Phonic Ear Field Bedienungsanleitung
teleloop amplifier
other resources online at www.phonicear.dk
GB user guide
FIELD function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
FIELD features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
FIELD accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
FIELD instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Test and approval . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
table of contents
1
FIELD is a teleloop amplifier. FIELD transfers the sound from TV and radio directly to your hearing
aid (or telemagnetic receiver) and you receive the sound loud and clear.
FIELD function
1 loop connection
To connect teleloop cable
FIELD features
back
2 12V AC connection
To connect 12 volt
power transformer
5 indicator light
Shows that power is on
3 radio/TV connections
To connect radio,
television, etc.
6 volume control
To adjust volume level
7 bass control
To adjust bass levels
8 treble control
To adjust treble levels
1 2 3 4
4 microphone connection
To connect external
microphone
front
65
bottom
7 8
2
English
3
9teleloop cable
Installed in rooms where
FIELD will be used
FIELD accessories (included with FIELD system)
10 teleloop cable clips
To secure teleloop cable
12 connector set
(optional in some countries)
Includes:
• Adaptor, SCART/phono
• Adaptor: 6,3mm (.25in) plug stereo
to 3,5mm (.125in) stereo jack
• Connector cable: 2m (6.5ft),
3,5mm (.125in) plug stereo to 3,5mm
(.125in) stereo plug
• Stereo cable: 2m (6.5ft),
3,5mm (.125in) stereo plug
to 2 x phono plug
11 screwdriver
To adjust bass and treble
11
12
10
9
13 power transformer
(optional in some countries)
13
FIELD accessories (not included, sold separately)
English
4
14 clip microphone
Placed in front of source loud-
speaker if sound source cannot be
attached to teleloop amplifier by
an output connection. Can also be
used to amplify conversations.
14
15 boundary microphone
16 cushion loop
16
15
5
FIELD instructions
teleloop installation
Place teleloop cable
along wall, floor, or
ceiling of room where
FIELD will be used and
secure with cable clips.
To avoid cable damage,
run cable under carpet,
behind baseboard or
around doorframe.
1
1
2
TV
top view of room
sofa
2
door
ATTENTION: Make sure that
teleloop cable is fully stretched
out. If cable is too long, shorten
it to fit room size.
1a
cushion loop installation (optional)
1b
Place cushion loop pad under
a cushion in the seat where
you are listening to the
sound source.
The cushion loop limits the
range of the teleloop and
possible “interference ability”. It
can also be easily moved around
the room if necessary.
FIELD instructions
English
6
connect to TV
Plug one end of the cable (from
connector set) into one of the
Radio/TV connections on back
of FIELD.
Then plug other end of the
cable into Line Out or SCART
connection on TV.
NOTE: Use only cables and jack
plugs supplied by an authorized
Phonic Ear representative/installer or
FIELD may be damaged.
3
connecting teleloop cables
Remove Loop connector
from back of unit.
Loosen cable connection
screws.
11
2
2
Strip ends of cable to
expose 1 cm of wire.
Insert ends of cable into
connector holes and
tighten screws using the
screwdriver.
Replace connector into
Loop hole on unit.
3
3
2
7
FIELD instructions
connect to microphone (optional)
Plug microphone cable into Mic
connection on back of FIELD.
NOTE: When clip microphone or
boundary microphone are used
for conversations, the TV and radio
should be switched off.
Use only cables and jack plugs
supplied by an authorized Phonic
Ear representative/installer
or FIELD may be damaged.
If sound source cannot be
attached to teleloop amplifier
by an output connection, then
microphone can be placed in
front of the source loudspeaker.
5
connect to radio
Plug one end of the cable (from
connector set) into one of the
Radio/TV connections on back
of FIELD.
Then plug other end of the cable
into Line Out connection
on radio.
NOTE: Sound sources other than
TV and radio can be connected to
FIELD. Contact an authorized
Phonic Ear representative/installer
for more information.
Use only cables and jack plugs
supplied by an authorized Phonic
Ear representative/installer
or FIELD may be damaged.
4
FIELD instructions
English
8
adjusting volume
Use volume control on front of
FIELD to adjust volume level:
Min = Lowest volume
Max = Highest volume
NOTE: As a general rule, the
volume should be adjusted so that
you don’t experience irritating
changes in volume when you
change between “M” and “T”
positions on your hearing aid.
7
connecting transformer
Plug transformer cord into
12V AC connection on
back of FIELD.
1
1Plug transformer into
wall socket. Red light on
front of FIELD should go on.
2
2
6
