CAUTION

1. To reduce the risk of electric shock, do not remove the cover (or back). No

user-serviceable parts inside. Refer servicing to qualified service personnel.

2. The manufacturer should not hold responsibility for the damage caused by any

substitutions and modifications of the product without authorization from the

manufacturer or authorized unit.

WARNING

The device should not be exposed to dripping or splashing and no objects filled with

liquids should be placed on the device.

To prevent the GPS from being damaged, be sure to keep the GPS out of direct

sunlight or heat. Maintain well-ventilated conditions around the unit to avoid

overheating.

Important Safety

Instructions

The exclamation point within an equilateral triangle is intended to alert the

user to the presence of important operating and maintenance (servicing)

instructions in the literature accompanying the appliance.

Accessories List

ITEM NAME QTY

Car Charger 1

Mounting Cradle 1

USB Cable 1

Stylus Pen 1

Driver/Documentation CD 1

User Manual 1

Warranty Card

Accessories

EN – 1

Front and Side View

1. LCD Touch Screen

Tap the screen with touch pen or finger to select menu commands or to enter

information.

2. Battery Status Indicator

The indicator glows in bright amber color when battery is fully charged and in red

color when charging.

3. Headphone Port

Connects to stereo headphones or headsets.

4. microSD Slot

Receives microSD memory card for data access or memory expansion.

5. Micro-USB Port

Connect to USB Cable for data access or battery charging.

View of Main Unit

EN – 2

Rear and Top View

1. Speaker

Emits sound, voice or music.

2. Stylus pen

3. Reset Button

Press to reset the device.

4. Power Button

Press to power ON/OFF device.

Device Connection

Inserting microSD Card

To insert a microSD card, place

connector towards device and card

label towards the front side of the

device.

To remove a microSD card, gently

press the edge of the card to release

the safety lock and pull the card out of

the slot.

NOTE:

Please always make sure that no application is accessing the microSD

card before extraction.

Connecting to External USB Device

(Charging)

Insert the mini USB connector into the

appropriate mini USB port.

Insert the other USB connector into the

USB port on PC to start charging.

Device Connections

Connecting to Earphones

Insert earphone jack (earphones not

included) into the appropriate

earphone port to switch audio output

from device speaker to earphone.

NOTE:

High volume level is a potential risk to your hearing. Please turn down

the volume before connecting the earphone and gradually turn up the

volume to a comfortable level.

Connecting to Car Charger

Insert USB connector into the appropriate

USB port.

Insert car charger connector into vehicle

12V accessory/cigarette socket to start

charging.

NOTE:

Please connect the car charger to vehicle 12V accessory/cigarette

socket after vehicle engine is started to protect the device from sudden

surges in current.

Cautions on Battery

Char

EN – 3

About Rechargeable Battery

The device is equipped with a built-in rechargeable battery. Please fully charge the

battery (for at least 8 hours) before initial use. The battery status indicator glows in red

color when charging, and turns green color when the battery is full. Charging time is

approximately 2 hours.

Working conditions and precautions for the rechargeable battery

Device with new batteries should be fully charged before initial use.

Battery should only be used and charged when temperatures are between 0~

37C.

It is not necessary to start charging the device before the battery is fully

discharged.

NOTE:

Please connect the car charger to vehicle 12V accessory/cigarette

socket after vehicle engine is started to protect the device from sudden

surges in current.

Cautions on Battery

Char

EN – 4

Device Mounting Procedures

The device can be securely mounted on vehicle dashboard or windshield with the

mounting cradle included. Please follow procedures below to install the mounting cradle:

1. Select an appropriate location on windshield or dashboard where the device and

mounting cradle will not obstruct driver field of vision.

2. Please also make sure that the device has a clear view of sky to attain best GPS

reception.

Place the device on the bracket with

the bottom positioned on the

appropriate socket as illustrated by

Arrow 1.

Push on the top edge as illustrated by

Arrow 2 to securely install device

onto the cradle.

Lift the suction cup lever and press

the suction cup at desired location.

Press down the suction cup lever as

illustrated by Arrow 3 to secure the

mounting cradle on the surface.

Rotate the knob to adjust device to

desired viewing angle.

To Dismount Device

1. Push the tap on top of the mounting cradle to release the device.

2. Lift the suction cup lever to easily remove the suction cup from windshield or

dashboard.

Using Mounting

Cradle

1. Press and hold Power Button to turn

on the device.

2. Shortly after the loading screen is

shown, the main menu will be

displayed.

3. Tap the corresponding buttons with

touch pen included to navigate

various functions.

4. Press and hold Power Button to turn

off the device or to allow the device to

enter sleep mode.

5. Tap Sleep icon to enter sleeping

mode or OFF icon to complete turn

off the device.

Getting Started

Sleep OFF

Bluetooth function (optional)

The following is shown how to select, switch on/off the Bluetooth function

1. Tap on Function icon on the main

menu.

2. Tap on Bluetooth icon to start using

Bluetooth function.

