Quick start guide

Depending on your TV, please see below to determine which QSG you will need to see.

There are two Android OS versions for this model. Please follow below to get started with QSG.

1. On the home menu of your Android TV, select Settings in the upper right corner of the screen,

or press

y(OPTIONS) on the remote.

2. Select About or Device Preferences >About

3. Under Version:

If version is Android O (8.x), please start from next page

If version is Android P (9.x), please start from p.14

Televisions

5704 series

5604 series

5504 series

Televisions

Android O (8.x)

If you can see below setting menu, please start to read from next page.

If not, please go to P.1 4

Quick start guide

Televisions

5704 series

5604 series

5504 series

1-866-309-5962

http://tinyurl.com/y2e29xsq

9 AM to 9 PM EST Monday – Saturday,

9 AM to 6 PM EST Sunday.

Call us:

Chat with us:

Hours of operation:

Scan to call us:

Scan to chat with us:

Product design and user interface are for illustrative purposes only.

Actual product and user interface may vary.

Quick start guide

1-866-309-5962

9 AM to 9 PM EST Monday – Saturday, 9 AM to 6 PM EST Sunday.

Hours of operation:

Call us: Scan to call us:

http://tinyurl.com/y2e29xsq

Chat with us: Scan to chat with us:

Using the remote control

How to install the batteries in the remote control

Open the battery cover by firmly sliding down. Insert 2

AAA(1.5V) batteries matching the polarity indicated inside

battery compartment of the remote control.

16 feet (5 m)

30° 30°

23 feet (7 m) 16 feet (5 m)

B(POWER)

Turns the TV on and off of standby.

z(TV GUIDE)

Access to the Electronic Program Guide (EPG).

x(HOME)

Access to your apps, Live TV, input devices, settings, and the Google Play Store.

1(INFO)

Displays input, resolution, and HDR information.

0(Google Assistant)

Activates your personal Google Assistant.

y(OPTIONS)

Displays a list of menu options applicable to the active screen.

Direct access to your installed TV channels.

(This feature is only available for OTA and select cable channels.)

w(INPUTS)

Change input source.

Select and change access to the attached devices such as Blu-ray player, gaming consoles, or cable box.

3(BACK)

Returns to the previous menu screen.

2 Best Experience

Google account

Unleash your television's true potential. With a Google® account you can effortlessly expand your

entertainment library via the Google Play Store and Google Play app and also keep apps up-to-date.

You can enjoy this Philips Android TV even without a Google account. For example, you can watch

Live TV programming, streaming applications such as Netflix, VUDU, YouTube and more.

C Note:

Simply login with your Google account.

E Tip:

It is recommended to create a new Google account specifically for your Android TV. A new

account will prevent interference and syncing of your personal account. To create a new Google

account, visit http://accounts.google.com/signup on your smartphone, tablet, or computer.

Network router

Wired Connection:

For the best experience, a wired connection is preferred. Connect an ethernet cable from your

router or modem to the LAN port located on the back of your Philips Android TV.

Wireless Connection:

The Philips 5000 Series Android TV is equipped with Wireless LAN 802.11ac MIMO for wireless

streaming of up-to 4K content.

C Note:

Wireless performance may be affected by various factors, including the distance between the

TV and your Wi-Fi router. To improve wireless performance, we recommend placing your Wi-Fi

router within 15 feet of your TV.

C Note:

The use of open or unencrypted Wi-Fi networks is not recommended, as these networks are

not secured, and your data could be at risk.

E Tip:

If your Wi-Fi Router was set up by your internet service provider (ISP), you may find a sticker on

the bottom of your router indicating your Wi-Fi SSID and password.

Set up Android TV with your Android smartphone or tablet

If you have an Android phone or tablet, you can quickly and easily set up your Android TV from your

Android device. Pairing your Android device will allow you to wirelessly sync your Wi-Fi credentials,

Google account, and Android TV compatible apps. During the initial setup, you will be prompted to

set up your TV with your Android device, select Yes, and follow the on-screen instructions.

C Note:

Be sure to enable pairing mode on your Android device in the beginning.

3 Explore your television

From the Android TV home screen, you can easily access movies, TV shows, music, apps, input

devices, settings, and more.

To go back to the home screen at any time, press x(HOME) on your remote control.

3 4

1Google Assistant

Activates your personal Google Assistant. Type or speak to search for content, control your TV,

manage your smart home devices, and more.

2 Inputs

Toggle inputs between your favorite source devices.

3 e-Help

Online help videos and tutorials

4 Settings

Configure your television settings and connect to wireless devices.

