Pro 1 IAQ T755 Bedienungsanleitung
Operation ManualOperation Manual
U.S. Registered Trademark. Patents pending
Copyright 2020 All Rights Reserved.
T755(S)
Pro1 Technologies
Toll Free: 888-776-1427
Web: www.pro1iaq.com
Hours of Operation: M-F 9AM - 6PM Eastern
1
Table of Contents
Table of Contents
Thermostat Operation
Thermostat Quick Reference
Programming
Features
Warranty Information
Page
2-3
4-7
8-10
1
Una version en español de este
manual se puede descargar en la
pagina web de la compañia.
Equipment damage hazard.
Do not operate the cooling
system if the outdoor
temperature is below 50 ˚F
(10 ˚C) to prevent possible
compressor damage.
Caution
Rev. 2028
11-12
13
P.O. Box 3377
Springeld, MO 65808-3377
Set At
Menu
3
Thermostat OperationThermostat Operation
2
LCD Display
Glow in the dark light button
Fan Button
Temperature Setpoint Buttons
See page 6 for details about
this display read out.
The glow in the dark light
button will self illuminate
for several hours after
exposure to ambient light.
This button turns on the
display light when pressed.
Auto will cycle the fan
on only when the heating
or cooling system is on.
ON will run the fan
continuously.
L, M, and Hmay be
selectable when the
thermostat is in PTAC mode
and will run the fan
continuously at low,
medium or high speeds.
Press the or
buttons to select the
desired room temperature.
User Program Buttons
See page 8 for further
information.
System Button
Selects the operation mode
on your HVAC system.
Selecting HEAT turns on
the heat mode. Selecting
COOL turns on the cool
mode. Selecting OFF turns
both heating and cooling o.
Selecting AUTO will turn the
HEAT or COOL on as needed.
(EM HEAT will appear as an
option if operating a heat
pump. EM HEAT setting will
turn on emergency heat)
Thermostat Quick Reference
4
Battery Door Information
5
Thermostat Quick Reference
Insert 2 AA
Alkaline batteries
(included). High
quality alkaline
batteries are
recommended.
Located ont he back of the thermostat.
The low battery indicator is displayed when the AA battery
power is low. If the user fails to replace the battery within 21
days, the screen will only show the low battery indicator but
maintain all functionality. If the user fails to replace the batteries
after an additional 21 days (days 22-42 since rst “low battery”
display) the setpoints will change to 55˚F (Heating) and 85˚F
(Cooling). If the user adjusts the setpoint away from either of
these, it will hold for 4 hours then return to either 55˚F or 85˚F.
After day 63 the batteries must be replaced immediately to
avoid freezing or overheating because the thermostat will shut
the unit o until the batteries are changed.
Important:
If your HVAC contractor has congured the thermostat to remind you when
the air lter needs changed, you will see FILT in the display when your air
lter needs to be changed.
Resetting The Filter Change Reminder: When FILT reminder is displayed,
you should change your air lter and reset the reminder by holding down
the second button down from the top left of the thermostat for 3 seconds.
Filter Change Reminder
•When the R250S is used as an outdoor sensor and a dual fuel balance point
is enabled, an outdoor temperature above balance point will cause the
thermostat to only allow Y terminal(s) to energize. An outdoor temperature
below balance point will cause the thermostat to only allow the W2 to
energize.
• The temperature shown is the average of all remotes, when using R251S
indoor sensors.
• When using the R250S as a oor sensor, High Limit may cause system to be
o even when temperature isn’t yet satised. This is to avoid heating
beyond setpoint.
Remote Information
When the battery icon appears replace your AA batteries
immediately. Failure to do so may result in your heating & cooling
system becoming inoperable. Freezing or overheating can occur.
Caution:
67
Thermostat Quick Reference Thermostat Quick Reference
6
Em.Heat
AutoCool
Set At
On LHM
Tech Set
Set Sched
Next
Run Sched
Set Time
Hold
Done
Menu
Prev
HOLD
STAGES
1+2+3
COOL ON
HEAT ON
FAN ON
1
2
3
7
8
Indicates the current room temperature
Time and day of the week
Setpoint: Displays the selected setpoint temperature.
Hold is displayed when the thermostat program is
permanently overridden.
System Operation Indicators:
The COOL ON, HEAT ON or FAN ON will display when the
COOL, HEAT, or FAN is on. The compressor delay feature
is active if these are ashing.