3. Tap on ON/OFF icon to enable/

disable Bluetooth function.

4. Tap Info icon to review Bluetooth

information.

5. Tap on to reset a new PIN code.

The default setting is 1234.

Bluetooth Function

Main Menu

EN – 5

How to operate the Bluetooth function.

1. Tap on DUN icon or HF icon on the

main menu.

2. Tap on Paired List icon to start

pairing with mobile phone device with

GPRS function.

3. Please make sure Bluetooth function

on mobile phone is detectable by

other devices.

4. Tap on to start searching

process.

5. Mobile phone name desired for

connection will be displayed on the

list when search is completed.

6. Tap on the mobile phone name and

tap on to establish connection.

7. Enter PIN code 1234 when PIN

number is required on mobile phone

device.

8. Tap on to disconnect current

Bluetooth connection.

9. Select mobile phone name from

Paired List and tap on to

re-connect from previously connected

mobile phone.

10. Select mobile phone name from

Paired List and tap on to remove

it from the list.

Bluetooth Connection

EN – 6

1. Tap on HF icon on the main menu.

NOTE:

Please refer to Bluetooth Connection

section before connecting by Hands Free

function.

2. Tap on Dial icon to make phone calls.

3. Tap on digit buttons and tap on

to start dialing.

4. Tap on to answer a call if it is on

standby.

5. Tap on to end call.

6. Tap on to switch the call to

mobile phone or switch it back to

device.

7. Tap on to show dialing keypad

to dial more numbers.

8. Tap on Phone Book icon to view

phonebook entries.

9. Tap on to browse phonebook

entries stored in SIM card.

10. Tap /to scroll pages up/down.

11. Select a phonebook entry and tap

to make the call.

12. Select a phonebook entry and tap

to delete it.

Hands Free Function

13. Tap on Calls List icon to review call

history.

14. Tap to view Dialed Call list,

Received Call list, and Missed Call

list.

15. Tap /to scroll pages up/down.

16. Select a phonebook entry and tap

to make the call.

17. Select a phonebook entry and tap

to delete it.

Hands Free Function

FM function (optional)

1. Tap on Function icon on the main

menu.

2. Tap on FM icon to start using

Bluetooth function.

3. Tap on /to tune FM

frequency down/up.

4. Tap on to open the selected

frequency for broadcast.

5. Tap on to save current FM

station.

6. Tap on to cancel settings and

exit.

FM Function

EN – 7

No. Name Function

1 Sound Sound menu opens by pressing this button

2 Compass

Context menu opens by pressing this button. In this menu

switches the orientation of the map («North up» - lock icon is

next to the compass, «Rotate in accordance with the

movement» - route is next to the compass), the type of card

(Flat view «2D» and the Panoramic view of the «3D») and the

skins («Night», «Day», «Auto»). When driving the compass

always points to the North.

3 Information

panel

A sign of the upcoming maneuver. There are various turns,

distance to the next maneuver in meters or kilometers, etc. on a

gray background. Clicking on the sign stops the route guidance

and more route options.

4 Information

panel

The estimated total time in a way, the total length of the route,

time of arrival at the final point of the route.

5 Route The active route.

6 GPS-cursor Your location indicator.

7 Menu Main menu opens by pressing this button.

Bluetooth Connection

EN – 8

No. Name Function

8Progress-bar Bar is filled in as you approach the place of maneuver.

9Traffic lane Displays the traffic lanes with valid maneuvers at the next

intersection.

Information

panel

Shows the name of the street you are currently driving along.

Available only if GPS/GLONASS connection is established. If

there

is no street name, the direction will be shown.

11 Scale button Zoom out.

12 Scale button Zoom in.

13 Navitel.Events * Navitel.Events button

Speed limit

and camera

In excess of the established speed displays the speed limit on

that road section.

If warning of the cameras turned on in the settings, then when

approaching the

camera distance to it displays.

15 Battery Icon shows the level of battery charge. Press it to see the

remaining memory.

GPS

GPS/GLONASS connection icon. If the indicator is grey —

receiver is disabled, red — switched on, but the connection is

not established, yellow - poor connection, green – connection

established. There is a number of the satellites in the dot.

Navitel.Friends

Pop-up menu to work with Navitel.Friends service. Here you

can add friends, see them on map

and talk to them.

18 Route panel Allows you to see the entire route, your location and traffic

jams* on the route directly on the Map page.

Program interface

No. Name Function

19 «Save» Saves current marc on map as a waypoint.

20 «Cursor» Shows the point menu.

Program interface

No. Name Function

21 Mark on the

map

You can set the mark by taping on the map. You can save this

mark as a waypoint, add it

to the route or see object’s characteristics the mark was set on.

22 Track record Track record. Red dot means that the track is recording, grey

dot means that the record stopped.

23 Traffic Jams* Shows the current traffic jams on a 10-point scale.

24 Navitel.SMS* This button is intended to read/send SMS-messages. Near the

icon you can see the number of unread messages.

