BASIC OPERATION INSTRUCTIONS
Remote Plus
Controller
ACN# 088 609 661
TMTM
TMTM
TM
2 BasicOperationInstructions
Remote Plus Controller www.pridemobility.com
INFORMATION LABELING
Read and follow the information in the owner’s manual.
Avoid exposure to rain, snow, ice, salt, or standing water
whenever possible. Maintain and store in a clean and dry
condition.
Disposal and recycling - Contact your authorized Pride
Provider for information on proper disposal and recycling of
your Pride product and its packaging.
Copyright© 2006
PrideMobilityProductsCorporation
INFMANU1773/RevC/November 06
Thesymbols beloware usedthroughout thisowner's manualand onthe power
chairtoidentifywarningsandimportantinformation.Itisveryimportantforyouto
readthemandunderstandthemcompletely.
WARNING! Indicates a potentially hazardous condition/
situation. Failure to follow designated procedures can cause
either personal injury, component damage, or malfunction.
On the product, this icon is represented as a black symbol
on yellow triangle with black border.
MANDATORY! These actions should be performed as
specified. Failure to perform mandatory actions can cause
personal injury and/or equipment damage. On the product,
this icon is represented as a white symbol on a blue dot with
a white border.
PROHIBITED! These actions are prohibited. These actions
should not be performed at any time or in any circumstances.
Performing a prohibited action can cause injury to personnel
and/or damage to equipment. On the product, this icon is
represented as a black symbol with a red circle and a red
slash.
BasicOperationInstructions 3
www.pridemobility.com Remote Plus Controller
TABLE OF CONTENTS
INTRODUCTION ................................................................................. 4
REMOTE PLUS CONTROLLER ................................................... 6
PRECAUTIONARY GUIDELINES................................................. 6
OPERATING THE REMOTE PLUS CONTROLLER............ 10
3-PIN OFF-BOARD CHARGER/PROGRAMMING SOCKET .13
CONTROLLER COMMUNICATIONS CONNECTOR ........... 14
ACTUATOR ADJUSTMENT ......................................................... 14
SPEED ADJUSTMENT/PROFILE SELECT........................... 15
SLEEP MODE .................................................................................... 15
THERMAL ROLLBACK .................................................................. 15
FAULT CODES................................................................................... 16
CARE AND MAINTENANCE ........................................................ 17
WARRANTY ........................................................................................ 17
4 BasicOperationInstructions
Remote Plus Controller www.pridemobility.com
INTRODUCTION
WELCOMEto PrideMobility ProductsCorporation (Pride).The productyou
havepurchasedcombinesstate-of-the-artcomponents with safety, comfort, and
stylinginmind.Weareconfidentthatthedesignfeatureswillprovideyouwiththe
conveniencesyouexpectduringyourdailyactivities.Understandinghowtosafely
operateandcareforthisproductshouldbring you yearsoftroublefreeoperations
andservice.
Readand followallinstructions,warnings,andnotesinthismanualandallother
accompanying literature before attempting to operate this product for the first
time.Inaddition,yoursafetydependsuponyou,aswellasyourprovider,caretaker,
orhealthcareprofessionalinusinggoodjudgement.
Thismanualistobeusedinadditiontothepowerbaseowner’smanualthatcamewith
yourpowerchair.Ifthereisanyinformationinthismanualwhichyoudonotunderstand,
or if you require additional assistance for setup or operation, please contact your
authorizedPrideProvider.Failuretofollowtheinstructions,warnings,andnotes
inthismanualandthoselocatedonyourPrideproductcanresultinpersonal
injuryand/orproductdamageandwillvoidPride’sproductwarranty.
PURCHASER’SAGREEMENT
Byacceptingdeliveryofthisproduct,youpromisethat you will notchange,alter,
or modify this product or remove or render inoperable or unsafe any guards,
shields,orothersafetyfeaturesofthisproduct;fail,refuse,orneglecttoinstallany
retrofitkits fromtimeto timeprovided byPrideto enhanceor preserve thesafe
useofthis product.
INFORMATIONEXCHANGE
Wewant tohearyour questions,comments,and suggestions aboutthis manual.
We would also like to hear about the safety and reliability of your new Pride
product,andabouttheserviceyoureceivedfromyourauthorizedPrideProvider.
Pleasenotifyusofanychangeofaddress,sowecankeepyouapprisedofimportant
informationabout safety, newproducts, and newoptions that canincrease your
abilitytouse andenjoyyourPride product.
