User manual

v1 5/19

Scan this code to

watch a video on how

to set up this remote

www.byjasco.com/remote

Audio/Video

SRP2024A/27

Install Your FireTV Remote.........................................2

Setup..............................................................................3

Button Functions .........................................................4

Programming Your Remote ........................................6

Direct Code Entry...................................................6

Auto Code Search ..................................................8

Controlling Combo Devices ..................................9

Using Your Remote ....................................................10

Primary Audio Control......................................... 10

Code Identication ...............................................11

Reset to Factory Settings .................................... 11

Troubleshooting......................................................... 12

Warranty...................................................................... 13

FCC Statement ........................................................... 14

Table of Contents

Install your FireTV remote

1 2 3

Remove the

two retaining

screws, then

carefully remove

the battery

compartment

cover

Install 2

AAA batteries,

noting correct

polarity

Replace the

battery cover

and reinstall the

two retaining

screws, and your

remote is ready

to use

Carefully slide

your FireTV

remote into

the cradle

IMPORTANT:SAVE THIS MANUAL AND CODE

LIST FOR FUTURE REFERENCE

Compatible with most Amazon®FireTV streaming device remotes.

Not compatible with FireTV Basic remote (1st Gen, 2nd Gen) or

FireTV Stick remote (1st Gen).

Setup

Your universal remote requires two (2) AAA

batteries (not included). Alkaline batteries are

recommended.

Battery Installation

1. On the back of the remote, remove the two

retaining screws at the bottom. Pull down on

the textured surface and slide battery cover

downward to remove.

2. Match the (+) and (-) marks on the batteries

to the (+) and (-) marks inside the battery

compartment, then insert two (2) AAA

batteries. Be sure to use fresh batteries.

3. Position battery cover slightly below opening

and push upward to lock into place. Reinstall

the two retaining screws.

NOTE:If your remote stops operating properly,

replace the batteries with new ones.

Battery Precautions

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc),

or rechargeable (Ni-Cd, Ni-MH, etc.) batteries.

• Always remove old, weak or worn-out batteries

promptly and recycle or dispose of them in

accordance with local and national regulations.

Battery Saver

Your remote automatically turns o if the buttons

are held down for more than 8 seconds. This will

save your batteries should your remote get stuck

in a place where the buttons remain depressed

(e.g., between sofa cushions).

Code Saver

You have up to 10 minutes to change the batteries

in your remote without losing the codes you have

programmed.

Button Functions

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

Button Functions

1. Power - turns devices ON/OFF (on side)

2. Volume Up/Down (on side)

3. Mute - Mutes sound (on side)

4. Home/Guide - Easily access features on today's

streaming devices, or Guide on cable/satellite

receivers

5. Input - Selects video inputs

6. Menu - Displays the on-screen menu

7. TV, STR, DVD, AUD - Selects the device to

control

8. Ok - Selects menu items for the controlled

device

9. Up/Down/Left/Right menu navigation

10. Exit - Exit on-screen menus

11. Info - Displays on-screen show/content

information

12. Channel Up/Down

13. Record, play, stop, rewind, fast forward, pause

14. ABCD - Access additional features for DVRs,

cable and satellite receivers

15. Numbers - Enter numbers for direct channel

selection

16. Previous Channel - Returns to the previously

selected channel

17. DVD/Blu-ray™open/close - open/close a player,

or List features on cable/satellite receivers

18. Sleep - Sleep timer functions

19. Setup - Used to program the remote

20. Dash (-) - Used to select digital channels

21. Enter -Some devices require enter to be

pressed after channel selection

Programming Your Remote

Your remote is designed to control multiple audio/

video devices. To use, you will need to program the

remote for your devices. There are two dierent

methods you can use to program the remote,

Direct Code Entry or Auto Code Search.

• The Direct Code Entry method is the

recommended method as it is the simplest

and quickest method in most cases.

• The Auto Code Search method searches

through all the codes in the remote to nd a

code for your device.

Note:This remote comes preprogrammed for

Roku®boxes and Samsung TVs. Press TV for

Samsung TVs and STR for Roku boxes.

Direct Code Entry (Recommended)

1. Locate the Code List included with

your remote. Find the section for the

type of device you wish to control,

(for example TV, STR, DVD, AUD.

