Porter-Cable C2025 Bedienungsanleitung

Française : Page 21

Español: Página 42

C2025

OIL-FREE HOTDOG

AIR COMPRESSOR

Compresor sin aceite con

forma de salchichade aire

Compresseur allongé

sans huile

Instruction manual

Manuel d'instructions

Manual de'instrucciones

www.deltaportercable.com

INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y

PÓLIZA DE GARANTÍA.

LÉASE ESTE INSTRUCTIVO ANTES

DE USAR EL PRODUCTO.

2 - ENGN000732

SAFETY GUIDELINES - DEFINITIONS

This manual contains information that is important for you to know and under-

stand. This information relates to protecting YOUR SAFETY and PREVENTING

EQUIPMENT PROBLEMS. To help you recognize this information, we use the

symbols below. Please read the manual and pay attention to these symbols.

Indicates an

imminently hazardous

situation which, if not avoided, will

result in death or serious injury.

Indicates a potentially

hazardous situation

which, if not avoided, may result in

minor or moderate injury.

Indicates a potentially

hazardous situation

which, if not avoided, could result in

death or serious injury.

Used without the

safety alert symbol

indicates a potentially hazardous

situation which, if not avoided, may

result in property damage.

IMPORTANT SAFETY INSTRUCTIONS

Some dust created by power sanding, sawing, grinding,

drilling, and other construction activities contains chemicals

known to the State of California to cause cancer, birth defects or other

reproductive harm. Some example of these chemicals are:

• leadfromlead-basedpaints

• crystallinesilicafrombricksandcementandothermasonryproducts

• arsenicandchromiumfromchemically-treatedlumber

Your risk from these exposures varies, depending on how often you do this

type of work. To reduce your exposure to these chemicals: work in a well

ventilated area, and work with approved safety equipment, always wear

OSHA/MSHA/NIOSH approved, properly fitting face mask or respirator when

using such tools.

When using air tools, basic safety precautions should always be followed to

reduce the risk of personal injury.

This product contains chemicals, known to the State of

California to cause cancer, and birth defects or other

reproductive harm. Wash hands after handling.

Do not operate this unit until you read and

understand this instruction manual for safety,

operation and maintenance instructions.

SAVE THESE INSTRUCTIONS

HAZARD

RISK OF EXPLOSION OR FIRE

WHAT CAN HAPPEN HOW TO PREVENT IT

• Itisnormalforelectricalcon-

tacts within the motor and

pressure switch to spark.

• Alwaysoperatethecompres-

sor in a well ventilated area

free of combustible materials,

gasoline, or solvent vapors.

3 - ENG N000732

• Ifelectricalsparksfromcom-

pressor come into contact with

flammable vapors, they may

ignite, causing fire or explosion.

• Ifsprayingflammablemateri-

als, locate compressor at least

20 feet (6.1 m) away from spray

area.Anadditionallengthof

air hose may be required.

• Storeflammablemateri-

als in a secure location

away from compressor.

• Restrictinganyofthecom-

pressor ventilation openings

will cause serious overheat-

ing and could cause fire.

• Neverplaceobjectsagainst

or on top of compressor.

• Operatecompressorinanopen

area at least 12" (30.5 cm) away

from any wall or obstruction that

would restrict the flow of fresh

air to the ventilation openings.

• Operatecompressorina

clean, dry well ventilated area.

Do not operate unit indoors

or in any confined area.

• Unattendedoperationofthisprod-

uctcouldresultinpersonalinjury

or property damage. To reduce the

risk of fire, do not allow the com-

pressor to operate unattended.

• Alwaysremaininattendancewith

the product when it is operating.

• Alwaysturnoffandunplug

unit when not in use.

HAZARD

RISK TO BREATHING (ASPHYXIATION)

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairdirectlyfrom

your compressor is not safe

for breathing. The air stream

may contain carbon monoxide,

toxic vapors, or solid particles

from the air tank. Breathing

these contaminant's can cause

seriousinjuryordeath.

