Philips TAPN505BK Bedienungsanleitung

TAPN505

5000 Series5000 Series

Headphones

User manual

www.philips.com/support

1 Important safety instructions 2

Hearing Safety 2

General information 2

2 Your Bluetooth in-ear

headphones 3

What's in the box 3

Other devices 3

Overview of your Bluetooth

wireless headphone 4

3 Get started 5

Charge the battery 5

Pair the headphones with your

mobile phone 5

4 Use your headphones 6

Connect the headphones to a

Bluetooth device 6

Connect to ANC(active noise

cancelation) 6

Connect to airline audio systems 7

Manage your calls and music 7

5 Technical data 8

6 Notice 9

Declaration of conformity 9

Disposal of your old product

and battery 9

Remove the integrated battery 9

Compliance with EMF 9

Environmental information 10

Notice of compliance 10

7 Trademarks 11

8 Frequently asked questions 12

Contents

1 Important

safety

instructions

Hearing Safety

Danger

 To avoid hearing damage, limit the time you

use headphones at high volume and set the

volume to a safe level. The louder the

volume, the shorter the safe listening time is.

Be sure to observe the following guide-

lines when using your headphone.

• Listen at reasonable volumes for

reasonable periods of time.

• Be careful not to adjust the volume

continuously upwards as your

hearing adapts.

• Do not turn up the volume so high

that you can't hear what's around

you.

• You should use caution or tempo-

rarily discontinue use in potentially

hazardous situations.

• Excessive sound pressure from

earphones and headphones can

cause hearing loss.

• Using headphones with both ears

covered while driving is not recom-

mended and may be illegal in some

areas while driving.

• For your safety, avoid distractions

from music or phone calls while in

trac or other potentially dangerous

environments.

General information

To avoid damage or malfunction:

Caution

 Do not expose headphones to excessive heat

 Do not drop your headphones.

 Headphones shall not be exposed to dripping

or splashing.

 Do not allow your headphones to be

submerged in water.

 Do not use any cleaning agents containing

alcohol, ammonia, benzene, or abrasives.

 If cleaning is required use a soft doth, if

necessary dampened with a minimum amount

of water or diluted mild soap, to clean the

product.

 The integrated battery shall not be exposed to

excessive heat such as sunshine, re or the

like.

 Danger of explosion if battery is incorrectly

replaced. Replace only with the same or

equivalent type.

About operating and storage

temperatures and humidity

• Store in a place where temperature

is between -20°C (-4°F) and 50°C

(122 °F) (up to 90% relative humidi-

ty.

• Operate in a place where tempera-

ture is between -10°C (14°F) and

50°C (122 °F) (up to 90% relative

humidity.

• Battery life may be shorter in high

or low temperature conditions.

2 Your

Bluetooth

in-ear

headphones

What's in the box

Philips Bluetooth in-ear headphones

Philips TAPN505

Replaceable rubber ear caps x 3 pairs

Quick start guide

Other devices

A mobile phone or device (e.g. note-

book, PDA, Bluetooth adapters, MP3

players etc) which supports Bluetooth

and is compatible to the headphone

(see 'Technical data' on page 8).

Congratulations on your purchase, and

welcome to Philips! To fully benet

from the support that Philips oers,

www.philips.com/support.

With this Philips in-ear headphones,

you can:

• enjoy convenient wireless

handsfree calls;

• enjoy and control wireless music;

• switch between calls and music.

Audio cable with micro USB plug

USB charging cable (for charging only)

Overview of your

Bluetooth wireless

headphone

Voice Assistant button

Micro USB charging slot

ANC On/O/Ambient sound button

ANC On/O/Ambient sound LED indicator

Volume / Track control button

LED indicator

 (Power On / O / Pairing)

Microphone

3 Get started

Charge the battery

Charging case

Note

 Before you use your headphone for the rst

time, place the headphones in the charging

case and charge the battery for 2 hours for

optimum battery capacity and lifetime.

 Use only the original USB charging cable to

avoid any damage.

 Finish your call before charging the

headphone, as connecting the headphone for

charging will power the headphone o.

Connect the supplied USB charging

cable to:

• The micro USB charging slot on the

headphones and;

• The charger/USB port of a

computer.

Tip

 Normally, a full charge takes 2 hours.

Pair the headphones

with your mobile phone

Make sure that the headphones are

fully charged and turned o.

The headphone remain in

pairing mode for 2 minutes.

Before you use the headphones with

your mobile phone for the rst time, pair

it with a mobile phone. A successful

pairing establishes a unique encrypted

link between the headphones and

mobile phone. The headphones store

the last 8 devices in the memory. If you

try to pair more than 8 devices, the

earliest paired device is replaced by the

new one.

