Contents

Preparation ...................................................................................... 2

Keys on top of the TV ................................................................... 2

Your remote control .................................................................. 3-4

To use the menus ........................................................................... 5

Select the menu language and country ..................................... 5

Store TV channels .......................................................................... 6

Automatic installation ............................................................6

Manual installation................................................................... 6

Give name ................................................................................. 6

Reshuffle the programme list................................................. 7

Select favourite TV channels ................................................. 7

Install TV setup ............................................................................... 7

Speakers .................................................................................... 7

General .................................................................................. 8-9

Source ........................................................................................ 9

Decoder .................................................................................... 9

Demo .............................................................................................. 10

Installation

TV menu

Picture menu .................................................................... 10-11

Sound menu ..................................................................... 11-12

Features menu ................................................................. 12-13

Dual screen / PIP / Multipip........................................................ 14

NEXTVIEW/Teletext guide ...................................................... 15-16

Teletext ..................................................................................... 17-18

Flex TV .......................................................................................19-22

Connect peripheral equipment

Connecting and selecting equipment .................................23-24

Audio and video equipment keys ............................................. 25

Tips ................................................................................................ 26

REnd of life directives

Philips is paying a lot of attention to

producing environmentally-friendly in

green focal areas.Your new TV contains

materials which can be recycled and

reused. At the end of its life specialised

companies can dismantle the

discarded TV to concentrate the

reusable materials and to minimise

the amount of materials to be

disposed of.

Please ensure you dispose of your old

TV according to local regulations.

Operation

EasyLink features are based on the “one touch operation” approach.

This means that a sequence of actions are executed at the same

time in both the television and the video cassette recorder, provided

both are fitted with the EasyLink function and connected with the

eurocable supplied with your video recorder.

Help?

If this instruction manual does

not give an answer or if ‘Tips’ do

not solve your TV problem, you

can call your Local Philips

Customer or Service Centre. See

the supplied World-wide

guarantee booklet.

Please, have the Model and

Product number which you can

find at the back of your

television set or on the

packaging, ready, before calling

the Philips helpline.

Model: 32PW9768

Product No: ............................................

English

DeutschFrançaisNederlandsItaliano

∂ÏÏËÓÈÎ¿

2200.2 en 04-09-2003 13:36 Pagina 1

&Place the TV on a solid surface.

! 32PW9768: 60 kg !

For ventilation, leave at least 5 cm free all

around the TV. Do not place the TV on a

carpet.To prevent any unsafe situations, do not

place any objects on top of the TV.Avoid heat,

direct sunlight and exposure to rain or water.

éInsert the aerial plug firmly into the aerial

socket xat the back of the TV. For best

picture quality use the suppressor-aerial cable

supplied.

“Insert the mains plug of the TV in the wall

socket having a mains voltage of 220V-240V.

Preparation

min.

‘Remote control: Insert the 2 batteries supplied

(Type R6-1,5V).

The batteries supplied do not contain the heavy

metals mercury and cadmium. Please check on

how to dispose of exhausted batteries according to

local regulations.

(Switch the TV on : Press the power switch A

on the front of your TV.

An indicator on the front of the TV lights up

and the screen comes on.

If the TV is in standby mode (red indicator),

press the -P+ keys on the remote control.

Keys on top of the TV

MENU/OK

Should your remote be lost or broken you can still

change some of the basic settings with the keys on

top of your TV.

Press:

•the V- or + key to adjust the volume;

•the -P+ keys to select the TV channels or

sources.

The Mkey can be used to summon the main menu

without the remote control.

Use:

•the V- and + keys and the P- and P+ keys to

select menu items in the directions as shown;

•the Mkey to confirm your selection.

Note:

When activated via the Mkey on top of the TV, only

Exit lets you dismiss the menu.

Navigate to Exit and press the Mkey.

Setup

Demo

Install

Exit

Picture Sound Features

2200.2 en 04-09-2003 13:36 Pagina 2

Select

VCR DVD SAT AMP CD

DVR

123

456

789

®‡π

†

Active Control

Ò†

Pause Live

REC

Use of the remote control RC4303

BStandby

Press to switch the TV on or off.

When switched off, a red

indicator on the TV lights up.

®Ò‡π†

Audio- and Video equipment keys

p. 25

REC / DVR / PAUSE / LIVE

Flex TV functions, see p. 19

UTime display

The time is displayed on the

screen.

QSurround mode

Press this key repeatedly to

select another available surround

mode.

ÌCinema Go

See separate Cinema Link

booklet supplied.

æNEXTVIEW on/off p. 15

Press the bkey to show

NEXTVIEW/ Teletext Guide on the

right half of the screen.