• Airobtaineddirectlyfromthe

compressor should never be

used to supply air for human

consumption. In order to use air

produced by this compressor

for breathing, suitable filters and

in-line safety equipment must be

properly installed. In-line filters and

safetyequipmentusedinconjunc-

tion with the compressor must

be capable of treating air to all

applicable local and federal codes

prior to human consumption.

• Sprayedmaterialssuchas

paint, paint solvents, paint

remover, insecticides, weed

killers, may contain harm-

ful vapors and poisons.

• Workinanareawithgoodcross

ventilation.Readandfollowthe

safety instructions provided on

the label or safety data sheets

for the materials you are spray-

ing.Alwaysusecertifiedsafety

equipment:OSHA/MSHA/NIOSH

respiratory protection designed for

use with your specific application.

4 - ENGN000732

HAZARD

RISK OF BURSTING

Air Tank: TheairtankonyourAirCompressorisdesignedandmaybeUM

coded[forunitswithairtanksgreaterthan6"(152mm)]accordingtoASME

SectionVIII,Div.1rules.Allpressurevesselsshouldbeinspectedonce

every two years. To find your state pressure vessels inspector, look under the

Division of Labor and Industries in the government section of a phone book .

The following conditions could lead to a weakening of the

air tank, and result in a violent air tank explosion:

WHAT CAN HAPPEN HOW TO PREVENT IT

• Failuretoproperlydrain

condensed water from air

tank, causing rust and thin-

ning of the steel air tank.

• Drainairtankdailyorafter

each use. If air tank develops

a leak, replace it immediately

with a new air tank or replace

the entire compressor.

• Modificationsorattempted

repairs to the air tank. • Neverdrillinto,weld,ormakeany

modifications to the air tank or its

attachments. Never attempt to

repair a damaged or leaking air

tank.Replacewithanewairtank.

• Unauthorizedmodifica-

tions to the safety valve or

any other components which

control air tank pressure.

• Theairtankisdesignedtowith-

stand specific operating pres-

sures.Nevermakeadjustments

or parts substitutions to alter the

factory set operating pressures.

Attachments & accessories:

• Exceedingthepressurerat-

ing of air tools, spray guns, air

operated accessories, tires,

and other inflatables can cause

them to explode or fly apart, and

couldresultinseriousinjury.

• Followtheequipmentmanufactur-

ers recommendation and never

exceed the maximum allow-

able pressure rating of attach-

ments. Never use compressor

to inflate small low pressure

objectssuchaschildren’stoys,

footballs, basketballs, etc.

Tires

• Over inflation of tires could result in

seriousinjuryandpropertydamage. • Useatirepressuregaugetocheck

the tires pressure before each use

and while inflating tires; see the tire

sidewall for the correct tire pressure.

NOTE:Airtanks,compressorsand

similar equipment used to inflate tires

can fill small tires similar to these very

rapidly.Adjustpressureregulatoron

air supply to no more than the rating

ofthetirepressure.Addairinsmall

increments and frequently use the

tire gauge to prevent over inflation.

5 - ENG N000732

HAZARD

RISK OF ELECTRICAL SHOCK

WHAT CAN HAPPEN HOW TO PREVENT IT

• Your air compressor is pow-

ered by electricity. Like any

other electrically powered

device, If it is not used properly

it may cause electric shock.

• Never operate the compres-

sor outdoors when it is rain-

ing or in wet conditions.

• Never operate compres-

sor with protective covers

removed or damaged.

• Repairsattemptedbyunqualified

personnel can result in serious

injuryordeathbyelectrocution.

• Anyelectricalwiringorrepairs

required on this product should be

performed by authorized service

center personnel in accordance with

national and local electrical codes.

• Electrical Grounding: Failure

to provide adequate grounding

to this product could result in

seriousinjuryordeathfrom

electrocution.Referto"Grounding

Instructions" paragraph in

the "Installation" section.

• Makecertainthattheelectrical

circuit to which the compressor

is connected provides proper

electrical grounding, correct voltage

and adequate fuse protection.

HAZARD

RISK FROM FLYING OBJECTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Thecompressedairstreamcan

cause soft tissue damage to

exposed skin and can propel dirt,

chips, loose particles, and small

objectsathighspeed,resultingin

propertydamageorpersonalinjury.

