Philips 65PUS7805 Bedienungsanleitung

www.philips.com/TVsupport

Manual do usuário

43PUS7805

50PUS7805

55PUS7805

65PUS7805

Sumário

1 Get Support 3

1.1 Identify and Register your TV 3

1.2 TV Help and User Manual 3

1.3 Consumer Care / Repair 3

2 Software 4

2.1 Update Software 4

2.2 Software Version 4

3 Quick Guide 5

3.1 Remote Control 5

3.2 Pair Your Remote Control to TV 5

3.3 IR sensor 6

3.4 Joystick - Local Control 6

4 Setting Up 7

4.1 Read Safety 7

4.2 TV Placement 7

4.3 Turn on TV 7

5 Connections 9

5.1 Connectivity guide 9

5.2 Antenna 9

5.3 Satellite 9

5.4 Video Device 9

5.5 Audio Device 9

5.6 Mobile Device 10

5.7 Other Device 11

6 Switch Source 13

6.1 Source List 13

6.2 Rename Device 13

7 Channels 14

7.1 About Channels and Switch Channels 14

7.2 Install Channel 14

7.3 Channel List 19

7.4 Favourite Channels 20

7.5 Text / Teletext 21

8 TV Guide 23

8.1 What You Need 23

8.2 Using the TV Guide 23

9 Videos, Photos and Music 24

9.1 Photos 24

9.2 360 Photo 24

9.3 Videos 24

9.4 Music 25

10 Open TV Setting Menus 26

10.1 Home Menu Overview 26

10.2 Frequent settings and All settings 26

10.3 All Settings 26

11 Wireless and Networks 36

11.1 Home Network 36

11.2 Connect to Network 36

11.3 Wireless and Network Settings 36

12 Smart TV 38

12.1 Setup Smart TV 38

12.2 Smart TV Start Page 38

12.3 App Gallery 38

12.4 Video on Demand 38

13 Ambilight 39

13.1 Ambilight Style 39

13.2 Ambilight+hue 39

13.3 Advanced Ambilight Settings 40

13.4 Lounge Light Mode 41

14 Netflix 42

15 Rakuten TV 43

16 Amazon Prime Video 44

17 YouTube 45

18 Alexa 46

18.1 About Alexa 46

18.2 Using Alexa 46

19 Environmental 47

19.1 European Energy Label 47

19.2 Product Fiche 47

19.3 End of Use 47

20 Specifications 49

20.1 Power 49

20.2 Reception 49

20.3 Display Resolution 49

20.4 Supported Input Resolution - Video 49

20.5 Supported Input Resolution - Computer 49

20.6 Sound 50

20.7 Multimedia 50

20.8 Connectivity 50

21 Troubleshooting 51

21.1 Tips 51

21.2 Switch On 51

21.3 Remote Control 51

21.4 Channels 51

21.5 Satellite 52

21.6 Picture 52

21.7 Sound 53

21.8 HDMI - UHD 53

21.9 USB 54

21.10 Wi-Fi and Internet 54

21.11 Wrong Menu Language 54

22 Safety and Care 55

22.1 Safety 55

22.2 Screen Care 55

23 Terms of Use 57

24 Copyrights 58

24.1 HDMI 58

24.2 Dolby Audio 58

24.3 DTS-HD (italics) 58

24.4 Other Trademarks 58

25 Open Source 59

25.1 Open Source Software 59

25.2 Open Source License 59

26 Disclaimer regarding services and/or

software offered by third parties 60

Índice 61

Get Support

1.1

Identify and Register your TV

Identify your TV - TV model number and serial

number

You might be asked to provide the TV product model

number and serial number. Find these numbers on

the packaging label or on the type label on the back

or bottom of the TV.

including full support (including downloads),

privileged access to information about new products,

exclusive offers and discounts, the chance to win

prizes and even participate in special surveys about

new releases.

Go to www.philips.com/TVsupport

1.2

TV Help and User Manual

 (Home) > Settings > Help

You can use Help function to diagnose and get more

information about your TV.

