Clarity Matrix MX55HDU

LCD Video Wall System

The Clarity™ Matrix MX55HDU-L with G2

Architecture is an ultra-narrow bezel 55" LCD video

wall that provides outstanding tiled visual

performance, supports extended operation and

requires minimal installation space. Designed for 24x7

operation, the Clarity MX55HDU-L features 800 nits

brightness, LED backlight technology and full HD

resolution making it the ideal video wall for high-

impact, mission-critical applications. The MX55HDU-L

sets a new benchmark with a tiled bezel width as

small as 3.7 mm, creating a near seamless digital

canvas.

SPECIFICATION DETAIL

Planar Part Number 997-7460-00

Technology Commercial-grade direct view LCD

Diagonal 55 inches

Aspect Ratio 16:9

Native Resolution Panels 1920 x 1080

Tiled Bezel Width 3.7 mm

Bezel Width N/A

Brightness (typ) 800 cd/m² or nits

Response Time (typ) 8 ms

Contrast ratio (full field) 3500:1

Full viewing angle 178°

Backlight life (1/2

brightness) 50,000 Hrs

Mounted depth 3.6" wall to front of screen

Acoustic noise Fanless operation

Heat load 628 BTU per hour at 500 nit

Operating temperature

range 5 - 40 Degrees C

Operating humidity range 20-90% RH non-condensing

Backlight control Individual and wall control

Backlight sensing and

reporting At display level

Display module position

sensing Auto-sensing integrated

Power Consumption (max) 231 watts (typical)

Power supply voltage 100-230V AC ± 10%, 50 to 60 Hz

Power status Diagnostics LEDs, health monitoring and alerts

Safety regulations Complies with EN60950, FCC Class A, CISPR22/85, CE, EU RoHS

Data Inputs 4 HDMI inputs, 1 DisplayPort input

Control IR Remote, RS232, Ethernet (optional)

Per Panel Dimensions

(Including Mount) 47.84" x 27.01" x 3.6"

Per Panel Weight

(Including Mount) 59 lbs

Wall Dimensions (WxHxD) N/A

Wall Dimensions (WxHxD)

including stand N/A

Shipping weight 150 lbs

In the Box N/A

UPC N/A

Touch Options Clarity Matrix MultiTouch Kits

Touch Frame Dimensions N/A

Power for Touch System N/A

OS Compatibility N/A

For more information, please visit www.planar.com

Specifications are subject to change without notice.

Specification Report Date: 5/29/2014