Locate the brand of your device and

circle all the remote codes for the

brand.

2. Press and hold down the SETUP

button on the remote until the red

light on the remote control turns on.

Release the SETUP button. The red

light will remain on.

Note: The red light will either be a

small light at the top of the remote

or the power ON/OFF button.

3. Press and release the device button

on the remote for the type of device

you wish to control, (for example TV,

STR, DVD, AUD). The red light will

blink once and remain on.

Note:Any of the device buttons on

the remote can be programmed

to control any of your devices. For

example, you can use the DVD

device button on the remote to

control a satellite receiver, digital

converter box, streaming media

player or any device category in the

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

Programming Your Remote

Code List.

4. Use the number buttons on the

remote to enter the rst 4-digit

remote code you circled in the Code

List in Step 1. The red light will turn

o after entering the fourth digit.

5. Point the remote at the device.

Test the buttons on the remote to

see if the device responds as you

would expect. If the buttons do not

operate the device, return to Step

2 above and use the next code that

you circled for that device.

6. Repeat Steps 1 – 5 for each device you wish

to control.

Programming Notes

• Some codes may operate only a few functions

of your device. There may be another code in

the Code List that controls more functions.

Test other codes in the Code List for more

functionality.

• If you do not nd a remote code that works your

device or there are no codes in the Code List for

your device, use the Auto Code Search method

in the next section to program your remote.

• For combination devices such as a TV/DVD

combo or TV/VCR combo, you may have to enter

a code for each device. (See Controlling Combo

Devices.)

• Write down the remote codes used to program

the remote for future reference.

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

Programming Your Remote

Auto Code Search

The Auto Code Search is a process where you can

search through all the codes stored in the remote

to nd a code for your device. It is recommended

that you read through all the steps below to

familiarize yourself with the Auto Code Search

before starting the process.

1. Manually turn on the device you wish

to control.

Note: The Auto Code Search process

cannot be used for devices without

power ON/OFF capability. Use the

Direct Code Entry method in these

cases.

2. Press and hold down the SETUP

button on the remote until the red

light on the remote control turns on.

Release the SETUP button. The red

light will remain on.

Note:The red light will either be a

small light at the top of the remote or

the power ON/OFF button.

3. Press and release the device button

on the remote for the type of device

you wish to control, (for example TV,

STR, DVD, AUD). The red light will

blink once and remain on.

4. With the remote pointed at the

device, press and release the POWER

button on the remote. The remote will

send 10 dierent codes to the device.

The red light will blink once for each

code and remain on after sending the

10 codes.

Did the device turn o?

• If YES, go to Step 5.

• If NO, repeat Step 4 to test the next

10 codes.

5. Manually turn the device back on.

6. With the remote pointed at the

device, press and release the VOL +

button.

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

Programming Your Remote

The remote will resend the rst code of the

10 codes from Step 4. The red light will blink

once and remain on.

Did the device turn o?

• If YES, you have found a code for the

device. Press and release the same device

button you pressed in Step 3. This will

store the code in the remote. Go to Step 7.

• If NO, continue to press and release the

VOL+ button until the device turns o to

test the other 9 codes from Step 4.

Be sure to wait approximately 3 seconds

after each VOL+ button press to allow

the device time to respond to the code.

When the device turns o, you have

found a code for your device. Press and

release the same device button pressed

in Step 3. This will store the code in the

remote. Go to Step 7.

Notes:

• The VOL– button can be used to go

backwards through each batch of 10

codes.

• The red indicator light will ash 2 times

after testing the rst or last code in each

batch of 10.

7. Use the remote to turn the device back on.

Test the buttons on the remote to see if

the device responds as you would expect.

If the buttons do not operate the device,

return to Step 2 and repeat this process

to search for a better code to operate the

device.

8. Repeat this process for each device you

wish to control.

Controlling Combo Devices

Some combo devices (e.g. TV/VCR, TV/DVD, DVD/

VCR, etc.) will require you to set up two dierent

device buttons to control both parts of the combo

device. For example, if you have a TV/DVD combo,

you may need to set up one code under the TV

button to control the TV and a separate code

under the DVD button to control the DVD.

