Philips 52PFL5605H/05 Bedienungsanleitung

EN User Manual

www.philips.com/welcome

32PFL5405H

37PFL5405H

42PFL5405H

32PFL5605H

40PFL5605H

46PFL5605H

52PFL5605H

40PFL5605K

40PFL5805H

46PFL5805H

32PFL6605H

40PFL6605H

Österreich 0800 180 016

België/Belgique 80080190

България 00800 11 544 24

Hrvatska 01 6403 776 Lokalni poziv

Česká republika 800142840 Bezplatný hovor

Danmark 3525 8759 Lokalt opkald

Estonia 6008600 kohalik kõne tariifi

Suomi 09 2311 3415 paikallispuhelu

France 0805 025 510 numéro sans frais

Deutschland 0800 000 7520 gebührenfreier Anruf

Ελλάδα 0 0800 3122 1280 Κλήση χωρίς χρέωση

Magyarország 0680018189 Ingyenes hívás

Hrvatska 0800 222778 free

Ireland 01 601 1777

Italia 800 088774 Numero Verde

Қазақстан +7 727 250 66 17 local

Latvia 52737691 local

Lithuania 67228896 local

Luxemburg/Luxembourg 40 6661 5644 Ortsgespräch/Appel local

Nederland 0800 0230076 Gratis nummer

Norge 22 70 81 11 Lokalsamtale

Polska 00800-311-13-18 Pozosta?e produkty RTV oraz AGD

Portugal 800 780 903 Chamada Grátis

România 0800-894910

0318107125

Apel gratuit

Apel local

Россия (495) 961-1111 0.15 USD/minute

Србија +381 114 440 841 Lokalni poziv

Slovensko 0800 004537 Bezplatný hovor

Slovenija 00386 12 80 95 00 lokalni klic

España 900 800 655 Teléfono local gratuito solamente para

clientes en España

Sverige 08 5792 9100 Lokalsamtal

Suisse/Schweiz/Svizzera 0800 002 050 Schweizer Festnetztarif/ Tarif réseau fixe

France

Türkiye 0800 261 3302 Şehiriçi arama

United Kingdom General No: 0800 331 6015

General National Rate No:

0870 911 0036

free

National rate

Україна 0-800-500-697

www.philips.com/support

Model

Serial

This information is correct at the time of press. For updated information, see www.philips.com/support.

EN 3

English

1Get started 4

TV Tour 4

Important 9

Position the TV 12

Product highlights 13

Access more information 14

2Use your TV 15

Overview 15

Side controls and indicators 15

Remote control 15

Basic TV menus 17

Watch TV 19

Watch a connected device 21

Use Ambilight 21

3Use more of your TV 23

Use teletext 23

Favourite channels 24

Use EPG 24

Use timers and locks 24

Use subtitles 25

Access multimedia 25

Use Scenea 26

Universal access 27

4Set up the TV 29

Change picture and sound settings 29

Change channel settings 30

Install channels 32

Change language settings 33

Change other settings 34

Update software 35

Reinstall the TV 36

5Connect the TV 37

First connections 37

About cables 37

TV connectors overview 39

Connect devices 40

Connect more devices 46

Use Philips EasyLink 50

Use a CAM 53

6Troubleshooting 54

General TV issues 54

TV channel issues 54

Picture issues 54

Sound issues 55

HDMI connection issues 55

USB connection issues 56

PC connection issues 56

7Technical data 57

Overview 57

Power and reception 57

Display and sound 57

Display resolutions 57

Multimedia 58

Connectivity 58

Dimensions 58

8Index 60

Contents

EN 4

1Get started

TV Tour

The remote control

To adjust the volume.

To switch TV channels.

To open or close the Home menu .

In the Home menu, you can access

connected devices, picture and sound

settings and other useful features.

To open or close the Browse menu .

In the Browse menu, you can open Teletext,

the Channel list or the TV programme guide.

