Polar Electro GH218-A Bedienungsanleitung

Model:

GH218-A/GH219-A

Display Glass Door

Fridge

Instruction manual

GH218-A_GH219-A_A5_v1_20210816.indb 1GH218-A_GH219-A_A5_v1_20210816.indb 1 2021/8/16 10:532021/8/16 10:53

AU Telephone Helpline: 1300225960

Safety Instructions

• Position on a flat, stable surface.

• A service agent/qualified technician should carry out

installation and any repairs if required. Do not remove any

components or service panels on this product.

• Consult Local and National Standards to comply with the

following:

- Health and Safety at Work Legislation

- Fire Precautions

- Wiring Regulations

- Building Regulations

• DO NOT use jet/pressure washers to clean the appliance.

• DO NOT use the appliance outside.

• DO NOT use this appliance to store medical supplies.

• DO NOT stand or support yourself on the base, drawers or

doors.

• DO NOT allow oil or fat to come into contact with the plastic

components or door seal. Clean immediately if contact occurs.

• Bottles that contain a high percentage of alcohol must be

sealed and placed vertically in the refrigerator.

• Always carry, store and handle the appliance in a vertical

position and move by holding the base of the appliance.

• Always switch off and disconnect the power supply to the unit

before cleaning.

• Keep all packaging away from children. Dispose of the

packaging in accordance with the regulations of local

authorities.

• If the power cord is damaged, it must be replaced by a POLAR

agent or a recommended qualified technician in order to avoid

a hazard.

GH218-A_GH219-A_A5_v1_20210816.indb 2GH218-A_GH219-A_A5_v1_20210816.indb 2 2021/8/16 10:532021/8/16 10:53

AUAU

Telephone Helpline: 1300225960

• This appliance is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities,

or lack of experience and knowledge, unless they have

been given supervision or instruction concerning use of the

appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play

with the appliance.

• Polar recommend that this appliance should be periodically

tested (at least annually) by a Competent Person. Testing

should include, but not be limited to: Visual Inspection,

Polarity Test, Earth Continuity, Insulation Continuity and

Functional Testing.

Caution Risk of Fire

• Do not store explosive substances such as aerosol cans with a

flammable propellant in this appliance.

Warning: Keep all ventilation openings clear of

obstruction. Unit should not be boxed in without

adequate ventilation.

• Warning: Do not use mechanical devices or other means

to accelerate the defrosting process, other than those

recommended by the manufacturer.

• Warning: Do not damage the refrigerant circuit.

• Warning: Do not use electrical appliances inside the food

storage compartments of the appliance, unless they are the

type recommended by the manufacturer.

Product Description

GH218-A - Polar Gastro Display Fridge - Glass Door - 600Ltr

GH219-A - Polar Gastro Display Fridge - Glass Door - 1200Ltr

Introduction

Please take a few moments to carefully read through this manual. Correct maintenance and operation of

this machine will provide the best possible performance from your POLAR product.

GH218-A_GH219-A_A5_v1_20210816.indb 3GH218-A_GH219-A_A5_v1_20210816.indb 3 2021/8/16 10:532021/8/16 10:53

AU Telephone Helpline: 1300225960

Pack Contents

The following is included:

• POLAR Refrigerator or Freezer

• Keys

• Shelf guides

• Shelves

• Instruction manual

POLAR prides itself on quality and service, ensuring

that at the time of packaging the contents are

supplied fully functional and free of damage.

Should you find any damage as a result of transit,

please contact your POLAR dealer immediately.

Installation

Note: If the unit has not been

stored or moved in an upright

position, let it stand upright for

approximately 12 hours before

operation. If in doubt allow to

stand.

1. Remove the appliance from the packaging.

Make sure that all protective plastic film and

coatings are thoroughly removed from all

surfaces.

2. To optimize performance and longevity, ensure

a minimum clearance of 2.5cm is maintained

between the unit and walls and other objects,

with a minimum 5cm clearance on the top.

NEVER LOCATE NEXT TO A HEAT SOURCE.

Note: Before using the appliance

for the first time, clean the

shelves and interior with soapy

water.

3. Set the brakes on the castors to keep the

appliance in position.