Low Battery Indicator: Replace batteries when this
indicator is shown.
Menu Options: Shows dierent options.
Program Time Periods: This thermostat has 4
programmable time periods per day.
System: Indicates current mode of operation.
Stages: +1 will appear in the display when second stage
of heat or cool is on. +2 will appear for third stage of heat.
1
2
3
7
8
Globe: Globe is displayed if an energy ecient
temperature has been selected.
Auto
Programming Programming
Set Time
Follow the steps below to set the day of the week and current time:
1. Press the MENU button.
2. Press SET TIME.
3. Day of the week will be ashing. Use the or key to
select the current day of the week.
4. Press NEXT.
5. The current hour is ashing. Use the or key to
select the current hour. When using 12-hour time, make sure
the correct a.m. or p.m. choice is selected.
6. Press NEXT.
7. Minutes are now ashing. Use the or key to
select current minutes.
8. Press DONE when completed.
(If using programming)
You will see a Tech Set option after the MENU key is pressed.
This Tech Set key is for installer conguration and should NOT be
changed unless you consult your professional heating and air
conditioning technician.
Important:
89
Set Program Schedule 5+1+1 or 7 Day
1. Select HEAT or COOL with the system switch. Note: You have
to program heat and cool each seperately.
2. Press the MENU button (If menu does not appear rst press RUN SCHED)
3. Press SET SCHED. Note: Monday-Friday or (Monday if in 7 Day)
is displayed and the WAKE icon is shown. You are now
programming the wake time period for that day.
4. Time is ashing. Use the or key to make your time
selection for that day’s WAKE time period. Note: If you want
the fan to run continuously during this time period, select
ON with the FAN key
5. Press NEXT STEP
6. The setpoint temperature is ashing. Use the or
key to make your setpoint selection for that day’s WAKE time
period.
7. Press NEXT STEP
8. Repeat steps 4 thru 7 for that day’s LEAVE time period,
RETURN time period, and SLEEP time period.
To customize your Program schedule, follow these steps:
Continued on next page...
Programming
Repeat steps 4 through 7 for the Saturday WAKE time period, LEAVE time
period, RETURN time period, and for the Saturday SLEEP time period.
Saturday:
Repeat steps 4 through 7 for the Sunday WAKE time period, LEAVE time
period, RETURN time period, and for the Sunday SLEEP time period.
Sunday:
10 11
Set Program Schedule 5+1+1 or 7 Day (continued)
Temporary Hold: The thermostat will display HOLD and RUN SCHED on
the left of your screen when you press the or
key. If you do nothing, the temperature will remain at this setpoint
temporarily for 4 hours. After this, the program setpoint will then replace
your temporary setpoint.
Permanent Hold: With a temporary hold set, if you press the HOLD key at
the left of your screen, you will see HOLD appear below the setpoint tem-
perature in the display. The thermostat will now
permanently stay at this setpoint and can be adjusted using the
or keys.
To Return To Program: Press the RUN SCHED key at the bottom of your
screen to exit temporary and permanent holds.
Temporary & Permanent Hold Feature (If using Programming)
Features
If using 7-Day Programming:
Use these same steps for every individual day.
12 13
Warranty Information
Warranty Registration
Your new thermostat has a 5 year limited warranty. You must register
your thermostat within 60 days of installation. Without this
registration the warranty period will begin on the date of manufacture.
For warranty issues please contact the HVAC professional that
installed this product. You can register your new thermostat in 2 ways:
Go to the company website, select warranty registration and
ll out a short registration form.
Complete the form below and mail it to the address shown.
Warranty Registration
Complete form and mail to:
Thermostat Warranty Registration
Online
Mail
Pro1iaq
P.O. Box 3377
Springeld, MO 65808-3377
Name:
Address:
City:
State:
Zip:
Thermostat Model:
Date Installed:
A Note About Auto Changeover:
When in Auto you have the ability to switch between auto heat or auto
cool by pressing the system key. This can be done once the current
mode has reached its setpoint. For example: if in auto heat, the heat
setpoint must be satised before the thermostat will allow you to switch
to auto cool. You can switch out of auto by holding down the system
key. To get back into auto, you must toggle the system key to auto.
Features
www.pro1iaq.com
Cut Out For
Warranty Registration
