INSTALLATION AND SETUP GUIDE

GENERAL INFORMATION

The 6150RFPL2 Keypad/Transceiver is a combination unit incorporating a normally-open relay output and the functions of:

•6150PL2 Fixed Addressable Keypad

•5881ENH RF Receiver

•5800TM Transmitter Module

The 6150RFPL2 Keypad/Transceiver may be used on any control panel that supports the 6150PL2 Keypad (e.g., 250P1).

Wireless Features

The 6150RFPL2 supports the following:

•5828/5828V wireless keypads.

•Up to eight wireless keys locally (programmed directly into

6150RFPL2) without occupying any zones supported by the

control panel.

•Button-type transmitters (e.g., 5804, 5804BD) for local operation.

•A maximum of 16 transmitters programmed into any 5800

Series-supported control panel.

•Wireless keys with high-security (e.g., 5804E).

•RF jam detection when the receiver is enabled.

•Low-battery indications for the local wireless keys.

•A nominal range of 200' for the RF transmitters (some

transmitters have a shorter range).

•Wireless keys for control panels that do not support RF

themselves (such as 4110DL).

•Sends status signals (Armed, Ready, etc.) to bi-directional

units such as 5804BDV and 5828/5828V.

LThe 5802, 5802MN, 5802MN2, 5804, 5804BD, 5804BDV, 5804E, 5814, 5816TEMP, 5819, 5819BRS, 5819WHS, 5828/5828V and 5850

transmitters are not intended for UL installations.

Programming Features

•Auto Enroll mode for programming wireless keys.

•Provides a method for deleting a serial number and re-enrolling a new one in its place.

•Provides default settings for the wireless key functions.

Additional Features

•Operates the on-board relay in conjunction with the receiver (e.g., to trip a garage door opener).

LThis feature is not intended for UL installations.

•Activates relays programmed into the control panel.

•Provides an End User mode to enable/disable local wireless keys (e.g., if a user accidentally loses a wireless key). Refer to the

6150RFPL2 User Guide for this procedure.

INSTALLING THE 6150RFPL2

Locate the 6150RFPL2 in an area and at a height where it is convenient for user operation. The 6150RFPL2 must be at least 10

feet from the control panel to ensure proper operation of the RF receiver. Perform the following steps to install the 6150RFPL2.

Refer to Figure 1 for wiring connections

Step Action

1 Remove the case back by pushing down the 2 snaps along the 6150RFPL2’s bottom edge and pulling the case apart.

Mount the case back directly to a wall in either of two ways (see table below), depending on the type of tamper

protection desired.

you want tamper protection against…

Then

mount case back…

removal of cover (removal causes transmission of

tamper signal).

using mounting holes.

removal of cover and of keypad from wall

(removal of either causes transmission of tamper

signal.

using mounting holes and placing additional screw through

hole in case back area surrounded by perforations along the

right side looking at the case back from the rear.

3 Connect the power and data wires from the control panel to the terminals on the 6150RFPL2 as indicated in the

wiring table adjacent to Figure 1.

4 Reattach the keypad to its case back.

5 Remove the clear protective films from the LCD display.

- 2 -

WIRING TABLE

Keypad Control Panel Wire Color

▲GData In Green

−−Aux Pwr (GND) Black

++ Aux Pwr Red

▼YData Out Yellow

Note: NO (normally Open) and C (common) are the

connections for the relay output

6150RF-003-V2

NO C

Figure 1 – 6150RFPL2 Wiring Connections

APPLICATION GUIDELINES

Use the following guidelines when planning an installation:

•Local wireless keys (wireless keys programmed directly into the 6150RFPL2) may be used regardless of whether

the RF receiver in the 6150RFPL2 is enabled or disabled.

•If using bi-directional devices, be sure to enable the transmitter module in the 6150RFPL2.

•If transmitters are programmed into the control panel, be sure to enable the receiver. (Make sure you do not

exceed the number of receivers supported by the control panel.)

•If a local wireless key is programmed to arm/disarm or to trigger a relay on the control panel, a user code must be

entered into the 6150RFPL2. This user code must also be programmed into the control panel.

•You must set the House ID only if you are using RF keypads and/or bi-directional devices; AND the House ID

Source is the 6150RFPL2 (Local).

