Regular Check for Safety before Riding
1. Check Tire Pressure before riding:
The tire pressure on front and rear tires is to be maintained at 50PSI (or 3.5Bar).
Check if the tire tread is worn excessively. If so the tire needs to be replaced.
2. Check Power Assist:
The power assist should cut off when one of handbrakes is engaged or the pedaling has
being stopped for over 3 seconds.
3. Check Battery:
Check the battery pack fits into the battery mount firmly and the LED Light of the battery
pack lights up when the main switch is switched on at the II position.
Check the battery is fully charged before use.
1. Check Motor and Control System:
Must check the motor and control system ensuring normal operation.
2. General Inspection:
Check if brake shoes are worn and need to be replaced.
Check if the braking function is operating correctly.
Check if the front and rear wheels are operated smoothly.
Check if all connectors on E-Trike are firmly secured without any damage.
If you have any questions after checking, please refer to the Page 19 for trouble shooting or
contact your authorized dealer for inspection and maintenance.
Riding Safety
˙Always follow local traffic rules while riding.
˙Check the battery gauge if the charge is sufficient to keep the power assist for your
planned riding.
˙The maximum loading capacity of the lockable box & front basket is 20 kgs & 2 kgs
respectively. Do not overload the lockable box or basket.
˙Do not keep riding your E-Trike if a problem has occurred. Refer to the solutions for
trouble shooting (page 18) or contact your authorized dealer for further inspection and
maintenance. Ensure to use the spare parts supplied by PMMC for replacement.
E-Trike Care
The lifetime of your E-Trike will be adversely affected by exposures to aggressive road
conditions, such as dirt, rain, water or salt spray, etc. Ensure your E-Trike, including the
battery pack, are used as instructed in this manual and are protected for transportation.
Always store your E-Trike indoors when not in use. This will prolong the lifespan of your
E-Trike.
