What’sInTheBox:



UponopeningyourMyriadReservoirboxyouwillnotice3innerboxeslabeledBox1,2,and3.Start

withBox3.ThisboxcontainsthepumphousingfortheD5pumpmount.Theincludedpiecesareshown

below.

 



 



 



Carefullyremovealltheitemsfromtheboxandsetthemontheflatsurfaceinfrontofyou.



MyriadReservoirSystem

Congratulationsonpurchasingthemostadvanceandversatilereservoirsystemeverbuilt.Pleasefollowthe

installguidestepsintheexactorderlisted.

AssemblyTime:20minutes

NeededforInstall:

‐PhillipsandFlatheadscrewdriver.Pleasedonotuseanypowerscrewdriversordrills.

‐Smallsectionoftubefortesting.

‐FlatCleansurface24inchby24inchareaisrecommended.

‐Welllitarea,andacomfortableseat.



Imp

orta

nt

Info





2



Step1–Box3InstallPumpO‐ring



ThePumpO‐ringistheroundO‐ringincludedinthe

box.LayO‐ringintopumpmountareaandpress

firmlyintoO‐ringchannel.Oncecompletely

installedtheO‐ringwillstickupanequaldistance

aroundtheO‐ringchannel.

Step2–Box3InstallOutletChannelO‐ring



OutletChannelO‐ringisthe“S”shapedO‐ring.

TurnPumpmountovertoexposetheinsideportion

ofthemount.SimplylaytheO‐ringintotheO‐ring

groove.OnceinplacefirmlypressdownontheO‐

ringtoinsureithasseateditselfproperly.Youwill

knowit’scorrectlyinstalledwhentheO‐ringsticks

upoutofthegroovebyabout1/32inch.

Step3–Box3InstallandSecureOutletChannelCover



Note*Overtighteningthescrewsin

thisnextstepwillcausetheacrylic

covertocrackandleak.



Theoutletchannelcoveristhepapercoveredpiece

ofacrylicintheshapeofthechannel.Testfitthe

partintothechanneltogettheorientationofthe

cover.Onceitisoriented,takeyourfingernailand

removethepaperonthesideoftheacrylicthatwill

gofacedownandthenpresscoverintoplace.You

mayneedtopresstheendstosnapthecover

securelyintoplace.



Nextinsertthe2blacknylonscrewsprovidedinto

thecover.Tightenscrews90%ofthewayandthen

proceedtoremovetheouterprotectivepaper

covering.





3



Step4–Box1 FacePlatePrepforInstall



RemoveacrylicfaceplatefromBox1andplaceit

facedownonyourflatworkarea.Thecountersink

holesandLEDLightchannelsshouldbefacing

down.



Usingyourfingernail,startinonecornerandslowly

peeltheprotectivepaperbackuntilit’s3/4ofthe

wayremovedandstop.Nowlaythepaperback

downontheacrylic.Itwillnotstickagain,butwill

protecttheacrylicfromgettingscratchedwhile

youmoveontothenextstep.



SetthispieceasideandproceedtoStep5.

Step5–Box2 CenterFrame–O‐RingInstall



Oncethepaperisremoved,tightenscrewstherest

ofthewaytoinsurethecoverisflushorslightly

underthesurfaceofthepumpmount.Donotover

tighten.



Pleasesetthisassembledpumpmountasideand

theotherunusedpieces(tobeusedinlatersteps).





4



Tips:

Foreveryinch,stopandpressFIRMLYontheO‐

ringintothechannel.



YouwillseethattheO‐ringlikestopopout

aroundthedipsaroundthescrews.Takeextra

timeintheseareastoinsureyouarepressingthe

O‐ringfirmlyintothechannel.



Nextisthemostdifficultstepandrequiresthemost

patience.Pleasereadcompletelyandcarefully

beforeattempting.Seetipsunderthepictureto

theleft.

DryHandsareneeded.Youmayneedtokeepa

towelhandytokeepyourhandsdrythroughoutthe

process.



Removethecenterframefromthebox.

EachsideofthecenterframehasanO‐ringthat

needstobeinstalled.Laytheframedownonyour

flatsurfaceandstarttheO‐ringinonecornerofthe

frame.



