Philips AZ1308/96 Bedienungsanleitung

AZ1308

MP3-CD Soundmachine

User manual

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 1

6 x R14 • UM-2 • C-CELLS

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 2

TUNER

MHz

PRESET

DBB

PROG

TRK

DBB

TRK

REP

ALL

TRK

SHUF TRK

PROG

CD MP3

DBB

TRK ALB

DBB

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 3

English Controls

Supplied Accessories

– AC power cord

Top/front panels (See 1)

Source selector:CD/MP3,TUNER, OFF

–

selects CD/MP3, or radio (FM/AM) source

of sound

–

power off switch

Display

–

shows the status of the disc/tuner

–

stops CD/MP3 playback;

–

erases a CD/MP3 program

2 ;

–

starts or pauses CD/MP3 playback

MODE

– selects different play modes:

e.g. REPEAT or SHUFFLE (random order)

PROG

CD/MP3: – programs tracks and reviews the

program

TUNER: – programs preset radio stations

ALB/PRESET +/-

For MP3: – selects albums (up, down)

TUNER: – selects a preset radion station

5LIFT TO OPEN – opens/ closes the CD

door.

DBB (Dynamic Bass Boost)

–

turns the bass enhancement on/off.

7Telescopic antenna - improves FM

reception.

8TUNING

§ ∞

TUNER: – tunes to radio stations

CD/MP3: –

selects the next/previous track

– fast searches forwards/backwards

(press and hold the button)

within the current track

BAND –

selects waveband: FM or MW(AM)

Back/bottom panels (See 1)

VOLUME

–

adjusts volume level

!p– 3.5 mm stereo headphone socket

Helpful hints: The speakers will be muted

when headphones are connected to the set.

@AC MAINS~ –inlet for power cord.

#Battery door –open to insert 6 x 1.5V

R-14/ UM-2/ C-cells

CAUTION

- Visible and invisible laser radiation.

If the cover is open, do not look at

the beam.

- High voltage! Do not open.You run

the risk of getting an electric shock.

The machine does not contain any

user-serviceable parts.

- Modification of the product could

result in hazardous radiation of

EMC or other unsafe operation.

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 4

Power Supply Basic Operation

Power Supply

Whenever convenient, use the power supply

cord if you want to conserve battery life.

Make sure you remove the plug from the set

and wall outlet before inserting batteries.

Batteries (not included)

1 Open the battery door and insert 6 batteries,

typed R-14,UM-2 or C-cells, (preferably

alkaline) with the correct polarity as indicated

by the "+" and "–" symbols inside the com-

partment. (See 1)

2 Replace the battery door, making sure the bat-

teries are firmly and correctly in place.The set is

now ready to operate.

Batteries contain chemical substances, so

they should be disposed of properly.

• Incorrect use of batteries can cause

electrolyte leakage and will corrode the

compartment or cause the batteries to burst:

• Do not mix battery types: e.g. alkaline with car-

bon zinc. Only use batteries of the same type

for the set.

• When inserting new batteries, do not try to mix

old batteries with the new ones.

• Remove the batteries if the set is not to be used

for a long time.

Using AC power

1 Check if the power voltage, as shown on

the type plate located on the

bottom of the set, corresponds to your

local power supply. If it does not, consult your

dealer or service center.

2 Connect the power cord to the

AC MAINS~ inlet and the wall socket.The

set is now connected and ready for use.

3To switch the set off completely, withdraw the

power cord from the wall socket.

4Install the unit near the AC outlet and where

the AC power plug can be easily reached.

•Disconnect the power cord from the wall

socket to protect your set during heavy

thunderstorms. Children could seriously injure

themselves as the free end of the cable may

still be live if only the connector is removed

from the MAINS socket at the back of the

unit.

The type plate is located on the

bottom of the set.

Helpful hints:

–To avoid unnecessary energy consumption,

always adjust the

Source selector

OFF

after using the set.

Basic operation

Switching on and off and selecting the

function

1To select your sound source, adjust the

Source selector to: CD/MP3 or

TUNER

2To switch off the set, adjust the

Source selector to

OFF

position.

Adjusting volume and sound

1Adjust the volume with the VOLUME

3, 4

controls.

➜Display briefly shows UUooLLand the vol-

ume level in number from 00-32.

2Adjust DBB to select dynamic bass boost on

or off.

➜Display shows “DBB” when activated.

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 5

Digital Tuner

Digital tuner

Tuning to radio stations

1Push the source selector to TUNER.

