PTN WHD4 Bedienungsanleitung

HDMISelectionSwitcher

PTN electronics Limited www.PTN-electronics.com

HDMI Switcher

WHD4 & WHD8

1 Function

WHD4 / WHD8 is a 4x1 / 8x1 selection switcher, which enables easy manual or RS232/infrared

remote switching within different HDMI sources.

It is a high performance HDMI device with resolution up to 1920*1200@60Hz, 1080p & 2K,

supporting EDID and DDC, with HDCP & HDTV compliant.

2 WHD4 / WHD8 (HDMI selection switcher 4x1 / 8x1)

WHD4:

WHD8:

USER MANUAL

HDMISelectionSwitcher

PTN electronics Limited www.PTN-electronics.com

3 Specification

Input Output

Input 4 / 8 HDMI Output 1 HDMI

Input Connector HDMI 1.3 Output Connector HDMI 1.3

Input Level T.M.D.S. 2.9V/3.3V Output Level T.M.D.S. 2.9V/3.3V

Input Impedence 50ΩOutput

Impedence 50Ω

General

Resolution Range Up to 1920 x 1200 or

1080P@60Hz Bandwidth 340 MHz (10.2 Gbit/s)

Switching Speed 200ns (Max.) Input / Output

Level T.M.D.S. 2.9V/3.3V

Gain 0dB Video Impedance 50Ω

EDID / DDC

Supports Extended Display Identification Data (EDID) and Display Data Channel (DDC)

data using DVI and HDMI standards, EDID and DDC signals are actively bufferred. The

built-in EDID/DDC database can analyze these two signals, mix them, and realize the

handshake of them internally.

HDCP

Compliant with High-bandwidth Digital Content Protection (HDCP) using DVI and HDMI

1.3 standards. The built-in HDCP management technology can analyze HDCP key, and

realize the handshake internally.

Control Parts

Control/Remote Buttons; RS-232 (9-pin female D

connector); IR remote

Pin

Configurations 2 = TX, 3 = RX, 5 = GND

General

Temperature -20 ~ +70℃Humidity 10% ~ 90%

Power Supply 100VAC ~ 240VAC, 50/60Hz Power

Consumption 10W

Case Dimension W155 x H30 x D80mm for WHD4

W310 x H30 x D100mm for WHD8 Product Weight 0.5Kg for WHD4;

1Kg for WHD8.

HDMISelectionSwitcher

PTN electronics Limited www.PTN-electronics.com

4 IR Remote

5 The switching command : RS232 controlling

Communication protocol:

Baud rate: 9600 Date bit: 8 Stop bit: 1 Parity bit: none

(WHD4 has the same protocol with WHD8, the only difference is without input5 to input8)

Command Function Description Feedback Code

1B1. Switching the audio/video to input 1 AV: 1 -> 1

2B1. Switching the audio/video to input 2 AV: 2 -> 1

2B2. Switching the audio/video to input 3 AV: 3 -> 1

2B3. Switching the audio/video to input 4 AV: 4 -> 1

2B4. Switching the audio/video to input 5 AV: 5 -> 1

2B5. Switching the audio/video to input 6 AV: 6 -> 1

2B6. Switching the audio/video to input 7 AV: 7 -> 1

2B7. Switching the audio/video to input 8 AV: 8 -> 1

0B0. Mute the output MUTE

0B1. UnMute the output UNMUTE

600% Checking the working status AV: 1 -> 1

HDMISelectionSwitcher

PTN electronics Limited www.PTN-electronics.com

6 System Diagram
