Automatic Voltage Regulator
PowerWalker AVR 500/SIV
PowerWalker AVR 1000/SIV
PowerWalker AVR 1500/SIV
PowerWalker AVR 2000/SIV
PowerWalker AVR 3000/SIV
Quick Start Guide
EN
EN
1. Introduction
This AVR/SIV series is designed to automatically maintain a constant voltage level to protect
sensitive electronics from brownouts and overvoltages. Equipped with comprehensive information
displa, it’s eas to oitor the poer status.
PowerWalker AVR 500/1000/1500/2000/3000/SIV Digital type series adopt switching mode
charging which creates a variety of benefits:
Microprocessor control guarantees high reliability
Selectable input voltage range
Time delay function eliminates transients that can affect connected equipment
Startup countdown time display
Over-voltage, under-voltage, over-heat and over current protection
Provides surge and spike suppression
2. Package Contents
You should have received the following items inside of package:
AVR Unit
Quick Start Guide
EN
3. Product Overview
Front Panel:
Power switch
Output voltage display/Startup countdown display
Input voltage display
Handle (Optional for 500VA/1000VA)
Startup delay time switch
Input voltage range selector
Power LED (Green)
AVR LED (Yellow)
Over-voltage / under-voltage indicator (Red)
Back Panel:
AVR 500/1000/SIV
AVR 1500/2000/SIV
AVR 3000/SIV
Output sockets for
French /Schuko
AC input
Output sockets for
French /Schuko
AC input
Output sockets for French /Schuko
AC input
Grounding
Line output terminal (brown)
Neutral output terminal (black)
French Schuko
EN
4. Installation
I: Inspection
Remove the AVR from the shipping package and inspect the unit. Be sure that nothing inside the
package is damaged.
II: Placement
Please install the AVR in a protected environment.
Do NOT block the top or side air vents on the unit. Please
reserve 20cm space to avoid interference.
Do NOT operate the AVR where the temperature and humidity
is outside the specific limits. (Please check the specs for the
limitations.)
III: Connect to Utility and Charging
Plug in the AC input cord to the wall outlet.
IV: Connect Your Equipment
Plug equipment into the AVR rear-panel outlets. Then switch the unit on by press the front panel
poer sitch to RESET positio.
5. Operation
I: Setting Startup Delay Time Switch
Delay : Settig dela tie as 3 iutes. It’s desiged to aoid daage deices ith AC
motor from consecutive starts. It’s perfect to use ith deices such as refrigerators, freezers,
air conditioners or dehumidifiers.
Undelay : Settig dela tie as secods. It’s desiged for use ith oltage sesitie
equipment such as: personal computers, monitors, inkjet printers, scaers or faes. It’s also
designed for use with home appliances such as televisions, stereos, CD/DVD players, VCRs,
modems, and telephone equipment.
II: Setting Input Voltage Range
The total power consumption of all equipment plugged into the AVR must not exceed
its capacity (Refer to spec). It may cause the breaker to fault (blow).
EN
110-280 V : Setting acceptable input voltage range within 110-280V.
150-270 V : Setting acceptable input voltage range within 150-270V.
6. Specifications
Model
PowerWalker AVR 500/SIV
PowerWalker AVR 1000/SIV
Capacity
500VA
1000VA
Input
Voltage
230VAC
Voltage Range
110-280VAC or 150-270 VAC
Frequency Range
50 Hz or 60 Hz
Output
Output Voltage
230VAC
Voltage Regulation
-10% ~ +10%
Efficiency
Normal Mode
95%
AVR Mode
92%
Physical
Dimension (DxWxH)
196.8 x 110 x 123.5
Net Weight (kgs)
2.4
3.91
Environment
Temperature
0-40°C
Humidity
0-90% relative humidity (Non-condensing)
Model
PowerWalker AVR
1500/SIV
PowerWalker AVR
2000/SIV
PowerWalker AVR
3000/SIV
Capacity
1500VA
2000VA
3000VA
Input
Voltage
230VAC
Voltage Range
110-280VAC or 150-270 VAC
Frequency Range
50 Hz or 60 Hz
Output
Output Voltage
230VAC
Voltage Regulation
-10% ~ +10%
Efficiency
Normal Mode
95%
AVR Mode
92%
Physical
Dimension (DxWxH)
233.6 x 134 x 181
297.1x150x199
Net Weight (kgs)
5.4
6.55
8.56
Environment
Temperature
0-40°C
Humidity
0-90% relative humidity (Non-condensing)