• TV information - View the Model name, Serial

number and Software version of your TV.

• How to - You can see instructions on how to

install channels, sort channels, update TV software,

connect external devices and use Smart functions on

your TV.

• Check the TV - You can check if the picture, sound,

Ambilight* are working fine during playing a short

video clip.

• Check the network - Check the network

connection.

• Check the remote control - Perform the test to

verify the TV bundled remote control functionality.

• View weak signal history - Display the list of

channel numbers that were automatically saved

when signal strength was weak.

• Update software - Check available software

updates.

• User manual - Read the user manual for TV

information.

• Troubleshooting - Find a solution for frequent ask

questions.

• Factory settings - Reset all settings to factory

settings.

• Reinstall TV - Reinstall and redo the complete TV

installation.

• Contact info - Show the telephone number or web

address for your country or region.

* Ambilight setting is only for models which support

Ambilight function.

1.3

Consumer Care / Repair

For support and repair, call the Consumer Care

hotline in your country. Our service engineers will take

care of a repair, if necessary.

Find the telephone number in the printed

documentation that came with the TV.

Or consult our

website www.philips.com/TVsupport and select

your country if needed.

TV model number and serial number

You might be asked to provide the TV product model

number and serial number. Find these numbers on

the packaging label or on the type label on the back

or bottom of the TV.

 Warning

Do not attemp to repair the TV yourself. This may

cause severe injury, irrepairable damage to your TV or

void your warranty.

Software

2.1

Update Software

Search for Updates

Update from Internet

 (Home) > Settings > Update software > Search

for updates > Internet (Recommended)

Look for a software update yourself.

• If the TV is connected to the Internet, you may

receive a message to update the TV software. You

need a high-speed (broadband) Internet

connection. If you receive this message, we

recommend you to carry out the update.

• During the software update, there is no picture and

the TV will switch off and on again. This might happen

several times. The update can take a few minutes.

• Wait until the TV picture comes back up. Do not

press the power switch  on the TV or on the

remote control during the software update.

Update from USB

 (Home) > Settings > Update

software > Search for updates > USB

• You need a computer with an high-speed Internet

connection and a USB memory device to upload the

software on the TV.

• Use a USB memory device with 512MB free space.

Make sure that write protection is switched off.

1 - Start the update on TV

Select Update software > Search for updates >

USB, then press OK.

2 - Identify the TV

Insert the USB memory into one of the USB

connections of the TV.

Select Start and press OK. An identification file is

written on the USB memory device.

3 - Download the TV software

- Insert the USB memory into your computer.

- On the USB memory device, locate the

file update.html and double click it.

- Click on Send ID.

- If new software is available, download the .zip file.

- After the download, unzip the file and copy the

file autorun.upg onto the USB memory device.

- Do not place this file in a folder.

4 - Update the TV software

Insert the USB memory into the TV again. The update

starts automatically.

The TV switches itself off for 10 seconds and then

back on again. Please wait.

Do not . . .

• use the remote control

• remove the USB memory device from the TV

• press  twice

• press the power switch on the TV

The TV switches itself off (for 10 seconds) and then

back on again. Please wait.

The TV software has been updated. You can use the

TV again.

To prevent an accidental update of the TV software,

delete the autorun.upg file from the USB memory

device.

Local Updates

 (Home) > Settings > Update

software > Search for updates > USB > Local

updates.

For dealers and expert users.

2.2

Software Version

 (Home) > Settings > Update

software > Current software info

To view the current TV software version.

Quick Guide

3.1

Remote Control

Batteries and Cleaning

Replace batteries

If the TV does not react on a key press on the remote

control, the batteries might be empty.

To replace the batteries, open the battery

compartment on the back of the remote control.

1 - Slide the battery door in the direction shown by

the arrow.

2 - Replace the old batteries with 2 Alkaline

type AAA-LR03-1.5V batteries. Make sure the + and

the - ends of the batteries line up correctly.

3 - Reposition the battery door and slide it back until

it clicks.

