1. Introduction

This Online R/T Series is an uninterruptible power supply

incorporating double-conversion technology. It provides perfect

protection specifically for computer equipment, communication

systems to computerized instruments. It protects your sensitive

electronic equipment from basic power problems such as power

failures, power sags, power surges, brownout, and line noise.

Power outages can occur when you least expect them and power

quality can be erratic. These power problems have the potential to

corrupt critical data, destroy unsaved work sessions, and damage

hardware

－

causing hours of lost productivity and expensive

repairs.

With the Online R/T UPS, you can safely eliminate the effects of

power disturbances and guard the integrity of your equipment. The

UPS can handle array--network devices flexibility that makes it the

best choice for protect your LANs, servers, workstations, and other

electrical equipment.

Online R/T UPS as Rack installation:

Figure 1-1: Online R/T 6K UPS

Figure 1-2: Online R/T 10K UPS

Online R/T UPS as Tower installation.

Figure 1-3: Online R/T 6K UPS Figure 1-4: Online R/T 10K UPS

Providing outstanding performance and reliability, the UPS’s unique

benefits include:

Online UPS design with pure sine wave output.

True online double-conversion technology with high power

density, utility frequency independence, and generator

compatibility.

Intelligent Battery Management technology that uses advanced

battery management to increase battery service life, optimize

recharge time.

Selectable High Efficiency mode of operation.

Start-on-battery capability for powering up the UPS even if

utility power is not available.

Standard communication options: one RS-232 communication

port, one USB communication port.

Optional connectivity cards with enhanced communication

capabilities.

Extended runtime with up to four Extended Battery Modules

(EBMs) per UPS.

Optional installation method

－

Rack & Tower.

Remote shutdown control through the Remote Emergent

Power-off (REPO) port.

Maintenances are simplified by allowing the safe replacement

of batteries without powering down the UPS.

Parallel with another Online R/T UPS, max amount is 2.

Optional Rack Slider.

PDU is standard configuration with maintenance bypass

switch.

2. Safety Warnings

IMPORTANT SAFETY INSTRUCTIONS FOR EACH STEP SAVE

THESE INSTRRUCTIONS.

2.1 Installation

Condensation may occur if the UPS is moved directly from a

cold to a warm environment. The UPS must be absolutely dry

before being installed. Please allow an acclimatization time of

at least two hours.

Do not install the UPS near water or in damp environment.

Do not install the UPS where it would be exposed to direct

sunlight or near heat.

Do not block ventilation openings in the UPS’s housing.

Place cables in such a way that no one can step on or trip over

them.

UPS has provided earthed terminal, in the final installed system

configuration, equipotent earth bonding to the external UPS

battery cabinets.

An integral single emergency switching device which prevents

further supply to the load by the UPS in any operation mode

should be provided in the building wiring installation.

An appropriate disconnect device as short-circuit backup

protection should be provided in the building wiring installation.

For three-phase equipment connection to an IT power system,

a four-pole device which disconnect all phase conductors and

CAUTION:

Before performing the procedures in this document, read and follow

the safety instructions and important regulatory information in your

Safety, Environmental, and Regulatory Information document.

the neutral conductor should be provided in the building wiring

installation.

This is permanently connected equipment , it must be installed

by qualified maintenance personnel.

For permanently connected equipment: make sure that a

readily accessible disconnect device is incorporated in the

building installation wiring.

To reduce the risk of fire, connect only to a circuit provided with

branch circuit overcurrent protection with an ampere rating in

accordance with the IEC/EN 60934 standard or your local

electrical code and have a contact air gap of at least 3 mm.

Uninterruptible power supply

output power 240V

6K 40 amp

2-pole circuit breaker

10K 63 amp

2-pole circuit breaker

You can connect four extended battery modules to the

uninterruptible power supply.

Earthing connection is essential before connecting to the

building wiring terminal.

2.2 Operation

Do not disconnect the earth conductor cable from the UPS or

the building wiring terminals in any time since this would cancel

the protective earthing of the UPS system and all connected

loads.

The UPS output terminal block may be electrically active even if

the UPS system is not connected to the building wiring

terminal.

In order to completely disconnect the UPS, firstly press the

OFF button, and then disconnect the mains lead.

Ensure that no liquid or other foreign objects can enter the

UPS.

The UPS can be operated by any individual without previous

experience.

2.3 Maintenance, servicing and faults

The UPS operates with hazardous voltages. Maintenance

should be carried out only by qualified maintenance personnel.