6150RFPL2 Application Guide

The following guide outlines how to program the wireless keys, RF receiver, and the House ID in the 6150RFPL2 for

your installation.

* If using an RF keypad on only one partition, the 6150RFPL2’s partition assignment in panel programming must match the partition.

** If set for Local on a partition control, the 6150RFPL2’s partition assignment must match the one programmed in the BD device.

An example of an installation using two 6150RFPL2

Keypad/Transceivers with 2-Way Wireless Devices (e.g.,

5828V) on Two Partitions is shown below:

Settings 6150RFPL2 #1 6150RFPL2 #2

Keypad: Must be assigned to

Partition 1 in the

control panel

Must be assigned to

Partition 2 in the

control panel

House ID: Match Partition 1

House ID in the

control panel and

House ID in Wireless

Device

Match House ID in

Wireless Device

House ID

Source:

System Local

Receiver

Enable:

On Off

Transmitter

Enable:

On On

Are you using

6150RFPL2 Programming Options

System Control Panel RF keys

beyond

system’s

capacity?

RF receivers

beyond

system’s

capacity?

RF keypads and/or

Bi-directional

devices on more

than 1 partition?

Program

Wireless Keys

Into Receiver

Enable

House ID

Source**

4110DL, 4110XM N/A N/A N/A 6150RFPL2 OFF Local [0]

NO NO N/A System ON [1] System [1]

YES NO N/A 6150RFPL2 ON [1] System [1]

300P1, VISTA-10P

YES YES N/A 6150RFPL2 OFF [0] Local [0]

NO NO NO* System ON [1] System [1]

YES NO NO* 6150RFPL2 ON [1] System [1]

YES YES NO* 6150RFPL2 OFF [0] Local [0]

NO YES YES System OFF [0] Local [0]

320P1

YES YES YES 6150RFPL2 OFF [0] Local [0]

CONTROL

PANEL

6150RFPL2

-3 -

PROGRAMMING THE 6150RFPL2

The 6150RFPL2 is shipped with pre-programmed default values. Later in these instructions are diagrams showing the wireless

keys' loops and their default functions. Regardless of which wireless key you use (even if it is one

not shown), loops 1-4 are defaulted for all eight devices as shown. These values may be changed to suit the installation.

Entering Program Mode

Press the [1] and [3] keys simultaneously for a few seconds,within 30 seconds after applying power. The keypad beeps three (3)

times, and two dashes and two zeroes flash alternately in the upper left-hand corner of the display. If any other numbers or

letters flash in the display, press the [✻] key.

Note: The keypad will not enter programming mode if the system has been armed before the 6150RFPL2 was powered up or down.

Pressing the [1] and [3] keys 30 seconds or more after applying power allows you to enter the User mode. This mode allows you to

enable and disable individual local wireless keys (useful if, e.g., a user accidentally loses a wireless key). Refer to the User Guide for

instructions.

Programming Operations

Once you have entered the Program mode, you may move to any program address simply by entering the program address

number. The 6150RFPL2 will automatically exit the Program mode if no keys are pressed for 90 seconds. While in the Program

mode:

•Pressing the [✻] key stores the information displayed, then moves you to the next prompt, and the keypad beeps twice.

•Pressing the [#] key erases the current information and moves you back so you may enter the correct information.

Enter a program address (e.g., press [1] for Keypad Address; [2] for Receiver Address) to set the parameters in the

6150RFPL2.The following chart lists the program addresses, the keypad display, and the choices.

Program

Address Description Display Choices Default

1Keypad Address cA 01-31 31

2Receiver Address rA 00-30 00

3House ID HI 01-31 10

4House ID Source hS 1 = System

0 = Local

1 System

5Wireless Key Editing d- Enter Existing Device Number

6Receiver Enable rE 1 = On 0 = Off 1 Enable

7Transmitter Module Enable tE 1 = On 0 = Off 1 Enable

8Wireless Key Auto Enroll d* Enter Serial Number

8 then 2 Wireless Key User Code u4 Enter 4-Digit User Code

8 then 4 Wireless Key Loop Function Ln Enter Loop Number then Function

(See Wireless Key Function Chart)

Loop 2 1 (Disarm)

Loop 3 2 (Arm Away)

Loop 4 3 (Arm Stay)

8 then 5 Wireless Key On-Board Relay

Assignment

o- Enter Loop Number then Relay

Action

Loop 1 Close for 2 Seconds

9Restore Defaults EE 1 = Restores Defaults

Any Other Key = Does Not

Restore Defaults

0High Security Mode✝En 1 = Enable; 0 = Disable 0 Disable

* The keypad will display the next number that can be enrolled (i.e., “d3”)

✝When operating the system in High-Security mode, non-encrypted wireless keys will not function.