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

Using Your Remote

Primary Audio Control

The primary audio control feature allows you to

select a single device that the volume buttons

always control. For example, the remote can be

in TV mode while the volume buttons control the

volume on your audio receiver or sound bar instead

of your TV.

Enabling the Primary Audio Control

Feature

1. Press and hold down the SETUP

button on the remote until the red

light on the remote control turns on.

Release the SETUP button. The red

light will remain on.

2. Press and release the device button

(TV, AUD, etc.) on the remote for

the device you wish to control the

volume.

3. Press and release the MUTE button.

4. Press and release the VOL+ button.

The red light will blink twice and

turn o.

Disabling the Primary Audio Control

Feature

1. Press and hold down the SETUP

button on the remote until the red

light on the remote control turns on.

Release the SETUP button. The red

light will remain on.

2. Press and release the device button

(TV, AUD, etc.) programmed to

control the primary audio control

feature.

3. Press and release the MUTE button.

4. Press and release the VOL -button.

The red light will blink twice and

turn o.

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

1 2 3

4 5 6

(-)

B C D

INPUT

STR

DVD

AUD

EXIT

ENTER

SETUP

SLEEP

Inhaltsverzeichnis

Sprachen:

Andere Philips Fernbedienung Handbücher

Philips

Philips Perfect replacement SRU5107 Bedienungsanleitung

Philips

Philips Perfect replacement SRU5108 Bedienungsanleitung

Philips

Philips SRU6080/37 Bedienungsanleitung

Philips

Philips PRESTIGO SRU8008 Bedienungsanleitung

Philips

Philips YKF406-001 Bedienungsanleitung

Philips

Philips SRP4004/53 Bedienungsanleitung

Philips

Philips 14PT1686/01P Bedienungsanleitung

Philips

Philips Perfect replacement SRP5107/27 Bedienungsanleitung

Philips

Philips SBCRU610 Bedienungsanleitung

Philips

Philips US2-PM310 Bedienungsanleitung

Philips

Philips SRP3011 Bedienungsanleitung

Philips

Philips Home power SRP4419V/27 Bedienungsanleitung

Philips

Philips SBC RU644/05 Bedienungsanleitung

Philips

Philips EasyLink 28PT7202/12 Bedienungsanleitung

Philips

Philips ProntoPro Next Generation Bedienungsanleitung

Philips

Philips KWR174002/01BRS Bedienungsanleitung

Philips

Philips SBCRU422 Bedienungsanleitung

Philips

Philips SRP2014C/27 Bedienungsanleitung

Philips

Philips SRP5004/87 Bedienungsanleitung

Philips

Philips Perfect replacement SRP5107/27 Bedienungsanleitung

Philips

Philips SRU5110/86 Bedienungsanleitung

Philips

Philips 29PT8403/32 Bedienungsanleitung

Philips

Philips SRU 5086 Bedienungsanleitung

Philips

Philips Perfect replacement SRC3036WM Bedienungsanleitung

Beliebte Fernbedienung Handbücher anderer Marken

Panasonic

Panasonic EUR7622KB0 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen Beo4 Bedienungsanleitung

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Bedienungsanleitung

Multiplex

Multiplex PROFI TX 9 Bedienungsanleitung

One Remote

One Remote RMB4 Bedienungsanleitung

FUTABA

FUTABA 9ZAP - PART2 Bedienungsanleitung

HR Matic

HR Matic HR MULTI 3 Bedienungsanleitung

Yamaha

Yamaha ACC-GNRST-30-20 Bedienungsanleitung

EisSound

EisSound KBSOUND Bedienungsanleitung

Marantz

Marantz RC101 Bedienungsanleitung

Conrad

Conrad FS20 TC6 Bedienungsanleitung

Anritsu

Anritsu MP1777A Bedienungsanleitung

Niles

Niles WVC100 Fehlerbehebungshandbuch

RCA

RCA RCU1300 Bedienungsanleitung

Bang & Olufsen

Bang & Olufsen BEO6 Bedienungsanleitung

GE 94901 Bedienungsanleitung

Onbon

Onbon YQ1-75 Bedienungsanleitung

FUTABA

FUTABA R7108SB Montageanleitung
