Philips BCool XG1 Bedienungsanleitung

multimedia projector

bCool XG1

Philips

User guide

English

Packaging contents 4

Optional accessories 5

Service accessories 5

6-9

Controls 6-7

Remote control 8

Connections 9

10-12

Positioning the projector and screen 10

Switching on the projector 10

Adjusting the focus and size of the image 11

Adjusting the vertical and horizontal angle of the projector 11

To raise the projector 11

To lower the projector 11

Keystone correction 11

Moving/transporting the projector 11

Preparation 11

Moving/transporting the projector 11

Inserting the batteries in the remote control 12

13-16

General information 13

Computer input 13

USB connection (Universal Serial Bus) 13

Video input 13

Connecting to a computer 14

PC/Macintosh 14

Connecting to video equipment 15-16

CVBS (Video) 15

S-VHS (S-Video) 15

Scart connection 15

Component/HDTV (YPbPr/ YCbCr) 16

1. Introduction

2. Functional overview

3. Set up

4. Installation

Philips Multimedia Projector 2English User guide bCool XG1

Index

17-23

Preparation 17

General 17

Messages 17

General explanation 17

Feedback messages 17

Some examples 17

On Screen Display Menu 18-23

Menu tree 18-19

General explanation 20

Computer adjustments 21

Picture adjustments 21

Video series adjustments 21

Picture adjustments 21

General adjustments 22-23

Features adjustments 22

Setup adjustments 23

24-26

Cleaning 24

Cleaning the cabinet 24

Cleaning the lens 24

Lamp 25

Lamp replacement 25

Resetting the lamplife time 26

27-29

5. Operation

6. Maintenance

7.Troubleshooting

Philips Multimedia Projector 3English User guide bCool XG1

Index

Congratulations on your purchase of one of the most sophisticated and reliable products on the

market today.We are sure that, used properly, it will bring you years of enjoyment.You will want

to keep this manual handy, as it is a convenient source of information about your projector.

For your own protection and prolonged operation of your projector, please read the enclosed

Safety Sheet.

Please confirm that the following items are packed in the projector box.They are provided to

help you use or set up your projector.

Projector - Lens cap Laser pointer Mains Lead

remote control + batteries

2 x Alkaline 1.5 V

Audio minijack to Audio minijack to S-Video cable

minijack cable RCA cable

VESA M1-A to VGA/ Composite Video cable Softbag

USB cable

Cable pouch Quick set up Card and Cd-rom (with Projection

Safety Sheet Assistant, Warranty card,

SecurityMax, User Guide,

Spec. sheet and more.)

Packaging contents

Philips Multimedia Projector 4English User guide bCool XG1

1. Introduction

LASER

VOolume

OKMenu

Standby

AVMute

D-ZoomD-FreezeSource

Mouse RIGHTLEFT RIightLeft

The following accessories are available via the dealer from which you purchased your Philips projector:

• LCA3125/00 - 180W replacement lamp - 8670 931 25009

• LCA2218/00 - Ceiling mount - 8670 922 18009

• LCA5317/00 - RCA/M1 component video adaptor cable - 8670 953 17009

• LCA5318/00 - DVI + USB/M1 adaptor cable - 8670 953 17009

The following accessories are available via our Service organisation only:

• Laser pointer remote Control - 3139 228 62631

• Compact remote control - 3139 228 62641

• User Guide (Cd- rom) - 3122 435 91181

Optional accessories

Service accessories

Philips Multimedia Projector 5English User guide bCool XG1

1. Introduction <

To activate and deactivate the menu.

To confirm actions in the menu when the menu is on screen.

When the menu is active the Cursor Control controls the menu cursor to navigate through the

OSD menu.The cursor control works with up/down and left/right button operation.

To automatically adjust frequency, tracking, horizontal and vertical position. With most signal

sources, Auto Image provides the best results

To switch the projector in or out of the Power/Standby mode.

The Standby indicator (text on button/ring around button):

In Power on mode:

– blinks green when the projector is warming up;

– lights up green when the projector is in Power On mode;

In Power off mode:

– lights up red when the projector is in Standby mode;

– blinks red when the projector is cooling down.

Lights up red in case of temperature error.

– Fast blinks red (0.5 sec On, 0.5 sec Off) when lamp start has failed.

– Fast blinks red (1 sec On, 1 sec Off) in case of fan error.

To select the current projection source (Auto, Computer, DVI,YPbPr,YCbCr, RGBS, S-Video or

Video).The button toggles between the seven signals.

To adjust the size of the projected image.

To adjust the focus of the projected image.