• Alwayswearcertifiedsafetyequip-

ment:ANSIZ87.1eyeprotection

(CAN/CSAZ94.3)withsideshields

when using the compressor.

• Neverpointanynozzleorsprayer

toward any part of the body or

at other people or animals.

• Alwaysturnthecompressor

off and bleed pressure from

the air hose and air tank before

attempting maintenance, attach-

ing tools or accessories.

6 - ENGN000732

HAZARD

RISK OF HOT SURFACES

WHAT CAN HAPPEN HOW TO PREVENT IT

• Touchingexposedmetalsuch

as the compressor head, engine

head, engine exhaust or outlet

tubes, can result in serious burns.

• Nevertouchanyexposedmetal

parts on compressor during or

immediately after operation.

Compressorwillremainhotfor

several minutes after operation.

• Donotreacharoundprotective

shrouds or attempt maintenance

until unit has been allowed to cool.

HAZARD

RISK FROM MOVING PARTS

WHAT CAN HAPPEN HOW TO PREVENT IT

• Movingpartssuchasthepulley,

flywheel, and belt can cause

seriousinjuryiftheycomeinto

contact with you or your clothing.

• Neveroperatethecompressor

with guards or covers which

are damaged or removed.

• Keepyourhair,clothing,and

gloves away from moving parts.

Looseclothes,jewelry,orlonghair

can be caught in moving parts.

• Airventsmaycovermovingparts

and should be avoided as well.

• Attemptingtooperatecompressor

with damaged or missing parts or

attempting to repair compressor

with protective shrouds removed

can expose you to moving parts

andcanresultinseriousinjury.

• Anyrepairsrequiredonthisproduct

should be performed by authorized

service center personnel.

7 - ENG N000732

HAZARD

RISK OF UNSAFE OPERATION

WHAT CAN HAPPEN HOW TO PREVENT IT

• Unsafeoperationofyourair

compressor could lead to serious

injuryordeathtoyouorothers.

• Reviewandunderstandall

instructions and warnings

in this manual.

• Becomefamiliarwiththe

operation and controls of

the air compressor.

• Keepoperatingareaclearofall

persons, pets, and obstacles.

• Keepchildrenawayfromthe

air compressor at all times.

• Donotoperatetheproduct

when fatigued or under the

influence of alcohol or drugs.

Stayalertatalltimes.

• Neverdefeatthesafetyfea

tures of this product.

• Equipareaofoperation

with a fire extinguisher.

• Donotoperatemachine

with missing, broken, or

unauthorized parts.

HAZARD

RISK OF FALLING

WHAT CAN HAPPEN HOW TO PREVENT IT

• Aportablecompressorcan

fall from a table, workbench,

or roof causing damage to

the compressor and could

resultinseriousinjuryor

death to the operator.

• Alwaysoperatecompressorina

stable secure position to prevent

accidental movement of the

unit. Never operate compressor

on a roof or other elevated

position. Use additional air

hose to reach high locations.

HAZARD

RISK FROM NOISE

WHAT CAN HAPPEN HOW TO PREVENT IT

• Undersomeconditions

and duration of use, noise

from this product may

contribute to hearing loss.

• Alwayswearcertifiedsafety

equipment:ANSIS12.6

(S3.19)hearingprotection.

SAVE THESE INSTRUCTIONS

FOR FUTURE USE

8ENGN000732

SPECIFICATIONS

Model No. C2025

Bore  1.875"

Stroke 1.250"

Voltage/HzSinglePhase 120/60

MinimumBranchCircuitRequirement 15amps

FuseType TimeDelay

AirTankCapacity(Gallon) 2.5

ApproximateCutinPressure 120psiG

ApproximateCutoutPressure 150psiG

SCFM@40psiG *3.7

SCFM@90psiG *2.6

*TestedperISO1217

RefertoGlossaryforabbreviations.

GLOSSARY

Become familiar with these terms before operating the unit.

CFM: Cubicfeetperminute.

SCFM: Standardcubicfeetperminute;aunitofmeasureofairdelivery.

psiG: Pounds per square inch gauge; a unit of measure of pressure.