VCR DVD SAT AMP CD

Audio- and Video equipment keys

(p. 25)

vSelect peripherals

(p. 24)

xPixel Plus demo on/off

In the right part Pixel Plus and

Digital Natural Motion are

switched on.

bTeletext on/off p. 17

Press the bkey to show

teletext on the right half of the

screen.

OK Press this key

• to activate your choice, when in

the menus.

• to display the programme list.

ÏMain menu on/off see p. 5

VTo adjust the volume.

¬Interrupt the sound or restore it.

PProgramme selection

To browse through the TV

channels and sources stored in

the favourite list.

0/9 Digit keys

To select a TV channel.

For a two digit programme

number, enter the second digit

before the dash disappears.To

switch immediately to a selected

one digit TV channel, keep the

digit key pressed a bit longer.

Note: For most keys pressing a key once will activate the function. Pressing a second time will de-activate it.

When a key enables multiple options, a small list will be shown. Press repeatedly to select the next item in the list.

The list will be removed automatically after 4 seconds or press OK to remove immediately.

2200.2 en 04-09-2003 13:36 Pagina 3

Select

VCR DVD SAT AMP CD

DVR

123

456

789

®‡π

†

Active Control

Ò†

Pause Live

REC

iOn Screen information

Press to display information about the selected TV channel and

programme.

Menu/Remote control info

When a menu is on screen, press ito display info on the selected

menu item. For information on the remote control functions, while the

menu info is displayed, press any key on the remote control.

The normal function of the key is not executed.

0Smart surf / NEXTVIEW themes

With this key you can easily switch between 2 up to 9 different TV

channels or sources or quickly select TV programmes if NEXTVIEW with

defined themes is broadcast. See General, Smart surf, p. 8.

Press the OK key or wait for the time out to dismiss the Smart surf

display.

bDual screen / PIP / Multipip See p. 8 and p. 14

hActive control see p. 11

qPicture format

Press this key repeatedly or press the cursor up/down to select another

picture format:Auto format, Super zoom, 4:3, Movie Expand 14:9, Movie

Expand 16:9, Subtitle zoom or Wide screen.

Auto format makes the picture fill the screen as much as possible.

In case of subtitles in the bottom black bar,Auto format makes the

subtitles visible. If subtitles are only partly visible, press cursor up.

In case of a broadcaster logo in the corner of the top black bar, the logo

disappears from the screen.

Super zoom removes the black bars on the sides of 4:3 programs with

negligible distortion.

When in Movie Expand 14:9, 16:9, Super zoom or Subtitle zoom picture

format, you can make subtitles visible with the cursor up/down.

Auto format Super zoom 4:3 Movie Expand 14:9

Movie Expand 16:9 Subtitle zoom Wide screen

2200.2 en 04-09-2003 13:36 Pagina 4

vSelect

VCR DVD SAT AMP CD

DVR

®‡π

†

Ò†

REC

To use the menus

&Press the MENU Ïkey on the remote control to

summon the main menu.At any moment you can exit the

menu by pressing the MENU Ïkey again.

Note: If you have connected equipment with Cinema Link, more

menu items are present.

éUse the cursor in the up/down direction to select the TV,

Setup,Demo or Install menu.

Use the cursor left/right to select Picture,Sound or

Features.

Note: Sometimes not all the menu items are visible on the screen

(indicated by a cluster of blue balls). Use the cursor down or right

to reveal all items.

“Use the cursor in the left/right direction to select the menu

item.

‘Use the cursor up/down again to select the control you

want to select or to adjust.

Note: Items temporary not available or not relevant are displayed

in a light grey colour and cannot be selected.

cursor to select

adjustments

OK key to

activate

return or switch

main menu on/off

Setup

Demo

Install

Picture Sound Features

Installation

&Press the MENU Ïkey on the remote control.

éUse the cursor down to select Install.

“Use the cursor right to select Language.

Follow the instructions on screen.

‘Use the cursor up/down to select your preferred language

and press the OK key to confirm your selection.

(Use the cursor right to select Country.

§Select the country where you are now located and press

the OK key.

Select Other when none of the countries applies.

èProceed with the Install menu.

Install

Language Country Automatic Manual Give name Reshuffle Favourite

install install programmes

The installation menu contains the following items:

EasyLink

If your video recorder has an EasyLink function, during installation, the language, country and available channels are

automatically transmitted to the video recorder.

Language

English

Deutsch

Français

Install

Country

Austria

Belgium

Croatia

Install

Select the menu language and country

2200.2 en 04-09-2003 13:36 Pagina 5

It is possible to change the name stored in the

memory or to assign a name to a TV channel for

which a name has not yet been entered.A name

with up to 5 letters or numbers can be given to

the programme numbers 0 to 99.

&Select Give Name in the Install menu and

press the cursor down.

éSelect the programme number.

Note: keep the cursor up/down pressed to scroll

through the programme list quickly.

“Press the cursor right.

A keyboard appears on the screen.