Menu 1

OK 2

Cursor Control 3

Auto Image 4

Standby/

Standby indicator 5

Temperature indicator 6

Lamp indicator 7

Source 8

Zoomring 9

Focus ring 0

Philips Multimedia Projector 6English User guide bCool XG1

2. Functional overview

Temp.

Source Auto Image

Lamp Temp.

Source Auto Image

Lamp

1 2

Controls

To connect the projector to the mains.

To adjust the vertical angle of the projector.

To adjust a possible oblique displayed picture.

To correct picture distortion of the vertical keystone type by internal scaling.

Mains inlet socket !

Elevator button @

Elevator foot #

Lamp compartment $

Horizontal adjuster %

Keystone corrections

keys ^

Philips Multimedia Projector 7English User guide bCool XG1

2. Functional overview Controls

Temp.

Source Auto Image

Lamp Temp.

Source Auto Image

Lamp

1 2

2. Functional overview

To switch the projector in or out of the Power/Standby mode.

Function as the Left and Right mouse keys of your pc when USB connection has been made.

To adjust the volume.

To activate and de-activate the menu.

To select the current projection source (Auto, Computer, DVI,YPbPr,YCbCr, RGBS, S-Video or

Video).The button toggles between the seven signals.

To capture a (moving) picture.The button toggles between the Freeze mode and the display

situation.

To magnifie the size of the projected image. Use Corsor control to select the zoom centre and

press D(igital)-Zoom to select the required zoom factor: 1 x, 4 x, 9 x or 16 x.

To mute the sound of the projector and to mute the picture.

To manipulate the mouse cursor on the connected computer as long as the menu is not active.

When the menu is active the Cursor Control controls the menu cursor to navigate through the

OSD menu.The cursor control works with up/down and left/right button operation.

The Cursor Control can only function as a mouse cursor when the projector is connected to the USB

connector of the computer. Windows 98, Windows ME,Windows 2000 or Windows XP should be

installed on the computer when you make the USB connection.

To confirm actions in the menu when the menu is on screen.

To activate the laser pointer to indicate items on the screen.

Note:The laser pointer sends out a laser beam. Do not look into this beam!

Exit point of laser pointer.

The maximum range of the remote control is approximately 7 m (± 25 feet).

Stand by On 1

Mouse Left/Right 2

– Volume + 3

Menu 4

Source 5

D(igital)-Freeze 6

D(igital)-Zoom 7

A(udio)/V(ideo) Mute 8

Cursor Control 9

Note

OK 0

Laser !

Laser pointer @

Note

Philips Multimedia Projector 8English User guide bCool XG1

<Remote control

VOLUME

OKMENU

Stand by

MOUSE

D-ZOOMD-FREEZESOURCE

Laser

RightLeft

AV MUTE

Laser pointer remote control

Data source connections

– Input socket to connect to the analog (VGA) Data out terminal of a computer.

– Input socket to connect to the digital (DVI) Data out terminal of a computer.

– In-/Output socket to connect a PC or Apple Macintosh computer equipped with a USB

downlink connection.When USB connection is used the mouse cursor on the connected

computer can be controlled via the projector remote control. Make sure Windows 98,

Windows ME, Windows 2000 or Windows XP is installed on the computer.

– Input socket to connect to DVD- and HDTV-video equipment

This socket can be connected to the following output sockets:YCbCr, YPbPr, RGBS

(Composite sync), RGBHV).

Video source connections

Input socket to connect to the S-Video out socket of a S-VHS video recorder, a VCR,

Laser Disc player, DVD player, video camera or TV with AV output socket.

This socket can be connected to a S-Video/S-VHS (Y/C) output socket.

Input socket to connect to the Video out socket of a video recorder, Laser Disc player, video

camera, DVD player, or TV with AV output socket.

This socket can be connected to CVBS output sockets.

Other connections

Input socket to connect to the Audio out terminal of a computer, video recorder, laser disc

player, video camera or TV with A/V output socket.

To receive the signals from the remote control.

To insert an optional locking device (Kensington lock).

Data in 1

S-Video 2

Video 4

Audio in 3

IR sensor 5

Lock slit 6

Philips Multimedia Projector 9English User guide bCool XG1

2. Functional overview

Data inS-VideoAudio inVideo Data inS-VideoAudio inVideo

12345

<Connections

3. Set up >

• Place the projector on a stable, level surface, out of direct sunlight and away from sources of

excessive dust, dirt, heat, water, moisture, vibration and strong magnetic fields.

• Allow sufficient cooling of the product by keeping all air inlets and outlets clear from

obstructions.

• Position the projector in such way that the viewers cannot watch into the projector light beam.

• Choose a screen size suitable for the number of viewers and the size of the room.

• Picture quality is best when you sit directly in front of the projector screen.

