Introduction

When setting up your television set for the first time, we advise

you to use the quick installation guide included below.

Please read the following instructions carefully to familiarise yourself with

all the features available on your set:

Remote control keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

The keys on the television set . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Tuning in to the TV channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Using other menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Peripherals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Installing your television set

æPositioning the television set

Place your TV on a solid, stable surface, leaving a space of at least 5 cm

around the appliance.

To avoid accidents, do not put anything on the set such as a cloth or

cover, a container full of liquid (vase) or a heat source (lamp).The set

must not be exposed to water.

ÂConnections

• Insert the aerial plug into the Msocket at the rear of the set.

Smaller sets are equipped with an internal aerial. Under certain conditions,

reception can be poor.You can improve it by repositioning the aerial. If the

reception remains unsatisfactory, an external aerial should be used.

• Insert the mains plug into a wall socket (220-240 V / 50 Hz).

êRemote control

Insert the two R6-type batteries (supplied) making sure that they are the

right way round.

The batteries supplied with this appliance do not contain mercury or nickel

cadmium. Please do not discard your used batteries if you have access to a

recycling facility (if in doubt, consult your dealer).When the batteries are

replaced, use the same type.

®Switching on

To switch on the set, press the on/off key.

A red indicator comes on and the screen lights up.

Go straight to the chapter Quick installation on the following page.

If the television remains in standby mode, press P on the remote control.

The indicator flashes when you use the remote control.

The television set has 4 keys which are located on the front or the top

of the set depending on the model.

The VOLUME - + (-a+) keys are used to adjust the sound level.

The PROGRAM - + (- P +) keys are used to select the required

programmes.

To access the menus, hold down the VOLUME - and VOLUME + keys

simultaneously.Then use the PROGRAM - + keys to select an adjustment

and the VOLUME - + keys to make the adjustment.

To exit from the menu, hold down the VOLUME - and VOLUME + keys

for a few seconds.

Note: when the LOCK function is activated, these keys are unavailable (see

page 6).

The keys on the TV set

The keys on the remote control

Standby

To set the TV to standby mode.

The red indicator lights up.To

switch the set back on, press P

, P or to .

Select Programme

Brings up the previous or

following programme.

Numerical Keys

For direct access to programmes

For a 2-digit programme number,

the second digit must be entered

before the dash disappears.

To view a programme which has been

locked, you must enter the confidential

code number (see p. 6).

Screen Information

Hold down for 5 seconds to

permanently display the

programme number. Press quickly

to display or remove the

programme number and the time.

Volume

To adjust the sound level.

Mute

To disable or enable the sound.

Smart sound controls

To access a series of settings:

CINEMA,MUSIC,SPEECH and

return to PERSONAL.

Smart picture controls

To access a series of settings:

RICH (when the room is very

light), NATURAL (optimum

conditions), SOFT (when the

room is very dark) and return to

PERSONAL.

To call up or exit from the menus.

Use and to adjust.

The menus disappear automatically

after 30 seconds if no further

command is given.

Select EXT sockets

Press several times to select EXT

sockets (see p.7).

Timer

To select an automatic standby

period (from 0 to 240 minutes).

Tuning in to channels

Quick installation (first use)

The following operations are all described in the enclosed quick

installation guide.We advise you to use it.

The first time you switch on the television, a menu appears on the screen.

This menu asks you to choose the language of the other menus.

If the menu does not appear, hold down the PROGRAM- and PROGRAM+ keys

(ora-and P -)

on the set for 4 seconds to bring it up.

æUse the keys numbered from to on the remote control to choose

your language (for English, press ).Another menu appears.

ÂSelect your country (for GB, press ).

êAs soon as your country is entered, tuning in starts automatically.

The operation takes a few minutes.A display shows the search status and

the number of programmes found.When it has finished, the menu

disappears and the last programme is displayed.

If no programmes are found, refer to the chapter entitled Tips on p. 8.

®If the transmitter or the cable network broadcasts the automatic sort

signal, the programmes will be correctly numbered.