Caution - risk of electric shock. Even after the unit is

disconnected from the mains power supply (building wiring

terminal), components inside the UPS are still connected to the

battery which have potentially dangerous.

Before carrying out any kind of service and/or maintenance,

please disconnect the batteries. Verify that no current is

present and no hazardous voltage exist in the capacitor or BUS

capacitor terminals.

Batteries must be replaced only by qualified personnel.

Caution – the risk of electric shock. The battery circuit is not

isolated from the input voltage. Hazardous voltage may occur

between the battery terminals and the ground. Verify that no

voltage is present before servicing!

Batteries have a high short-circuit current and pose a risk of

shock. Take all precautionary measures specified as below and

any other measures necessary when working with batteries:

1) Remove all jewellery, wristwatches, rings and other metal

objects

2) Use only tools with insulated grips and handles.

3) When changing batteries, replace with the same quantity

and the same type of batteries.

4) Do not attempt to dispose of batteries by burning them. It

could cause explosion.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere PowerWalker UPS Handbücher

PowerWalker

PowerWalker VFI 3000 LCD Installationsanleitung

PowerWalker

PowerWalker VFI 160K CPG 3/3 BX Bedienungsanleitung

PowerWalker

PowerWalker VFI 1000R LCD Bedienungsanleitung

PowerWalker

PowerWalker VFI 10000CP 3/3 Bedienungsanleitung

PowerWalker

PowerWalker VI 400 SE Bedienungsanleitung

PowerWalker

PowerWalker MBP 1-1 Bedienungsanleitung

PowerWalker

PowerWalker VFI 6000 ICT Bedienungsanleitung

PowerWalker

PowerWalker VFI 10K CPH Bedienungsanleitung

PowerWalker

PowerWalker VFI 6000 TGB Bedienungsanleitung

PowerWalker

PowerWalker VI 1200 RLE Bedienungsanleitung

PowerWalker

PowerWalker VFI 10000 CG PF1 Bedienungsanleitung

PowerWalker

PowerWalker VI 1000RT LCD Bedienungsanleitung

PowerWalker

PowerWalker VFI 1000 RMG PF1 Bedienungsanleitung

PowerWalker

PowerWalker BP P96T Administratorhandbuch

PowerWalker

PowerWalker VI THID Series Bedienungsanleitung

PowerWalker

PowerWalker VI 750 PSW Bedienungsanleitung

PowerWalker

PowerWalker VFI 1000RM Bedienungsanleitung

PowerWalker

PowerWalker VFI 1000 R1U Bedienungsanleitung

PowerWalker

PowerWalker VI TW Series Bedienungsanleitung

PowerWalker

PowerWalker VFI CPG PF1 3/3 Series Bedienungsanleitung

PowerWalker

PowerWalker VFI 3000T LCD Bedienungsanleitung

PowerWalker

PowerWalker 1000VA Bedienungsanleitung

PowerWalker

PowerWalker VFI 6000 CT LCD Bedienungsanleitung

PowerWalker

PowerWalker VFI 10000CP 3/3 Bedienungsanleitung

Beliebte UPS Handbücher anderer Marken

Pylontech

Pylontech Victron & Pylontech US5000 Bedienungsanleitung

Tecnoware

Tecnoware EVO DSP PLUS MM 6.8 Bedienungsanleitung

Mecer

Mecer ME-1000-WTU Bedienungsanleitung

Mustek

Mustek PowerMust 530(B) Plus Installations- und Betriebshandbuch

Emerson

Emerson Liebert NXL series Bedienungsanleitung

MAKELSAN

MAKELSAN BOXER SERIES Bedienungsanleitung

Block

Block PC-0524-400-0 Bedienungsanleitung

CyberPower

CyberPower CP585LCD Bedienungsanleitung

Eaton

Eaton 3S Montageanleitung

CyberPower

CyberPower Office Tower Series UPS 1000 Bedienungsanleitung

CyberPower

CyberPower BM100 Bedienungsanleitung

Best Power

Best Power 610 Bedienungsanleitung

Best Power

Best Power Unity/I UT3K Bedienungsanleitung

Mustek

Mustek PowerMust 400 Offline Bedienungsanleitung

Xantrex

Xantrex Trace 512 UR-UPS Bedienungsanleitung

Forza

Forza SL-1501UL Bedienungsanleitung

LEGRAND

LEGRAND keor 310081 Bedienungsanleitung

ABB

ABB Conceptpower DPA 500 Bedienungsanleitung
