PTN Electronics

PS121 Presentation Switcher

User Manual

Please read this manual carefully before using this product.

PS Series --- Presentation Switche

Auto-SwitchLearning Function

PS121 Presentation Switcher

PTN Electronics Limited www.PTN-electronics.com

Content table

1.Function.................................................................................................................................................. 5

2.Front Panel............................................................................................................................................. 6

3.Real Panel.............................................................................................................................................. 7

4.Controlling .............................................................................................................................................. 8

5.Specification......................................................................................................................................... 12

6.Connection of PS121 and WP18R................................................................................................... 13

7.Optional accessory.............................................................................................................................. 14

8.System Diagram.................................................................................................................................. 15

9.Troubleshooting & Maintenance ....................................................................................................... 15

PS121 Presentation Switcher

PTN Electronics Limited www.PTN-electronics.com

Attention：

This is a manual for Presentation switcher PS121.

This manual is only an instruction for operators, not for any maintenance usage. The

functions described in this version are updated till Jan 2010. Any changes of functions

and parameters since then will be informed separately. Please refer to the dealers for

the latest details.

publication may be copied or reproduced without the prior written consent of PTN

Electronics Limited.

All product function is valid till 2010-1-1

Operation Notice

PS121 Presentation Switcher

PTN Electronics Limited www.PTN-electronics.com

In order to ensure the credibility use of the product and the user’s safety, please comply with the

following items during installation and maintenance:

The system must be earthed properly. Please do not use two blades plugs and ensure the

alternating power supply ranged from 100v to 240v and from 50Hz to 60Hz.

Do not put the machine in a place of too hot or too cold.

To avoid any damage by over heat, please keep the working environment good in ventilation to

radiate the heat when running the machine.

The machine should be turned off when in rainy and humid days or nonuse for a long time.

The AC power supply line should be disconnected with the power socket during the following

operation.

A. Take out or reinstall any component of the machine.

B. Disconnect or re-connect any connector of the machine.

Please do not attempt to maintain and uncover the machine for there is a high-voltage component

inside and the risk of the electric shock.

Do not splash any chemical product or liquid on or near the equipment.

PS121 Presentation Switcher

PTN Electronics Limited www.PTN-electronics.com

1. Function

PTN PS121 switcher is the multi-format input unit special for the presentation usage, built in

the RS232/RS485 controller. It is the economical and high level solution for the audiovisual

system.

zIt has three parts DVI 4x1 selection switcher, VGA 4x1 selection switcher, C-Video

4x1 selection switcher, separately working.

zVideo:

a) The DVI signal input is compatible with DVI1.0 and HDMI 1.3 video, i.e.340 MHz

(10.2 Gbit/s). It supports the HDCP, EDID, DDC.

b) The VGA signal input supports the super bandwidth, up to 750MHz(-3dB).

Supporting HDTV.

c) The Composite video signal input is compatible with NTSC 3.58, NTSC 4.42,

PAL, and SECAM

d) Video resolution adjustable, ranging from 800*600@60Hz to 1280*1024@60Hz (4:3

display), 480p to 720p (16:9 display), Maximum resolution 1920*1200.

zAudio:

a) Three following Audio parts, 4*1 DVI, 4*1 VGA, 4*1 C-video, stereo

balanced/unbalanced on capture screw connector, supports Volume input

adjustable and preset.

b) One program audio output (Line audio), break away, supports volume output

adjustable separately, preset, and volume output adjustable mixed with MIC,

preset

c) One MIC input. Support volume output adjustable

zAuto-control and Learning function:.

a) The PS121 will automatically send out the RS232/RS485 command by the

RS232/RS485 port to the third-party device, for controlling the display device,

including input source changing, and others.

b) The PS121 can infinitely learn the new RS232 series command of your display

device.

PS121 Presentation Switcher

PTN Electronics Limited www.PTN-electronics.com

zControl :

a) RS-232 serial control port. Public command, working with the third-party device.

b) RS-232/RS-485 output, programmable output. The user can customize the

RS-232/RS-485 commands, controlling the displaying equipments.

c) IR remote control .Default IR remote to control the full function of selection

switcher

zRack-mountable aluminum enclosure, 1 U height.

zInternal international power supplies (100Volt~240Volt AC, 50/60Hz) for worldwide

compatibility, all models are equipped with an internal, auto-switching power supply

that meets or exceeds all appropriate safety certifications.