Beginfeedingitandpressingitintothegrooveof

theframe.Takeyourtime,ifyougotoofasttheO‐

RingWILLpopout.Asyoudothis,youwillneedto

stretchtheO‐ringandpushitintothechannela

littleeach¼inch.Ifyougetallthewayaroundthe

frameandyourO‐ringisshortyoudidnotstretch

theO‐ringenoughwheninstalling.StartOver.



Onceonesideiscomplete,flipoverframeandset

onflatsurface.(ThiswillhelpkeeptheO‐ringin

placewhileyouinstallthenextone.)Repeat.

ProceedtoStep6.

Step6 Frametopumphousing



OncebothsidesoftheframehaveO‐ringsinstalled,

theframecannowbeattachedtothepump

housing.



Placetheframesoitisflushontheedgesandthe

holeslineupforthethroughscrews.Doublecheck

thattheO‐ringsarestillinplaceandarenotvisible.



ProceedtoStep7.



Step7 FaceplateInstall(4screws)





5



Tightenscrew1to80%,nextTightenscrew2to

80%,nextTightenscrew3to80%,andnext

Tightenscrew4to80%.Onceallscrewsare80%,

startprocessovertillscrewsare100%.



NOTE:DONOTOVERTIGHTEN.Thisreservoirdoes

notrequirealargeamountoftorquetowork

properly,sodonotwrenchdownonthescrewsor

theacrylicwillcrackandleak.



Oncethecentralframeisproperlyfittedtothe

pumphousing,removetherestoftheprotective

paperofftheacrylicfaceplateandlaygentlyonthe

frame.MakesuretheO‐ringisstillinthechannel

andnotprotrudingoutANYWHERE.



Oncethefaceplateisinplace,locatethefourpack

ofM4screwsinthebagWITHOUTtheplasticcaps.

(Seepicturetotheleft).



Gentlyplacethescrewsintotheholes.These

screwsaretobeusedinthecenter4holesONLY.

Gentlytightenthescrewsintheordershowninthe

pictureto80%,thenrepeatto100%.100%should

betheequivalenttohandtighttension.DONOT

OVERTIGHTEN.



ProceedtoStep8.

Step8 MountingBracketThroughScrews–4Corners



Withthe4centerscrewsinplace,proceedtopeel

offthepaperonthetwoedgesnexttotheLED

Lightchannel.Leavethecenterpieceunpeeledfor

now.



Onceyoupeeloffthepaperontheedgesyouwill

seetheO‐ringmakingcontactwiththeacrylicface

plateiftheO‐ringhasbeeninstalledproperly.



Locatethe6‐32screwswiththe4plasticcaps.

Insertthescrewsintotheholesandbeginto

tighten.Followthesametighteningprocessasyou

didinStep7.



Tighteningthesescrewstohandtighttensionjust

likethecenterscrewsisadequatetomakeawater

tightseal.IfthesescrewsareovertighteneditWILL

CAUSETHEACRYLICTOCRACK.





6

Thebelowpictureillustratestheleveloftightness

youshouldachieve.IMPORTANT:Ifyouseethat

theacrylicistouching(makingcontact)withthe

framethenthescrewistootight.Untightenthe

screwuntilitdoesnotmakecontactwiththe

frame.ProceedtoStep9.









7

Step9–Box1 DualBayMountingSystem



OptionalThumbscrewsareincludedifyour

specificcomputercaserequiresthem.



Thesebracketsaredesignedtogivethereservoir

moreflexibiltyonwhereandhowthereservoiris

installed.Thefollowingstepsexplainhowto

mountthereservoirintothe2x5¼DriveBays.



a.Assemblethemountingbrackets:



Placethefirstbracketonaflatsurfaceandslide

oneoftheplatesunderneathitandtightenscrews

intoplate.Tightenthescrewsallthewaydown

andthenuntightenapproximately½turnoruntil

theplateslidesbackandforth.Repeatforother

bracket.Thereare8screwsperbrackettobe

installed.ProceedtoStep10.



Step10 MarrybodyWithMount

Now,gentlyplacethereservoironitsface.Next,lay

theanti‐vibrationpadoverthe2exposedscrews

andlineuptheshapetomatchthecut‐outonthe

reservoir.



Finally,lineupthebracketwiththecut‐outshape

andscrewonthenutcaps.Repeatforotherside.

Thesecapssecurethebracketstothereservoirand

allowyoutomountitintoyourdrivebays.