5 Apps

Apps gallery

You must sign in with a Google account to visit and download apps from the Google Play store.

6 How to rearrange channels

Within the row, you want to rearrange, press Jon your remote control.

To rearrange channels, Select arrow (H/I) icon, and press OK. Use HIto move up or down.

Press OK.

To delete channels, Select minus (-) icon, and press OK.

7Install Additional Apps

Select the “+” and click on the Google Play Store to expand your entertainment library.

8 How to move or delete applications

Select the application and long press OK on your remote control.

To move, Select Move in the list, and press OK. Use JKto move left or right. Press OK.

To delete, Select Remove from favorites in the list, and press OK.

4 Live TV

The Live TV channels feature on Android TV loads television shows, sports, news, and more from

your participating TV apps or OTA TV tuner so you can watch them all in one place.

To select channels by using HIon your remote control.

Options

Press OK while viewing Live TV to switch between Channels and TV options.

Channels: switches between program guide and channel.

TV options: configure picture and audio preferences.

Program guide

The built-in electronic program guide (EPG) allows you to find channels and content easily.

Pause Live TV

You can pause OTA Live TV programming when a 16GB or larger USB Flash Drive is connected to

your Android TV.

Press oon your remote control to either pause or resume playback of Live TV programming.

E Tip:

Live TV feature is only compatible with antenna and select cable broadcasting. To access

your cable box or other source inputs, you must select w(INPUTS) on your remote control.

5 Google Assistant

Activate Google Assistant

E Tip:

To enjoy all of the benefits Google Assistant can provide, an internet connection and a Google

account are required.

How to use the remote control

1. • Activating the Google Assistant on the home screen will launch a Google Query.

• Activating the Google Assistant within an app will allow you to search and find information only

related to a specific app.

2. Speak into the microphone located on the top of your remote control.

Speech examples may be displayed depending on your model.

To learn more about the Google Assistant visit https://assistant.google.com

SafeSearch filter for Google Search

SafeSearch can help you block inappropriate or explicit images from your Google search results.

The SafeSearch filter helps block most adult content from your television. Parental supervision is

strongly recommended.

1. On the Android TV home screen, select Settings in the upper right corner of the screen, and press

OK.

2. Scroll down to Preferences and select Google.

3. Select SafeSearch filter and press OK.

Connecting your devices

How to use external devices

Connecting antenna or cable / satellite / IPTV set-top box

E Tip:

Connect your external devices to your Android TV before powering on.

If connecting to an antenna via an RF cable If connecting a set-top box via an HDMI cable

DTV programs that are broadcasted in your

area can be received for free through a digital

antenna.

If the TV is connected to a cable or satellite set-

top-box via an HDMI cable, you must select the

correct source by using w(INPUTS) on your

remote control.

ININ

OUTOUT

RF cableRF cableRF cable

AntennaAntenna

CableCable

Set-top boxSet-top box

RF cableRF cable

HDMI cable

OUTOUT

Changing input to devices that are connected to the TV.

Press w(INPUTS) to switch input device list.

E Tip:

To get the best picture quality for your source device, you may have to adjust the EDID version.

EDID 1.4 is used for legacy devices that can output in 2K or 4K @30Hz.

EDID 2.0 is used for modern devices that can output 4K @ 60Hz and 4K with HDR 10.

1. Press x(HOME) on your remote control and navigate to Settings and select Inputs.

2. Scroll down until you reach HDMI EDID Version.

3. Select the input you want to modify and adjust the EDID.

How to use Chromecast

Casting allows you to mirror your favorite apps on the big screen.

E Tip:

The device you are using to cast to your television must be on the same Wi-Fi network.

1. Open a Chromecast-enabled app.

2. Tap u.

3. Tap the device you would like to cast to.

How to connect to your Bluetooth® devices

To pair your pair Bluetooth® devices, such as a wireless headset, keyboard, game controller,

with your Android TV.

1. On the Android TV home screen, select Settings in the upper right corner of the screen, and press OK.

2. Scroll down to Remote & accessories and select Add accessory.

3. Enable pairing mode on your device.

4. Using your TV remote control, select your device from the list shown on your TV.

5. Your Android TV will pair with your device.

E Tip:

Some devices may require additional steps. Please consult your Bluetooth device manual for

more information.

Troubleshooting

Category Problem Tip

Performance Remote response is

delayed or sluggish during

initial use.

• Your television is automatically,

downloading and installing the latest

applications, for the best user experience.

• During this time, you may experience

a delayed response from your remote

control. Upon successful installation, your

remote control will operate normally.

Accessibility Television is speaking

prompts out-loud.

