English

EasyLink features are based on the“one touch operation”approach.This means that a sequence of actions are

executed at the same time in both the television and the video cassette recorder, provided both are fitted

with the EasyLink function and connected with the eurocable supplied with your video recorder.

Digital & Analogue Mode

Your Remote Control 2

Preparation 3

InstallTV setup 13-14

Digital Mode only

Tuning in digital channels 5

StoreTV channels 5

AddTV channels 5

Change channel numbers 6

Channel list 6

Favourite channels 6

Viewing preferences 7

Video/Modem settings 8

Subscription information 8

Technical information 9

Analogue Mode only

Tuning in analogue channels 10

Select menu language and country 10

Automatic installation 11

Manual installation 11

Give name 12

Reshuffle the programme list 12

Select favouriteTV channels 12

Digital & Analogue Mode

Use of the remote control 15-17

Adjusting the settings 18

Picture menu 18

Sound menu 18-21

Features menu 22

Keys on top of theTV 29

Digital Mode only

DigitalTeletext 29

Setting the timer 30

Parental lock 31

Analogue Mode only

Programme list 22

NEXTVIEW 23-26

AnalogueTeletext 27-29

Connecting & selecting equipment 32-36

RC functions for peripherals 37-38

Recording 39

Tips 40

Index 40

Glossary 41

Remark: due to continuous product improvements this document is subject to change without prior notice.

Connect peripheral equipment

Operation

Installation

Contents

Mha

SMARTSMART

213

546

879

®Ò‡π

†

Mqa

EXIT

GUIDE

DIGITAL

TEXT

VCR DVD SAT

SELECT

SETTINGS

DIGITAL

SETUP

SMARTSMART

PICTURESOUND

¬V P

h‡ hX

yÚ

pπ

yÚ

qQUb

2Preparation

Sfreeze the picture p.17

hold teletext page p. 28

fsolution to puzzles p.28

display PDC/VPS code

Preduce image noise p.17

Smart Controls

Msmart sound p.16

hactive control p.16

asmart picture p.16

qpicture format p. 16

Utime display p.16`

txt-subpage selection p.28

bdual screen on/off p.16

Qsurround mode p.16

Bswitch to standby p.15

SETTINGS

Oanalogue main menu on/off p. 15

0previous programme p.15

hzoom on/off p. 17

Xbilingual choice/sound info p. 17

TXT language group selection p.27

preferred audio language with

digital channels p.7

EasyLink p.37

®recording

‡stop

bteletext on/off p.27

DIGITAL SETUP

Ïdigital menu on/off when in

digital mode p.5

cursor to select

your choice p.10

Installation p.10

Vvolume up/down p. 15

¬sound mute p. 15

Pprogramme selection p. 15

Peripherals p. 37

wselection of EXT1,EXT2,EXT3,

FRONT,Digital or Analogue

TV, videorecorder (VCR), DVD or

Satellite (SAT) selection.

Colour keys

- selectTV channels by theme p.24

(present according to the type ofTV set)

- direct teletext page or

subject selection p.26

Audio andVideo equipment

p.37-38

nAnalogue or Digital mode p.15

jsubtitles on/off p. 15

iscreen information p.17

GUIDE

ONEXTVIEW on/off p.15

(only in analogue mode)

SELECT

OK activate your choice

Your remote control

Preparation

3Preparation

R6 / AA

&Place theTV on a solid surface.

For ventilation, leave at least 5 cm free all around theTV.

Do not place theTV on a carpet.

To prevent any unsafe situations,do not place any objects on top of theTV.

Avoid heat,direct sunlight and exposure to rain or water.

éInsert the aerial plug firmly into the aerial socket at the back of

theTV. For best picture quality use the aerial cable supplied. (According to

your type ofTV, there may be a suppressor-aerial cable supplied for a better

picture quality.)