Removing the Compressor Safety

Band

• The compressor is located on the top of the

appliance, and sits on rubber washers. Under

normal operating conditions the compressor is

allowed to vibrate.

• To avoid damage through excessive motion

during transit, a stainless steel safety band is

placed over the compressor and screwed into

the top of the appliance.

• This safety band and the two screws fixing it

to the appliance must be removed before the

appliance is turned on.

Compressor

Safety Band

Compressor

Screws

Lock/Unlock the Doors

A lock is fitted to the doors to ensure foodstuffs

are kept secure within your POLAR appliance.

Use the keys provided to lock/unlock the doors.

Fitting the Shelves

1. Place one set of shelf guides on either side of

the cabinet at the desired height.

2. Slide the shelf into place.

3. Repeat for the remaining shelves.

GH218-A_GH219-A_A5_v1_20210816.indb 4GH218-A_GH219-A_A5_v1_20210816.indb 4 2021/8/16 10:532021/8/16 10:53

AUAU

Telephone Helpline: 1300225960

Operation

Storing Food

To get the best results from your POLAR appliance,

follow these instructions:

• Only store foodstuffs in the appliance when it

has reached the correct operating temperature.

• Do not place uncovered hot food or liquid

inside the appliance.

• Wrap or cover food where possible.

• Do not obstruct the fans inside the appliance.

• Avoid opening the doors for prolonged periods

of time.

Turn On

1. Close the door(s) of the appliance.

2. Ensure the power switch is set to [O] and turn

on at the socket.

3. Switch on the Power [I]. The current

temperature within the appliance is displayed.

Control Panel

A BC

A - Power Switch

B - Lamp Switch

C - Controller

To See the Setpoint

Push and immediately release the SET key: the

display will show the Setpoint value.

Changing the Setpoint

1. Push the SET key for more than 2 seconds to

change the Setpoint value.

2. The value of the set point will be displayed and

the COMPRESSOR LED starts blinking.

3. To change the Set value push and

buttons within 10 seconds.

4. To store the new Setpoint push the SET key or

wait 10 seconds.

Manual Defrost

The appliance will automatically run a defrost cycle

every six hours.

Note: The cycle starts from the

time the appliance is initially

powered up.

To manually defrost the appliance:

1. Press and hold the aux button for more then 2

seconds.

2. The defrost cycle will start immediately and the

Defrost LED illuminates.

Note: Starting a manual defrost

also resets the automatic

defrost timer.

3. The next automatic defrost will start six hours

after the manual defrost has finished.

Cleaning, Care &

Maintenance

Defrost appliance at least

every 3 months, more often if

required.

Switch off and disconnect

from the power supply before

cleaning.

• Clean the interior of the appliance as often as

possible.

• Do not use abrasive cleaning agents. These

can leave harmful residues.

• Clean the door seal with warm soapy water.

• Always wipe dry after cleaning.

• Do not allow water used in cleaning to run

through the drain hole into the evaporation

pan.

• Take care when cleaning the rear of the

appliance. Sharp edges can cut.

• A POLAR agent or qualified technician must

carry out repairs if required.

GH218-A_GH219-A_A5_v1_20210816.indb 5GH218-A_GH219-A_A5_v1_20210816.indb 5 2021/8/16 10:532021/8/16 10:53

AU Telephone Helpline: 1300225960

Stainless Steel Care

To maintain the stainless steel exterior of your Polar item, please consider the following information:

Never:

• Use abrasive Scourers or scrubbing pads, etc.

• Use Chlorinated or acidic detergents.

• Allow anything e.g. food, dirt, cleaning chemicals to remain on the surface for longer than necessary,

clean them off right away.

• Allow the surface to remain wet.

Do:

• Clean often.

• Use soft Cloths or plastic Scourers.

• Rub with the grain of the metal, rather than across it.

• Use detergents and polish designed for cleaning Stainless Steel.

• Ensure that the cleaning products are washed off fully and that the steel is left dry.

Cleaning the Condenser

• The condenser is part of the refrigeration

system. The condenser requires monthly

cleaning.

• Always disconnect power supply before

carrying out Routine Maintenance.

• Failure to clean the condenser will reduce the

performance and life of your Polar unit and

may invalidate your warranty.