BasicOperationInstructions 5
www.pridemobility.com Remote Plus Controller
NOTE: If you ever lose or misplace your product registration card or your
copy of this manual, contact us and we will be glad to send you a new one
immediately.
My authorized Pride Provider Is:
Name: _____________________________________________________
Address:____________________________________________________
PhoneNumber: ______________________________________________
PurchaseDate: _______________________________________________
6 BasicOperationInstructions
Remote Plus Controller www.pridemobility.com
REMOTEPLUS CONTROLLER
TheRemotePlusControllerisafully-programmable,modularelectroniccontroller
systemthatallowsyoutooperateyourpowerchair. It is designedtoallowtheuser
tohavecomplete controloverchairmovement andspeed.
The controller has been pre-programmed to meet a typical user’s needs. The
programis set using either apersonal computer with software providedby the
controllermanufacturer orwith ahand-held programmer, also providedby the
controllermanufacturer.
WARNING! The controller program can affect speed,
acceleration, deceleration, dynamic stability, and braking.
If it is programmed incorrectly or outside of the safe limits
as determined by your healthcare professional, it can create
a dangerous situation. Only the power chair manufacturer,
an authorized representative of the manufacturer, or a trained
service technician should program the controller.
PRECAUTIONARYGUIDELINES
Beforeoperating theRemote PlusController, please read thefollowing.These
guidelinesareprovided foryourbenefitand willaidyouin thesafeoperationof
thecontrollersystem.
!Turnoffthe power tothecontrollerwhentransferring to orfromyourpower
chair.
!Followalloftheproceduresandheedthewarningsasexplainedinyourpower
chairowner’smanual.
Failure to heed the above warnings can result in personal injury and/or
equipmentdamage.
BasicOperationInstructions 7
www.pridemobility.com Remote Plus Controller
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic
and radio frequency waves can have an adverse affect on
the performance of electrically-powered mobility vehicles.
ElectromagneticandRadioFrequencyInterferencecancomefromsourcessuchas
cellularphones,mobiletwo-wayradios(suchaswalkie-talkies),radiostations,TV
stations,amateurradio(HAM)transmitters,wirelesscomputerlinks,microwavesig-
nals,pagingtransmitters,andmedium-rangemobiletransceiversusedbyemergency
vehicles.Insomecases,thesewavescancauseunintendedmovementordamageto
thecontrolsystem.Everyelectrically-poweredmobilityvehiclehasanimmunity(or
resistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainst
EMI.Thisproducthasbeentestedandhaspassedatanimmunitylevelof20V/m.
WARNING! Be aware that cell phones, two-way radios,
laptops, and other types of radio transmitters may cause
unintended movement of your electrically-powered mobility
vehicle due to EMI. Exercise caution when using any of these
items while operating your mobility vehicle and avoid coming
into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to
the electrically-powered mobility vehicle can increase the
susceptibility of the vehicle to EMI. Do not modify your power
chair in any way not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself
can disturb the performance of other electrical devices
located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on
www.pridemobility.com. If unintended motion or brake release occurs, turn
yourcontroller offassoon as itissafe to doso.Call Prideor your authorized
Pride Provider to report the incident.
8 BasicOperationInstructions
Remote Plus Controller www.pridemobility.com
Remote Plus Controller Features
Figure1providesinformationontheRemotePluscomponents and connections.
Usethis diagramto familiarize yourself with the function andlocation ofeach
componentbeforeusingtheRemotePlusController.
ThefollowingfunctionsareavailablewiththeRemotePlusController:
!JoystickControl
Thejoystick is usedto controlthedirection andspeed of thepower chair.
!ActuatorAdjustment
TheusercancontrolpositioningofpoweraccessoryactuatorswiththeRemote
Plus.
!DriveProfileSelection
Theusercanselectoneoffiveavailabledrive profiles.
!SpeedAdjustment
Theuser can increaseor decrease themaximum speed ofthe power chair.
!SleepMode
Thisfeatureisdesignedtopreservebatterycharge,andcanbedisabledthrough
programming.
!ThermalRollback
Thisisasafetyfeaturedesignedtoprevent the power chairfromoverheating
andcausingdamage to themotorsorcontroller.
NOTE: The Remote Plus can be programmed to have up to five drive
profiles or one drive profile and five speed adjustments.
BasicOperationInstructions 9
www.pridemobility.com Remote Plus Controller
Figure 1. Remote Plus Components and Connections (3-Key Shown)
Mode Button
Used to select the various
functions available with the
Remote Plus.
On/Off Button
Press to power on or off the
power chair and controller.