LED turns red during charging and

turns o when the headphones in

fully charged.

Press and hold for 5 seconds

until the blue and red LED ashes

alternately.

Philips PN505

Make sure that the mobile phone is

turned on and its Bluetooth feature

is activated.

The following example shows you how

to pair the headphones with your mobile

phone.

Pair the headphones with the

mobile phone. For detailed infor-

mation, refer to the user manual of

your mobile phone.

Activate the Bluetooth feature of your

mobile phone, select Philips PN505

Enter the headphone password

“0000” (4 zeros) if prompted. For

those mobile phones featuring

Bluetooth 3.0 or higher, no need to

enter a password.

Headphones status Indicator

ANC is on The white LED

will turn on.

ANC is o The white LED will

turn o.

Ambient sound

The white LED

ashes slowly

4 Use your

headphone

Connect the headphone

to your Bluetooth device

Connect to ANC (active

noise cancelation)

Turn on your mobile phone/

Bluetooth device.

Press and hold the on/o button to

turn the headphones on.

The blue LED is on 3s.

The ANC function will be on/o/

Ambient sound automatically.

The headphones are recon-

nected to the last connected

mobile phone/ Bluetooth

device automatically. If the last

one is not available, the

headphones will be in pairing

mode.

Tip

 If you turn on the mobile phone/Bluetooth

device or activate the Bluetooth feature

after turning on the headphones, you have

to reconnect the headphones and mobile

phone/Bluetooth device manually.

Tip

 The function keys will be disabled when

using line-in mode.

Tip

 When the ANC function is not required, switch

o the ANC button to continue your call or

listening to music.

Note

 The Ambient sound can be enable only when

ANC is also enabled.

 If the headphones fail to connect to any

Bluetooth device within range in 8 minutes,

it will switch o automatically to save the

battery life when ANC o or in idle mode.

Note

You can also use the headphones with

the audio cable provided. Make sure

the headphones turned on before using

the audio cable. Connect the supplied

audio cable to the headphones and

external audio device.

Enable ANC

• Press once ANC button for enable

noise cancelation.

• Press once ANC button for disable

noise cancelation.

Enable Ambient sound mode

ANC LED indicator status

Wired Connection

• Press once ANC button to enable

Ambient sound.

• Press once ANC button disable

Ambient sound.

Connect the audio cable into the

plane adapter.

Insert the adapter into the dual

output jacks in the airplane seat.

Connect the audio cable into the

headphone.

Manage your calls and

music

On/o

Task Button Operation

Turn the

head-

phones on.

On/o,

music/call

control

Press and hold

for 3 seconds.

Turn the

head-

phones o.

On/o,

music/call

control

Press and hold

for 5 seconds.

The blue

LED

ashes 1s

and fades

out.

Connect to airline audio

systems

Music control

Task Button Operation

On/o,

music/call

control

Play or

pause music.

Press once.

Long press.

Adjust volume.

Next track.

Previous track.

Task Button Operation

Voice

assistant

Trigger voice

assistant

Press and

hold

Other headphones indicator status

Headphones status Indicator

The headphones

are connected

to a Bluetooth

device, while the

headphones in

standby mode

or while you are

listening to music.

The blue LED will

turn on.

The headphones

are ready for

pairing.

The LED ashes

blue and red

alternately.

The headphones

are on but not

connected to a

Bluetooth device.

The blue & red LED

ashes slowly

If no connection

can be made, the

headphones will

turn itself o within

8 minutes.

Low battery level. The red LED

ashes until it is

out of power

Battery is fully

charged.

Red LED is o.

Call control

Task Button Operation

Pick up/

hang up a

call.

Switch

caller

during a

call.

On/o,

music/

call control

On/o,

music/-

call

control

Press once.

Press twice.

 Need to turn on headphone when connect to airline audio systems.

Note

Voice Assistant

5 Technical data

Note

 Specications are subject to change without

notice.

