Philips GoGear Mix SA1MXX02W Bedienungsanleitung

Philips GoGear

MP3 player

Mix

2GB*

SA1MXX02W

Enjoy your music on the move

Full color display for easy navigation

The compact Philips GoGear Mix MP3 Player with push-out USB makes file transfer a

snap - no cables required. Enjoy easy, intuitive navigation on the full color display and up

to 25-hour music playback with its embedded battery.

All your music on the go - everyday

• MP3 and WMA playback

• FM radio with 20 presets for more music options

• Equalizer to suit your music preferences

Ready to wear, ready to go

• Full color display for intuitive and enjoyable navigation

• Small and wearable for ultimate portability

• Up to 25-hour music playback

• Voice recording to take notes or record anything, anytime

Easy and intuitive experience

• Drag and drop your songs easily - no software needed

• Push-out USB for easy file transfers - without cables

Issue date 2012-01-20

Version: 1.0.3

12 NC: 8670 000 55419

EAN: 87 12581 49871 9

Specifications are subject to change without notice.

Trademarks are the property of Koninklijke Philips

Electronics N.V. or their respective owners.

www.philips.com

Specifications

SA1MXX02W/97

MP3 player

Mix 2GB*

Highlights

FM radio with 20 presets

Digital FM radio offers you additional music options

to your music collection on your GoGear. Simply

tune into the station that you want to preset, press

and hold the preset button to memorize the

frequency. You can preset up to 20 radio stations

and enjoy your favorite programs whenever you go.

Push-out USB

Push-out USB for easy file transfers - without cables

Picture/Display

•Backlight

•Linesoftext:4

• Resolution: 128 x 64

•Type:LCD

Sound

• Equalizer customizable

• Equalizer settings: Funk, Hip Hop, Jazz, Rock,

Techno, Classical

• Frequency response: 80 - 18 000 Hz

• Signal to noise ratio: > 80 dB

• Channel separation: 35 dB

• Output power (RMS): 2 x 3 mW

Audio Playback

• Compression format: MP3, WAV, WMA

• ID3 Tag support: Song title, artist, album

• MP3 bit rates: 8-320 kbps and VBR

• WMA bit rates: 64-320 kbps

• WMA sample rates: 8, 11.025, 16, 22.050, 32, 44.1,

48 kHz

• MP3 sample rates: 16, 32, 44.1, 48, 11.025, 22.050,

24, 8 kHz

Storage Media

• Built-in memory type: NAND Flash

• Built-in memory capacity: 2 GB

• Mass storage class compliant

• Music memory capacity, MP3: Up to 450 tracks*

Connectivity

• Headphone: 3.5 mm

•USB:HighspeedUSB2.0

Convenience

• Function: Keypad lock

•Superscroll

•Volumecontrol

• Battery charging indication: On user interface

• Firmware upgradeable

Accessories

• Headphones: AY3820

•Quickstartguide

Software

• Device manager: to restore and upgrade

Green Specifications

• Lead-free soldered product

System Requirements

• PC OS: Windows 2000 / XP / Vista

• Internet connection: Yes (for access to updated

support documents, manuals, future firmware and

PC software upgrades)

• USB: Free USB port

Power

• Battery capacity: 250 mAh

• Playtime on internal battery: Up to 25 hours

•BatteryType:LI-Polymer

• Rechargeable: Yes, via USB

Dimensions

• Blister dimensions (WxDxH): 40 x 50 x 168 mm

• Product dimensions (WxDxH): 71 x 28 x 14 mm

• Product weight: 0.029 kg

• Packaging type: D-box

Tuner/Reception/Transmission

•TunerBands:FM

• Station presets: 20

Audio Capturing

• Audio file format: WAV

• Built-in microphone: mono

• Voice recording

• FM radio recording

•

* Storage capacity based on 4 minutes per song and 64 kbps WMA or

128 kbps MP3 encoding.

* Actual transfer speed may vary based on your operating system and

software configuration.

* 1GB = 1 billion bytes; available storage capacity will be less.

* Rechargeable batteries have a limited number of charge cycles and

may eventually need to be replaced. Battery life and number of

charge cycles vary by use and settings.