†If not, the programmes found will be numbered in descending order

starting at 99, 98, 97, etc. (or 79, 78, ...).

Use the SORT menu to renumber them.

Some transmitters or cable networks broadcast their own sort parameters (region,

language, etc.).Where this is the case, make your choice using the keys and

confirm with .

æPress the key.The main menu is displayed.

ÂPress once to select INSTALLATION, then press .

The INSTALLATION menu appears.The LANGUAGE option is activated.

êPress 3 times to select SORT then press .

The SORT menu appears.The FROM option is activated.

®Select the programme you wish to renumber using keys or to .

Example: to renumber programme 78 as 2, press .

†Select option A (key ) and enter the new number with keys

or to (for the example given, enter 2)

ÚSelect EXCHANGE (key ) and press .The message EXCHANGED

appears, the exchange takes place ( to cancel). In our example,

programme 78 is renumbered as 2 (and programme 2 as 78).

ºSelect the option FROM (key ) and repeat stages ®to Úas many times

as there are programmes to renumber.

îTo exit from the menus, press .

To renumber the programmes found

æPress .The main menu is displayed on-screen.

ÂPress once to select INSTALLATION and press .The INSTALLATION

menu appears.

êUse to select a setting and to adjust.

• LANGUAGE: to change the menu language.

• COUNTRY: to select the country you are in (GB for Great Britain).

This setting affects the automatic programme sort.

• AUTOSTORE: press to begin storing.The operation takes a few minutes.

When it is complete, the INSTALLATION menu reappears automatically.

For more information, see the Quick Installation chapter, steps êto †

on the previous page.

To exit or interrupt the search, press .

• EXTERNAL: press to bring up the menu.You have access to a series of

names which allow you to customise the names of the external sockets.

When you next select an external socket, its chosen name will be displayed

for a few seconds.

®To exit from the menus, press .

Manual tuning

This menu allows you to store the programmes one by one.

æPress .The main menu comes up on the screen.

ÂPress once to select INSTALLATION then press .

êSelect MANUAL STORE ( ) and press .

The MANUAL STORE menu appears.

®Select SYSTEM (only available on certain models). Use to select AUTO

(automatic detection) or manual detection: EAST- EU (standard DK) or

WEST- EU (standard BG).

†Select SEARCH and press .The search begins.

As soon as a programme is found, the search will stop.

If you know the frequency of the programme required, simply enter its

number using keys to .

If no programme is found, refer to the Tips chapter on p. 8.

ÚIf reception is unsatisfactory, select FINE TUNE and press or to fine

tune.

ºSelect PROGRAM NO. and enter the required programme number using

or to .

îSelect STORE and press .

The message STORED appears.The programme has been stored.

œRepeat steps †to îas many times as there are programmes to store.

To exit the menus, press .

Other settings on the INSTALLATION menu

Using other menus

To adjust a menu:

æDisplay the menu. ÂSelect a setting. êAdjust.

Note: the menus disappear automatically after 30 seconds if no further adjustments are made.

To exit from the menus, press (or to come back to the previous stage).

Adjusting the sound

You can store your own sound and picture settings.

æFirst carry out your menu settings.

ÂNext, select PERSONAL and press .The message STORED is displayed.

The settings are stored.

Values are saved under PERSONAL in the Smart sound and picture controls

( and )

Note: volume and DELTA VOL. are automatically stored and do not need to be stored

in the PERSONAL menu.

Press .You can adjust: BRIGHTNESS,COLOUR,CONTRAST,SHARPNESS,

TINT,CONTRAST+ and NOISE RED..

• SHARPNESS: alters the crispness of the image,

• TINT: alters the colour balance.There are 3 options: COLD (blue tint), NORMAL

(balanced) or WARM (red tint).

• CONTRAST+: automatically adjusts the image contrast according to content

(the darkest part of the image is always black).

• NOISE RED.: alleviates fuzziness (snowy picture).This setting is useful when

reception is difficult.

Press .You can adjust DELTA VOL.

