PROAIM Universal P-DMC-59 Bedienungsanleitung

1

What’s In The Box

Please inspect the contents of your shipped package to ensure you have received everything

that is listed below.

All rights reserved.

No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,

electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable

copyright statutes or in wring by the Publisher.

Universal 9” Monitor Director Cage (P-DMC-59)

Assembly Manua l

(4pcs) 3/8 x 16 mm

LCD mount screw

Monitor Cage Neck Strap Velcro Strap

4 x Teradek XT/LT 1/4 LCD screw

(12pcs) 6x 4 mm

Gruve screw

(4pcs)

4 x12 mm LN Bolt (6pcs) 3 x12mm

pan Philips screw (6pcs) 1/4 X12.5 mm

BH screw

(4pcs) 3 x 6 mm

LN Screw

(2pcs) 1/4 x 14 mm

LCD Mount Screw

(4pcs) 3 x 8 mm

Philips screw

(6pcs) 1/4 X 9.5

mm LN Screw

6 x Washer

Sun Shade

3/16, 4mm, 3mm,

2.5mm, 2mm

Allen key

2x brackets

2

Monitor Cage Setup

 Aach the LCD securely into the cage and

ghten the screw with the help of provided

allen key.

 Mount the monitor cage into the stand and

ghten the provided knob to secure it

properly.

NOTE: you can adjust the height of the cage

according to the LCD monitor.

 Insert the side handles to the monitor cage

and ghten the knob.

 Remove the baery plate by loosening the

screw both side cage rod.

3

 Slide the v-mount baery and aach the

Baery into Baery plate.

 Push the buon of the top baery plate and

remove the v-mount Baery.

 Insert the Sun shade into the provided space

in order to aach it with the monitor cage.

 Insert the strap hook into the cage provided

four connecon point.

 The monitor cage easily held in hand.

4

YOUR PROAIM DIRCTOR’S MONITOR CAGE

ALL DRESSED UP AND READY TO GO!

Warranty: We oer one year warranty for our products from date of purchase. Within this period of

me, we will repair it without charge for labor or parts. Warranty doesn’t cover transportaon costs nor

does it cover a product subjected to misuse or accidental damage. Warranty repairs are subjected to

inspecon and evaluaon by us.

Liability: We are not liable for damage caused by products that we do not supply or from mishandling

in transit, accident, misuse, neglect, lack of care of the product, or service by anyone other than our

company.

Contact Us: In case of any kind of dissasfacon, please Contact us immediately and we promise our

utmost support and care unl you use our product.