• The condenser is located above the

refrigeration cabinet. These models have a

removable filter which can be cleaned with a

vacuum cleaner.

Troubleshooting

If your POLAR appliance develops a fault, please check the following table before making a call to the

Helpline or your POLAR dealer.

Fault Probable Cause Solution

The appliance is not

working

The unit is not switched on Check the unit is plugged in correctly and

switched on

Plug or lead is damaged Call POLAR agent or qualified Technician

Power supply Check power supply

GH218-A_GH219-A_A5_v1_20210816.indb 6GH218-A_GH219-A_A5_v1_20210816.indb 6 2021/8/16 10:532021/8/16 10:53

AUAU

Telephone Helpline: 1300225960

Fault Probable Cause Solution

The appliance turns on,

but the temperature is

too high/low

Too much ice on the evaporator Defrost the appliance

Condenser blocked with dust Clean condenser with hose attachment of

vacuum

Doors are not shut properly Check doors are shut and seals are not

damaged

Appliance is located near a

heat source or air flow to the

condenser is being interrupted

Move the refrigerator to a more suitable

location

Ambient temperature is too high Increase ventilation or move appliance to a

cooler position

Unsuitable foodstuffs are being

stored in the appliance

Remove any excessive hot foodstuffs or

blockages to the fan

Appliance is overloaded Reduce the amount of food stored in the

appliance

The appliance is

leaking water

The appliance is not properly

levelled

Adjust the screw feet to level the appliance

(if applicable)

The discharge outlet is blocked Clear the discharge outlet

Movement of water to the drain is

obstructed

Clear the floor of the appliance

(if applicable)

The water container is damaged Call POLAR agent or qualified Technician

The drip tray is overflowing Empty the drip tray (if applicable)

The appliance is

unusually loud

The safety band has not been

removed

Remove the safety band

Loose nut/screw Check and tighten all nuts and screws

The appliance has not been

installed in a level or stable

position

Check installation position and change if

necessary

Technical Specifications

Model Voltage Power Current Temp.

Range

Net

Capacity

(Ltr)

Refrigerant

Dimensions

H x W x D

Weight

(kg)

GH218-A 220-240V

50Hz

255W 2.0A +2°C ~ +8°C 369 R290 90g 2000 x 680 x

810

145

GH219-A 220-240V

50Hz

410W 3.0A +2°C ~ +8°C 754 R290 130g 2000 x 1340

x 810

195

GH218-A_GH219-A_A5_v1_20210816.indb 7GH218-A_GH219-A_A5_v1_20210816.indb 7 2021/8/16 10:532021/8/16 10:53

AU Telephone Helpline: 1300225960

Electrical Wiring

The plug is to be connected to a suitable mains socket.

POLAR appliances are wired as follows:

• Live wire (coloured brown) to terminal marked L

• Neutral wire (coloured blue) to terminal marked N

• Earth wire (coloured green/yellow) to terminal marked E

This appliance must be earthed.

If in doubt consult a qualified electrician.

Electrical isolation points must be kept clear of any obstructions. In the event of any emergency

disconnection being required they must be readily accessible.

Compliance

The product must not be disposed of as household waste. To help prevent possible harm to human

health and/or the environment, the product must be disposed of in an approved and environmentally safe

recycling process. For further information on how to dispose of this product correctly, contact the product

supplier, or the local authority responsible for waste disposal in your area.

POLAR parts have undergone strict product testing in order to comply with regulatory

standards and specifications set by international, independent, and federal authorities.

POLAR products have been approved to carry the following symbol:

mechanical, photocopying, recording or otherwise, without the prior written permission of POLAR.

Every effort is made to ensure all details are correct at the time of going to press, however, POLAR reserve the right to

change specifications without notice.