• DELTA VOLUME (volume difference): allows you to compensate for the volume

differences between the different programmes or the EXT sockets.This setting is

available for programmes 1 - 40 and the EXT sockets.

Adjusting the picture

Storing settings

This function (only available on certain models) allows you to lock the set in order

to limit its use completely or partially.

Key lock

æPress , select TV LOCK ( ) and press .

ÂSet the LOCK to ON.The keys are locked.

êSwitch off the set and put the remote control out of sight.The set cannot be

used (it can only be switched on using the remote control).

To cancel: switch LOCK to OFF.

Programme lock

æPress , select TV LOCK ( ) and press .

ÂSelect PARENTAL CONT. and press .

êEnter your confidential access code.The first time, enter the code 0711 then

confirm by re-entering 0711.The menu appears.

®Select PROGRAM NO. and use keys or to to enter the number

of the programme or socket you wish to lock.

To lock all of them, select ALL.

†Select LOCK then YES.

ÚRepeat stages ®and †for each programme to be locked.You can lock 5

programmes separately.

ºPress to exit.To watch a programme which has been locked you will now

need to enter the confidential code; otherwise the screen will remain blank.

When a locked programme is displayed, use the P keys to access other

programmes (the keys are used to enter the code). Caution: in the case of

encrypted programmes which use an external decoder, it is necessary to lock the

corresponding EXT socket (and not the programme number).

To unlock all programmes

Repeat stages æ- êabove, then:

®Select CLEAR ALL and press .All programmes are unlocked.

To change the confidential code

Repeat stages æ- êabove, then:

®Select CHANGE CODE and enter your own 4-digit number.

†Confirm by entering it again.Your new code will be stored.

If you have forgotten your confidential code, enter the universal code 0711 twice.

To exit: press .

This function (only available on certain models) allows you to use your TV as an

alarm clock.

æPress , select TIMER ( ) and press .

ÂThe SET CLOCK menu appears. Enter the time ( or ).

êSelect TIMER ACTIVE and press to switch the timer on or off.

®Select PROGRAM NO. and enter the number of the programme required.

†Select START TIME and enter the time at which the set is to switch on.

ÚPress to put the set into standby mode. It will switch on automatically at

the programmed time. If you leave the set switched on, it will merely change

programmes at the set time.

The set switches off automatically after 4 hours if no further commands are given.

Locking the set

Timer function

To select connected equipment

Press to select EXT(1) and, on models with 2 euroconnector

sockets: EXT2 and Y/C2 (S-VHS signal on EXT2).

The switch is automatic on most appliances (decoders, etc.).

Depending on the model, sockets are on the front

(sometimes under a flap) or on the right-hand side of the set.

Headphones

When the earphones are plugged in, the sound on the set is

cut off.Adjust the volume using the akeys.

The headphones must have an impedance of between 32 and

600 ohms.

Camcorder

Certain models are equipped with AUDIO/VIDEO

connections. Make the connections, then use the key to

select EXT (or EXT2 for models with 2 euroconnector

sockets).The switch between the front and rear sockets is

automatic with priority on front sockets.

Front panel connections

Video recorder (only)

Connect as shown using a good quality euroconnector

cable.

If your video recorder does not have a euroconnector socket, the

only connection possible is via the aerial cable.You will therefore

need to tune in your video recorder test signal and assign it

programme number 0 (see manual store, p. 4).To reproduce the

video recorder picture, press .

Video recorder with decoder

Connect the decoder to the second euroconnector on the

video recorder.You can then record scrambled transmissions.

Satellite receiver, decoder, DVD, games, etc.

For sets equipped with two euroconnector sockets, it is

best to connect the equipment which produces RGB signals

(digital decoder, DVD drives, games, etc.) to EXT1 and the

equipment which produces S-VHS signals (S-VHS and Hi-8

video recorders) to EXT2.

Video recorder

Connecting other appliances

Depending on the model, the TV is equipped with 1 or 2 euroconnector sockets, EXT1 and EXT2.

The EXT1 socket controls audio video input/output and RGB input.

