Pyle PLCD54MP Bedienungsanleitung

AM/FM/CD/MP3/USB/AUX Stereo Receiver, Single DIN,

30 Preset Memory Stations, LCD Display

with Remote Control (Black)

PLCD54MP

CD/MP3StereoReceiverPowerAmplifier

www.PyleUSA.com

CONTENTS

INTRODUCTION

What’s in the Box

DIMENSIONS

OVERVIEW OF THE COMPONENTS

GENERAL OPERATION

Power On/O

Removing The Front Panel

Volume Up And Down

Mute On/O

Changing The Modes

Setting The Audio/Menu

Display

Auxiliary Input Jack

Reset

RADIO OPERATION

Switch Between Europe/USA/Asian/Russian Frequency

Changing Bands

To Store / Recall Preset Stations

Manual Tuning

Seek Tuning

Automatic Store Preset Station

CD/USB OPERATION

Insert/Eject CD

USB Connection

Select Next Track Or Previous Track

Fast Forward/Reverse

Play/Pause

Introduction Scan

Repeating The Track

Playing All Tracks In Random

Folder/Track Navigation

WIRELESS BT OPERATION

Pair And Connect

Make A Call

Redial Last Dialed Number

Answer A Call

Reject A Call Or End A Call

Switch Audio Between Car Audio And Mobile Phone

Adjust Talk Volume Audio Streaming (A2DP)

APP OPERATION

SPECIFICATION

www.PyleUSA.com

INTRODUCTION

Do keep your original invoice and purchase receipt in a safe place in case

of future service and warranty claims. You may also contact your appointed

service agent for any future technicalsupport requirements.

What’s in the Box:

• Stereo Receiver

• Remote Control

Dimensions (Unit: mm)

1. 20

www.PyleUSA.com

WIRING CONNECTIONS

Violet

Purple/Black

Grey/Black

Gray

White/Black

White

Green/Black

Green

Red Ignition Line

Earth wire

ANT automatic

Power supply

Rear left horn (+)

Rear left horn (-)

Front left horn (+)

Front left horn (-)

Front right horn (+)

Front right horn (-)

Rear right horn (+)

Rear right horn (-)

Black

Blue

Yellow

COLOR FUNCTION

www.PyleUSA.com

COMPONENTS

OVERVIEW OF THE COMPONENTS

1. Power on/o, Mode (Source)

2. Volume knob, SEL (Push for Audio/Menu Setting)

3. AS (Auto Store Preset Station)

4. Mute

5. Preset #1, Play/Pause

6. Preset #2, Intro Scan

7. Preset #3, Repeat

8. Preset #4, Random

9. Preset #5, Folder Down, Jump 10 Track backward

10. Preset #6, Folder Up, Jump 10 Track forward

11. Answer Call, End Call (press and hold)

12. Tune/Track down, reverse

13. Tune/Track Up, fast forward

14. IR Remote Sensor

15. LCD Display

16. Band, Disp (Display clock time and other info)

17. USB Port

18. Aux Input Socket

19. Hands-free Microphone

20. Eject CD

21. Disc Slot

22. Reset

3 1214 1613

152219

www.PyleUSA.com

GENERAL OPERATION

Power On/O

• Press any button to turn the unit on.

• Press and hold the /MODE button to turn the unit o.

Removing The Front Panel

Press the RELEASE button to detach the front panel.

Volume Up And Down

Rotate the Volume knob to adjust the volume level.

Mute On/O

Briey press the button to toggle mute on or o.

Changing The Modes

Press the /MODE to select between Radio, Disc, USB (with USB device inserted),

AUX-IN (auxiliary input) and BT (Wireless BT) modes.

Seing The Audio/Menu

• Press Volume (SEL) button momentarily to select between the audio/

menu functions: BASS, TREBLE, BALANCE, FADER, EQ USER/FLAT/CLASSIC/

ROCK/POP, LOUD OFF/ON, BEEP OFF/ON, CLOCK 24/12, CLOCK SETTING,

BT MENU/AUTO, DISTANT/LOCAL, STEREO/MONO, AREA EU/US/AS/RU.

• Rotate the Volume knob to adjust or activate your desired function/audio.

Display

• With the unit on, press and hold DISP to display clock time.

• Press and hold DISP to toggle display between various displayed information.

Auxiliary Input Jack

Usinga 3.5mm cable to connecta external device such as MP3 players, CD

players etc. to the auxiliary input jack on front panel. Then you can hear the

sound of other playback devices such as MP3 players, CD players etc. through

your car speakers.

Reset

Push the RESET button (behind the front panel) with a thin object with a

pointed end to reset the unit back to the factory default settings 6 Second.

www.PyleUSA.com

RADIO OPERATION

Switch Befween Europe /USA/Asian/Russian frequency

In radio mode, press the Volume button momentarily to choose the“AREA EU/

US/AS/RU" item, then rotate it to switch between EU(europe), US (USA), AS

(Asian), RU(Russian) frequency. The system will change the frequency setting in

about 3 seconds.