GH218-A_GH219-A_A5_v1_20210816.indb 8GH218-A_GH219-A_A5_v1_20210816.indb 8 2021/8/16 10:532021/8/16 10:53

DECLARATION OF CONFORMITY

• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •

• Declaración de conformidad • Declaração de conformidade

Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp

• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento

Model • Modèle • Modell • Modello

• Modelo • Malli

G-Series Gastro Display Fridge 600L

G-Series Gastro Display Fridge 1200L

GH218-A

GH219-A

Application of Territory Legislation &

Council Directives(s)

Toepassing van Europese Richtlijn(en) •

Application de la/des directive(s) du

Conseil • Anwendbare EU-Richtlinie(n) •

Applicazione delle Direttive

• Aplicación de la(s) directiva(s) del

consejo • Aplicação de directiva(s) do

Conselho

Electrical safety

AS/NZS 60335.1:2011 +A1:2012 +A2:2014 +A3:2015 +A4:2017

AS/NZS 60335.2.89:2010 +A1:2013 +A2:2016

Electro-Magnetic Compatibility

EN 55014-1:2017

EN 55014-2:2015

EN 61000-3-2:2014

EN 61000-3-3:2013

Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers

• Nome del produttore • Nombre del fabricante • Nome do fabricante

Polar

I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s)

and Standard(s).

Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande

Richtlijn(en) en Standaard(en).

Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus

Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und

Norm(en) entspricht.

Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.

El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y

estándar(es) arriba mencionadas.

Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es)

Directiva(s) e Norma(s)

Date • Data • Date • Datum • Data •

Fecha • Data

10th August 2021

Signature • Handtekening • Signature

• Unterschrift Firma • Firma •

Assinatura

Full Name • Volledige naam • Nom et

prénom • Vollständiger Name • Nome

completo • Nombre completo • Nome

por extenso

Ashley Hooper

Nerida Pearse

Position • Functie • Fonction • Position

• Qualifica • Posición • Função

Technical & Quality Manager

Commercial Manager/ Responsible

Supplier

Producer Address • Adres fabrikant •

Adresse du producteur • Anschrift des

Herstellers • Indirizzo del produttore •

Dirección del fabricante • Morada do

fabricante

Fourth Way,

Avonmouth,

Bristol,

BS11 8TB

United Kingdom

15 Bagdally Road,

Campbelltown

NSW 2560

DocuSign Envelope ID: D9AE9490-0D1D-4214-8035-944271F1C08E

GH218-A_GH219-A_A5_v1_20210816.indb 9GH218-A_GH219-A_A5_v1_20210816.indb 9 2021/8/16 10:532021/8/16 10:53

GH218-A_GH219-A_A5_v1_20210816.indb 10GH218-A_GH219-A_A5_v1_20210816.indb 10 2021/8/16 10:532021/8/16 10:53

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Polar Electro Kühlschrank Handbücher

Polar Electro

Polar Electro FA440-A Bedienungsanleitung

Polar Electro

Polar Electro CN267 Bedienungsanleitung

Polar Electro

Polar Electro CD080-A Bedienungsanleitung

Polar Electro

Polar Electro UA001 Bedienungsanleitung

Polar Electro

Polar Electro G592 Bedienungsanleitung

Polar Electro

Polar Electro G Series Bedienungsanleitung

Polar Electro

Polar Electro Deli CG841-A Bedienungsanleitung

Polar Electro

Polar Electro G596-A Bedienungsanleitung

Polar Electro

Polar Electro GL180 Bedienungsanleitung

Polar Electro

Polar Electro CR711 Bedienungsanleitung

Polar Electro

Polar Electro FD169 Bedienungsanleitung

Polar Electro

Polar Electro GL180-A Bedienungsanleitung

Polar Electro

Polar Electro FA854 Bedienungsanleitung

Polar Electro

Polar Electro CD080-A Bedienungsanleitung

Polar Electro

Polar Electro UA001-A Bedienungsanleitung

Polar Electro

Polar Electro CS102 Bedienungsanleitung

Polar Electro

Polar Electro GH215-A Bedienungsanleitung

Polar Electro

Polar Electro CD610 Bedienungsanleitung

Polar Electro

Polar Electro GD881 Bedienungsanleitung

Polar Electro

Polar Electro CD610 Bedienungsanleitung

Polar Electro

Polar Electro G590/G591/G592/G593/G594/G595/U632/U633/U634/U635/CC663/CD616/GD879/GD880/ Bedienungsanleitung

Polar Electro

Polar Electro CM287 Bedienungsanleitung

Polar Electro

Polar Electro G609 Bedienungsanleitung

Polar Electro

Polar Electro CP728-A Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
