Project Timber Evolution My Den Bedienungsanleitung

10x8

Evolution My Den

Building Instructions

Cover Size:

Please read the instruction carefully

and retain for future reference

For Queries and Help please contact 01777 802300

Please note that all images are for illustration purpose only.

V1.4 20.04.22 INS0137

10x8 My Den - Metal Roof

Side Opening Window (RIGHT)

Building shown

10x8 Evolution My Den

Metal Roof

Side Window Opening (RIGHT)

shown Floor Assembly

1467mm x 1217mm (4)

Metal Roof

position 610mm

505mm

1000mm

585mm

1220mm 1220mm

Back Panels

position

Front Panels

position

610mm

Single

Door

Panel

610mm 610mm

1220mm1220mm

1220mm

(LOW)

1220mm

(LOW)

1220mm

(HIGH)

585mm

610mm 610mm

610mm

Side

Window

Opening

(RIGHT)

Door

Position

(LEFT)

10x8 Floor Plan

Front of Building

Door Position (LEFT)

Door Position (RIGHT)

Door and Front Windows position options

Single Door Panel

(LEFT)

Glazing Units

(610mm)

Single Door Panel

(RIGHT)

Glazing Units

(610mm)

To p

Panel

Bottom

Panel

To p

Panel

Bottom

Panel

IMPORTANT: Always check the internal lining corner gap of the panels

Side Opening Window (LEFT)

position option

Front

Left Side

1220mm1220mm

1220mm

(LOW)

1220mm

(LOW)

1220mm

(HIGH)

585mm

610mm 610mm

610mm

Side

Window

Opening

position

(LEFT)

Door

Position

RIGHT

Floor Plan

Front of Building

2135mm

1220mm

Side Window

Opening Panel

(LEFT)

Diagram

ID: PT25521

Drip Edge

Flashing

Barge Board

Flashing

Gable Panel

(LEFT - Low)

Gable Panel

(LEFT - High)

Back Corner

Trims

Front Corner

Trims

Base Module

A - LEFT

Base Module

A - RIGHT

Base Module

B - CENTRE

11mm Floor

Panels

8ft Gable

Plinth

10ft Plinth

Top Plain

Panel

Bottom Plain

Panel

Single Door

Panel / UPVC

Single Door

(LEFT SIDE)

Gable Panel (High)

with Window Opening

Gable Panel

(Right - Low)

Plain Panel

Back - LEFT

(1220mm WIDTH)

Window Panels

(610mm WIDTH)

Roof Section

1000mm Width

Roof Section

505mm Width

Roof Section

610mm Width

Roof Section

1000mm Width

Rear Frame

Standoff

Gable Frame

Standoff

Plain Panel

(585mm WIDTH)

Plain Panel

Back - RIGHT

(585mm WIDTH)

10ft Front Monopitch

Ridge Flashing

10ft Back Water

Deflector Flashing

Building Parts: 10x8 Evolution My Den

Metal Roof

Building Parts

Part ID

PT25544

PT25545

PT25524

PT25533

PT25535

PT20322

PT25547

21140

21148

21192

21181

21182

21183

21177

15603

15606

PT18490

PT25522

PT25534

PT20329

19525

PT25385

PT25386

PT18177

PT21078

Wood Kit

QTYNo.

16 17

21 21

Base Module Woodkits

1220mm 585mm

Base Modules (For each end of the assebled base)

Gable Bearers

Fixing Kit

1. Base Module A - 1220mm x 2528mm (2)

[ID: PT23585]

2. Base Module B - 585mm x 2528mm (1)

[ID: PT25386]

3. Gable Bearers - 38mm x 2452mm (2)

[ID: PT23598]

Parts List required:

Base Module fixing

Side

Front

Module A x2

Module B x1

1220mm 1220mm

585mm

Side

1220mm

Module

Pilot drill

holes before

fixing

Base Module fixing

100mm

Screws

ID: PT25385

Side

585mm

Module

Pilot drill

holes before

fixing

Base Module fixing

100mm

Screws

ID: PT25386

Base Module Stages

Side

Front

Back

Position the gable bearers each side to

the fully assembled base. Secure with

S70 screws

Base Module fixing

70mm

Screws

ID: PT23598

Side

Front

Gable Bearers are fitted on each side of

fully assembled base. This gives extra

room for the floor sections. (see diagram)

Pilot drill holes

before fixing

Base Module fixing

70mm

Screws

Side

Front

Back

Alternate sides

to screw together

Pilot drill holes

before fixing

Base Module fixing

70mm

Screws

Side

Front

Back

Ensure the ground must be flat and level,

before laying the base module assembly.