“To enjoy Dolby Pro Logic Surround sound,connect two Surround Sound rear

loudspeakers (either supplied or not according to the type ofTV set

purchased) to the back of theTV.

See Connect Extra Loudspeakers/Amplifier, p.34.

‘Insert the mains plug in the wall socket having a mains voltage of 220V-

240V.

To prevent damaging the mains (AC) cord which could cause a hazard,do not

place theTV on the cord.

(Remote control:Remove the cover of the battery compartment.

Insert the 2 batteries supplied (Type R6-1,5V) as indicated.

The batteries supplied do not contain the heavy metals mercury and cadmium.

Nevertheless in many countries exhausted batteries may not be disposed of with

your household waste. Please check on how to dispose of exhausted batteries

according to local regulations.

Note: this remote control functions withTVs which use the RC6 signalling standard.

CABLE

Preparation

4Preparation

➪

✹

congratulations for selecting this philips product

click ok to start enjoying your digital television

✹

◆main menu

1 setting the timer

2 choosing favourite channels

3 parental lock

4 viewing preferences

5 getting started

6 subscription information

7 technical information

✹

➪

◆channel list

1 BBC ONE

2 BBC TWO

3 ITV Channel 3

4 Channel 4

5 SDN-5 Eng./N.I.

6 ITV 2

7 BBC CHOICE

✹

➪

◆store channels

Your digital TV is now searching

for all available channels

this may take about 20 minutes,

please be patient

digital channels found 3

other channels found 5

➪

Automatic installation

Start

Stop

TV is searching

One moment please ...

§Switch theTV on: Press the power switch Aon the front of yourTV.

A green indicator on the front of theTV lights up and the screen comes on.

If the indicator is red,press the -P+ key on the remote control.

The green lamp blinks every time you press a key on the remote control.

Switch on for the first time

•When you switch on your set for the first time,the congratulations

message appears on the screen.TheTV is in digital mode.

Press the SELECT/OK key on the remote control to get started.

If the message does not appear and the screen remains snowy, press the n

key on the remote control to switch theTV from analogue to digital mode.

•The main menu is displayed.

The menu item in yellow is actually selected.

The menu items in bold are selectable.

Press the digit key 5 on the remote control.

•The Automatic Installation menu is displayed and theTV begins to search all

available channels.

First all the available analogue channels are searched for and stored

automatically.The channel list is automatically filled with all the programme

numbers and names of theTV channels transmitted.

Next,the store channels menu is displayed and all the available digital

channels are searched for.

•When the search is complete,a channel list is displayed and theTV is

switched to digital mode again.

Note: the instructions on screen may help you to navigate through the menus and to

execute certain actions.Additionally information will be displayed about the

selected channel.

èCard reader

With your newTV you can watch the free to air digital channels like BBC1

and ITV.

If you signed up for an ONdigital subscription, your ONdigital Smartcard will

arrive by post.

If you didn’t start an ONdigital subscription yet,you can still do.

Just visit your local electrical retailer or call ONdigital customer services on

0870 600 9696.Put your ONdigital Smartcard into the slot at the front or

the right side of yourTV (according to the type ofTV set). Make sure it is the

right way round:gold chip facing you or up, the arrow pointing to the slot.

Now call the ONdigitalActivationTeam on 0870 600 1616.

They’ll confirm your name,address, account number,Viewing Smartcard

number and your choice of ONdigital channels.You’ll be able to start viewing

straight away.

Note: See also Subscription information, p. 8.