ProceedtoStep11.





8

Step11 InstallD5Pump



Removepumpfromstockhousingandplaceinto

therearpumpmountareaofthereservoir.Next,

slippumpwirethroughthepumpretainingcapand

beginscrewingcapontorearpumpmounthousing,

securingthepumpinplace.Youmayhavetoturn

thecapcounterclockwiseandthenclockwiseto

properlyalignthethreadsevenly.Thecapwillnot

secureproperlyifcrooked.



Finally,tightentheretainingcapuntilitstops

turning.



Aproperlyinstalledcapwillbeperfectlyhorizontal

withthepumpandhousing.Ifthecapiscrookedit

willleak.Unscrewthecapandrepeatuntilthecap

isinstalledproperly.

Step12 FillandTest



Pleasenote:Theoutletwillalwaysbethetop

rightandbottomleftwhenlookingattherearof

thereservoir,nomattertheorientation.



Aswithanywatercoolingproject,testingnew

hardwarebeforeputtingitintoserviceisrequired.



Thefollowingconfigurationisfortestingpurpose

only.



Plugonesideofthereservoir.Ontheothersideof

thereservoirinstall2xG¼BSPPfittingsandasmall

sectionoftubetoloopbackthefluidfromthe

outletbackintothereservoir.Thiswillcreatea

closedloopfortesting.



Nowaddfluidwithsuppliedfunnel.De‐Ionizedor

Distiledwaterisrecommended.Thiswillneedtobe

dumpedoncetestingiscomplete.



Connectpumpto12voltpowersourceandrunfor

aminimumof24hrs.After24hrs,checkforleaks

orpuddlesformingnearthereservoir.Aslongas

yourO‐ringsareinstalledproperlythereshouldbe

noleaks.



Oncetestingiscompletedraintestfluid.

ProceedtoStep13.





9

Step13 FinalInstall



a.InstallBrushAluminumFaceCover:Peelpaper

offthedoublesidedadhesivetapeandsticktothe

acrylicfaceplate.Makesurealltheedgesareflush

andpressstickysideagainstfaceplate.



b.InstallReservoirintoCase:Picktwobaysand

slidein.(InstallationisjustlikeinstallingaDVD

drivethatistwiceastall.)



Insertthereservoirsoitsflushwiththecaseand

tightenthescrewsonthebracketplates.Youmay

needtoremovethereservoirandrepeatthis

processacoupletimestogettheperfectfit.



Onceyouaresatisfiedwiththefit,tightenthe

screwscompletelysothereservoirdoesnotslide.



Youarenowreadytocompletetherestofyour

watercooingrigandreaptherewardsofyournew

reservoir.



Stillhavequestions?ContactusatPrimochill.comorcallustollfreeat(800‐690‐9081).



Andere Primochill Wassersystem Handbücher

Primochill

Primochill Myriad Bedienungsanleitung

Beliebte Wassersystem Handbücher anderer Marken

Spirotech

Spirotech SPIROVENT SUPERIOR S250 Bedienungsanleitung

Culligan

Culligan Aqua-Cleer Aqua-Cleer Advanced Drinking Water... Bedienungsanleitung

A.O. Smith

A.O. Smith Dura-Max AJH - 1000A - P Bedienungsanleitung

Microline

Microline T.F.C.-4 Handbuch

Eureka Forbes

Eureka Forbes Aquaguard Select Bedienungsanleitung

Cetetherm

Cetetherm AquaEfficiency Bedienungsanleitung

CB Tech

CB Tech CB-VOC Bedienungsanleitung

Vaillant

Vaillant auroFLOW plus VPM 15 D Bedienungsanleitung

resideo

resideo Braukmann HS10S Bedienungsanleitung

Gude

Gude INOX 100/24 Bedienungsanleitung

Mono

Mono Eco 1-60 Handbuch

SpectraPure

SpectraPure Drinking Water Kit Bedienungsanleitung

HydroCare

HydroCare Dual Action Bedienungsanleitung

NEXT pool

NEXT pool STERILOR Cu/Ag Verdrahtungsschema

Alpha

Alpha SolarSmart 150 Benutzerhandbuch

TA FRISTAR3 Bedienungsanleitung

GÜDE

GÜDE HWA 800 K Bedienungsanleitung

Rainfresh

Rainfresh UCS2 Bedienungsanleitung