BACK VIEW
Speed/Profile Indicator
Series of five colored LEDs
which display the speed or
profile setting.
Battery Condition Meter
Indicates the approximate
amount of battery life using
color-coded LED bars.
Horn Button
Activates a warning horn.
Mounting Bracket Access
An alternate Remote Plus mounting option
may be available with your power chair.
Harness Connector Port
Used to connect the Remote Plus to the
power base.
Actuator Indicators
Four LEDs indicate
recline, tilt, power leg
rests, and elevating seat
actuator modes.
Joystick
A multi-functional tool used
to control speed, direction,
and actuator adjustment.
Off-board Charger/
Programming Port
Used to charge or
program the power base.
10 BasicOperationInstructions
Remote Plus Controller www.pridemobility.com
OPERATING THEREMOTE PLUSCONTROLLER
The Remote Plus Controller is used to operate your power chair and all of its
components.
TheRemotePluscontrollerconsistsof(seefigure2):
1. joystick
2. keypad
3. controllercommunicationsconnector
4. 3-pinoff-boardcharger/programmingsocket
5. powermodule
6. intermediateharnesswithchargerconnection
Joystick Control
The joystick controls the direction and speed of your power chair. When you
movethejoystick from theneutral(center) position, theelectromagneticbrakes
releaseand allow your power chairto move. The farther youpush thejoystick
fromitsneutralposition,thefasteryourpowerchairmoves.Whenyoureleasethe
joystickandallowittoreturn to the neutralposition,youengagetheelectromag-
neticbrakes.This causes yourpowerchairto decelerate andcometoa complete
stop.
Keypad
Thekeypadislocateddirectlyinfrontofthejoystick.Itcontainskeysthatyouwill
useto controlyour powerchair.See figures3 and4.
On/Off Key
Theon/offkeyturns the systemonandoff.
WARNING! Unless faced with an emergency situation, do
not use the on/off key to stop the chair. This will cause the
power chair to stop abruptly.
WARNING! Always turn the power off when you are stationary
to prevent unexpected movement.
Dieses Handbuch passt für folgende Modelle
1
Inhaltsverzeichnis
Andere Pride Mobility Mobilitätshilfe Handbücher
Pride Mobility
Pride Mobility SilverStar SilverBoom 300 Bedienungsanleitung
Pride Mobility
Pride Mobility Meuris Bedienungsanleitung
Pride Mobility
Pride Mobility Jazzy 600 Series Bedienungsanleitung
Pride Mobility
Pride Mobility Power Tote P-100 Bedienungsanleitung
Pride Mobility
Pride Mobility Vista Bedienungsanleitung
Pride Mobility
Pride Mobility Jazzy Select Traveller Bedienungsanleitung
Pride Mobility
Pride Mobility CELEBRITY X Bedienungsanleitung
Pride Mobility
Pride Mobility PATHRIDER 140 XL Bedienungsanleitung
Pride Mobility
Pride Mobility Jazzy Elite ES Bedienungsanleitung
Pride Mobility
Pride Mobility TRAVEL SCOOTER Series Bedienungsanleitung
Pride Mobility
Pride Mobility Jet 12 Bedienungsanleitung
Pride Mobility
Pride Mobility Go-Go Ultra X Bedienungsanleitung
Pride Mobility
Pride Mobility PVM Series Bedienungsanleitung
Pride Mobility
Pride Mobility Jazzy 1122 Bedienungsanleitung
Pride Mobility
Pride Mobility Jazzy Select Bedienungsanleitung
Pride Mobility
Pride Mobility KIT2008618 Betriebsanleitung
Pride Mobility
Pride Mobility Go-Go Elite traveller Bedienungsanleitung
Pride Mobility
Pride Mobility S34P Bedienungsanleitung
Pride Mobility
Pride Mobility FUSION Bedienungsanleitung
Pride Mobility
Pride Mobility QUEST Bedienungsanleitung
Beliebte Mobilitätshilfe Handbücher anderer Marken
Rhythm Healthcare
Rhythm Healthcare B3800F Bedienungsanleitung
AMF-BRUNS
AMF-BRUNS PROTEKTOR Bedienungsanleitung
Drive DeVilbiss Healthcare
Drive DeVilbiss Healthcare OTTER Bedienungsanleitung
Rhythm Healthcare
Rhythm Healthcare C500U Bedienungsanleitung
Lumex
Lumex RJ4200A Bedienungsanleitung
Rebotec
Rebotec Jumbo Bedienungsanleitung
