Premium PFV30500MW Bedienungsanleitung
3.0 cu. ft.
3.0 cu. ft.
PFV30500MW
PFV30600MS
PFV30500MW
PFV30600MS
UPRIGHT FREEZER
CONGELADOR VERTICAL
PFV30500MW/PFV30600MS
3.0
115
60
57.3
R600a,1.59Oz
19.72*21.26*33.86
21.26*22.68*34.25
(cu.ft.)
from
When using, please use scissors
to cut out the plastic cable ties
in the picture from top to
bottom, a total of three cable
ties.
4
ceiling.
If you are installing your upright freezer next to a fixed wall,
leave enough space on the hinge side to allow that door
swings open freely.
Never install your upright freezer near heat source or direct
sun light.
ELECTRICAL REQUIREMENT
WARNING: DO NOT REMOVE GROUND PRONG.
DO NOT USE AN ADAPTOR.
DO NOT USE EXTENSION CORD.
Failure to follow these instructions can result in death, fire or
electrical shock.
Before you move your upright freezer into its final location, it
is important to make sure you have the proper electrical
connection.
Grounded power supply
AC 115Volt/60Hz, AC only, 10A fused and properly grounded
electrical supply is required. It is recommended to use a
separate circuit serving only this appliance. Use receptacles
which cannot be turned off with a switch or pull chain. Do not
use an extension cord.
5
NOTE: Before performing any type of maintenance or
installation, turn off and disconnect the upright freezer from
the electrical source. When you are finished, connect the
upright freezer to the electrical source and reset the control
to the desired setting.
LEVELING
It is very important that the freezer is leveled for proper
operation. If the upright freezer is not leveled during
installation; the doors may not close or seal properly, causing
cooling, frost, or moisture problems.
To level your upright freezer you may either turn the level leg
clockwise to raise that side or turn counter–clockwise to
lower that side.
NOTE: Having someone pushing against the top of the
upright freezer take some weight off the leveling leg. This
makes it easier to adjust the leveling leg.
HOW TO USE THE FREEZER
To obtain the best possible results from your upright freezer,
it is important that you operate it properly.
Temperature Control
The temperature in the freezer is controlled by the
located
7
aluminum sheets or freezing containers and place it into the
freezer.
See the data plate on freezer’s back for the maximum
permissible amount of fresh food in kilograms that can be
frozen in a 24 hour period with a room temperature of 32.2oC.
Never freeze more than the maximum allowed.
Note: Never place bottled food or drinks in the freezer
compartment.
For best performance, leave enough space in the upright
freezer compartment for air to circulate around the
packages.
Defrosting
Remove power plug from the wall socket, open the door and
remove all the food and place it in a cool place. Defrost using
a plastic scraper, or let the temperature rise naturally until
the frost melts; then wipe away the remaining ice and water.
After freezer is dry plug power cable back into the socket.
Note: To avoid damaging the freezing compartment wall, do
not use any sharp objects to remove frost or separate frozen
food packages.
Cleaning your freezer
Before you start to clean your freezer remove the mains plug
from the power supply.
Use a clean sponge or soft cloth and a mild detergent in warm
water. Do not use abrasive or harsh cleaners.
8
Hand wash, rinse and dry all surfaces thoroughly.
Do not use cleaning waxes, concentrated detergents,
bleaches or cleaners containing petroleum on plastics or
rubber parts.
Never use paper towels, window sprays, scouring cleansers
or flammable fluids on plastic parts as these can scratch or
damage material.
Clean with a soft cloth soaked in non-abrasive cleanser
solution and then dry with a soft cloth.
REVERSING THE DOOR POSITION
Caution: To avoid personal injuries or property damages, we
recommend someone assist you during the door reversal
process.
▪Ensure the appliance is unplugged and empty.
▪Adjust both leveling legs to their highest position.
Tools required
▪Phillips head screwdriver
▪Flathead screwdriver
NOTE: To take the door off it is necessary to tilt freezer
backward (no beyond 45o). You should rest the appliance on
something solid e.g. a chair just below the top panel so you
can access the bottom of the appliance.