Change Bands

In radio mode, shortly press the BAND/DISP to select between the FM1, FM2,

FM3 and AM1 (MW1), AM2 (MW2) bands.

To Store/Recoil Preset Stations

The radio can be stored 6 preset stations for each band (FM1, FM2, FM3, AM1

and AM2) for a total of 30 preset stations.

• To memorize a station:

Press and hold the desired preset buttons (1-6) to save a radio station.

• To recall a preset station:

Briey press the respective station button (1-6) to recall the corresponding

preset station.

Manual Tuning

In the radio mode:

Briey press the or button to search the next or previous frequency step

by step.

Seek Tuning

In radio mode:

Press and hold the or button to seek to next or previous strong station.

CD/USB OPERATION

Insert CD

With the label facing up, insert a standard size CD into the CD slot.

Playback will begin automatically.

Eject CD

Press (Eject button) to eject the CD.

www.PyleUSA.com

USB Connection

If you would like to playback les contained in a USB stick, please insert the

stick into the USB port. The MP3/WMA and other music les will be played

automatically.

Note: The USB port of this car radio is also designed for charging for iPhone/

andriod mobile phone. The charging current consumption is 1 ampere.

Select Next Track Or Previous Track

In the CD/USB mode, briey press the or button to play the next or

previous track.

Fast Forward/Reverse

Press and hold the or button to fast forward or reverse a track.

Play/Pause

Press the button to interrupt the CD/USB playback (pause function).

Press this button again to continue the playback.

Introduction Scan

Press INT to play the rst 10 seconds of each track on CD/USB.

Press again to cancel the INT function.

• INT ON - Plays the rst 10 seconds of each track.

• INT OFF - Cancels the INT function.

Repeating The Track

Press RPT to toggle between RPT FLD, RPT ALL, and RPT ONE.

• RPT FLD - Continuously repeats all les in current folder.

• RPT ALL - Plays all tracks on CD/USB device.

• RPT ONE - Continuously repeats selected track.

Playing All Tracks In Random

Press RDM to play songs in random order, press again to cancel the RDM

function.

• RDM ON - Plays all tracks in random order.

• RDM OFF - Cancels the RDM function.

1. (Power ON/OFF) Button

2. VOL +/VOL- (volume up/down)

3. Band button, (reply call)

4. button: Tune down, seek down;

Track down, fast reverse

5. SEL (selection) button

6. button: Tune up, seek up; Track up,

fast forward

7. Mute/DEL (Delete) button

8. CLK (clock setting) button,

(end call) button

9. button: preset station 1 button,

keypad 1

10. INT (intro) button,

preset station 2 button, keypad 2

11. RPT (repeat) button,

preset station 3 button, keypad 3

12. RDM (random), preset station 4 button,

keypad 4

13. -10 (previous 10 tracks),

preset station 5 button, keypad 5

14. +10 (next 10 tracks),

preset station 6 button, keypad 6

15. ST (stereo) button, keypad 7

16. LOUD (loudness) button, keypad 8

17. AMS (automatic music search) button,

keypad 9

18. MODE button, keypad

19. EQ (Equalizer) button, keypad 0

20. LOC (local)/DX button, keypad #

www.PyleUSA.com

Folder/Trock Navigotion

• Press the or button to select the previous or the next folder.

Folder access is only available on devices with more than one folder.

• Press and hold the or buttons to jump 10 tracks backward or forward.

It is required that over 10 tracks be available on the storage medium.

Remote Control

Name of buttons and location

www.PyleUSA.com

WIRELESS BT OPERATION

Pair And Connect

Before using the Wireless BT device as a handsfree system for a BT enabled

mobile phone for the rst time, you must pair and connect the two devices

as follows:

1. In any mode, prior to pairing and connecting, the BT logo on the LCD indicating

that no device is connected. The head unit broadcasts the pairing signal

constantly when no devices are connected. Activate the BT on your device

before you begin with the pairing process.

2. When your phone nds the car audio system, the“PYLE" name will be displayed

on your phone screen.

3. Choose the“PYLE" from your mobile phone list to pair and connect with the

car audio system. Upon conrming, the BT logo will stop ashing.

4. When pairing is complete, the mobile phone audio will automatically transfer

to the car audio system whenever a call is made or received, or when the

mobile phone plays music.

Note:

For more deatails of Wireless BT pairing, please refer to the owner's manual for

your mobile phone.

Make A Call

• To make a call, dial the call directly from the paired mobile phone.

Redial Last Dialed Number

Press and hold the button to redial the last dialed phone number.

Press the button to activate SIRI function.

Answer A Call

When the mobile phone is called, the incoming telephone number displays on

the LCD display, press the button to answer the incoming call.

Reject Or End A Call

Press the button to reject, press and hold the to end the call.

Switch Audio Between Cor Audio And Mobile Phone

During a call, press the button to switch the audio source from the car audio

system back to your mobile phone.
