846 Bedienungsanleitung

Philips

Philips SHS3201 - Headphones - Over-the-ear Bedienungsanleitung

Philips

Philips SHB5250 Bedienungsanleitung

Philips

Philips SBCHD1500U Bedienungsanleitung

Philips

Philips SHE2637 Bedienungsanleitung

Philips

Philips SHE9555 Bedienungsanleitung

Philips

Philips SBCHL150 Bedienungsanleitung

Beliebte Kopfhörer Handbücher anderer Marken

Sony

Sony MDR-NC8 Bedienungsanleitung

AUSounds

AUSounds AU-Stream Bedienungsanleitung

ENERGY SISTEM

ENERGY SISTEM Style 7 Bedienungsanleitung

Insignia

Insignia NS-CAHBTSPORT Bedienungsanleitung

Movie Vision

Movie Vision HP-400 Bedienungsanleitung

MobiFren

MobiFren SM Pro Bedienungsanleitung

Motorola solutions

Motorola solutions PMLN8120 Bedienungsanleitung

Jaybird

Jaybird freedom Installationsanleitung

Sony

Sony MDR-ED12LP Bedienungsanleitung

HiFuture

HiFuture Tidy Buds Pro Bedienungsanleitung

Creative

Creative CB2530 Bedienungsanleitung

Renkforce

Renkforce RF FTVK-100 Bedienungsanleitung

Sennheiser

Sennheiser 500371 Bedienungsanleitung

Califone

Califone 2924AV Bedienungsanleitung

Technics

Technics EAH-AZ80 Bedienungsanleitung

Bose

Bose On-Ear Headphone Gebrauchs- und Wartungshandbuch

Aluratek

Aluratek ABH02F Bedienungsanleitung

Waterfi

Waterfi swimQ Bedienungsanleitung
