Planet POE-151S Bedienungsanleitung

IEEE 802.3at / af Power over Ethernet Splitters

Fendeur Ethernet IEEE 802.3at / af

802.3at / af PoE Strom über Ethernet Splitter

Il Power over Ethernet Splitter 802.3at / af

O 802.3at / af Energia para Divisores Ethernet

Сплиттер 802.3at / af PoE

El 802.3at / af Energía sobreEthernet Separador

POE-151S / POE-152S / POE-162S

User's Manual

Table of Contents

English

1. Overview ......................................................................... 1-1

2. Package Contents ............................................................. 1-1

3. Product Outlook................................................................ 1-2

4. LED Indication.................................................................. 1-2

5. Hardware Installation ........................................................ 1-3

6. Product Specication ......................................................... 1-7

Française

1. Vue d’ensemble ................................................................ 2-1

2. Contenu du lot ................................................................. 2-1

3. Détail du produit .............................................................. 2-2

4. Voyant DEL ...................................................................... 2-2

5. Installation du matériel ..................................................... 2-3

6. Caractéristiques du produit ................................................ 2-7

Deutsch

1. Überblick ......................................................................... 3-1

2. Packungsinhalt ................................................................. 3-1

3. Produkt Ansicht ................................................................ 3-2

4. LED Anzeige..................................................................... 3-2

5. Hardware Installation ........................................................ 3-3

6. Produkt Spezikation......................................................... 3-7

Italiano

1. Informazioni generali ........................................................ 4-1

2. Contenuto della confezione ................................................ 4-1

3. Vista del Prodotto ............................................................. 4-2

4. LED di stato ..................................................................... 4-2

5. Hardware Installation ........................................................ 4-3

6. Speciche del Prodotto...................................................... 4-7

Português

1. Apresentação ................................................................... 5-1

2. Conteúdos da Embalagem ................................................. 5-1

3. Apresentação do Produto................................................... 5-2

4. Indicação LED .................................................................. 5-2

5. Instalação do Equipamento................................................ 5-3

6. Especicação do Produto ................................................... 5-7

Pусский

1. Обзор ............................................................................. 6-1

2. В комплект входят........................................................... 6-1

3. Внешний вид продукта .................................................... 6-2

4. Светодиодная индикация ................................................. 6-3

5. Установка оборудования.................................................. 6-3

6. Характеристики продукта................................................. 6-8

Español

1. Información general.......................................................... 7-1

2. Contenido del paquete ...................................................... 7-1

3. Vista general del Producto ................................................. 7-2

4. Indicación LED ................................................................ 7-2

5. Instalación del hardware ................................................... 7-3

6. Especicación de Producto ................................................. 7-7

1-1

English

1.Overview

Thank you for purchasing PLANET IEEE 802.3at / af Power over

Ethernet Splitters. These PoE splitters will work with any Power

Sourcing Equipment (PSE) that also supports the IEEE 802.3af / at

standards. The models bellows are included:

Model PoE Standard DC Power Out Power Input Pass-thru. Speed

POE-151S IEEE 802.3af 5V / 12V 48V DC 10/100Mbps

POE-152S IEEE 802.3af 5V / 12V 48V DC 10/100/1000Mbps

POE-162S IEEE 802.3at / af 12V / 24V 56V DC 10/100/1000Mbps

Unless specied, terms of “PoE Splitter” in the following sections

means the model listed above.

2.Package Contents

Upon open the box of the PoE Injector and carefully unpack it. The box

should contain the following items:

POE-151S / POE-152S POE-162S

The 802.3af Power over

Ethernet Splitter x 1

User’s Manual x 1

15cm UTP Straight Network

Cable x 1

DC Plug Cable x 2

The IEEE 802.3at Gigabit High

Power over Ethernet Splitter x 1

User’s Manual x 1

15cm UTP Straight Network

Cable x 1

DC Plug Cable x 2

Note

If any of these pieces are missing or damaged, please

contact your dealer immediately. If possible, retain the

carton including the original packing material, and use

them again to repack the product in case of a need to

return for repair.

1-2

English

3.Product Outlook

POE-151S / POE-152S

There are two RJ-45 Twisted-Pair jack , one LED indicator, one DC 5V /

2A, 12V / 1A DIP switch and one DC Plug connector.

PoE

Ethernet+DC

Power over Ethernet Splitter

IEEE 802.3af

PoE-IEEE 802.3af

Ready

Power in-use

DC OUT

Ethernet 5V 12V

Figure 1: POE-151S / POE-152S

POE-162S

There are two RJ-45 Twisted-Pair jack, one LED indicator, one DC 12V /

2A, 24V / 1A DIP switch and one DC Plug connector.

Note

IEEE 802.3at High Power PoE Splitter

DC Out Ethernet

PoE In

24V 12V

Incorrect voltage might

cause device damage

CAUTION

Disconnect "PoE In" cable

before change 12/24V

Figure 2: POE-162S Overview

4.LED Indication

LED Color Function

PoE In Green Lights to indicate the port is connected with IEEE 802.3af

/ at PSE device.

1-3

English

5.Hardware Installation

This section describes the hardware features of PoE Splitter. Before

connecting any network device to the PoE Splitter, refer to this

chapter carefully.

5.1 Before Installation

The PLANET PoE Splitter separates the power out and provides two

kind of DC power output through its DIP switch and its voltage and

current shown as below:

Model DIP switch for DC Voltage Output Default Mode

POE-151S 5V DC / 2A

12V DC / 1A 5V DC

POE-152S

POE-162S 12V DC / 2A

24V DC / 1A 12V DC

POE-151S / POE-152S POE-162S

PoE

Ethernet+DC

Power over Ethernet Splitter

IEEE 802.3af

PoE-IEEE 802.3af

Ready

Power in-use

DC OUT

Ethernet 5V 12V

Note

IEEE 802.3at High Power PoE Splitter

DC Out Ethernet

PoE In

24V 12V

Incorrect voltage might

cause device damage

CAUTION

Disconnect "PoE In" cable

before change 12/24V

Note

The PLANET PoE Splitter and PLANET PoE Injector (ex.

