Portable DVD Player with Swivel Screen
User’s Manual
Important Safety Instructions
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USE-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightening flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute
a risk of electrical shock.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
Caution: Laser radiation when open. Do not stare into beam.
CAUTION: USE OFANY CONTROLS, ADJUSTMENTS, OR PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
Power Supply:
Connect the supplied power adapter to the side of the DVD player in the slot marked “DC In”. Plug the two-
prong end of the power cord to an AC outlet. If you have difficulty inserting the plug, turn it over and reinsert
it; if the player will not be used for a long time, disconnect the power from the outlet.
Note: before plugging in the power cord to an AC outlet, make sure that all the connections have been made.
2
Important Safety Instructions
CAUTION: These servicing instructions are for use by qualified service personnel only. To reduce the risk of
electric shock, do not perform any servicing other than that contained in the operating instructions unless you
are qualified to do so.
Refer to service manual for servicing instructions.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with dry cloth.
Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Do not install near any hear sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug has two blades and a third grounding prong. The
wide blade or the third prong is provided for your safety. If the provided plug does not fit in your outlet,
consult an electrician for replacement of the obsolete outlet.
Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
at the point where they exit the apparatus.
Only use attachments/accessories specified by the manufacturer.
Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the
apparatus. When a card is used, use caution when moving the car/apparatus to avoid injury from tip-over.
Unplug this apparatus during lightening storms or when unused for long periods of time.
Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damages in
any way, which as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
Note: Do not touch the color TFT LCD screen by hand directly.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
3
Important Safety Instructions
Copyright Protection
This product incorporates copyright protection technology that is protected by U.S. patents and other
intellectual property rights. Use of this copyright protection technology must be authorized by Macrovision,
and is intended for home and other limited viewing uses only unless otherwise authorized by Macrovision.
Reverse engineering or disassembly is prohibited.
Region Code Information
DVD players and discs are coded by region. If the region number described on the DVD disc does not
correspond to the region number of this product, this product cannot play the disc.
WEEE
IMPORTANT FOR LASER PRODUCTS
CLASS 1 LASER PRODUCT
DANGER: Visible laster radiation when open and interlock failed or
defected. Avoid direct exposure to beam.
CAUTION: Do not open the top cover. There are no user serviceable
parts inside the player. Leave all servicing to qualified personnel.
1.
2.
3.
This product contains electrical or electronic materials. The presence of these
materials may, if not disposed of properly, have potential adverse effects on the
environment and human health. Presence of this label on the product means it
should not be disposed of as unsorted waste and must be collected separately. As a
consumer, you are responsible for ensuring that this product is disposed of properly.
To find out how to properly dispose of this product, please go to www.polaroid.
com and click on “Company“ or call the customer service number for your country
listed in the instruction manual.
4
Features
High-quality Audio and Video
Excellent Sound: Dolby Digital Decoder delivers great sound.
AV Input: External audio, video can be connected to most external AV sources.
AV Output: Analog audio output can be connected to external amplifier.
Advanced Playing Functions
Compatibility: Compatible with DVD, CD, and JPEG discs, etc.
On-Screen Display: You can choose English, French, Spanish, etc. for the on-screen display language.
Particular Performance: Multi-speed, fast forward, fast backward, slow playback, and repeated
playback.
Search by Time: Search for a certain track of a disc by selected time.
Last Memory Playback: Memorizes the stopped playback track and continues playing the disc from
this spot when the power remains on. (Only available for DVD and CD discs.)
Special Functions: Supports screen multi-angle viewing and zooming functions.
Other Special Functions
High Resolution: MPEG-2 decoding format archieves more than 500 lines of horizontal resolution.
Power Adapter Switch: Automatically adapts to voltage requirements in UK and other countries.
•
•
•
•
•
•
•
•
•
•
•
5
Accessories
6
ITEM
ITEM
NAME
NAME
Remote Control (with battery)
Power Supply Cord with AC Adaptor
Rechargeable Battery Pack
DC Adapter (Car Adapter)
Audio/Video Cord
Headphone
Carrying Case / Car Bag
Operation Manual
Note: Accessories and their parts numbers are subject to change without prior notice.
Your portable DVD player may not include all accessories listed below.
To purchase additional accessories for your player, visit www.polaroid.com.
Contents
7
Important Safety Instructions 2
Features 5
Accessories 6
View of Front Panel 8
View of Side Panel 9
View of Bottom Panel 10
Revolving LCD Screen 11
Remote Control 12
System Connections 14
Power Supply 15
Rechargeable Battery 16
Notes on Discs 18
Playback Operation 19
DVD Playback 20
CD Playback 21
JPEG Playback 22
System Setup 24
Definitions 26
Troubleshooting 27
Specifications 28
View of Front Panel*
FUNCTION button: press to enter the brightness, contrast, or color adjusting mode
button: press to stop playback or press it twice to stop completely
S/button: press Sto select different items; press to go to previous list/track/chapter
MENU button: press to access the DVD disc menu during playback
/button: press to select different items; press and hold to search backwards fast
button: press to pause the playback
T/button: press Tto select different items; press to go to next list/track/chapter
Disc tray: when the disc tray is loaded, gently press the cover to close it
OPEN switch: push to open the disc tray cover
LCD screen
ENTER button: press ENTER to confirm selection
AUDIO button: press to access the DVD disc language during playback
SETUP button: press to access or exit the system setup menu
TITLE button: press to display the title menu
/button: press to select different items; press and hold to search forward fast
Speaker
LCD on/off switch
Working/Standby indicator
Charge indicator: light is red when the battery is being charged; green when battery is fully charged.
Remote sensor
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
8
* Your portable DVD player may differ from the player shown.
View of Side Panel*
Side View
Volume Control Knob: Used to adjust the volume of headphones and speaker
Headphone Jack: Used to connect to headphones for private listening. When headphone is plugged in,
the speakers will automatically turnoff.
Headphone Jack
Audio/Video Output Jack: For connecting to an external amplifier or monitor source
Power ON/OFF Switch: Switch the power on or off
DC 9/12V Input Jack: Used to connect the DC 9/12V adaptor
1.
2.
3.
4.
5.
6.
9
* Your portable DVD player may differ from the player shown.
View of Bottom Panel*
Rechargeable Battery Contacts: For connecting the rechargeable battery pack
Note: All markings are on the bottom of the portable DVD player.
1.
10
* Your portable DVD player may differ from the player shown.