Defaulting the 6150RFPL2

To restore the 6150RFPL2 to the default values, perform the following steps:

Step Action

1. Enter the Program mode by pressing the [1] and [3] keys simultaneously for a few seconds within 30 seconds after

applying power. The keypad alternately flashes “oo” and two dashes.

2. Press the [9] key. The display flashes “EE.”

3. Press the [1] key to restore the default values, or press any other key to exit without restoring the default values.

If you pressed [1], the keypad beeps three (3) times and returns to alternately flashing “oo” and two dashes. If you

pressed any other key, the keypad will beep two (2) times, and return to alternately flashing “oo” and two dashes.

4. Press [✻] to exit the 6150RFPL2 Program mode.

- 4 -

Programming Procedure

This section is divided into two parts.

•Programming for an installation WITHOUT local wireless keys.

•Programming for an installation WITH local wireless keys.

Using the programming procedure WITH local wireless keys, is necessary only if you plan to use wireless keys

beyond the control panel’s capacity, or on a system that does not support 5800 Series wireless. Refer to the

6150RFPL2 Application Guidelines section for installations that require these settings.

Note: See the control panel's installation instructions for the acceptable keypad and receiver addresses.

If you are using a wireless key in High-Security mode (5804E) in the control panel, it will occupy one of the devices in the 6150RFPL2.

Programming for an Installation WITHOUT Local Wireless Keys

To program the 6150RFPL2 for an installation without any local wireless keys, perform the following steps:

Step Action Display

1. Enter the Program mode by pressing the [1] and [3] keys

simultaneously for a few seconds within 30 seconds after applying

power or within 30 seconds after removing the case back.

Alternately flashes "oo" and two dashes.

2. Enter [1] (Keypad Address). Enter the 2-digit keypad address (01-31).

Press the [✻] key to continue.

Alternately flashes "cA" and the 2-digit keypad

address.

3. Enter [2] (Receiver Address). Enter the 2-digit receiver address (00-30).

Press the [✻] key to continue.

Alternately flashes “rA” and the 2-digit receiver

address.

4. Enter [4] (House ID Source). Enter [1] (System) to use the House ID

programmed into the control panel, if RF keypad(s) and/or bi-

directional device(s):

•Are used on the control panel.

•Neither is used.

Enter [0] (Local) to use the House ID programmed into the 6150RFPL2

(Program Address 3).

Note: If the House ID Source is:

•System (1), RF keypad and bi-directional units MUST match the

House ID programmed into the control panel.

•Local (0), RF keypad and bi-directional units MUST match the

House ID programmed into the 6150RFPL2.

Press the [✻] key to continue.

Alternately flashes “hS” and either "1" or "0."

5. Enter [6] (Receiver Enable). Enter [1] to enable, or [0] to disable.

Enable the receiver if RF transmitters or wireless keypads are

programmed into the control.

Note: Make sure the number of receivers set for Enable (1) does not

exceed the capacity of the control panel.

Press the [✻] key to continue.

Alternately flashes “rE” and either "1" or "0."

6. Enter [7] (Transmitter Module Enable). Enter [1] to enable, or [0] to

disable. Enter [1] if bi-directional devices are being used.

Note: If the House ID Source is System and more than one 6150RFPL2 is

used, make sure each of the keypads have the Transmitter Module

enabled. See Note under House ID Source step 4.

Press the [✻] key.

Alternately flashes “tE” and either "1" or "0."

Step Action Display

7. Enter [0] (High-Security Mode). To put the system into High-Security

mode, enter [1]. Enter [0] to disable.