5Installation

213

546

®Ò‡ π†

TV VCR DVD SAT

DIGITAL

¬V P

EXIT

TEXTGUIDE

SELECT

DIGITAL

SETUP

select menu item

activate

switch main

menu on

return to

main menu

switch main

menu off

✹

◆channel list

1 BBC ONE

2 BBC TWO

3 ITV Channel 3

4 Channel 4

5 SDN-5 Eng./N.I.

6 ITV 2

7 BBC CHOICE

➪

✹

◆getting started

1 channel list

2 change channel numbers

3 add channels

4 store channels

➪

◆main menu

1 setting the timer

2 choosing favourite channels

3 parental lock

4 viewing preferences

5 getting started

6 subscription information

7 technical information

➪

✹

◆add channels

Your digital TV is now searching

for all available channels

this may take about 20 minutes,

please be patient

number of channels found 3

✹

➪

◆store channels

Your digital TV is now searching

for all available channels

this may take about 20 minutes,

please be patient

digital channels found 3

other channels found 5

This function is used to search for new digital channels that may have been

launched by the broadcaster after the initial installation.

&Select add channels in the getting started menu.

éPress the SELECT/OK key.

The search begins and only new channels will be stored and added to the

channel list.

“Press the red key to return to the getting started menu or press the EXIT

key to return to a normalTV picture when the installation is finished.

Add channels

&Select getting started in the main menu with the cursor down or with the

digit key 5.

éPress the SELECT/OK key.

The getting started menu appears.

“Select store channels with the cursor down or with the digit key 4.

‘Press the SELECT/OK key to activate the searching.

All available digitalTV channels are searched for and stored automatically;

The on screen display indicates the percentage of the installation that has

been completed and the number of channels found.

When the search is complete,a channel list is displayed.

(Press the red key to return to the getting started menu or press the EXIT

key to switch the menu off.

TheTV then displays the current programme being broadcast on channel 1.

Note: If you want to stop the search, press the red key.

Store channels

&Press the DIGITAL SETUP key on the remote control to display the main

menu.

Note: if the main menu does not appear,theTV may be in analogue mode. Press the

nkey to switch theTV to digital mode and press the DIGITAL SETUP key again.

éUse the cursor in the up/down,left/right directions to select a menu item or

use the digit key for direct access to a menu item.

“Press the SELECT/OK key to activate.

‘Press the red key to return or press the EXIT key to switch a menu off.

Note: the instructions on screen may help you to navigate through the menus and to

execute certain actions.Additionally information will be displayed about the

selected channel.

To use the menus

These menus enable you to make all the adjustments required to receive

digital channels.

Tuning in the digital channels

6Installation

✹

➪

◆favourite channels

favourites are off

1 BBC ONE v

2 BBC TWO v

3 ITV Channel 3 v

4 Channel 4

5 SDN-5 Eng./N.I. v

6 ITV 2

7 BBC CHOICE

✹

◆channel list

1 BBC ONE

2 BBC TWO

3 ITV Channel 3

4 Channel 4

5 SDN-5 Eng./N.I.

6 ITV 2

7 BBC CHOICE

➪

✹

◆change channel numbers

1 BBC ONE

2 BBC TWO

3 ITV Channel 3

4 Channel 4

5 SDN-5 Eng./N.I.

6 ITV 2

7 BBC CHOICE

➪

✹

◆main menu

1 setting the timer

2 choosing favourite channels

3 parental lock

4 viewing preferences

5 getting started

6 subscription information

7 technical information

➪

This menu enables you to select favourite channels so that after leaving the

installation you can browse through those channels by pressing the - P + key.

Only those channels which are marked as favourites will be displayed.

Non-favourite channels can still be selected with the digit keys.

&Select choosing favourite channels in the main menu.

éPress the SELECT/OK key.

The favourite channel list is displayed.

“Use the cursor up/down to select the channel you want to make a favourite

and press the SELECT/OK key.

A heart symbol alongside the channel name is displayed.

‘Repeat for every channel you want to make a favourite or a non-favourite

channel.

(To remove any of these channels as favourites,select the channel you want to

remove and press the SELECT/OK key.

§After you have selected or de-selected all your favourites,press the green key

as indicated to switch the favourite mode on or off.

Favourite channels

This menu lists all the stored and available digital channels.

&Select channel list in the getting started menu.

éPress the SELECT/OK key.