Code Certification: Products that bear one or more of the following marks: UL,

CUL,ETL,CETL,havebeenevaluatedbyOSHAcertifiedindependentsafetylabo-

ratoriesandmeettheapplicableStandardsforSafety.

Cut-In Pressure: Whilethemotorisoff,airtankpressuredropsasyoucontinue

touseyouraccessory.Whenthetankpressuredropstoacertainlowerlevelthe

motor will restart automatically. The low pressure at which the motor automatically

restarts is called "cut-in" pressure.

Cut-Out Pressure: Whenanaircompressoristurnedonandbeginstorun,air

pressure in the air tank begins to build. It builds to a certain high pressure before

the motor automatically shuts off, protecting your air tank from pressure higher

than its capacity. The high pressure at which the motor shuts off is called "cut-

out" pressure.

Branch Circuit: Circuitcarryingelectricityfromelectricalpaneltooutlet.

DUTY CYCLE

Thisaircompressorpumpiscapableofrunningcontinuously.However,to

prolong the life of your air compressor, it is recommended that a 50%-75%

average duty cycle be maintained; that is, the air compressor pump should not

run more than 30-45 minutes in any given hour.

ACCESSORIES

Accessoriesforthisunitareavailableatthestoretheunitwaspurchased.

9ENG N000732

ASSEMBLY

Unpacking

1. Removeunitfromcartonanddiscardallpackaging.

INSTALLATION

HOW TO SET UP YOUR UNIT

Location of the Air Compressor

• Locatetheaircompressorinaclean,dryandwellventilatedarea.

• Theaircompressorshouldbelocatedatleast12"(30.5cm)awayfromthe

wall or other obstructions that will interfere with the flow of air.

• Theaircompressorpumpandshroudaredesignedtoallowforpropercooling.

The ventilation openings on the compressor are necessary to maintain proper

operating temperature. Do not place rags or other containers on or near these

openings.

GROUNDING INSTRUCTIONS

Risk of Electrical Shock. In the event of a short circuit, ground-

ing reduces the risk of shock by providing an escape wire for the electric cur-

rent. This air compressor must be properly grounded.

The portable air compressor is equipped with a cord having a grounding wire with

an appropriate grounding plug (see following illustrations).

1. The cord set and plug with this unit contains a grounding pin. This plug

MUSTbeusedwithagroundedoutlet.

IMPORTANT: The outlet being used must

Grounded

Outlets

Plug

Grounding Pin

be installed and grounded in accordance

with all local codes and ordinances.

2. Makesuretheoutletbeingusedhas

the same configuration as the ground-

ed plug. DO NOT USE AN ADAPTER.

Seeillustration.

3. Inspect the plug and cord before each

use. Do not use if there are signs of damage.

4. If these grounding instructions are not completely understood, or if in doubt as

to whether the compressor is properly grounded, have the installation checked

by a qualified electrician.

Risk of Electrical Shock. IMPROPER GROUNDING CAN

RESULT IN ELECTRICAL SHOCK.

Do not modify the plug provided. If it does not fit the available outlet, a correct

outlet should be installed by a qualified electrician.

Repairs to the cord set or plug MUST be made by a qualified electrician.

10 - ENGN000732

EXTENSION CORDS

If an extension cord must be used, be sure it is:

• a3wireextensioncordthathasa3bladegroundingplug,anda3slotrecep-

tacle that will accept the plug on the product

• ingoodcondition

• nolongerthan50feet

• 14gauge(AWG)orlarger.(Wiresizeincreasesasgaugenumberdecreases.

12AWGand10AWGmayalsobeused.DONOTUSE16OR18AWG.)

The use of an undersized extension cord will cause voltage to

drop resulting in power loss to the motor and overheating. Instead of using

an extension cord, increase the working reach of the air hose by attach-

ing another length of hose to its end. Attach additional lengths of hose as

needed.

VOLTAGE AND CIRCUIT PROTECTION

Refertothespecificationchartforthevoltageandminimumbranchcircuitrequire-

ments.

Risk of Opertion.Certain air compressors can be operated on

a 15 amp circuit if the following conditions are met.