➜ttuuis displayed briefly, then the radio sta-

tion frequency, waveband and, if pro-

grammed, a preset number are shown.

(See 2)

2Push BAND to FM or MW(AM) to select

desired waveband.

3Press and hold TUNING ∞or §until the

frequency in the display starts running.

➜The radio automatically tunes to a station

of sufficient reception. Display shows

SSrrcchhduring automatic tuning.

4Repeat step 3 if necessary until you find the

desired station.

•To tune to a weak station, press TUNING

∞or § briefly and repeatedly until you have

found optimal reception.

To improve radio reception:

• For FM, extend, incline and turn the tele-

scopic antenna. Reduce its length if the signal

is too strong.

• For MW(AM), the set uses a built-in aerial.

Direct this aerial by turning the whole set.

Programming radio stations

You can store up to a total of 20 radio sta-

tions in the memory (10 FM and 10 MW),

manually or automatically (Auto store).

Manual programming

1Tune to your desired station (see Tuning to

radio stations).

2Press PROG to activate programming.

➜Display: PROG flashes.

3Press ALB/PRE +/- once or more to allo-

cate a number from 1 to 10.

4Press PROG to confirm.

5Repeat steps 1-4 to store other stations.

Helpful hints:

–You can erase a preset station by storing

another frequency in its place.

Autostore

Autostore automatically starts programming

radio stations from preset 1. Any previous

presets e.g. manually programmed will be

erased.

1Push BAND to FM or MW to select

desired waveband.

2Press PROG until AAuuttOOdisplays and flashes.

➜Available stations are programmed (MW

or FM). After all stations are stored, the

first autostore preset station will then

automatically play.

To listen to a preset or autostore sta-

tion

Press the ALB/PRE +/- buttons once or

more until the desired preset station is dis-

played.

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 6

CD/MP3 Player

About MP3

The music compression technology MP3

(MPEG1 Audio Layer 3) significantly reduce

the digital data of an audio CD while main-

taining CD quality sound.

•Getting MP3 files: you can either down-

load legal music files from the internet to

your computer hard disc, or create such files

by converting audio CD files in your comput-

er through appropriate encoder software.

(128kbps bit rate or higher is recommended

for MP3 files.)

•Creating a MP3 CD: burn the music files

from your computer hard disc on a CDR or

CDRW using your CD burner.

Helpful hints:

–Make sure that the file names of the MP3 files

end with .mp3.

–Total number of music files and albums: around

350 (with a typical file name length of 20 char-

acters)

–The length of file names affects the number of

tracks for playback. With shorter file names,

more files can be burned on a disc.

Playing a disc

•This CD player plays Audio Discs including

CD-R/CD-RW and MP3-CD. Do not try to

play a CD-ROM, CD-I, CDV,VCD, DVD or

computer CD.

IMPORTANT!

•CDs encoded with copyright protection

technologies by some record companies may

be unplayable by this product.

1Adjust the Source selector to CD/MP3.

2Open the CD door, and insert a CD/MP3

with the printed side facing up, then press

the CD door gently to close.

➜Display shows flashing rrEEAAdd,indicating

the disc reading, then the total track num-

ber and playing time. “CD” is also display

(See 3).

➜For MP3: “MP3” and the total album

number are also displayed (See 4).

3Press

to start playback.

➜Display shows current track number and

the elapsed time of the track.

4To pause playback, press

➜

Display:The elapsed playing time flashes.

5To resume, press

again.

6To stop CD playback, press

Helpful hints:

CD play will also stop when:

–you open the CD door;

–you select

TUNER

OFF

;

–the CD has reached the end.

Selecting a different track

•Press TUNING

∞/ §

once or repeatedly

until the desired track number appears in the

display.

For MP3: First press ALB/PRE +/- once or

more to find your album.

•In the pause/stop position, press 2; to start

playback.

Finding a passage within a

track

1During playback, press and hold TUNING

∞/ §

➜ The CD/MP3 is played at high speed and

with reduced volume.

2When you recognize the passage you want,

release TUNING

∞/ §

to resume normal

playback.

Helpful hints:

– When your searching reaches the end of the

last track, the CD/MP3 goes to stop mode.

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 7

CD/MP3 Player

Programming track num-

bers

You may store up to 20 tracks (for MP3: 10

tracks) in the desired sequence. If you like,

store any track more than once.