8. Press the [✻] key to exit the 6150RFPL2 Program mode. “READY” or “NOT READY”

Note: This is all the 6150RFPL2 programming necessary for this application. Upon exiting the Program mode, the 6150RFPL2

alternately flashes "Ad," the 2-digit keypad address, and the 2-digit receiver address. If either of these is incorrect, repeat steps 1

through 3.

-5 -

Programming for an Installation WITH Local Wireless Keys

•The 6150RFPL2 is supplied with default settings for the functions of the wireless keys. See page 3.

•If, during the programming of the wireless keys, you make a wrong entry and want to reprogram a wireless key, simply

press the [#] key, then enter the correct information.

Perform steps 1-6 in the Programming for an Installation Without Local Wireless Keys section. Then perform the following steps:

Step Action Display

1. Enter [3] (House ID). Enter the 2-digit House ID for the 6150RFPL2

(01-31).

Note: The House ID is needed only if RF keypads and/or bi-directional

units are used and House ID source is set for Local.

The House ID entered here MUST match the House ID

programmed in the RF keypad and the bi-directional unit.

Press the [✻] key to continue.

Alternately flashes “hl” and a 2-digit number.

2. Enter [8] (Wireless Key Auto Enroll). The 6150RFPL2 automatically

advances to first available device number.

Note: If all 8 devices have been enrolled, the 6150RFPL2 beeps three

times and continues to alternately flash "oo" and "--."

Flashes "d" with the next available device

number; followed by “- -“ (four times) and then

repeats the sequence.

3. Press any button on the wireless key to enroll the serial number. The

keypad will beep three times.

Note: If enrolling a wireless key (5804E) in high-security mode, press all

four buttons on the wireless key simultaneously.

Alternately flashes "d" with the device number

and the serial number.

4. Press the [✻] key to accept the serial number; OR press the [#] key to

reject the serial number.

If you accept the serial number, the 6150RFPL2 beeps two times. If

you reject the serial number, the 6150RFPL2 beeps once and returns

to the “enroll serial number” prompt.

Note: A maximum of 8 wireless keys may be enrolled into the

6150RFPL2. These wireless keys DO NOT occupy any zones

supported by the control.

If you are finished programming for now, press [✻] to exit. Otherwise,

continue with step 5.

If you accept the serial number, the display

flashes the device number and a hyphen.

If you reject the serial number, the display

flashes "d" with the device number followed by

“--” four times.

5. Enter [2] (User Code). Enter the 4-digit user code for the wireless

key.

Note: The user code must be a valid code that is programmed in the

control panel.

Press the [✻] key to accept the user code.

If you are finished programming for now, press [✻] to exit. Otherwise,

continue with step 6.

Flashes "u4." Once the 4-digit user code is

entered, the display flashes "u4," the first two

digits, and then the last two digits of the user

code.

Enter [4] (Loop Functions). Enter the loop number (1-4).

Note: The 6150RFPL2 is shipped with the loop functions pre-

programmed. Perform steps 6 through 10 only if it is necessary to

change any of the loop functions.

Loop 1 Close the 6150RFPL2 On-Board Relay for 2 sec.

Loop 2 1 (Disarm)

Loop 3 2 (Arm Away)

Loop 4 3 (Arm Stay)

See the Wireless Key Function Chart below for the choices.*

* Entering a number other than the one specified may give

unpredictable results

Flashes "Ln."

Once the loop number is entered, alternately

flashes "L" with the loop number; and the present

function.

- 6 -

Step Action Display

(Cont’d)

Wireless Key Function Chart

Function Entry

Disarming 1

Arming Away 2

Arming Stay 3

Arming Maximum (Away Instant) 4

Arming Instant 7

Panic Alarm

Produces type of alarm [* & #]

programmed in control panel.

# + 99

Manually Start a Relay Action # + 7 + n (250P1)

Manually Stop a Relay Action # + 8 + n (250P1)

n = Device Number programmed in 250P1 to be controlled

Press the [✻] key.

Default Loop Functions

5804

Loop 3

Arm AWAY

Loop 1

Close on-board relay

for 2 seconds

Loop 2

Disarm

Loop 4

Arm STAY

5804BD/5804BDV

Loop 3

Ar m AWAY Loop 1

Close on-board relay

for 2 seconds

Loop 2

Disarm

SET

HOUSE

CODE

•

••

•

•••

Loop 4

Arm STAY

NOTE: If the loop is defaulted with a function (e.g.,

Arm, Disarm) and also is assigned to activate

the on-board relay, the system performs

BOTH functions.