• Remove the batteries if you are not using the remote

control for a long time.

• Safely dispose of your old batteries according to the

end of use directions.

Cleaning

Your remote control is treated with a scratch-resistant

coating.

To clean the remote control, use a soft damp cloth.

Never use substances such as alcohol, chemicals or

household cleaners on the remote control.

Key Overview

Top

1 -  Standby / On

To switch the TV on or back to Standby.

2 - VOICE microphone

Speak near this hole during voice search.

3 - 

To select one of the Ambilight style or switch off

Ambilight.

4 -  INFO

To open or close programme info.

5 -  SOURCES / PAIR

• To open or close the Sources menu.

• Mantenha pressionado para emparelhar o controle

remoto à TV.

6 -  Alexa

To start Alexa voice control operations.

3.2

Pair Your Remote Control to

This remote control uses both Bluetooth and IR

(infrared) to send its commands to the TV.

• You can use this remote control via IR (infrared) for

most operations.

• To use Alexa voice control operations, you need to

pair (link) the TV with the remote control.

When you started the initial TV installation, the TV

invited you to long press the PAIR key, and by

doing so, the pairing was done.

Note:

1 - Once the remote control has entered pairing

mode successfully, the blue LED indicator ring around

the microphone on the front side of the remote

control starts blinking.

2 - The remote control must be kept close to the TV

(within 1m distance) during pairing in order to ensure

success.

3 - If the TV does not launch the Alexa voice

control operations when press  Alexa, pairing was

unsuccessful.

4 - It is advisable to wait until the set has fully started

up and launched all background processes before

pairing mode is entered as the toast message

containing further instructions may appear too late,

thereby negatively impacting the pairing procedure.

Pairing or pairing again

If the pairing with the remote control was lost, you

can pair the TV with the remote control again.

You can simply long press

the PAIR key (approximate for 3 seconds) for

pairing.

Alternatively, go  (Home) > Settings > All settings

> Wireless and network > Remote control > Pair

remote control, then follow the on-screen

instructions.

A message appears when the pairing is successful.

Remote Control Software

 (Home) > Settings > All settings > Wireless and

network > Remote control > Current software info

Once the remote control is paired, you can check the

current remote control software version.

 (Home) > Settings > All settings > Wireless and

network > Remote control > Update remote

control software

Check available remote control software for updates.

3.3

IR sensor

The TV can receive commands from a remote control

that uses IR (infrared) to send commands. If you use

such a remote control, always make sure you point

the remote control at the infrared sensor on the front

of the TV.

 Warning

Do not put any objects in front of IR sensor of the TV,

it may block the IR signal.

3.4

Joystick - Local Control

Keys on TV

If you lost the remote control or its batteries are

empty, you can still do some basic TV operations.

To open the basic menu…

1 - With the TV switched on, press the joystick key on

the back of the TV to bring up the basic menu.

2 - Press left or right to

select  Volume,  Channel or  Sources.

Select  Demo, to start a demo movie.

3 - Press up or down to adjust the volume or tune to

the next or previous channel. Press up or down to go

through the list of sources, including the tuner

selection.

The menu will disappear automatically.

Setting Up

4.1

Read Safety

Read the safety instructions first before you use the

TV.

To read the instructions, in Help > User manual,

press the colour key  Keywords and look

up Safety and Care.

4.2

TV Placement

Tips on Placement

• Position the TV where light does not shine directly

on the screen.

• Position the TV up to 15 cm away from the wall.

• The ideal distance to watch Ultra HD TV is 2 to 5

times of its screen height. When seated, your eyes

should be level with the centre of the screen.

Note:

Please keep the TV away from dust-producing

sources such as stoves. It is suggested to clean the

dust regularly to avoid getting dust into the TV.

TV Stand

You can find the instructions for mounting the TV

stand in the Quick Start Guide that came with the TV.

In case you lost this guide, you can download it

from www.philips.com/TVsupport.

Use the model number of the TV to look for

the Quick Start Guide to download.