1In the stop position, press TUNING

∞

to select your desired track number.

For MP3: First press ALB/PRE +/- once or

more to find your album.

2Press PROG to store the desired track

number.

➜“PROG” is displayed, and display briefly

shows current program sequence, then

the currently stored track number.

(see 5 6)

➜“For MP3: The current album number is

also displayed.

•If you attempt to program without first

selectig a track, display will show NNOOSSEEbriefly,

then the total track number.

3Repeat steps 1 to 2to select and store all

desired tracks in this way.

➜If you attempt to store more than 20

tracks (for MP3: 10 tracks), no track can

be stored and the display shows FFuuLLLL.

4To play your program, press

To review your program

In the stop position, press PROG to view the

first program information, then press PROG

again to view the next program information.

Repeat the above to view all the program

stored.

➜ Each time the display shows the program

sequence (PPrrOOggX) briefly, then the program

track number (see 5 6).

To erase a program

You can erase a program by:

– pressing

(twice during playback or once

in the stop position);

– selecting TUNER or OFF position;

– opening the disc door.

➜ Display: PROG disappears.

Different play modes:

REPEAT and SHUFFLE

(See 7 8)

You can play the current track or the whole

disc repeatedly, and combine REPEAT modes

with PROGRAM.

REP – plays the current track continuously.

REP ALL –repeats the entire CD/program

SHUF –plays all the tracks in random order

•Selection of shuffle play is not available in the

program mode.

1To select play mode, press MODE once or

more.

➜ The display shows selected play mode.

2Press 2; to start playback if in the stop/pause

position.

➜ The disc will play automatically around

few seconds later when SHUF mode is

selected.

3To return to normal playback, press

MODE

repeatedly until the modes are no longer dis-

played.

– You can also press 9to cancel your play

mode.

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 8

Maintenance & safety (See 9)

CD player and CD handling

•If the CD player cannot read CDs correctly,

use a cleaning CD to clean the lens before

taking the set to repair.

•The lens of the CD player should never be

touched!

•Sudden changes in the surrounding

temperature can cause condensation on the

lens of your CD player. Playing a CD is then

not possible. Do not attempt to clean the

lens but leave the set in a warm environment

until the moisture evaporates.

•Always close the CD-tape door to avoid dust

on the lens.

•To clean the CD, wipe in a straight line from

the center towards the edge using a soft,

lint-free cloth. Do not use cleaning agents as

they may damage the disc.

•Never write on a CD or attach any stickers

to it.

Safety information

•Place the set on a flat, hard and stable surface

so that the system does not tilt.

•Do not expose the set, batteries, CDs to

humidity, rain, sand or excessive heat caused

by heating equipment or direct sunlight.

•The apparatus shall not be exposed to drip-

ping or splashing.

•Adequate ventilation with a minimum gap of

15cm (6 inches) between the ventilation

holes and surrounding surfaces is necessary

to prevent heat build-up.

•Do not cover the ventilation openings with

items such as newspapers, table-cloths, cur-

tains, etc.

•No objects filled with liquids, such as vases,

shall be placed on the apparatus.

•No naked flame sources, such as lighted can-

dles, should be placed on the apparatus.

•The mechanical parts of the set contain

self-lubricating bearings and must not be oiled

or lubricated.

•To clean the set, use a dry cloth. Do not use

any cleaning agents containing alcohol,

ammonia, benzene or abrasives as these may

harm the housing.

Environmental information

All unnecessary packaging material has been omitted.The packaging can be easily separated

into three materials: cardboard, polystyrene and plastic.

Yo ur set consists of materials which can be recycled if disassembled by a

specialized company. Please observe the local regulations regarding the

disposal of packaging, dead batteries and old equipment.

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 9

Problem

–Possible cause

•Remedy

No sound /power

–Volume not adjusted

•Adjust the VOL

–Power cord not securely connected

•Connect the AC power cord properly

–Batteries dead/ incorrectly inserted

•Insert (fresh) batteries correctly

–Headphones connected to the set

•

Disconnect headphones.

–CD contains non-audio files

•Press

TUNING ∞,§

once or more to skip to

a CD audio track, instead of the data file.