EN 5

English

To open or close the Options menu .

Options menus offer convenient settings

related to what is on screen.

To open or close the Experience menu .

In the Experience menu, you can access a

range of frequently used settings.

Back .

To return to the previous TV channel or

menu.

Red

To select the red option, access digital

Interactive TV services or watch TV

demonstration clips.

EN 6

Green

To select the green option or the Eco

settings.

Yellow

To select the yellow option or the Help

menu.

Blue

To select the blue option or open the

Widgets.

Read more in Help > Use your TV > Basic

TV Menus > Add your devices (Page 18).

In Help > Connect the TV (Page 37), you can learn to connect the most common devices through

illustrations, for example:

EN 9

English

High Definition TV

You can watch High Definition (HD)

programmes in HD picture quality.

If you watch non-HD programmes, the

picture quality will be similar to non-HD TVs.

Your TV can display HD video content from:

a Blu-ray disc player, connected with an

HDMI cable, playing a Blu-ray disc

an upscaling DVD player, connected

with an HDMI cable, playing a DVD

disc

an over-the-air HD broadcaster

(DVB-T MPEG4)

a digital HD receiver, connected with

an HDMI cable, playing HD content

from a cable or satellite operator

an HD channel on your DVB-C

network

an HD game console (for example,

X-Box 360 or PlayStation 3), connected

with an HDMI cable, playing an HD

game

HD video clip

To experience the stunning sharpness and

picture quality of HD TV, you can watch the

High Definition video clip from the Home

menu. Press > [Setup] > [Watch

demos] (on the second page of the setup

menu).

Contact your dealer for more information.

Go to www.philips.com/support to find

FAQs that list the HD channels or providers

in your country.

Important

Congratulations

NonPublish

Congratulations on your purchase, and

welcome to Philips! To fully benefit from the

support that Philips offers, register your TV

at (http://www.philips.com/welcome).

Safety

NonPublish

Read and understand all instructions before

you use your TV. If damage is caused by

failure to follow instructions, the warranty

does not apply.

Risk of electric shock or fire!

Never expose the TV to rain or water.

Never place liquid containers, such as vases,

near the TV. If liquids are spilt on or into the

TV, disconnect the TV from the power

outlet immediately. Contact Philips

Consumer Care to have the TV checked

before use.

Never insert objects into the ventilation

slots or other openings on the TV.

When the TV is swivelled, ensure that

no strain is exerted on the power cord.

Strain on the power cord can loosen

connections and cause arcing.

Never place the TV, remote control or

batteries near naked flames or other

heat sources, including direct sunlight.

To prevent the spread of fire, keep

candles or other flames away from the

TV, remote control and batteries at all

times.

Risk of short circuit or fire!

Never expose the remote control or

batteries to rain, water or excessive

heat.

Avoid force coming onto power plugs.

Loose power plugs can cause arcing or

fire.

Risk of injury or damage to the TV!

Two people are required to lift and

carry a TV that weighs more than 25

kg/55 lbs.

When stand mounting the TV, use only

the supplied stand. Secure the stand to

the TV tightly. Place the TV on a flat,

level surface that can support the

combined weight of the TV and the

stand.

EN 10

When wall mounting the TV, use only a

wall mount that can support the weight

of the TV. Secure the wall mount to a

wall that can support the combined

weight of the TV and wall mount.

Koninklijke Philips Electronics N.V. bears

no responsibility for improper wall

mounting that result in accident, injury

or damage.

Before you connect the TV to the

power outlet, ensure that the power

voltage matches the value printed on

the back of the TV. Never connect the

TV to the power outlet if the voltage is

different.

Risk of injury to children!

Follow these precautions to prevent the TV

from toppling over and causing injury to

children:

Never place the TV on a surface

covered by a cloth or other material

that can be pulled away.

Ensure that no part of the TV hangs

over the edge of the mounting surface.

Never place the TV on tall furniture,

such as a bookcase, without anchoring

both the furniture and TV to the wall

or a suitable support.