The EXT2 socket (if available) controls audio video input/output and S-VHS input.

Other equipment

Tips

Poor reception or no picture

The proximity of mountains or high buildings can cause ghost pictures,

echoing or shadows. If this is the case, try tuning the picture using FINE

TUNE (p. 4).

Do you have the right system (p. 4)?

Check that the aerial plug or euroconnector plug is properly connected.

Check also that your aerial is capable of receiving broadcasts in this

frequency range (UHF or VHF).

Adjusting the picture

If the picture is out of focus, or if you are having difficulties finding the right

settings, select one of the Smart picture controls (p. 2) and store it

using the PERSONAL setting (p.5).

In case of bad reception (fuzzy picture), set the NOISE RED to ON: p. 5.

The picture is in black and white

To read a video cassette, check that it is recorded in the same format as

that of the video recorder (PAL,SECAM or NTSC).

No sound

If certain programmes have a picture but no sound, this is because you do

not have the correct TV system (see p. 4).

Standby

When you switch on the set, if it remains

in standby mode and the LOCKED message is displayed, this means that the

LOCK function is activated (p. 6).

The set switches automatically to standby if it receives no signals for a period

of 15 minutes.

When it is in standby mode, the set uses energy.To save electricity, we

advise you to switch it off using the on-off button.

Still having problems?

If the set breaks down, never try to repair it yourself. Consult your after-

sales service department instead.

Recycling

The materials used in your set are either reusable or can be recycled.

To minimise environmental waste, specialist companies collect used

appliances and dismantle them after retrieving any materials that can be

used again (ask your dealer for further details).

Inhaltsverzeichnis

Andere Philips Fernseher Handbücher

Philips

Philips 28PW9512 Bedienungsanleitung

Philips

Philips 65OLED804/78 Bedienungsanleitung

Philips

Philips 4504 Series Bedienungsanleitung

Philips

Philips 50PUG7907/78 Bedienungsanleitung

Philips

Philips 32PFL3509 Bedienungsanleitung

Philips

Philips CTV TABLE STEREO 36 INCH TP3669C Bedienungsanleitung

Philips

Philips 34PW8520 Handbuch

Philips

Philips AZ 1565 Bedienungsanleitung

Philips

Philips Q552.2E Bedienungsanleitung

Philips

Philips SK4.0A CA Bedienungsanleitung

Philips

Philips 29PT9415/12 Bedienungsanleitung

Philips

Philips 50PUS8506 Bedienungsanleitung

Philips

Philips 30 IN WIDESCREEN REAL FLAT HDTV 30PW850H Bedienungsanleitung

Philips

Philips 55PFL5766 Bedienungsanleitung

Philips

Philips 50PUT7966 Bedienungsanleitung

Philips

Philips 15PF5120 Montage- und Bedienungsanleitung

Philips

Philips 29PT8521 Bedienungsanleitung

Philips

Philips 14PT4626/V7 Bedienungsanleitung

Philips

Philips 28PW6332 - annexe 1 Bedienungsanleitung

Philips

Philips 50PFL3708 Bedienungsanleitung

Philips

Philips 21PT3324 Bedienungsanleitung

Philips

Philips A10E Bedienungs- und Montageanleitung

Philips

Philips OLED806 Series Bedienungsanleitung

Philips

Philips 47PFL5704D - 47" Class Full Hd 1080p Lcd Tv... Konfigurationshandbuch

Beliebte Fernseher Handbücher anderer Marken

Toshiba

Toshiba 27A10 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Sylvania

Sylvania 6427FB Bedienungsanleitung

Sanyo

Sanyo CE19LD90N-B Bedienungsanleitung

North State

North State TV2GO Bedienungsanleitung

RCA

RCA RTU7877 Bedienungsanleitung

Sharp

Sharp 21K-FG1RU Bedienungsanleitung

Sony

Sony Esprit TAV-L1 Bedienungsanleitung

Grundig

Grundig 43 VLE 4820 Bedienungsanleitung

Samsung

Samsung LN26C350D1D Bedienungsanleitung
