Polsen HPS-A40 Bedienungsanleitung
HPS-A40
HEADPHONES
THREE-LEVEL
BASS ADJUSTMENT
PRODUCT
MANUAL
2
THANK YOU FOR CHOOSING POLSEN.
Polsen’s HPS-A40 headphones are designed for studio tracking and mixing, as well as DJ and personal
monitoring applications. The 40 mm Neodymium drivers deliver a wide frequency response with high
sensitivity for accurate and detailed audio.
The HPS-A40 headphones feature a unique three-step bass adjustment switch on each driver that allows you
to adjust the low end to your taste. Each step adds 3 dB at 200 Hz, the heart of bass frequencies. With less
bass, vocals and speech are clearer and more understandable. Increasing the bass adds texture and depth to
music and soundtracks.
The headphone’s over-the-ear design offers sound isolation in noisy environments. Each earphone swivels
up to 90 degrees for convenient one-ear monitoring. The single-sided detachable cable terminates with a
1/8-inch (3.5 mm) mini plug and comes with a 1/4-inch adapter for compatibility with portable devices and
computers, as well as home stereos, headphone amps, and mixing boards. Thick replaceable ear cushions and
a padded headband provide comfort throughout long monitoring sessions.
3
PRECAUTIONS
•Keep this unit away from water and any flammable gases or liquids
•Clean the unit with only a soft, dry cloth.
•Make sure that this product is intact and that there are no missing parts.
•Be mindful of your surrounding environment when using this product. Do not use this product while driving
an automobile, operating machinery, or performing other tasks that require your undivided attention.
•All images are for illustrative purposes only.
Protect your hearing
Exposure to high sound pressure levels may cause permanent hearting loss. Avoid listening at high volumes for
extended periods.
Symptoms of noise-induced hearing loss may include persistent ringing, pain, itching, or inflammation of the ears, and
difficulty understanding speech.
For more information visit:
http://www.osha.gov/SLTC/noisehearingconservation/
https://www.cdc.gov/nceh/hearing_loss/
Please note:Government URLs are subject to change. If these links don’t connect you to the right information, we
recommend that you visit www.cdc.gov and www.osha.gov or do an Internet search for the phrase “hearing loss.”
4
1. 3-level bass adjustment switch
2. 2.5 mm input jack
3. Replaceable ear cushions
Also Included:
Detachable cable
Screw-on 1/4-inch adapter
Carry pouch 1.
2.
3.
OVERVIEW
5
CONNECTING THE HPS-A40
Plug the included cable’s 2.5 mm connector into the input jack on the headphones.
Plug the cable’s 1/8-inch (3.5 mm) connector into a device such as a smartphone, MP3 player, portable
stereo,
or computer.
Use the 1/8 to 1/4-inch adapter to connect your headphones to devices with a 1/4-inch headphone jack
such as an amplier, home stereo, or mixing board.
ADJUSTING THE BASS LEVEL
Each side of the headphone has a three-step bass adjustment selector.
Up (no exposed vents):subtle bass
For the least amount of bass, use this setting for clearer and more
intelligible vocals and speech. Music tracks sound bright and present
6
with this setting.
Middle (one exposed vent):+3 dB of bass
This setting adds a subtle boost to the low frequencies. It adds
dimension and depth to your audio.
Down (two exposed vents):+6 dB of bass
This setting gives the bass frequencies an extra boost. It’s good
for contemporary music and adds depth and richness to live music
performance, as well as jazz and classical recordings.
7
TYPE Circumaural, closed back
FREQUENCY RESPONSE 10 Hz to 20 kHz
IMPEDANCE 32 Ω ±15%
SENSITIVITY 96 dB ±3 dB @1 kHz
MAXIMUM POWER RATING 20 mW
RATED POWER 10 mW
MAGNET TYPE Neodymium
DRIVER DIAMETER 1.6 in. (40 mm)
CABLE DIAMETER 0.16 in. (4 mm)
CABLE LENGTH 6.2 ft. (1.9 m)
WEIGHT 8.4 oz. (237 g)
SPECIFICATIONS
8
ONE-YEAR LIMITED WARRANTY
This Polsen product is warranted to the original purchaser to be free from defects in materials and workmanship under normal consumer
use for a period of one (1) year from the original purchase date or thirty (30) days after replacement, whichever occurs later. The warranty
provider’s responsibility with respect to this limited warranty shall be limited solely to repair or replacement, at the provider’s discretion,
of any product that fails during normal use of this product in its intended manner and in its intended environment. Inoperability of the
product or part(s) shall be determined by the warranty provider. If the product has been discontinued, the warranty provider reserves the
right to replace it with a model of equivalent quality and function.
This warranty does not cover damage or defect caused by misuse, neglect, accident, alteration, abuse, improper installation or
maintenance. EXCEPT AS PROVIDED HEREIN, THE WARRANTY PROVIDER MAKES NEITHER ANY EXPRESS WARRANTIES NOR ANY IMPLIED
WARRANTIES, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. This warranty provides you with specic legal rights, and you may also have additional rights that vary from state to state.
To obtain warranty coverage, contact the Polsen Customer Service Department to obtain a return merchandise authorization (“RMA”)
number, and return the defective product to Polsen along with the RMA number and proof of purchase. Shipment of the defective product
is at the purchaser’s own risk and expense.
For more information or to arrange service, visit www.polsenaudio.com or call Customer Service at 212-594-2353.
Product warranty provided by the Gradus Group.
www.gradusgroup.com
Polsen is a registered trademark of the Gradus Group. ©2018 Gradus Group LLC. All Rights Reserved. GG2