Press the cursor right to enter the keyboard.

Press the cursor up/down, left/right to select

the first character and press OK.Repeat for

every character you want to enter.

Select Space to enter a space; Delete to erase

the highlighted character in the name entered;

Shift to display upper- or lowercase characters

on the keyboard; Special to display special

characters on the keyboard. Press OK to

confirm.

‘Press the cursor left repeatedly when you have

finished the name giving.

(Select another programme number and repeat

steps “to ‘.

&Select Automatic install in the Install menu.

Note: All channels must be unlocked in order to

autoprogram. If requested, enter your code to unlock

all channels.

(See TV, Features menu, Childlock, p. 13.)

éPress the cursor down.

The autoprogramming option label Start

appears.

“Press the cursor right.

‘The message Searching appears and the

progress of autoprogramming is displayed.

If a cable system or a TV channel which broadcasts

ACI (Automatic Channel Installation) is detected, a

programme list appears.Without ACI broadcast,

the channels are numbered according your

language and country selection.You can use

Reshuffle to renumber them. See p. 7.

It is possible that the cable company or the TV channel

displays a broadcast selection menu. Layout and items

are defined by the cable company or the TV channel.

Make your choice with the cursor and press the OK

key.

After language and country are set correctly, you can now search for and store the TV channels in two

different ways: using Automatic Installation or Manual Installation (tuning-in channel by channel).

Select your choice with the cursor right.

Automatic installation

Manual installation Searching for and storing TV channels is done channel by channel.

You must go through every step of the Manual Installation menu.

&Select Manual install in the Install menu.

éPress the cursor down.

Follow the instructions on screen.

Note: Search or direct selection of a TV channel.

If you know the frequency, the C- or S-channel number, enter the 3 or

2 digits of the frequency or the channel number directly with the digit

keys 0 to 9 (e.g. 048). Press the cursor down to proceed.

Repeat to search for another TV channel.

Manual install

Install

Selection mode

System

Programme

Fine tune

Store

Give name

pπ

® Space ® Delete

ABCDEFG 123

HIJKLMN 456

OPQRSTU 789

VWXYZ 0

® Shift ® Special

Give name

Install

VCR1

BBC1

BBC2

CNN

TVE

.....

Automatic install

Install Start

Install

Store TV channels

2200.2 en 04-09-2003 13:36 Pagina 6

Reshuffle the programme list

You can change the order of the stored TV

channels.

&Select Reshuffle in the Installation menu.

éFollow the instructions on screen.

Select Favourite TV channels

&Select Favourite programmes in the Install

menu.

éSelect your programme number with the

cursor up/down.

“Select Yes or No with the cursor right.

‘Repeat éand “for every TV channel or

external you want to make a favourite or a

non-favourite TV channel or external.

Your TV is equipped with integrated front left, right

and centre loudspeakers, capable of reproducing

Stereo, Dolby 3 stereo and 3D Surround modes.

For full Dolby Pro Logic and Hall you should use

two amplified rear surround speakers connected to

the back of the TV.

See Extra loudspeakers/Amplifier, p. 24.

Depending on the output and Surround mode (see

Main menu,TV, Sound, Surround mode, p. 12)

selected, some menu items may be greyed out and

are not selectable.

Test tone controls

The menu item Test tone enables you to

balance the volume levels of the speakers.

&Select Test tone and press the cursor right.

éOnce turned on, the Test Tone will circulate

through the left, centre, right speakers and

both rear surround speakers (if present).

“Press the cursor up/down to select the desired

speaker for individual volume level adjustment.

‘Press the cursor left/right to adjust the volume

level.

Speakers

Surround Speakers

See Connect Peripheral Equipment, Extra

loudspeakers/amplifier, p. 24.

If no Surround Speakers are connected do

not change the predefined factory settings

which is Off.If Surround Speakers are

connected select On.

(Dolby Pro Logic and Hall are not available

if Off is selected.)

Auto Surround

Sometimes the broadcaster transmits

special signals for Surround Sound

encoded programmes.

The TV automatically switches to the best

surround sound mode when Auto

Surround is switched On.

However it is possible to overwrite this

setting.

TV Setup

The Setup menu contains items that control the

settings of the TV’s functions, features, services and

peripherals you may have connected.

The Speakers menu reflects the speaker-related

controls.

The General menu allows you to change settings

that will typically be accessed only occasionally.

The Source menu allows you to select a source.

The Decoder menu allows you to define one or

more programme numbers as decoder programme

numbers.

Speakers General Source Decoder

Test tone

Balance

Centre volume

(Surround volume)

Surround speakers

Auto surround

Setup

2200.2 en 04-09-2003 13:36 Pagina 7

General General

Menu background

Smart surf

Dual screen format

Factory settings

NEXTVIEW provider

Tilt adjust

OSD

Programme title

Teletext level 2.5

Record quality

Set/Change code

Setup

Smart surf

&Select Smart surf.

