PictureTel
210 Terminal Adaptor
Software Version 2.1
Release Notes
PictureTel
Copyright 2000: PictureTel Corporation
PictureTel Corporation
100 Minuteman Road
Andover, MA 01810
U.S.A.
Telephone: (+1) 978.292.5000
FAX: (+1) 978.292.3300
PictureTel is a registered trademark of PictureTel Corporation. The PictureTel logo and the PictureTel 210 Terminal Adaptor are
trademarks of PictureTel Corporation. All other products and company names are the trademarks or registered trademarks of their
respective owners.
All rights reserved. Printed in the United States of America. The information contained in this document is based on software release
2.1 and is subject to change without. PictureTel assumes no responsibility for technical or editorial errors or omissions that may
appear in this document or for the use of this material. Nor does PictureTel make any commitment to update the information
contained in this document. This document contains proprietary information which is protected by copyright. All rights reserved. No
part of this document may be photocopied or reproduced in any form without the prior written consent of PictureTel Corporation.
Edition: 800-1090-04
1 About this Document
These release notes provide information about the PictureTel 210 Terminal Adaptor. It is meant
to supplement the information contained in the Users Guide and Installation Notes for version
2.1. The following sections are included:
1. About this Document
2. Packing List
3. Version 2.1 Features
4. Fixed Bugs
5. Known Issues
Note: Please note that all reference to the VIU-323 is synonymous
with PictureTel 210 Terminal Adaptor.
2 Packing List
Please check that the package you have received contains the following items:
!"PictureTel 210 unit.
!"RADVision OnLAN Video Tools CD ROM containing: System Configuration Software,
Software Upload Utility, the VIU–323 User Guide and a Data Sheet describing the
RADVision video product line.
!"Release Notes.
!"Power Cable
!"Two V.35/RS-366 Y-cables.
!"Terminal/Modem cable.
!"Mounting kit for 19" rack installation.
3 Version 2.1 Features
After you unpack and install your PictureTel 210 Terminal Adaptor you will discover the many
new and exciting features in 2.1, including:
!"The 210 TA is now fully H.323 version 2.0 compliant.
!"The following bit rates are supported (restricted bit rates are now included): 2x56 Kbps,
2x64 Kbps, 112 Kbps, 128 Kbps, 224 Kbps, 256 Kbps, 336 Kbps, 384 Kbps, 672 Kbps,
and 768 Kbps.
Note: The Concorde must have a rev 3 vCP card in the system to handle
768Kb conferences. To determine if the current card will work at 768Kb,
reboot the system and watch the start-up tests. If the vCP is shown in all
caps (VCP) then it is an older card and must be replaced. A good card will be
shown with a lower case v (vCP).
!"Support for G.722 audio coding in the following bit rates: 336 Kbps, 384 Kbps, 672 Kbps,
and 768 Kbps.
!"The Configuration, Remote diagnostics, Telnet, FTP and Upload utilities are now
protected by utilizing the same (configurable) user name and password.
!"Dialing profiles for the 210 TA have been changed: a list of predefined bandwidth profiles
is preset for setting the bandwidth of incoming and outgoing calls, as shown below (see
Chapter 6 of the VIU-323 User Guide for further information). The use of a dialing prefix
to indicate the required bandwidth profile eases the operation of the 210 TA in that
mode. (For the configurable port default bandwidth, a prefix is not needed.)
To Force Calling
Bandwidth to: Use Prefix:
2 x 64 Kbps (2B) #00
128 Kbps #10
256 Kbps #20
384 Kbps #30
768 Kbps #70
2 x 56 Kbps (2B) (restricted) #01
112 Kbps (restricted) #11
224 Kbps (restricted) #21
336 Kbps (restricted) #31
672 Kbps (restricted) #71
To Force Receiving
Bandwidth to: Use Suffix:
2 x 64 Kbps (2B) 00
2 x 56 Kbps (2B) 01
128 Kbps 10
112 Kbps 11
224 Kbps 21
256 Kbps 20
336 Kbps 31
384 Kbps 30
672 Kbps 71
768 Kbps 70
!"Remote configuration via PPP can now be used from Windows 95/98/NT.
!"RADVision OnLAN Tools is now installed automatically using the RADVision OnLAN Video
Tools CD-ROM.
!"Improved User Guide.
4 Fixed Bugs
!"There was a problem working with third-party gatekeepers in Direct Mode. This has been
fixed.
5 Known Issues
!"T.120 does not work with the Concorde or Venue. It must be disabled or there will be
video problems.
!"LiveLans will freeze if you try to connect with a 210 TA.
!"When using NetConference, it is best to set up the conference at 384Kb, QCIF, 15 FPS.
If you set the 210 TA to 768Kb, you wont get video.
!"When connecting to an Accord MCU, you must choose Audio algorithms G.711 or G.728.
!"To enable interzone calls to a 210 TA registered to a Cisco MCM Gatekeeper, the 210 TA
has to be registered with the MCM with its zone prefix followed by the dial in number
(instead of using the number only). For example, if the zone prefix is 2 and the 210 TA
phone number is 789, the 210 TA should be reconfigured at the MCM to have a phone
number 2789.
!"When performing configuration using a terminal, default values are not entered
automatically by pressing ENTER. The default values must be retyped into the system
before pressing ENTER.
!"Corrections to Appendix D, Technical Specifications in the VIU-323 User Guide:
Safety UL (1950 Standard), CSA (CS22.2 No. 950), CE Marks (EN 60950)
EMC FCC Part 15 Class A, EN 50082-1, EN 300 386-2 (EN 55022 Class
A, CISPR-22)