7. Repeat step 6 for the rest of the loops of the wireless key.

8. To program a button on the wireless key to control the on-board

relay, enter [5] (On-Board Relay Assignment).

Flashes "o-."

9. Enter the loop number of the wireless key (1-4). Enter the relay

action (0 = no action; 1 = relay off; 2 = relay on; 3 = relay toggles on

and off; 4 = relay closes for 2 seconds).

Note: The relay action must be "0" for UL installations.

Press the [✻] key.

Flashing “o” and the loop number.

Once the action is entered, displays “o” and

alternately flashes the loop number and the relay

action.

10. Repeat step 9 for the rest of the loops.

11. When all loops have been programmed for the wireless key, press the

[✻] key.

Flashes “d” followed by the device number.

12. The 6150RFPL2 automatically displays the next available device

number (one that does not have a serial number).

If you want to program additional wireless keys, repeat steps 3

through 10. Otherwise, press the [#] key. This takes you back to the

main display, which alternately flashes “oo” and “- -.”

13. Enter [0] (High Security Mode). To put the system into High-Security

mode, enter [1]. Enter [0] to disable.

Flashes “En” and “0” alternately OR “En” and

“1” if the keypad is in high-security mode

14. Press [✻] to exit the 6150RFPL2 Program mode.

Note: Upon exiting the Program mode, the 6150RFPL2 alternately flashes "Ad," the 2-digit keypad address, and the 2-digit receiver

address. If either of these is incorrect, repeat steps 1 through 3 in the Programming for an Installation Without Local Wireless

Keys section.

Deleting, Replacing, or Editing Wireless Keys

Use the following procedure to delete, replace, or change any of the programming for a wireless key.

Step Action Display

1. Enter the Program mode by pressing the [1] and [3] keys

simultaneously for a few seconds within 30 seconds after applying

power.

Alternately flashes "oo" and two dashes.

2. Enter [5] (Wireless Key Editing). Enter the device number for the

wireless key you want to edit. This must be a device that has its

serial number programmed in the 6150RFPL2 already.

To delete the serial number, press [✻], then press [9], and press [✻]

again.

To exit without deleting the serial number, press the [#] key.

Press the [✻] key to continue.

Flashes the device number and a hyphen.

Once the device number is entered, alternately

flashes "d" with the device number; and the serial

number.

-7 -

Step Action Display

3. To change any of the programming for the wireless key, perform one

of the following steps in the Programming for an Installation WITH

Local Wireless Keys section.

•For the user code, perform step 5.

•For the loop functions, perform steps 6 and 7.

•For the on-board relay assignment, perform steps 8 to 10.

Alternately flashes "d*" with the device number;

and “--.”

4. When you have completed editing the wireless keys, press the [✻] key

twice to exit the Program mode.

* The keypad will display the last number that was enrolled (i.e., “d3”)

Note: Upon exiting the Program mode, the 6150RFPL2 alternately flashes "Ad," the 2-digit keypad address, and the 2-digit receiver

address. If either of these is incorrect, repeat steps 1 through 3 in the Programming for an Installation Without Local Wireless

Keys section.

TROUBLESHOOTING

The following error messages cause the 6150RFPL2 to produce rapid beeps for 5 seconds. The table below describes

the error messages and the corrective actions.

Display Probable Cause Corrective Action

Lb Low battery in a wireless key 1. Replace the battery in the wireless key.

2. Replace the transmitter if the wireless key does not have a replaceable

battery.

OC Open circuit Verify that the Data Out wire is connected properly.

1C Incompatible connection Verify that the control panel is a Honeywell-type control panel.