1. VoltagesupplytocircuitmustcomplywiththeNationalElectricalCode.

2. Circuitisnotusedtosupplyanyotherelectricalneeds.

3. Extension cords comply with specifications.

4. Circuitisequippedwitha15ampcircuitbreakeror15amptimedelayfuse.

NOTE: If compressor is connected to a circuit protected by fuses, use only

timedelayfuses.Timedelayfusesshouldbemarked"D"inCanadaand"T"

intheUS.

If any of the above conditions cannot be met, or if operation of the compressor

repeatedly causes interruption of the power, it may be necessary to operate it from

a 20 amp circuit. It is not necessary to change the cord set.

Inhaltsverzeichnis

Sprachen:

Andere Porter-Cable Luftkompressor Handbücher

Porter-Cable

Porter-Cable PXCMLC3706056 Bedienungsanleitung

Porter-Cable

Porter-Cable 888970-799 Bedienungsanleitung

Porter-Cable

Porter-Cable 1000003754 Bedienungsanleitung

Porter-Cable

Porter-Cable CPLDC2541S Bedienungsanleitung

Porter-Cable

Porter-Cable C2002-WK Bedienungsanleitung

Porter-Cable

Porter-Cable C2555 Bedienungsanleitung

Porter-Cable

Porter-Cable C2004 Bedienungsanleitung

Porter-Cable

Porter-Cable JOB BOSS C3150 Bedienungsanleitung

Porter-Cable

Porter-Cable CPF23400S Bedienungsanleitung

Porter-Cable

Porter-Cable C6110 Bedienungsanleitung

Porter-Cable

Porter-Cable JOB BOSS C3555 Bedienungsanleitung

Porter-Cable

Porter-Cable CPLC7060V Bedienungsanleitung

Porter-Cable

Porter-Cable 1000001703 Bedienungsanleitung

Porter-Cable

Porter-Cable CF1540 Bedienungsanleitung

Porter-Cable

Porter-Cable CPLMC7580V2C Bedienungsanleitung

Porter-Cable

Porter-Cable CPLMC7580V2C Bedienungsanleitung

Porter-Cable

Porter-Cable CPLMC7580V2C Bedienungsanleitung

Porter-Cable

Porter-Cable CPF23400P Bedienungsanleitung

Porter-Cable

Porter-Cable PXCM302 Bedienungsanleitung

Porter-Cable

Porter-Cable C6110 Bedienungsanleitung

Porter-Cable

Porter-Cable A18760-1006-1 Bedienungsanleitung

Porter-Cable

Porter-Cable PXCMF220VW Bedienungsanleitung

Porter-Cable

Porter-Cable 1000003145 Bedienungsanleitung

Porter-Cable

Porter-Cable PXCM201 Bedienungsanleitung

Beliebte Luftkompressor Handbücher anderer Marken

Sparmax

Sparmax DC-25XR Bedienungsanleitung

KAESER

KAESER M122 Bedienungsanleitung

GMC

GMC GAC1500 Bedienungsanleitung

Briggs & Stratton

Briggs & Stratton Air Compressor Bedienungsanleitung

Fini

Fini F3GST2TK Bedienungsanleitung

Industrial Air

Industrial Air CP1580325 Programmierhandbuch

Campbell Hausfeld

Campbell Hausfeld RP3300 Kurzanleitung

Ingersoll-Rand

Ingersoll-Rand UP6 20 HP Bedienungsanleitung

Hitachi

Hitachi EC99S Bedienerhandbuch

Parkside

Parkside PKO 270 A1 Bedienungsanleitung

Sullair

Sullair 185 Bedienungsanleitung

Clas Ohlson

Clas Ohlson QIE-ZTH-15 Bedienungsanleitung

Ferm

Ferm CRM1046 Bedienungsanleitung

BE AC153 Bedienungsanleitung

RIDGID

RIDGID OF25150A Bedienungsanleitung

Johnson Controls

Johnson Controls QUANTUM LX Handbuch

Sears

Sears Craftsman 919.167463 Bedienungsanleitung

Ring Automotive

Ring Automotive RAC700 Bedienungsanleitung