Wall Mounting

Your TV is also prepared for a VESA-compliant wall

mount bracket (sold separately).

Use the following VESA code when purchasing the

wall mount . . .

• 43PUS6504

VESA MIS-F 200x200, M6 (Minimum 12 mm,

Maximum 18 mm)

• 50PUS6504

VESA MIS-F 200x200, M6 (Minimum 12 mm,

Maximum 18 mm)

• 58PUS6504

VESA MIS-F 300x200, M6 (Minimum 16 mm,

Maximum 20 mm)

• 65PUS6504

VESA MIS-F 400x300, M6 (Minimum 12 mm,

Maximum 18 mm)

• 70PUS6504

VESA MIS-F 400x200, M8 (Minimum 18 mm,

Maximum 23 mm)

Preparation

Make sure that the metal screws, to mount the TV to

the VESA-compliant bracket, go about 10mm deep

inside the threaded bushes of the TV.

Caution

Wall mounting the TV requires special skills and

should only be performed by qualified personnel. The

TV wall mounting should meet safety standards

according to the TVs weight. Also read the safety

precautions before positioning the TV.

TP Vision Europe B.V. bears no responsibility for

improper mounting or any mounting that results in

accident or injury.

4.3

Turn on TV

Connect Power Cable

• Insert the power cable into the POWER connector

on the back of the TV.

• Make sure the power cable is securely inserted in

the connector.

• Make sure that the power plug, in the wall socket, is

accessible at all times.

• When you unplug the power cable, always pull the

plug, never pull the cable.

Although this TV has a very low standby power

consumption, unplug the power cable to save energy

if you do not use the TV for a long period of time.

On or Standby

Before you switch on the TV, make sure you plugged

in the mains power in the POWER connector on the

back of the TV.

Switch On

• Press the small joystick key on the bottom of the TV.

Switch to standby

To switch the TV to standby, press  on the remote

control. You can also press the small joystick key on

the bottom of the TV.

In standby mode, the TV is still connected to the

mains power but consumes very little energy.

To switch off the TV completely, disconnect the

power plug.

When disconnecting the power plug, always pull the

power plug, never the cord. Ensure that you have full

access to the power plug, power cord and outlet

socket at all times.

Connections

5.1

Connectivity guide

Always connect a device to the TV with the highest

quality connection available. Also, use good quality

cables to ensure a good transfer of picture and

sound.

When you connect a device, the TV recognizes its

type and gives each device a correct type name. You

can change the type name if you wish. If a correct

type name for a device is set, the TV automatically

switches to the ideal TV settings when you switch to

this device in the Sources menu.

5.2

Antenna

Insert the antenna plug firmly into

the Antenna socket at the back of the TV.

You can connect your own antenna or an antenna

signal from an antenna distribution system. Use an

IEC Coax 75 Ohm RF antenna connector.

Use this antenna connection for DVB-T and DVB-C

input signals.

5.3

Satellite

Attach the satellite F-type connector to the satellite

connection SAT at the back of the TV.

5.4

Video Device

HDMI

An HDMI connection has the best picture and sound

quality.

For best signal quality transfer, use a High speed

HDMI cable and do not use an HDMI cable longer

than 5 m, and also connect devices supporting HDR

on any one of HDMI connections.

Copy protection

HDMI ports support HDCP (High-bandwidth Digital

Content Protection). HDCP is a copy protection signal

that prevents copying content from a DVD disc or Blu-

ray Disc. Also referred to as DRM (Digital Rights

Management).

5.5

Audio Device

HDMI ARC

All HDMI on the TV have HDMI ARC (Audio Return

Channel).

If the device, typically a Home Theatre System (HTS),

also has the HDMI ARC connection, connect it

to HDMI connection on this TV. With the HDMI ARC

connection, you do not need to connect the extra

audio cable that sends the sound of the TV picture to

the HTS. The HDMI ARC connection combines both

signals.

Digital Audio Out - Optical

Audio Out - Optical is a high quality sound

connection.