Music time — ANC enabled with

Bluetooth: 9 hours | ANC disabled

with Bluetooth: 14 hours

Talk time — ANC enabled with

Bluetooth: 9 hours | ANC disabled

with Bluetooth: 14 hours

Standby time — ANC enabled with

Bluetooth: 160 hours | ANC disabled

with Bluetooth: 160 hours

Charging time: 2 hours

Rechargeable lithium polymer

battery (180 mAh)

Bluetooth version: 5.0

Compatible Bluetooth proles:

• HSP (Hands-Free Prole-HFP)

• A2DP (Advanced Audio Distri-

bution Prole)

• AVRCP (Audio Video Remote

Control Prole)

Supported audio codec: SBC

Frequency range: 2.505-2.480 GHz

Transmitter power: < 10 dBm

Operating range: Up to 10 meters (33

feet)

Digital echo & noise reduction

Auto power o

Micro-USB port for charging

Supports SBC

Low battery warning: available

Remove the integrated battery

6 Notice

Hereby, MMD Hong Kong Holding Limited

declares that this product is in compli-

ance with the essential requirements and

other relevant provisions of Directive

2014/53/EU. You can nd the Declaration

of Conformity on www.p4c.philips.com.

Declaration of conformity

Disposal of your old

product and battery

Your product is designed and manufac-

tured with high quality materials and

components, which can be recycled and

reused.

This symbol on a product means that

the product is covered by European

Directive 2012/19/EU.

This symbol means that the product

contains a built-in rechargeable battery

covered by European Directive

2013/56/EU which cannot be disposed

of with normal household waste. We

strongly advise you to take your product

to an ocial collection point or a Philips

service centre to have a professional

remove the rechargeable battery.

Inform yourself about the local separate

collection system for electrical and

electronic products and rechargeable

batteries. Follow local rules and never

dispose of the product and rechargeable

batteries with normal household waste.

Correct disposal of old products and

rechargeable batteries helps prevent

negative consequences for the environ-

ment and human health.

If there is no collection/recycling system

for electronic products in your country,

you can protect the environment by

removing and recycling the battery

before disposing the headphones.

• Make sure the headphone is

disconnected from the charging

case before removing the battery.

Compliance with EMF

This product complies with all applica-

ble standards and regulations regarding

exposure to electromagnetic elds.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips Kopfhörer Handbücher

Philips

Philips SHP5401/00 Bedienungsanleitung

Philips

Philips SBCHP900/00U Bedienungsanleitung

Philips

Philips SBCHN060/00 Bedienungsanleitung

Philips

Philips TAT3217 Bedienungsanleitung

Philips

Philips SHC8565/05 Bedienungsanleitung

Philips

Philips TAT6908 Bedienungsanleitung

Philips

Philips TAUN102 Bedienungsanleitung

Philips

Philips 1000 Series Bedienungsanleitung

Philips

Philips SHB5250 Bedienungsanleitung

Philips

Philips SHB5850 Bedienungsanleitung

Philips

Philips SHH9700 Bedienungsanleitung

Philips

Philips SHK3020 Bedienungsanleitung

Philips

Philips TAT4205 Bedienungsanleitung

Philips

Philips SBCHD1505U/00 Bedienungsanleitung

Philips

Philips HC8390 Bedienungsanleitung

Philips

Philips TAN4207 Bedienungsanleitung

Philips

Philips EARGEAR HE205 Series Bedienungsanleitung

Philips

Philips SHN050 Bedienungsanleitung

Philips

Philips HC8650 Bedienungsanleitung

Philips

Philips SHS4846 Bedienungsanleitung

Philips

Philips SHE9703 Bedienungsanleitung

Philips

Philips SHS3200 Bedienungsanleitung

Philips

Philips SHD8900 Bedienungsanleitung

Philips

Philips In Ear 1000 Series Bedienungsanleitung

Beliebte Kopfhörer Handbücher anderer Marken

Sony

Sony MDR-NC8 Bedienungsanleitung

AUSounds

AUSounds AU-Stream Bedienungsanleitung

ENERGY SISTEM

ENERGY SISTEM Style 7 Bedienungsanleitung

Insignia

Insignia NS-CAHBTSPORT Bedienungsanleitung

Movie Vision

Movie Vision HP-400 Bedienungsanleitung

MobiFren

MobiFren SM Pro Bedienungsanleitung

Motorola solutions

Motorola solutions PMLN8120 Bedienungsanleitung

Jaybird

Jaybird freedom Installationsanleitung

Sony

Sony MDR-ED12LP Bedienungsanleitung

HiFuture

HiFuture Tidy Buds Pro Bedienungsanleitung

Creative

Creative CB2530 Bedienungsanleitung

Renkforce

Renkforce RF FTVK-100 Bedienungsanleitung

Sennheiser

Sennheiser 500371 Bedienungsanleitung

Califone

Califone 2924AV Bedienungsanleitung

Technics

Technics EAH-AZ80 Bedienungsanleitung

Bose

Bose On-Ear Headphone Gebrauchs- und Wartungshandbuch

Aluratek

Aluratek ABH02F Bedienungsanleitung

Waterfi

Waterfi swimQ Bedienungsanleitung