Educate children about the dangers of

climbing on furniture to reach the TV.

Risk of overheating!

Never install the TV in a confined

space. Always leave a space of at least 4

inches around the TV for ventilation.

Ensure curtains or other objects never

cover the ventilation slots on the TV.

Risk of injury, fire or power cord damage!

Never place the TV or any objects on

the power cord.

To easily disconnect the TV power

cord from the power outlet, ensure

that you have full access to the power

cord at all times.

When you disconnect the power cord,

always pull the plug, never the cable.

Disconnect the TV from the socket and

aerial before lightning storms. During

lightning storms, never touch any part

of the TV, power cord or aerial cable.

Risk of hearing damage!

Avoid using earphones or headphones at

high volumes or for prolonged periods of

time.

Low temperatures

If the TV is transported in temperatures

below 5°C/41°F, unpack the TV and wait

until the TV temperature matches room

temperature before connecting the TV to

the power socket.

Screen care

NonPublish

Risk of damage to the TV screen!

Never touch, push, rub or strike the

screen with any object.

Unplug the TV before cleaning.

Clean the TV and frame with a soft

damp cloth. Never use substances such

as alcohol, chemicals or household

cleaners on the TV.

To avoid deformations and colour

fading, wipe off water drops as soon as

possible.

Avoid stationary images as much as

possible. Stationary images are images

that remain on-screen for extended

periods of time. Stationary images

include on-screen menus, black bars,

time displays etc. If you must use

stationary images, reduce screen

contrast and brightness to avoid screen

damage.

End of use

NonPublish

Your product is designed and manufactured

with high quality materials and components,

which can be recycled and reused.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips Fernseher Handbücher

Philips

Philips 8506 Series Bedienungsanleitung

Philips

Philips 75PML9506 Bedienungsanleitung

Philips

Philips 20PS35S Bedienungsanleitung

Philips

Philips 32PFL5008T/12 Bedienungsanleitung

Philips

Philips 32PF9967D Bedienungsanleitung

Philips

Philips A02U AA Bedienungsanleitung

Philips

Philips HTL1190B Bedienungsanleitung

Philips

Philips 32PW6408 Bedienungsanleitung

Philips

Philips 15AA3330 Bedienungsanleitung

Philips

Philips LC4.1U AA Bedienungsanleitung

Philips

Philips 21PT4628/V7 Bedienungsanleitung

Philips

Philips 26PF3302/10 Bedienungsanleitung

Philips

Philips 50PFL5602/F8 Bedienungsanleitung

Philips

Philips COLOR TV 32 INCH TABLE TP3267C Bedienungsanleitung

Philips

Philips 43PUS7406 Bedienungsanleitung

Philips

Philips LC4.3E Bedienungsanleitung

Philips

Philips 32MF231D - Hook Up Guide Bedienungsanleitung

Philips

Philips 4101 series Bedienungsanleitung

Philips

Philips 32PFL6636T Bedienungsanleitung

Philips

Philips TC5.1U CA Bedienungsanleitung

Philips

Philips MAGNAVOX TP3675C99 Bedienungsanleitung

Philips

Philips OLED907 Series Bedienungsanleitung

Philips

Philips TS2744C Bedienungsanleitung

Philips

Philips 25PT827A/12 Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Toshiba

Toshiba 27A10 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Sylvania

Sylvania 6427FB Bedienungsanleitung

Sanyo

Sanyo CE19LD90N-B Bedienungsanleitung

North State

North State TV2GO Bedienungsanleitung

RCA

RCA RTU7877 Bedienungsanleitung

Sharp

Sharp 21K-FG1RU Bedienungsanleitung

Sony

Sony Esprit TAV-L1 Bedienungsanleitung

Grundig

Grundig 43 VLE 4820 Bedienungsanleitung

Samsung

Samsung LN26C350D1D Bedienungsanleitung
