Planet IGS-6325 Series Bedienungsanleitung
Industrial L3 Rack-mount
Managed Ethernet Switch
IGS-6325 Series
Quick Installation Guide
Table of Contents
1. Package Contents................................................................................. 3
2. Requirements....................................................................................... 4
3. Wiring DC Power Inputs........................................................................ 5
4. Terminal Setup..................................................................................... 7
4.1 Logging into the Console ................................................................ 8
4.2 ConguringIPAddressviaConsole ................................................. 9
5. Starting Web Management .................................................................. 11
5.1 LoggingintotheIndustrialManagedSwitch .................................. 12
5.2 SavingCongurationviaWeb ....................................................... 14
6. ReturningtoDefaultConguration ....................................................... 16
7. Customer Support .............................................................................. 17
3
1. Package Contents
Thank you for purchasing PLANET Industrial L3 Managed Ethernet Switch.
“Industrial Managed Switch” is used as an alternative name in this Quick
InstallationGuide.
Open the box of the Industrial Managed Switch and carefully unpack it. The
boxshouldcontainthefollowingitemsforeachmodel:
IGS-6325-
20T4C4X
IGS-6325-
20S4C4X
IGS-6325-
24P4X
IGS-6325-
24P4S
IGS-6325-
24UP4X
Quick
Installation
Guide
DB9 to RJ45
Interface
RS232 Console
Cable
Rack-mount
AccessoryKit
ACPowerCord ---
RJ45 Dust Cap 25 525 25 25
SFP Dust Cap 828 844
If any item is found missing or damaged, please contact your local reseller for
replacement.
4
2. Requirements
The Industrial Managed Switch provides a remote login interface for
management purposes. The following equipment is necessary for further
management:
zWorkstations running Windows 7/8/10/11, MAC OS X 10.10 or later, Linux,
UNIX,orotherplatformsarecompatiblewithTCP/IPProtocols.
zWorkstationsareinstalledwithEthernetNIC(NetworkInterfaceCard)
zSerial Port Connection(Terminal)
The above Workstations come with COM Port (DB9) or USB-to-RS232
converter.
The above Workstations have been installed with terminal emulator, such
asputtyorTeraTerm,etc.
Serial Cable -- Connect one end of the serial cable to the RS232 serial
port, and the other end to the console port of the Industrial Managed
Switch.
zEthernet Port Connection
Network cables -- Use standard network (UTP) cables with RJ45 connec-
tors.
TheabovePCisinstalled withWebbrowser.
It is recommended to use a modern browser, such as Google
Chrome, Mozilla Firefox, or Microsoft Edge, to access the Indus-
trial Managed Switch. If the Web interface of the Industrial
Managed Switch is not accessible, please turn off the anti-virus
softwareorfirewallandthentryitagain.
5
3. Wiring DC Power Inputs
The 6-contact terminal block connector on the panel of Industrial Managed
Switch is used for two DC redundant power inputs. Please follow the steps
below to insert the power wires.
1.Insert positive and negative DC power wires into contacts 1 and 2 for DC
POWER1,or5and6forDCPOWER2.
DI/DO
FaultR.O.
Ring
AC
DC 2
DC 1
DC POWER
ON
Fault DC 2DC 1
OFF
DC Input Range:
24-60V , 1.7A max.
GNDGNDDO 1DO 0DI 1DI 0
Max. fault loading: 24V, 1A
Figure 3-1: 6-contact terminal block connector of
IGS-6325-20T4C4X and IGS-6325-20S4C4X
+
FaultDC 1 DC 2
+
DC Input: 48-56V , 11A
Figure 3-2: 6-contact barrier terminal block of
IGS-6325-24P4X, IGS-6325-24P4S, IGS-6325-4UP4X
6
2.Tightenthewire-clampscrewstopreventthewiresfromloosening.
123456
Power 1 Alarm Power 2
+ - + -
Figure 3-3: The screws of 6-contact terminal block connector
Thewiregaugeoftheterminalblockshouldbebetween12and
24AWG.
7
4. Terminal Setup
Tocongurethesystem, connecta serialcablefromaCOMporton yourPCor
notebookcomputertotheRJ45serialportontheIndustrialManagedSwitch.
Managed Switch
PC / Workstation
with
Terminal Emulation Software
Serial Port
RS232 to RJ45 Cable
Console Port
RJ45
Figure 4-1: Console Connection for Industrial Managed Switch
A terminal program is required to establish a software connection to the
IndustrialManagedSwitch.
1. Run the terminal program on your operating system.
2.When the following screen appears, ensure that the COM port is congured
asfollows:
zBitspersecond:115200
zDatabits:8
zParity:None
zStopbits:1
zFlowcontrol:None
Figure 4-2: COM Port Conguration
8
4.1 Logging into the Console
After connecting the terminal to the device, turn on the Industrial Managed
Switch. The terminal will then display the message “running testing
procedures”.
Next, the message prompts the user to log in with their username and
password. The factory default username and password are displayed on the
loginscreen,asshowninFigure4-3(TeraTermisusedasarepresentative.).
Username:admin
Password:admin
Figure 4-3: Industrial Managed Switch Console Login Screen
Users can now enter commands to manage the Industrial Managed Switch.
For a detailed description of these commands, please refer to the following
chapters.
1.For security reasons, please change and memorize the new
passwordaftercompletingthefirstsetup.
2.Please only enter commands in lowercase letters when using
the console interface.
9
4.2 ConguringIPAddressviaConsole
The Industrial Managed Switch is shipped with a default IP address, shown
below.
IPAddress:192.168.0.100
SubnetMask:255.255.255.0
To check or modify the current IP address for the Switch, follow the
procedures below (ICS-6325-20T4C4X is used to demonstrate how to use the
commands):
Show the current IP Address
1.Atthe“#”prompt,enter“show ip interface brief”.
IGS-6325-20T4C4X # show ip interface brief
2.ThescreendisplaysthecurrentIPaddress,asshowninFigure4-4.
Figure 4-4: IP Information Screen
Conguring IP Address
3.At the “#” prompt, enter the following command and press <Enter> as
shown in Figure 4-5.
IGS-6325-20T4C4X # congure terminal
IGS-6325-20T4C4X(cong)#interface vlan 1
IGS-6325-20T4C4X(cong-if-vlan)#ip address 192.168.1.100
255.255.255.0
The previous command would apply the following settings for the Industrial
ManagedSwitch.
IPAddress:192.168.1.100
SubnetMask:255.255.255.0
10
Figure 4-5: IP Address Conguration Screen
4.Repeatstep1tocheckiftheIPaddressischanged.
5.Enterthefollowing commandandpress<Enter> to go back to “#” prompt.
# exit
Figure 4-6: Exit Command
6.Atthe“#”prompt,enterthefollowingcommandandpress<Enter>.
# copy running-cong startup-cong
Figure 4-7: Saving Current Conguration
If the IP address is successfully congured, the Industrial Managed Switch will
immediately apply the new setting. You can access the web interface of the
IndustrialManagedSwitchusingthenewIPaddress.
If you’re unfamiliar with the console commands or related
parameters, enter “help” at any time in the console to get a
descriptionofavailablehelpoptions.