Check 09 OR

Check 100 OR

Check 1nn *

1. 6150RFPL2 Receiver is

not communicating

2. Another device on the

keypad terminals is not

communicating to the

control panel

1. Verify that the Data In wire is connected properly.

2. Verify the wiring connections between the control and all other devices.

E8 Too many RF zones

programmed

Verify the number of transmitters programmed into the control panel

*nn = receiver address programmed in VISTA control panel

SPECIFICATIONS

Physical: 6-1/4” H x 4-7/8” W x 1” D

(158.75mm x 123.8mm x 25.4mm)

Wiring: Refer to Wiring Table on page 2

Range: 200' nominal

Frequency: 345 MHz

Voltage: 12VDC

Current: Standby 80mA

Backlighting on and

Sounder on 105mA

Relay: Normally-Open, 1A, 28VDC

Sounder: Piezo-electric (fire alarm is loud pulsing tone;

burglary/audible panic alarm is two tone

sound

FOR DETAILS ON THE LIMITATIONS OF THE ENTIRE ALARM SYSTEM, REFER TO THE INSTALLATION INSTRUCTIONS

FOR THE CONTROL PANEL WITH WHICH THIS DEVICE IS USED.

This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful

interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT

This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your

information:

This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manu-

facturer's instructions, may cause interference to radio and television reception. It has been type tested and found to comply with the limits for a

Class B computing device in accordance with the specifications in Part 15 of FCC Rules, which are designed to provide reasonable protection

against such interference in a residential installation. However, there is no guarantee that interference will not occur in a particular installation. If this

equipment does cause interference to radio or television reception, which can be determined by turning the equipment off and on, the user is

encouraged to try to correct the interference by one or more of the following measures:

• If using an indoor antenna, have a quality outdoor antenna installed.

• Reorient the receiving antenna until interference is reduced or eliminated.

• Move the radio or television receiver away from the receiver/control.

• Move the antenna leads away from any wire runs to the receiver/control.

• Plug the receiver/control into a different outlet so that it and the radio or television receiver are on different branch circuits.

If necessary, the user should consult the dealer or an experienced radio/television technician for additional suggestions. The user or installer may

find the following booklet prepared by the Federal Communications Commission helpful: "Interference Handbook"

This booklet is available from the U.S. Government Printing Office, Washington, DC 20402.

The user shall not make any changes or modifications to the equipment unless authorized by the Installation Instructions or User's Manual.

Unauthorized changes or modifications could void the user's authority to operate the equipment.

LIMITED WARRANTY

Honeywell International Inc., acting through its Security & Custom Electronics business ("Seller") 165 Eileen Way, Syosset, New York 11791,

warrants its product(s) to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under

normal use and service for 24 months from the date stamp control on the product(s) or, for product(s) not having a manufacturer’s date stamp, for

12 months from date of original purchase unless the installation instructions or catalog sets forth a shorter period, in which case the shorter period

shall apply. Seller's obligation shall be limited to repairing or replacing, at its option, free of charge for materials or labor, any product(s) which is

proved not in compliance with Seller's specifications or proves defective in materials or workmanship under normal use and service. Seller shall

have no obligation under this Limited Warranty or otherwise if the product(s) is altered or improperly repaired or serviced by anyone other than

Honeywell factory service. Connection of any device(s) to a communicating bus of a Honeywell security system (e.g., keypad bus, polling loop)

other than those manufactured or approved by Honeywell shall void this warranty. For warranty service, return product(s) transportation prepaid, to

Honeywell Factory Service, 165 Eileen Way, Syosset, New York 11791. THERE ARE NO WARRANTIES, EXPRESS OR IMPLIED, OF

MERCHANTABILITY, OR FITNESS FOR A PARTICULAR PURPOSE OR OTHERWISE, WHICH EXTEND BEYOND THE DESCRIPTION ON THE

FACE HEREOF. IN NO CASE SHALL SELLER BE LIABLE TO ANYONE FOR ANY CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR BREACH OF

THIS OR ANY OTHER WARRANTY, EXPRESS OR IMPLIED, OR UPON ANY OTHER BASIS OF LIABILITY WHATSOEVER, EVEN IF THE LOSS OR

DAMAGE IS CAUSED BY THE SELLER'S OWN NEGLIGENCE OR FAULT.

Seller does not represent that the product(s) it sells may not be compromised or circumvented; that the product(s) will prevent any personal injury

or property loss by burglary, robbery, fire or otherwise; or that the product(s) will in all cases provide adequate warning or protection. Customer

understands that a properly installed and maintained alarm system may only reduce the risk of a burglary, robbery, fire, or other events occurring

without providing an alarm, but it is not insurance or a guarantee that such will not occur or that there will be no personal injury or property loss as