The channel list is displayed.The symbols alongside the channel numbers

indicate whether the channel has been selected as a favourite channel (heart

symbols) or as locked channels (padlock symbols).

To lock channels or to select channels as favourites, see further.

“Use the cursor up/down to move through the channel list,or left/right to

move a whole page at a time.

‘Press the SELECT/OK key to view the channel selected or press the red key

to return to the getting started menu.

Channel list

If you prefer you can change the order of the stored channels.This is done

by exchanging the position of the channels.

&Select change channel numbers in the getting started menu.

éPress the SELECT/OK key.

The channel list is displayed.

“Select the channel number you want to exchange with the cursor up/down.

‘Press the SELECT/OK key.

(Select the new channel number you want to exchange it with.

§Press the SELECT/OK key.

Repeat the operation until all channels are in your preferred positions.

èPress the red key to return to the getting started menu or press the EXIT

key to return to a normalTV picture.

Change channel numbers

7Installation

✹

➪

◆viewing preferences

1 digital settings

2 video settings

3 modem settings

✹

➪

◆digital settings

1 preferred language gaelic

2 subtitles off

3 subtitles language

4 info display time long

5 timer alarm visual+audio

6 date and time 00:40

This menu enables you to adjust the digital, video and modem settings.

Digital settings

&Select viewing preferences in the main menu with the cursor up/down or

with the digit key 4.

éPress the SELECT/OK key.

The viewing preferences menu appears.

“Select digital settings with the cursor up/down or with the digit key 1.

‘Press the SELECT/OK key.

The digital settings menu appears.

(Use the cursor up/down to select a menu item and cursor left/right to adjust.

•preferred language: you can select a language preference for programmes

that have an alternative audio track: English,Welsch, Gaeilic or none.

If the selected language is available,theTV always plays your preferred

language.When your preferred language is not available,the default audio

language will be selected.

You can also use the Xkey under the door of the remote control to switch

between the available languages.

•subtitles:channels often transmit certain programmes with subtitling.

Select on or off.When selected on, the subtitles will be displayed if they are

available.

•subtitles language:you can select a language in which the subtitles will be

displayed when they are available.

On screen information usually indicates whether or not subtitles are available

for a programme.

Press the jkey on the remote control to switch subtitles on or off.

•info display time:you can set the length of time that on-screen information is

displayed:off,normal or long.

Note: if set to off, certain menus, including the channel list, will no longer appear on-

screen at all.

•timer alarm:select either visual or audio & visual.

The alarm gives a warning when a programme is about to start for which the

timer has been set.

When audio & visual is selected theTV will beep and display RED.

See Setting the timer, p.30.

•date and time: yourTV will automatically set the current date and time by

taking information from digital mode.If you wish to adjust these settings,you

can do so manually using the cursor left/right and the digit keys.

§Press the red key to return to the viewing preferences menu.

Viewing preferences

8Installation

✹

➪

◆viewing preferences

1 digital settings

2 video settings

3 modem settings

✹

➪

◆modem settings

1 modem internal

2 dialling pulse

3 connection direct

4 prefix 0

5 wait for dial tone yes

6 STD code no

7 prefix 011

✹

➪

◆subscription information

1 smartcard data

2 check your postbox

✹

➪

◆subscription information

1 smartcard data

2 check your postbox

✹

➪

◆postbox

✹

➪

◆smartcard data

rights ends on

ONdigital 1 99/12/27

See also Preparation,Card reader,p. 4.

Smartcard data

This option enables you to display the current expiry date of your

subscription account.

&Select subscription information in the main menu with the cursor up/down

or with the digit key 6.

éPress the SELECT/OK key.

“Select smartcard data and press the SELECT/OK key to display the current

expiry date of your subscription account.

‘Press the red key to return to the subscription information menu.