POE-151, POE-152 and POE-161) can be installed in

pair. Use of third-party PoE Injector device is allowed if

the device complied with IEEE 802.3at or IEEE 802.3af

standard.

1-4

English

5.2 802.3af/at Device Installation

The PLANET PoE Splitter also provide the alternative to make the non

IEEE 802.3af / 802.3at devices the possibility to connect with an IEEE

802.3af / 802.3at PSE power device like Power over Ethernet Injector

or Power over Ethernet Switch, the gure is as below.

802.3af in-line power Switch

Wireless AP

POE-151S

POE-152S

100 meters

Power

Data

Power

Data

PoE DC

100Base-TX UTP

DC Power Line (DC)

PoE 100Base-TX UTP with PoE

PoE

Ethernet+DC

PoE-IEEE 802.3af

Ready

Power in-use

DC OUT

Ethernet 5V 12V

Figure 3: Connection to IEEE 802.3af Device

100 meters

PTZ Speed

Dome

802.3at in-line power Switch

POE-162S

1000Base-T UTP

1000Base-T UTP with PoE

PoE

Power Line (DC)

PoE

Power

Data

Power

Data

PoE In DC Out Ethernet

24V 12V

Figure 4: Connection to IEEE 802.3at Device

1-5

English

Note

With IEEE 802.3af / 802.3at standard; the PLANET PoE

Splitter also can co-work with IEEE 802.3af / 802.3at

End-Span Switch that feeding power over pin 1, 2, and

3, 6.

5.3 PoE Injector and PoE Splitter Installation

For non PoE remote device or Ethernet equipment, the PoE Splitter

and PoE Injector can runs in pair to provide DC Power for those

devices, the table below shows the model of PLANET PoE Injectors:

Model PoE Standard Max. PoE Out Power In Pass-thru. Speed

POE-151 IEEE 802.3af 15.4 Watts 48V DC 10/100Mbps

POE-152 IEEE 802.3af 15.4 Watts 48V DC 10/100/1000Mbps

POE-161 IEEE 802.3at / af 30 Watts 56V DC 10/100/1000Mbps

Steps:

1. [Switch & PoE Injector] Connect a standard network UTP cable

from Switch / workstation to “Ethernet” port of PoE Injector and

the PoE Injector get DC power from attached power adapter.

2. [PoE Injector & PoE Splitter]

Connect the long UTP cable between the port “Ethernet+DC” of

PoE Injector to the port “Ethernet+DC” (or “PoE IN”) of PoE

Splitter.

The PoE LEDs of both Injector and Splitter will light on continu-

ance.

3. [PoE Splitter]

Connect the UTP cable in the package from “Ethernet” of the

PoE splitter to the RJ-45 port of remote device.

Adjust proper DC power output and connect proper DC plug from

“DC OUT” of PoE Splitter to the remote device.

1-6

English

100 meters

100Base-TX UTP

DC Power Line (DC)

AC Power Line (AC)

PoE 100Base-TX UTP with PoE

Data

Power

Data

Wireless AP

PoE

Power

Data

Ethernet Switch

POE-151/152

PoE Injector

POE-151S

PoE Splitter

PoE

Ethernet+DC

PoE-IEEE 802.3af

Ready

Power in-use

DC OUT

Ethernet 5V 12V

Power

Figure 5: Connection Architecture via 802.3af PoE Injector and PoE Splitter

Switch

POE-162S

POE-161

100 meters

PTZ Camera

1000Base-T UTP

1000Base-T UTP with PoE

PoE

Power Line (AC)

Power Line (DC)

PoE

Power

Data

Power

Data

Power

Data

PoE In DC Out Ethernet

24V 12V

56V DC

Ethernet Ethernet+DC

Figure 6: Connection Architecture via 802.3at PoE Injector and PoE Splitter

Note

Please ensure the PoE Splitter output voltage is correct

before applying power to remote device otherwise, it

may damage the remote device.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Planet Netzwerk-Hardware Handbücher

Planet

Planet BM-2010A Bedienungsanleitung

Planet

Planet IPOE-171-60W Bedienungsanleitung

Planet

Planet NVR-820 Bedienungsanleitung

Planet

Planet GRT-101 Bedienungsanleitung

Planet

Planet NVR-401 Bedienungsanleitung

Planet

Planet FGSW-2402VS Bedienungsanleitung

Planet

Planet IKVM-8000 Bedienungsanleitung

Planet

Planet ADE-3000 Bedienungsanleitung

Planet

Planet NVR-401 Bedienungsanleitung

Planet

Planet BM-2002 Bedienungsanleitung

Planet

Planet NVR-400 Bedienungsanleitung

Planet

Planet NVR-820 Bedienungsanleitung

Planet

Planet FSD-624SF Bedienungsanleitung

Planet

Planet NAS-7450 Bedienungsanleitung

Planet

Planet EPL-2000 Bedienungsanleitung

Planet

Planet GRT-101 Bedienungsanleitung

Planet

Planet NVR-820 Bedienungsanleitung

Planet

Planet IVS-H125 Bedienungsanleitung

Planet

Planet NVR-420 Bedienungsanleitung

Planet

Planet MGB-Series Bedienungsanleitung

Planet

Planet WBS-512AC Bedienungsanleitung

Planet

Planet NVR-3210 Bedienungsanleitung

Planet

Planet IVS-100 Bedienungsanleitung

Planet

Planet GRT-501 Bedienungsanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