This optical connection can carry 5.1 audio channels.

If your device, typically a Home Theatre System

(HTS), has no HDMI ARC connection, you can use this

connection with the Audio In - Optical connection on

the HTS. The Audio Out - Optical connection sends

the sound from the TV to the HTS.

Headphones

You can connect a set of headphones to

the  connection on the side of the TV. The

connection is a mini-jack 3.5mm. You can adjust the

volume of the headphones separately.

5.6

Mobile Device

Wi-Fi Direct / Miracast

About Wi-Fi Miracast

You can view your photos or play your music and

videos from a mobile device on your TV with Wi-Fi

Miracast™. The mobile device and the TV should be

within range, which usually means being in the same

room.

Check if your mobile device is ready for Miracast.

Your TV is a Wi-Fi CERTIFIED Miracast™ device.

With Miracast™, you can watch and share the screen

of your smartphone, tablet or computer on your TV

screen wirelessly. You can stream videos (audio and

video), share photos or anything else that's on screen

of the device. No need to connect the device to your

home network. Both the TV and the device must be

Wi-Fi CERTIFIED Miracast™ devices and have

Miracast switched on.

Miracast on this TV is subject to the HDCP protocol

and cannot display copy-protected premium content

sent by a device. The maximum video resolution

supported is 720p for 2.4GHz Wi-Fi or 1080p for 5GHz

Wi-Fi.

For more information on Wi-Fi CERTIFIED Miracast™

go to www.wi-fi.org

Wi-Fi®, the Wi-Fi CERTIFIED logo, the Wi-Fi logo are

registered trademarks of the Wi-Fi Alliance. Wi-Fi

CERTIFIED Miracast™, Miracast™ are trademarks of

the Wi-Fi Alliance.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Philips Fernseher Handbücher

Philips

Philips 24PW6322/05 Bedienungsanleitung

Philips

Philips androidtv 5604 Series Bedienungsanleitung

Philips

Philips 29PT6456 Bedienungsanleitung

Philips

Philips Econova 46PFL6806T/12 Bedienungsanleitung

Philips

Philips 32PT563S Handbuch

Philips

Philips 42PFL5432D Bedienungsanleitung

Philips

Philips 43PUG7408/78 Bedienungsanleitung

Philips

Philips 50PF7320G/98 Bedienungsanleitung

Philips

Philips 34PT9421/69R Bedienungsanleitung

Philips

Philips 46HFL3683S/F7 Technisches Handbuch

Philips

Philips 20PT4331 Bedienungsanleitung

Philips

Philips 29PT5408/01 Bedienungsanleitung

Philips

Philips Momentum 329M1 Bedienungsanleitung

Philips

Philips 25ML8505 Bedienungsanleitung

Philips

Philips MLink 27PT41B199 Bedienungsanleitung

Philips

Philips 8107 Series Bedienungsanleitung

Philips

Philips 42PF9531 Bedienungsanleitung

Philips

Philips 19-MONO COLOR TV W-REM CONT-CHARCOAL-20LL200 Bedienungsanleitung

Philips

Philips 40PFL4706 Bedienungsanleitung

Philips

Philips 27PT8420 Bedienungsanleitung

Philips

Philips matchline 33CE7538 Bedienungsanleitung

Philips

Philips 49PUS6162 Bedienungsanleitung

Philips

Philips 7556 Series Bedienungsanleitung

Philips

Philips 43HFL5011T/12 Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Toshiba

Toshiba 27A10 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Sylvania

Sylvania 6427FB Bedienungsanleitung

Sanyo

Sanyo CE19LD90N-B Bedienungsanleitung

North State

North State TV2GO Bedienungsanleitung

RCA

RCA RTU7877 Bedienungsanleitung

Sharp

Sharp 21K-FG1RU Bedienungsanleitung

Sony

Sony Esprit TAV-L1 Bedienungsanleitung

Grundig

Grundig 43 VLE 4820 Bedienungsanleitung

Samsung

Samsung LN26C350D1D Bedienungsanleitung