Display does not function properly / No

reaction to operation of any of the con-

trols

–Electrostatic discharge

•Switch off and unplug the set. Reconnect after a

few seconds

Poor radio reception

–Weak radio signal

•FM: Adjust the FM telescopic aerial

Nocd indication

–No CD inserted

•

Insert a CD

–CD badly scratched or dirty

•

Replace/ clean CD, see Maintenance

–Laser lens steamed up

•Wait until lens has cleared

–CD-R/CD-RW is blank or not finalized

•

Use a finalized CD-R/CD-RW or suitable CD

Audio disc only

Note:

Make sure the CD is not encoded with

do not conform to the Compact Disc stan-

dard.

The CD skips tracks

–CD damaged or dirty

•Replace or clean CD

–Program/Shuffle is active

•Quit program/shuffle mode

Sound skips during MP3 playback

–

MP3 file made at compression level exceeding

320kbps

•Use a lower compression level to record CD

tracks into MP3 format

–Disc damaged or dirty

•Replace or clean disc

The MP3-CD skips albums

–

CD contains non-MP3 file folders

•Check your disc contains suitable file folders.

Troubleshooting

If a fault occurs, first check the points listed below before taking the set for repair.

If you are unable to remedy a problem by following these hints, consult your dealer or service centre.

WARNING: Do not open the set as there is a risk of electric shock. Under no

circumstances should you try to repair the set yourself, as this will

invalidate the guarantee.

AZ1308_96 IFU-Eng (single page) 2006.8.31 11:15 AM Page 10

Andere Handbücher für AZ1308/96

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips MP3-Player Handbücher

Philips

Philips PSA612 Bedienungsanleitung

Philips

Philips GoGear SA2ARA16S Bedienungsanleitung

Philips

Philips AZ1302/98 Bedienungsanleitung

Philips

Philips GOGEAR VIBE SA2VBE04RC Bedienungsanleitung

Philips

Philips SA3MXX04WA/02 Bedienungsanleitung

Philips

Philips GoGear Muse SA2MUS08 Bedienungsanleitung

Philips

Philips GoGear SA028302 Bedienungsanleitung

Philips

Philips GoGear LUXE SA2442BT Bedienungsanleitung

Philips

Philips GoGear SA2622 Bedienungsanleitung

Philips

Philips GoGEAR Ariaz SA4ARA16KF/37 Bedienungsanleitung

Philips

Philips 411EXP Bedienungsanleitung

Philips

Philips PSA[FM ACT100 Bedienungsanleitung

Philips

Philips GOGEAR SA3MXX02 Bedienungsanleitung

Philips

Philips PSS110/05 Bedienungsanleitung

Philips

Philips Expanium EXP 201 Bedienungsanleitung

Philips

Philips SA1982A/02 Bedienungsanleitung

Philips

Philips SA3CNT16K/02 Bedienungsanleitung

Philips

Philips SA2323 - 2 GB Digital Player Bedienungsanleitung

Philips

Philips GoGear SA018102S Bedienungsanleitung

Philips

Philips GoGear SA170/93 Bedienungsanleitung

Philips

Philips AZ1836 Bedienungsanleitung

Philips

Philips GoGear SA6014 Bedienungsanleitung

Philips

Philips SA220 Bedienungsanleitung

Philips

Philips GoGear SA2925R Bedienungsanleitung

Beliebte MP3-Player Handbücher anderer Marken

Blaupunkt

Blaupunkt Compact Drive MP3 Bedienungsanleitung

Memorex

Memorex MMP9008 - 8GB USB 2.0 Bedienungsanleitung

Meizu Electronic Technology

Meizu Electronic Technology E5 Bedienungsanleitung

Naxa

Naxa NMV-173NX Bedienungsanleitung

Zipy

Zipy go! Waving Bedienungsanleitung

Sylvania

Sylvania SMPK4068 Bedienungsanleitung

Sony

Sony NW-MS7 - Memory Stick Walkman Bedienungsanleitung

Irradio

Irradio RF-42UC Bedienungsanleitung

NABAIJI

NABAIJI SWIM MUSIC 100 Bedienungsanleitung

Laser

Laser MP3-A9-4GB Bedienungsanleitung

Samsung

Samsung YP-T7F Bedienungsanleitung

Savant

Savant SMS-1001-00 Kurzanleitung

Trevi

Trevi XP 71 BT Bedienungsanleitung

AGPtek

AGPtek C2 Bedienungsanleitung

MobiBlu

MobiBlu DAH-1500i Bedienungsanleitung

Denver

Denver MPS-201 Bedienungsanleitung

Steren

Steren MP3-002 Bedienungsanleitung

Kenwood

Kenwood M1GD50 Bedienungsanleitung
