Philips 28PT4404 Bedienungsanleitung

Colour Television

28PT4404

Product highlights

• Black Line D picture tube

• Contrast Plus

• Sharpness Control

• Sleeptimer

• Plug & Play

• Easy Tune (ATS/ACI)

• 5 pages TOP/FLOF Teletext

RC 2543

Colour Television

28PT4404

Product Information


Screen size 28” (70 cm)

Picture tube Black Line D

Viewing area 67 cm (28”)

Iron Mask

Contrast Plus

Sharpness Control

Color Temperature Control

4 : 3 Expand

Noise Reduction

Sound

Sound output 2 x 5 Watts RMS

Loudspeakers Full Range Speakers

Ultra Bass

Bilingual switch on remote control

Reception

Tuning system PLL digital tuning

Tuner UV, S and Hyperband

Channel selection 80 presets

Aerial input 75 Ohm Coaxial

TV systems See table

Video playback NTSC 3.58 / 4.43

Stereo systems See table

Plug and Play

Easy Tune (ATS / ACI) : UK, FR, BE, NL, CH, DE,AT,

ES, PL, IT, ND

Teletext

Reception standards TOP / FLOF

5 page memory

Connectors

Front Stereo headphone out (3.5 mm)

Rear Ext 1: Scart CVBS In / Out + RGB In

Operation

Remote control RC2543/01

Side TV/VCR switch on remote control

Program Information Line

Sleeptimer (240 minutes)

Measurements

Mains 220 - 240V, 50 Hz

Power consumption

• 97 Watts (normal operation)

• 5 Watts (Standby)

Net weight

• 36 kg (approx.)

Gross weight

• 38 kg (approx.)

Set dimension

• 763 x 476 x 580 (W x D x H mm)

Box dimension

• 856 x 597 x 725 (W x D x H mm)

Cabinet Colour Light Grey (10762)

Product Highlights

Black Line D picture tube

The Black Line D picture tube offers excellent images

with high sharpness and contrast and less reflection for

brilliant colors and improved viewing in daylight

conditions.

Contrast Plus

A special circuitry has been incorporated into this

receiver to enhance the darker portions of the picture

for added realism and overall picture quality.

Easy Tune (ATS / ACI)

A no fuss and easy way to install and store channels in

any favorite order.

Sleeptimer

The Sleeptimer automatically turns the TV off at a

preset time of up to 240 minutes from the time the

feature is activated. Sleeptimer settings are

programmed in 15, 30 and 60-minute increments.

Plug and Play

No problem anymore to install your new TV.

You choose the language you are more famliar with,

the country you are in and the TV will install

automatically all available programs.

Predecessor : 25/28PT4423

Chassis : L9LS

Release date (TTM) : Febuary 2000

Date of issue : January 2000

Features and specifications subject to change without notice

2CS NICAM 2CS NICAM NICAM NICAM PAL PAL PAL SECAM SECAM SECAM

DK DK BG BG I LL’ BG DK I BG DK LL’

version stereo

system

transmission

system

28PT4404 /00 •• •