25 Software

update* Shows available updates.

26 «Go!» Marks the current position on the map as the end of the route

27 «Route through» Mark becomes the start point on the route. You should turn off

your GPS/GLONASS receiver.

28 «Set start» Mark becomes the middle point of the route.

29 «Set finish» Mark on the map becomes the end of the route. And previous

end of the route becomes the middle point.

30 Map Back to map.

* - This function is available only on some devices with GSM or Bluetooth with

DUN support. Please, refer to your supplier for more information.

Program interface

EN – 9

Route to the objects.

To create a route to the object with known address, press the «Menu» button at the lower

left corner of the screen [1]. Then select «Find», «By address» [2]. Press the «Select

country» button and enter its name [4]. To minimize the keyboard, press the icon at the

right top of the screen. Select the required country[5]. Menus «Select city», «Select

street» and «Select building» will become active [6]. After choosing the required

information press «Go!» to create a route. The route will be shown on the map [8]. You

can follow this route or start simulation by pressing the «Demo route» button.

Autorouting

EN -10

Route to the selected point on the map.

You can set the route to any point on the map. This point will be the end of the route,

your current position will become the start of the route. Create a mark on the route by

pressing any place on the map[1]. Press the «Cursor», then «Go!»[2]. The route is

created[3].

Route from point to point.

If you want to create a route from point to point you should create a point on the map[1].

Then set this button as a start route by pressing «Cursor» > «Go!». If you didn’t turn off

your GPS receiver, the system will ask you to do it[3]. The start point will be marked by

green flag[4]. Then find the finish point, tap on map and press «Cursor» > «Go!»[5]. The

route will be created from point to point.

Autorouting

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Prestigio GPS Handbücher

Prestigio

Prestigio GeoVision 5850HDDVR Bedienungsanleitung

Prestigio

Prestigio GeoVision 5300 Bedienungsanleitung

Prestigio

Prestigio GeoVision 7790 Bedienungsanleitung

Prestigio

Prestigio GeoVision 5500 Bedienungsanleitung

Prestigio

Prestigio RoadScout 4150 Bedienungsanleitung

Prestigio

Prestigio GEOVISION 5000 Bedienungsanleitung

Prestigio

Prestigio GEOVISION 5066 Mireo Bedienungsanleitung

Prestigio

Prestigio GEOVISION 5055 Bedienungsanleitung

Prestigio

Prestigio GeoVision 430 Bedienungsanleitung

Prestigio

Prestigio GV4500 Bedienungsanleitung

Prestigio

Prestigio GeoVisison 5066 Bedienungsanleitung

Prestigio

Prestigio GeoVision 5056 Navitel Bedienungsanleitung

Prestigio

Prestigio GEOVISION 150 Bedienungsanleitung

Prestigio

Prestigio GeoVision 4500 Bedienungsanleitung

Prestigio

Prestigio GEOVISION 5055 Bedienungsanleitung

Prestigio

Prestigio GeoVision 5050 Bedienungsanleitung

Prestigio

Prestigio GeoVisison 5066 Bedienungsanleitung

Prestigio

Prestigio GeoVision 4766 Bedienungsanleitung

Prestigio

Prestigio GV5055 Bedienungsanleitung

Prestigio

Prestigio GEOVISION 7795 Bedienungsanleitung

Prestigio

Prestigio GeoVision 5800BTHDDVR Bedienungsanleitung

Prestigio

Prestigio GV7059 Bedienungsanleitung

Prestigio

Prestigio Geovision Tour 3 Sygic Bedienungsanleitung

Prestigio

Prestigio GV7790 Bedienungsanleitung

Beliebte GPS Handbücher anderer Marken

Raven

Raven Cruizer II Handbuch

Hama

Hama 53118 Bedienungsanleitung

Garmin

Garmin SOUNDER 125 Bedienungsanleitung

Garmin

Garmin DEZL 580 Bedienungsanleitung

Jigabot

Jigabot EX Bedienungsanleitung

Pointer

Pointer Cellocator CelloTrack XT LTE Installationsanleitung

Queclink

Queclink GV55LITE Bedienungsanleitung

Voxson

Voxson Voxtrack GPS500 Gebrauchsanweisung

Garmin

Garmin ECHOMAP PLUS Bedienungsanleitung

Starcom Systems

Starcom Systems Kylos Compact Bedienungsanleitung

Garmin

Garmin 15 H Series Bedienungsanleitung

Cobra

Cobra Marine MC 600Ci Bedienungsanleitung

Cellocator

Cellocator CelloTrack T Bedienungsanleitung

Enfora

Enfora Mini-MT GSM2228UG001 Bedienungsanleitung

Magellan

Magellan eXplorist 100 Bedienungsanleitung

LTE

LTE G50B Bedienungsanleitung

Garmin

Garmin DEZL OTR500 Bedienungsanleitung

SkyGolf

SkyGolf SkyCaddie SG1 Bedienungsanleitung