Check your postbox

Your television has the ability to display messages that have been sent to you

by a broadcaster, perhaps about a special offer or your current subscription

package.You will be advised when a message is waiting to be read by the

indication Post appearing on the screen when switching the television to

digital mode.

&Select subscription information in the main menu with the cursor up/down

or with the digit key 6.

éPress the SELECT/OK key.

“Select check your postbox and press the SELECT/OK key to display the most

recent message received.

‘Use the cursor up/down to select the previous messages.

Note: messages cannot be manually deleted, but the oldest messages are

automatically removed as new messages are received.

(Press the red key to return to the subscription information menu or press

the EXIT key to switch off the menus.

Subscription information

Modem settings

This menu enables you to adjust the modem settings.

&Select viewing preferences in the main menu and press the SELECT/OK key.

éSelect modem settings and press the SELECT/OK key.

“Select the modem settings one by one with the cursor up/down and change

the settings.

Your service provider will give you more details if necessary.

‘Press the EXIT key to switch off the menus.

Video settings

&Select viewing preferences in the main menu and press the SELECT/OK key.

éSelect video settings and press the SELECT/OK key.

“Use the cursor left/right to select the video standard:vhs or s-vhs + EasyLink.

9Installation

See p. 30.

See p. 31.

✹

◆technical information

1 signal strength

2 manufacturer data

3 auto update

✹

➪

◆manufacturer data

manufacturer PHILIPS

hardware version 00 01 0d 34

software version 00 80 70 11

manufacturer update 00 00 00 00

api version 00 12 a0 04

run version 00 07 03 0b

run update version 00 00 00 00

✹

➪

◆auto update

do you really want

to start a download

to update your

digital TV ?

✹

➪

◆signal strength

uhf channel number

signal strength ◆

good ◆

satisfactory ◆

poor ◆

➪

Parental lock

Setting the timer

The options contained within the technical information menu enable you to

check the status of your television.

This is not something you should need to do, apart from in the unlikely event

of a problem occurring with your television.

In this case, it will help the customer services people to understand the

problem and resolve it as quickly as possible.

&Select technical information in the main menu with the cursor up/down or

with the digit key 7.

éUse the cursor up/down or the corresponding digit key to select a menu item

and press the SELECT/OK key.

•signal strength:this option allows you to check the strength of the signal you

are receiving through your aerial.

•manufacturer data:this screen shows information about your television,such

as it’s manufacturer and the hard- and software versions it contains.

•auto update:this option can update the software used in your digitalTV.This

may update certain menus or functions of yourTV, as well as add new

features, but the general way in which theTV operates will not change.

Normally this type of update will be broadcast to your television like any

normal programme. You may be asked to start this update process by a

member of the ONdigital customer services team.

A message will be displayed asking you to confirm that you want to go ahead,

as it may change some of the personal settings you have made on yourTV,

such as locked or favourite channels.

“Follow the on screen instructions.

If you experience difficulties with this function and you are a current

ONdigital subscriber, please contact ONdigital customer services on

0870 600 9696.If you are not a subscriber but have difficulties,please call the

Philips digital help line on 0870 606 0117.

‘Press the EXIT key to switch the menus off.

Technical information

10 Installation

213

546

879

TV VCR DVD SAT

DIGITAL

TEXTGUIDE

¬V P

SELECT

SETTINGS

DIGITAL

SETUP

®Ò‡ π†

X®‡

yÚ

EXIT

INSTALLATION menu

activate

return or switch

main menu off

switch to

analogue mode

select menu

item

MENU TITLE

Subject 1

Subject 2

Subject 3

JSubject 4

Subject 5

Subject 6

JSubject 4 L M

pπ

After the new or extraTV channels have been

stored, theTV automatically transfers thoseTV

channels to the video recorder if it is equipped with

the EasyLink function. The message EasyLink :

downloading ...... appears on the screen. The

programme list of the video recorder is now the

same as the one of theTV. If the TV is connected

to a video recorder which supports the

NEXTVIEWLink function, theTV also automatically

transfers the language and country selections to the

video recorder.