• To disable the talkback (text to speech) on

your television, press x(HOME) on your

remote control, navigate to settings icon in

the upper right corner of the home screen

and select accessibility, select talkback,

press OK to toggle between on or off.

Network Slow Data Connection or

buffering.

• Check the settings between your router

and ISP modem or gateway (if applicable).

• Connect to a stable wireless connection

from home wireless or wired network.

• The use of mobile hot spots or public

wireless connections is not recommended.

Sound on

HDMI with

external devices

Television has no sound. • Please check to be sure the device is

connected to the HDMI 2 (ARC) input on

the TV.

Power No power • Ensure that the AC outlet supplies the

proper voltage.Plug another electrical

appliance into the AC outlet to ensure that

the AC outlet operates normally.

• If a power failure occurs, unplug the AC

power cord for 1 minute to allow the unit

to reset itself.

Remote control Remote control buttons

are not functional.

• Re-insert or replace the AAA batteries with

their polarities (+/–) as indicated on the

remote control battery area.

(Google Assistant)

microphone on the remote

control does not work.

• To pair the remote control, refer to the

step “6 Connecting your devices ” in the

previous page and see “How to connect to

your Bluetooth® devices”.

To enable pairing mode, press (Google

Assistant) and vol down (–) button on

your remote control simultaneously for 5

seconds.

Troubleshooting

For further assistance, call the customer support service in your country.

- To obtain assistance, contact Philips customer care center;

In the U.S.A., Canada, Puerto Rico, or the U.S. Virgin Islands 1 866 309 5962

Enter below the model and serial numbers located on the left side and the rear of the TV cabinet.

Model :

Serial :

Category Problem Tip

Network Cannot connect the

network.

• Check if your router and/or modem is

properly connected.

• Check if the Ethernet cable connection

between the TV and your router or modem

is properly secured.

• Power cycle the router and/or modem.

• Check your network settings.

Picture Power is on but screen

image is off.

• Check if the connection for your source

device is properly secured.

• Check if the correct input is selected by

pressing w(INPUTS).

• Verify that your HDMI mode, for the input

selected matches the resolution output of

your source device.

Change source input until you have

picture and sound.

Performance Remote response is

delayed or sluggish during

initial use.

• Your television is automatically,

downloading and installing the latest

applications, for the best user experience.

• During this time, you may experience

a delayed response from your remote.

Upon successful installation, your remote

will operate normally.

Troubleshooting

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips Fernseher Handbücher

Philips

Philips 32TA1600/93 Bedienungsanleitung

Philips

Philips EM5A P/M Bedienungsanleitung

Philips

Philips 8217 Series Bedienungsanleitung

Philips

Philips 19-CTV W-DBX STEREO-REM... Bedienungsanleitung

Philips

Philips 32PFL4765/F8 Bedienungsanleitung

Philips

Philips 32 IN HDTV MONITOR WITH ACTIVE CONTROL 32PT830H... Handbuch

Philips

Philips 32PT8419 Bedienungsanleitung

Philips

Philips 29PT6446 Bedienungsanleitung

Philips

Philips 19PR16C Handbuch

Philips

Philips 20HF5335D Bedienungsanleitung

Philips

Philips Matchline 28PW9617 Bedienungsanleitung

Philips

Philips MAGNAVOX TP2785C199 Bedienungsanleitung

Philips

Philips 32PF7321 - 2 Bedienungsanleitung

Philips

Philips The Xtra 9308 Series Bedienungsanleitung

Philips

Philips 28PW6341/85 Bedienungsanleitung

Philips

Philips 20HF5335D Handbuch

Philips

Philips 21PT5432/78R Bedienungsanleitung

Philips

Philips 7906 Series Bedienungsanleitung

Philips

Philips 20PT155A/07 Betriebsanleitung

Philips

Philips 42FD9944-69S Bedienungsanleitung

Philips

Philips OLED754 Series Bedienungsanleitung

Philips

Philips 5242 Series Bedienungsanleitung

Philips

Philips AZ 1565 Bedienungsanleitung

Philips

Philips 21PT2217B Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Toshiba

Toshiba 27A10 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Sylvania

Sylvania 6427FB Bedienungsanleitung

Sanyo

Sanyo CE19LD90N-B Bedienungsanleitung

North State

North State TV2GO Bedienungsanleitung

RCA

RCA RTU7877 Bedienungsanleitung

Sharp

Sharp 21K-FG1RU Bedienungsanleitung

Sony

Sony Esprit TAV-L1 Bedienungsanleitung

Grundig

Grundig 43 VLE 4820 Bedienungsanleitung

Samsung

Samsung LN26C350D1D Bedienungsanleitung