Base Module fixing

Check the base module can sit level to the

ground. Use spirit level when leveling all

corners of the base.

Base Module fixing

Side Front

Floor Joist

Floor Boards

Side of

Base Module

Plinth

Gable

Bearer

Base Module fixing

78 9

5 6

Floor Section Stages

Side

Front

Back

Lay and fix the Plinth

lengths together at

the corner

Pilot drill

holes

Floor Stages

4 70mm

Screws

ID: 15603

ID: 15606

Plinth

Base Module

Position the plinth into the top of

assembled base module

Floor Stages

Base Module fixing

Side

Front

Fix and secure the

plinth and base

module together

Side

Front

Back

Floor Stages

Pilot drill holes

before fixing

70mm

Screws

Fix the Floors together

Floor Stages

Side

Front

Back

11mm Floor

assembly shown

ID: PT18177

Floor Sections Diagram

Wall

Panel

Plinth

Gap

Base Module

Side View

Floor

Boards

Floor Joist

13 14 15

11 12

Floor Section Stages

Wall Panels Section Stages

Panel Position Diagram

Front of Building

Rear

Side

(Left)

Side

(Right)

Side

(LEFT) Front

1. Door Panel - LEFT (1)

2. UPVC Single Door - LEFT (1)

3. Left Gable Panel - HIGH (1)

4. Left Gable Panel - LOW (1)

5. Gable Cloaking Strip (1)

60mmx16mmx2050mm

Parts List required:

ID: PT20329 / 19503 ID: PT25534

16mm

2135mm

74mm1146mm

1220mm

Lining Flush

16mm

2135mm

1220mm

Lining Flush

Single Door Panel

Diagram Left Gable Panel (HIGH)

Diagram

12 50mm

Screws

Floor Stages

Fix the Floors with

screws in angled

position

Back

Side

Floor Stages

Side

Front

Back

Place the floor assembly

inside the plinth and

base module.

Wall Panels Section Stages

2 50mm

Screws

Front

Side

(LEFT)

Pilot drill holes

before fixing

*Check the Side Opening

Window (LEFT) position

option floor plan for

guidelines.

Position and fix

the plain gable

panel (Left)

Left Gable (High) Panel Stages

ID: PT25534

50mm

Screws

Front

Side

Front

Side

(LEFT)

Pilot drill holes

before fixing

Align and fix the door

panel to the left gable

panel (high) and plinth

Left Gable and Door Panel (LEFT) Position

Front

Side

Lining

Flush

Lining

Flush

Left Gable (High) Panel Stages

Front

Side

(LEFT)

Align and fit the UPVC Door Cill

to the door panel (LEFT)

UPVC Door fixing

ID: 19503

80mm

Screws

Front

Fix and secure the UPVC

Door Cill to the door panel

UPVC Door fixing

ID: 19503

50mm

Screws

Side

Front

Pilot drill holes

before fixing

Fit the Plain Gable

Panel and Door

Panel in this position

Gable and Door Panel Position

21 22 23

19 20

Wall Panels Section Stages

80mm

Screws

Front

Fix and secure the UPVC Door

section to the door panel

UPVC Door fixing

ID: 19503

50mm

Screws

Side

(LEFT)

Pilot drill holes

before fixing

Cloaking Strip is used to fix

the panels together

Position and fix

the gable

cloaking strip

LEFT - Gable Cloaking Strip (CS)

ID: PT21078

Front

Side

(LEFT)

Position and fit the UPVC Door

section to the door panel (LEFT)

UPVC Door fixing

ID: 19503

50mm

Screws

Side

(LEFT)

Front

Pilot drill holes

before fixing

Position and fix the Side

Gable (Low) Panel

Left Gable (Low) Panel Stages

ID: PT25533

16mm

2094mm

1220mm

Lining Flush

Left Gable (Low) Panel Diagram

ID: PT25533

27 28

25 26