Menu language

JINSTALLATION

MENU TITLE

United Kingdom

....

JCountry

MENU TITLE

English

....

JMenu language

First,select your language and country.

&Select Menu language and press the SELECT/OK key.

éSelect your language and press the SELECT/OK key.

Use the cursor up/down to scroll through the list and to bring up other

languages which are not displayed on the screen at present.

“Select Country and press the SELECT/OK key.

‘Select the country where you are now located and press the SELECT/OK

key.Use the cursor up/down to scroll through the list and bring up other

countries which are not displayed on the screen at present.

Select Other when none of the countries applies.

You can now search for and store theTV channels in two different ways:

using automatic installation or manual installation (tuning-in channel by

channel).

Select your choice and press the SELECT/OK key.

Select the menu language and country

StoreTV channels

&Use the cursor in the up/down,left/right directions to select a menu item.

“Press the SELECT/OK key to activate.

‘Use the SETTINGS key to return or to switch the menu off.

Note: the instructions on screen may help you to navigate through the menus and to

execute certain actions.Additionally information will be displayed about the selected

channel.

To use the menus

&Press the n key, if necessary,to switch theTV in analogue mode.

éOpen the door of the remote control.

“Press hand Xat the same time.

The analogue INSTALLATION menu appears on the screen.

Select the INSTALLATION menu

These menus enable you to make all the adjustments required to receive

analogue channels.

Tuning in the analogue channels

Andere Handbücher für 32DW9625/05

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips Fernseher Handbücher

Philips

Philips 6703 Series Bedienungsanleitung

Philips

Philips PHS5507 Bedienungsanleitung

Philips

Philips 32PFL3605/12 Bedienungsanleitung

Philips

Philips 32PFL5605M Bedienungsanleitung

Philips

Philips 22PFS4232 Bedienungsanleitung

Philips

Philips 32PFL4606H/60 Bedienungsanleitung

Philips

Philips 50PUG6601/77 Bedienungsanleitung

Philips

Philips 32PW6305/58 Bedienungsanleitung

Philips

Philips M-Link 36PT41B1 Bedienungsanleitung

Philips

Philips MAGNAVOX TP3675C99 Bedienungsanleitung

Philips

Philips 32PFL3008D/78 Bedienungsanleitung

Philips

Philips 27PS55S Bedienungsanleitung

Philips

Philips 32PW9523 - annexe 1 Bedienungsanleitung

Philips

Philips 32 IN HDTV MONITOR WITH ACTIVE CONTROL 32PT830H... Bedienungsanleitung

Philips

Philips 32PFL5403D - annexe 1 Bedienungsanleitung

Philips

Philips 32PHT5200 Bedienungsanleitung

Philips

Philips Magnavox PR1317 Bedienungsanleitung

Philips

Philips M-Link 27PT81S1 Technisches Handbuch

Philips

Philips 8508 Series Bedienungsanleitung

Philips

Philips 55PFL4709 Bedienungsanleitung

Philips

Philips 26PFL5322/10 Bedienungsanleitung

Philips

Philips 20PT9007D-17B Bedienungsanleitung

Philips

Philips 32PFL3405 Bedienungsanleitung

Philips

Philips 14PV135 Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Toshiba

Toshiba 27A10 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Sylvania

Sylvania 6427FB Bedienungsanleitung

Sanyo

Sanyo CE19LD90N-B Bedienungsanleitung

North State

North State TV2GO Bedienungsanleitung

RCA

RCA RTU7877 Bedienungsanleitung

Sharp

Sharp 21K-FG1RU Bedienungsanleitung

Sony

Sony Esprit TAV-L1 Bedienungsanleitung

Grundig

Grundig 43 VLE 4820 Bedienungsanleitung

Samsung

Samsung LN26C350D1D Bedienungsanleitung