2. Front Panel

1) DVI signal selection zone:

You can select any one channel of the 4 DVI signal channels by pressing the button

marked by the corresponding NO 1.2.3.4. Status showed by the LED indicating light.

2) Composite video selection zone:

You can select any one channel of the 4 Composite Video signal channels by

pressing the button marked by the corresponding NO 1.2.3.4. Status showed by the

LED indicating light.

3) VGA signal selection zone:

You can select any one channel of the 4 VGA signal channels by pressing the button

marked by the corresponding NO 1.2.3.4. Status showed by the LED indicating light.

4) Volume selection and adjust zone: Including one volume selection button and one

knob.

“Volume selection button”:

a) Alternatively switch between Line Audio and MIC Audio. Status showed by the

LED indicating light.

b) Press the “Volume Selection” button for 3 seconds. When the LED of line audio

flickers, it enters into the input audio volume adjustment status.At this time, input

volume can be adjusted by the knob. Single-Press the button again to return.

1 2 3 4

PS121 Presentation Switcher

PTN Electronics Limited www.PTN-electronics.com

“volume knob”:

a) Adjust the volume, with bar indicator on the screen.

b) Press the surface of knob to mute the audio.

5) Power status LED indicator

6) MIC Mono audio input connector

7) IR sensor

3. Real Panel

1) DVI signal connectors zone: 4 inputs * 1 output

2) Composite video signal connectors zone: 4 inputs * 1 output

3) VGA video connectors zone: 4 inputs * 1 output

4) Three parts of following audio connector zone: (Left to right order: VGA audio, DVI

audio, Composite audio, prog audio )

VGA audio connector: 3.5mm mini jack connector for VGA, 4 inputs * 1 output

DVI audio connector: Balance/unbalance Stereo audio on capture screw connector,

4 inputs * 1 output

Composite video following audio connector: Balance/unbalance Stereo audio on

capture screw connector, 4 inputs * 1 output

Prog audio: Line audio, break away, can mixed with any one of the following audio

and the MIC audio, adjust by Volume selection and adjust front button.

5) RS 232 input: connect to the control device, (see below the “RS232 protocol”)

6) RS 232 & RS485 output: connect to the display device (like projector, LCD displayer,

LED displayer etc.). When you switch PS121, it will send the presupposed RS232 or

RS485 command series. (see below the “RS232 protocol”)

7) Power supply

1 2

3 4

5 6

PS121 Presentation Switcher

PTN Electronics Limited www.PTN-electronics.com

4. Controlling

Part A: Remote operation

1) Audio volume adjustment zone:

“Mute”: mute the displaying audio signal.

“Audio Lock”: keep the last-selected audio display; it will not change with the new

switch operation.

“Line audio Button – and + ”: adjust the volume of line audio, with bar indicator on the

screen.

2) Video signal source/channel selection zone:

Video signal selection: press any button of the 4 to change to the corresponding

signal change and display, with signal indicating lag on the screen and the LED

indicator on the front panel.

VGA signal channel selection: 4 channels corresponding to 4 VGA inputs source.

Composite video signal channel selection: 4 channels corresponding to 4 composite

video inputs source.

DVI signal channel selection: 4 channels corresponding to 4 DVI signal inputs source.

2): Video signal source/channel selection

1): Audio adjustment zone

PS121 Presentation Switcher

PTN Electronics Limited www.PTN-electronics.com

Part B: PC or RS232 control

RS-232 Protocol

Baud: 9600bps 8,n,1 format: no ASCII

Series Function Feedback code

600% Mute Mute ON /Mute OFF

601% Master volume + VGA1 Volume : XX (0~60)

0602% Master volume - VGA1 Volume : XX (0~60)

603% MIC volume + MicVolume : XX (0~60)

0604% MIC volume - MicVolume : XX (0~60)

LOCK% Keyboard Lock System Locked!/System Unlock!

01XX% Set Line volume to ‘XX’0~60 Line out Volume : XX (0~60)

02XX% Set MIC volume to ‘XX’0~60 MicVolume : XX (0~60)

0700%

Check Series:

Current video source,

Switching series,

Last video source status,

Band rate

Source: VGA1

232/485 DVI data:

232/485 AV data:

232/485 VGAdata:

232/485 Current data:

Baud rate: 9600

0701% Switch to DVI 1 input Source: DVI 1

0702% Switch to DVI 2 input Source: DVI 2

0703% Switch to DVI 3 input Source: DVI 3

0704% Switch to DVI 4 input Source: DVI 4

0709% Switch to VGA1 input Source: VGA 1

0710% Switch to VGA2 input Source: VGA 2

0711% Switch to VGA 3 input Source: VGA 3

0712% Switch to VGA4 input Source: VGA 4

0705% Switch to C-video 1 input Source: CVIDEO 1

0706% Switch to C-video 2 input Source: CVIDEO 2

0707% Switch to C-video 3 input Source: CVIDEO 3

0708% Switch to C-video 4 input Source: CVIDEO 4

0747% Lock audio LOCK VOICE OUT

0748% Unlock audio input

(follow the video switch) UNLOCK VOICE OUT

PS121 Presentation Switcher

PTN Electronics Limited www.PTN-electronics.com

0800% Check the volume

DVI 1 Volume: XX (0~60)

DVI 2 Volume: XX (0~60)

DVI 3 Volume: XX (0~60)

DVI 4 Volume: XX (0~60)

AV 1 Volume: XX (0~60)

AV 2 Volume: XX (0~60)

AV 3 Volume: XX (0~60)

AV 4 Volume: XX (0~60)

VGA 1 Volume: XX (0~60)

VGA 2 Volume: XX (0~60)

VGA 3 Volume: XX (0~60)

VGA 4 Volume: XX (0~60)

MicVolume: XX (0~60)

0801% Set band rate to 4800 bps Baud rate: 4800

0802% Set band rate to 9600 bps Baud rate: 9600

0803% Set band rate to 19200 bps Baud rate: 19200

0804% Set band rate to 38400 bps Baud rate: 38400

0805% Set band rate to 57600 bps Baud rate: 57600

0806% Set band rate to 115200 bps Baud rate: 115200

/+1xxxx; Following the DVI switch, RS232/RS485

Series command: XXXXXXX 232/485 DVI data: XXXXXXX

/+2xxxx; Following theAV switch, RS232/RS485

Series command: XXXXXXX 232/485 AV data: XXXXXXX

/+3xxxx;

Following the VGA switch,

RS232/RS485 Series command:

XXXXXXX 232/485 VGA data: XXXXXXX

/+0xxxx; Direct output series by RS232/RS485

output: XXXXXXX 232/485 Direct out data: XXXXXXX

0900% Change all volume input mode Change to output vol control/Change to

input vol control

31XX% Set DVI 1 volume to XX DVI 1 Volume : XX 0~60

32XX% Set DVI 2 volume to XX DVI 2 Volume : XX 0~60

33XX% Set DVI 3 volume to XX DVI 3 Volume : XX 0~60

34XX% Set DVI 4 volume to XX DVI 4 Volume : XX 0~60

41XX% Set AV 1 volume to XX AV 1 Volume : XX 0~60

42XX% Set AV 2 volume to XX AV 2 Volume : XX 0~60

43XX% Set AV 3 volume to XX AV 3 Volume : XX 0~60

44XX% Set AV 4 volume to XX AV 4 Volume : XX 0~60

51XX% Set VGA 1 volume to XX VGA1 Volume : XX 0~60

52XX% Set VGA 2 volume to XX VGA2 Volume : XX 0~60

53XX% Set VGA 3 volume to XX VGA3 Volume : XX 0~60

54XX% Set VGA 4 volume to XX VGA4 Volume : XX 0~60

Inhaltsverzeichnis

Beliebte Schalten Handbücher anderer Marken

URC

URC Total Control MFS-8 Bedienungsanleitung

Azbil

Azbil HPQ-D11 Bedienungsanleitung

Sony

Sony DFS-900M Bedienungsanleitung

SICK

SICK i17S Bedienungsanleitung

F&F

F&F SZR-277 Bedienungsanleitung

Shure

Shure UAMS/BK Bedienungsanleitung

Dräger

Dräger X-zone Switch Off Bedienungsanleitung

Asco

Asco Joucomatic 349 Series Bedienungsanleitung

BT Mini Hub Bedienungsanleitung

D-Link

D-Link DES-1226G Bedienungsanleitung

Johnson Controls

Johnson Controls FS80-C Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Bedienungsanleitung

MicroNet

MicroNet SP1200A Bedienungsanleitung

Ruijie

Ruijie RG-PF2920 Series Installations- und Betriebsanleitung

Altinex

Altinex DA1914SX Bedienungsanleitung

MiLAN

MiLAN MIL-SM2401M Bedienungsanleitung

RJM

RJM MASTERMIND PBC/6X Bedienungsanleitung

Atlas

Atlas MMK-KVM8 Bedienungsanleitung