éWith the cursor left/right, select

• 2 programmes if you want the 0key to

toggle between the current and the previously

selected channel,

•9 programmes if you want the 0key to

summon a list of up to 9 channels which can

be selected,

•Theme if you want the 0key to quickly

select TV programmes if NEXTVIEW with

defined themes is broadcast.

To add/remove a channel or source:

Tune to the channel or source you wish to add

or remove. Press the 0key and press the

cursor right to add or remove.

Note: If there are already 9 channels/sources in the

list, the one at the bottom of the list will be

removed.

Dual screen format

This menu allows you to select the preferred

format which can then be displayed toggling the

bkey on and off.

See Dual screen/PIP/ Multipip, p. 14.

Select Dual screen,PIP,PIP 3 or PIP 12 with

the cursor down.

When Dual screen mode is activated with the

remote control bkey, and when:

•Dual screen is selected, the TV splits the

screen into two equally sized screens.

•PIP is selected, the TV shows a full screen of

video with a pip window of video on top if it;

• PIP3 or PIP12 is selected, the TV will display 3

or 12 pip screens.

Factory settings

This resets the picture and sound settings to

their predefined factory values, but maintains

the channel installation settings.

NEXTVIEW provider

Select a TV broadcaster that provides

NEXTVIEW data. How to make use of NEXTVIEW,

see p. 15.

OSD (On Screen Display)

See Use of the remote control, p. 4, iOn

screen information.

&Select OSD.

éSelect Normal to activate the continuous

display of the programme number.Also TV

channel and programme information are

extended. Minimum will display reduced

channel information.

Note:When subtitles is switched on, see Features,

p.12, continuous display of the programme number

is not possible.

Teletext level 2.5

Some broadcasters offer the opportunity to

see more colours, other background colours

and nicer pictures in the teletext pages.

&Select Teletext level 2.5.

éPress the cursor right to select Teletext level

2.5 On to take advantage of this feature.

“Press the cursor right again to select Teletext

level 2.5 Off if you like the more neutral

teletext layout.

The selection made is valid for all channels

which broadcast teletext level 2.5.

Note: It may take a few seconds before teletext

broadcast switches over to Teletext level 2.5.

Record quality

See Flex TV, Modifying the record quality of

Instant recording, p. 22.

This menu allows you to change various settings

that are presumably adjusted less frequently than

most other settings.

Press the ikey on the remote control to get

information about the selected menu item.

2200.2 en 04-09-2003 13:36 Pagina 8

Andere Handbücher für Breedbeeld 32PW9768/12

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Philips Fernseher Handbücher

Philips

Philips 65PUT8609 Bedienungsanleitung

Philips

Philips TV Bedienungsanleitung

Philips

Philips 5505 Series Bedienungsanleitung

Philips

Philips Signage Solutions BDL9870EU Bedienungsanleitung

Philips

Philips PDP42V7 series Bedienungsanleitung

Philips

Philips 29PT9413 - annexe 1 Bedienungsanleitung

Philips

Philips Matchline 33PT702C Bedienungsanleitung

Philips

Philips LC7.1HE LA Bedienungsanleitung

Philips

Philips 42PFL7422D Installations- und Betriebshandbuch

Philips

Philips 42PFL3604H/12 Bedienungsanleitung

Philips

Philips 25GR9963/32B Bedienungsanleitung

Philips

Philips 32PF9551 Bedienungsanleitung

Philips

Philips 4131 series Bedienungsanleitung

Philips

Philips 28PT5008 Bedienungsanleitung

Philips

Philips 19PFL3403D Bedienungsanleitung

Philips

Philips 43PUS8105 Bedienungsanleitung

Philips

Philips 50PUD6513/55 Bedienungsanleitung

Philips

Philips 32PFL3506 Bedienungsanleitung

Philips

Philips LC03E Bedienungsanleitung

Philips

Philips 14CE1000 Bedienungsanleitung

Philips

Philips 50PUT7303/56 Bedienungsanleitung

Philips

Philips 32PW6720D/05 Bedienungsanleitung

Philips

Philips 7907 Series Bedienungsanleitung

Philips

Philips 55PU 6794 Series Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Toshiba

Toshiba 27A10 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Sylvania

Sylvania 6427FB Bedienungsanleitung

Sanyo

Sanyo CE19LD90N-B Bedienungsanleitung

North State

North State TV2GO Bedienungsanleitung

RCA

RCA RTU7877 Bedienungsanleitung

Sharp

Sharp 21K-FG1RU Bedienungsanleitung

Sony

Sony Esprit TAV-L1 Bedienungsanleitung

Grundig

Grundig 43 VLE 4820 Bedienungsanleitung

Samsung

Samsung LN26C350D1D Bedienungsanleitung
