Quick Start Guide

What’s in the Box?

You should find these items upon opening the box.

Quick Start Guide

Quick start guide

User Manual

Remote control with one

CR2025 battery loaded

DIN cable

User manual

Composite video cable Remove the insulation plastic tab

before use

FM wire antenna

MCD139_79_QSG_Eng 21/7/06, 17:561

Speakers

Right Speaker

Subwoofer White

Red

Green

––

Black

1 1

AC Power Cord

FM wire antenna

ANTENNA

(75Ω)

Important!

–This set can only be operated after the

supplied DIN cable has been connected.

Tips

–See the User Manual for otherTV

connection options.

–For connecting to a Progressive Scan

TV, refer to the user manual for proper

connections and detailed setup.

Connect the speaker wires of the right speaker and subwoofer to the

left speaker.

Connect the left speaker and the DVD player by using the supplied

DIN cable.

Connect the DVD player to your TV using the supplied composite video

cable.

Connect the AC power cord to the wall socket.

Connect the supplied FM wire antenna.

Setting up the TV

Press SOURCE (DISC on the remote) to select disc source.

Turn on the TV and set it to the correct Video In channel.

PROG

AUDIO MUTE

GOTO

VOL

ZOOM

DSC

DBB

SYSTEM MENU

MODE CLOCKA-B

SLEEP/TIMER

DISPLAY

OSD

DISC MENU

DISC AUX TUNER

SUBTITLE

Notes for the remote control:

–First, select the source you wish to

control by pressing one of the source

select keys on the remote control

(DISC or AUX, for example).

–Then select the desired function

(

for example).

MCD139_79_QSG_Eng 21/7/06, 17:562

OFF

NIGHT MODE

GOTO SOUND SETUP PAGE

TEST TONE

Tip

See chapters "Getting Started" and "DVD menu operations" in the

User Manual for detailed descriptions.

SETUP MENU

8 ADULT

CHANGE

ENGLISH

RESET

GOTO FEATURE SETUP PAGE

OSD LANG

NORMAL/PS

MULTI

OFF

GOTO PICTURE SETUP PAGE

TV DISPLAY

TV TYPE

PROGRESSIVE

SCREEN SAVER

ENGLISH

GOTO LANGUAGE SETUP PAGE

AUDIO

SUBTITLE

DISC MENU

Setting DVD menu options

IMPORTANT!

If the progressive scan feature is activated but the connectedTV does not support

progressive signals or the video cables are not connected accordingly, see the user

manual for proper progressive scan setup or deactivate the progressive scan

feature as below:

1)Turn off your TV progressive scan mode then turn on to interlaced mode.

2) Select “OFF” in PROGRESSIVE menu of the system setup menu to turn off

progressive scan, then press SYSTEM MENU on the remote to exit the system

menu.

OrTo turn off progressive scan, you may also first open the disc door, then hold

down ™on the front panel, and press numeric key “1” on the remote.

Setting the clock

PROG

AUDIO MUTE

GOTO

VOL

ZOOM

DSC

DBB

SYSTEM MENU

MODE CLOCKA-B

SLEEP/TIMER

DISPLAY

OSD

DISC MENU

DISC AUX TUNER

SUBTITLE

SYSTEM MENU

In standby or power on mode, press and hold CLOCK on the remote control.

The clock digits flash on the display.

Press ¡/ ™repeatedly to set the hours.

Press à/ árepeatedly to set the minutes.

PROG

AUDIO MUTE

GOTO

VOL

ZOOM

DSC

DBB

SYSTEM MENU

MODE CLOCKA-B

SLEEP/TIMER

DISPLAY

OSD

DISC MENU

DISC AUX TUNER

SUBTITLE

CLOCK

Press CLOCK again to store the setting.

MCD139_79_QSG_Eng 21/7/06, 17:563

Playing a disc

Push OPEN /CLOSEçto open the disc door.

Load in a disc with the label side facing up, then close the disc door.

Playback will start automatically. If not, pressÉÅ.

To stop playback, press 9.

PDCC-JH-0627

2006 CKoninklijie Philips Electronics

http://www.philips.com

Tip

Detailed playback features and

additional functions are described in the

accompanied user manual.

Programming and tuning to radio stations

Press SOURCE (TUNER on the remote) to select tuner source (FM).

Press PROGRAM on the set for more than two seconds to program all available stations

in order of waveband.

Press ¡/ ™(Numberic keys on the remote) until the desired preset station is displayed.

To s witch on the system,

press STANDBY ONB/

SOURCE on the set, or

DISC/TUNER/AUX on the

remote.

MCD139_79_QSG_Eng 21/7/06, 17:564