• The projector can be used for both front projection, rear projection and ceiling projection

applications. As default factory setting, the projector has been set up for front projection.You

can change to rear or ceiling projection via the ‘Mirror’ function in the ‘Setup’ menu.

•

For more information on the projection properties of the projector, check the Projection

Assistant application on the Cd-rom.

1Insert the mains lead into the projectors Mains inlet socket and connect it to the wall socket.

– The Standby indicator lights up red, the projector is now in the Standby mode.

2Remove the lens cap.

3Press the Standby button on projector or remote control to switch on the projector.

– The Standby indicator starts blinking green, the projector is now warming up.

– When the projection lamp is on, the Standby indicator lights up green after the start-up

screen appeared for several seconds.

4Press the Standby button twice to switch the projector back into the Standby mode.

– The Standby Warning screen will appear for 20 seconds.

– The projector will now go into Standby mode.

5To switch off the mains supply completely, disconnect the mains lead.

– Save energy! Please put the projector in the Standby position if you are not going to use the

projector for more than 15 minutes.

–When no signal inputs are detected for 15 minutes, the projector automatically switches

to Standby (Auto Standby).This setting can be changed in the Features menu

–Before disconnecting the mains lead, make sure that the cooling fan has stopped (about 1

minute after the projector has been switched to Standby).

Positioning the projector and

screen

Switching on the projector

Notes

Philips Multimedia Projector 10 English User guide bCool XG1

SCREEN

Front projection Ceiling front projection

Rear projection Ceiling rear projection

Temp.

Source Auto Image

Lamp Temp.

Source Auto Image

Lamp

Andere Handbücher für bCool XG1

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips Projektor Handbücher

Philips

Philips LC4433 Bedienungsanleitung

Philips

Philips ProScreen PXG30 Series Bedienungsanleitung

Philips

Philips PPX 3407 Bedienungsanleitung

Philips

Philips LC5141 Bedienungsanleitung

Philips

Philips LC1345 Referenzhandbuch

Philips

Philips LC3142 - bSure XG2 XGA LCD Projector Bedienungsanleitung

Philips

Philips PicoPix PPX361 Bedienungsanleitung

Philips

Philips NeoPix Easy+ Bedienungsanleitung

Philips

Philips LC313199 Bedienungsanleitung

Philips

Philips LC5341 Bedienungsanleitung

Philips

Philips PicoPix PPX5110/INT Bedienungsanleitung

Philips

Philips PPX 3610 Bedienungsanleitung

Philips

Philips LC4242 Bedienungsanleitung

Philips

Philips Bedtime Magic SBCSC940 Bedienungsanleitung

Philips

Philips bSure SV2 Brilliance LC3136 Bedienungsanleitung

Philips

Philips PPX321 Bedienungsanleitung

Philips

Philips PicoPix Bedienungsanleitung

Philips

Philips ProScreen PXG30 Series Bedienungsanleitung

Philips

Philips PicoPix PPX2340/F7 Bedienungsanleitung

Philips

Philips PicoPix Micro PPX325 Bedienungsanleitung

Philips

Philips PicoPix Max One PPX520 Bedienungsanleitung

Philips

Philips Garbo Bedienungsanleitung

Philips

Philips PicoPix PPX2450 Bedienungsanleitung

Philips

Philips LC 3000 Bedienungsanleitung

Beliebte Projektor Handbücher anderer Marken

iEmmet

iEmmet MP-312 Bedienungsanleitung

Epson

Epson VS400 Bedienungsanleitung

Sony

Sony VPL-HS10 Marketing Specifications & Features Bedienungsanleitung

Sony

Sony VPL-HW65ES Service-Handbuch

Toshiba

Toshiba TLP-791U Bedienungsanleitung

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Bedienungsanleitung

NEC

NEC NP600S EDU Bedienungsanleitung

BenQ

BenQ SH753P Bedienungsanleitung

Eiki

Eiki EK-623U series Bedienungsanleitung

Epson

Epson PowerLite Pro Cinema 6020UB Bedienungsanleitung

Epson

Epson PowerLite Home Cinema 705HD Bedienungsanleitung

Christie

Christie LHD700 Bedienungsanleitung

Navitar

Navitar FX Bedienungsanleitung

InFocus

InFocus LitePro 560 Bedienungsanleitung

Sony

Sony SRX-R815P Bedienungsanleitung

Vivitar

Vivitar DP1500 X Bedienungsanleitung

Acer

Acer C20 Series Bedienungsanleitung

Asus

Asus ZenBeam Latte Bedienungsanleitung

Philips bCool XG1 Bedienungsanleitung

Beliebte Projektor Handbücher anderer Marken
