Prestigio RoadScanner 500WGPS Bedienungsanleitung

Car VideoRecorder

RoadScanner 500WGPS

User Manual

Version 1.0

www.prestigio.com

About this user manual

This user manual is specially designed to detail the device’s functions and features.

1. Please read this manual before using the device to ensure safe and proper use.

2. Descriptions are based on the device’s default settings.

3. Prestigio continuously strives to improve its products. Due to software upgrading, some

contents in this user manual may be diﬀerent from your product. Prestigio reserves the

rights to revise this user manual or withdraw it at any time without prior notice. Please take

your product as standard.

Conventions used in this manual

In this user manual, we use the following symbols to indicate useful and important information:

Caution: provides safety precaution and important information.

Note: gives additional information.

Tips: usage tips.

> The order of options or menus you must select to perform a step.

Contents

1. Unboxing.................................................................................... 1

Inside your package.................................................................................................................................1

Device overview ........................................................................................................................................1

2. Getting started........................................................................... 2

Insert a microSD card .............................................................................................................................2

Install the suction mount .......................................................................................................................2

Charge the battery ................................................................................................................................... 3

3. Screen interface Instruction ......................................................4

4. APP Operation ............................................................................5

5. Settings........................................................................................5

6. Specifications ..............................................................................7

1. Unboxing

Inside your package

•

Car videorecorder

•

Crowbar for cable installation

•

Quickstartguide

•

Suctionmount

•

Car charger

Device overview

MODE MUTE OK/ POI

Lens

Reset

User Manual RoadScanner 500WGPS

Before starting video recording, please insert a micro SD card (not included)

into the slot until it locks in place.

The device will automatically recognize it as default storage and all the data will be

saved on this card.

Install suction mount

•

Remove the protection paper from the suction mount and position the device on the

clean windshield or dashboard.

User Manual

RoadScanner 500WGPS

2. Getting started

Insert a micro SD card

User Manual RoadScanner 500WGPS

Charge the battery

Before using the device for the first time, please fully charge the Li-ion battery.

The battery will be completely charged in 1-2 hours.

•Using the car charger: charge the device through cigarette lighter. The device will start

charging after the car engine is turned on.

•Using micro USB cable: connect the device to AC 5V adapter or the USB port of a

computer/laptop.

①Recording icon. It flashes when recording.

②Emergency recording icon. Only appears when emergency recording starts.

③WiFi icon. Appears when WiFi signal transmission is ok. Disappears when there is no WiFi

signal and the icon does not flash when mobile phone connects WiFi.

④Audio icon. There will be no sound in the video if it is off.

⑤TF card icon. Only appears when card inserted.

⑥Battery icon. Displays the current battery capacity after cutting off the out- source

power. The battery icon bounces when charging.

⑦E-dog function icon.

⑧Current speed limit icon.

⑨The distance from current place to the speed limit point.

⑩GPS satellite icon. It will highlight after receiving satellite signal.

Does not display when there is no satellite signal.

⑪Volume icon. Set the volume. It displays 0 when it is off.

When the volume is 1-7, the corresponding volume figure will display.

⑫Automute icon. Only displays when Automute is on.

⑬Normal speed and Autodoria average speed display.

If there is no Autodoria, then display normal speed (no AVG display).

When there are AVG speed and normal speed, then displays alternately.

⑭Radar Modes: H is Highway, C1 is City1, C2 is City2.

Highlight when switching to different modes.

⑮Indicates CT is receiving. There are totally 9 levels, the level displays according to the

signal strength received. The radar band (K, LA) will highlight when receiving the related

radar signal.

3. Screen interface instruction

User Manual RoadScanner 500WGPS

The device has a built-in WiFi function. WiFi is on automatically when powering on the

device, you could use mobile phone APP to connect and operate accordingly.

Firstly, please install the APP which is provided by our company to your mobile phone.

Then power on the device, add the device to check the real-time image, also you can

record videos, take photos, playback the videos in the SD card and adjust parameter

settings. After APP connects the device successfully, the WiFi icon on the device display

will not flash.

1. Use APP to add device. Enter into APP, then click ‘+’ button, then select the device

model, then click to switch network and redirect to mobile phone WiFi connection

setting(For iOS, need to switch to mobile phone WiFi setting manually), finally choose the

WiFi of the device (Prestigio_XXXXXX, Pass word: 12345678) to connect.

2. Operate device via APP

5. Settings

Please download application “PlusCam” to change settings:

Wifi Settings:

Wifi name: Prestigio_XXXXXXX, WiFi Password: 12345678

Subtitle: on/off

APP Video Resolution: 720p/360p

Record Resolution: 1080p/720p

Loop recording: 1 minute/3 minutes/5 minutes. Video recording is provided in a cyclic order

and chosen periods of time. When micro SD card is full then the oldest unprotected files will

be replaced by new recorded files.

Storage Settings: Memory Card/Used Storage/Free Capacity/Total Storage

Microphone: on/off

GPS: on/off

Satellite info: on/off

Loudspeaker Volume: 0-7

Collide Sensitivity: High/Medium/Low

Motion Detection: on/off, Time-lapse recording time. DVR automatically starts recording

when motion is detected in front of camera. Recording stops when there is no movement any

more but a delay of 15-20 seconds. The function works only when power is supplied.

User Manual

RoadScanner 500WGPS

4. APP Operation

E-Dog: on/off

Area: Auto/400m/500m/600m/700m/800m/900m/1000m

Demo: on/off

Voice: on/off

Human Voice: on/off

Extra Mute: on/off

Radar: on/off

Radar Mode: highway limit/city1 limit/city2 limit/auto

Highway limit:

0km/m;10km/m;20km/m;30km/m;40km/m;50km/m;60km/m;70km/m;80km/m;90km/m;100

km/m;110km/m;120km/m;130km/m

city1 limit:

0km/m;10km/m;20km/m;30km/m;40km/m;50km/m;60km/m;70km/m;80km/m;90km/m;10

0 km/m;110km/m;120km/m;130km/m

city2 limit:

0km/m;10km/m;20km/m;30km/m;40km/m;50km/m;60km/m;70km/m;80km/m;90km/m;10

0 km/m;110km/m;120km/m;130km/m

K Band: on/off

La Band: on/off

Automatic Mute: on/off

Language: Choose your language

Time setting: Sync GPS Time

Time zone settings: on/off

Timed Shutdown:

Always on/5 Seconds/10 Seconds/15 Seconds/30 Seconds/1 Minute/3 minutes/5 minutes

Device Version: Device FW Version/Device Data Version

Factory Reset: Reverts all settings back to the original factory default

User Manual

RoadScanner 500WGPS

Display

1.7", 960x480

Solution

HiSilicon 3516C

Image sensor

AR0237

Viewing Angle

150°

Video Resolution

1920x1080@30fps, 1280x720@30fps

Video Format

MP4

Picture Resolution

4 MP

Picture Format

JPEG

Memory

Micro SD/SDHC up to 32GB (class 10 )

Microphone

Built-in

Other Functions

Radar Detector, Motion Detection, Cyclic

Recording, Voice Announcements,

WiFi Firmware/Edog update via smartphone

GPS tracker and POI

Yes

G-sensor

Yes

WiFi

Yes

Power Source

Built-in battery 240 mAh, car charger

Interface

USB 2.0

Operating Temperature

0°C ~ 45°C

Dimension

58 x 66 x 88mm (H x W x D)

Weight

140g

Radar Detector Bands

K-BAND (23.3 to 24.4GHz), LASER (904 NM)

6. Specifications

User Manual RoadScanner 500WGPS
