Qpcom QP-748MI Gebrauchsanweisung

QP-748MI User Manual

Version 1.0

www.qpcom.com

Hardware User Manual

Industrial Managed Ethernet Switch

QP-748MI

QP-748MI User Manual

Version 1.0

www.qpcom.com

Contents

Overview ................................................................................................................................................. 1

Package Check List ............................................................................................................................ 1

Hardware Description ............................................................................................................................. 2

Front Panel Instruction...................................................................................................................... 2

Dimensions ......................................................................................................................................... 2

Top View ............................................................................................................................................ 3

LED Instruction................................................................................................................................... 3

Reset Button ...................................................................................................................................... 4

USB Port ............................................................................................................................................. 4

Hardware Installation ............................................................................................................................. 5

SFP Cabling......................................................................................................................................... 5

Wiring Power Inputs........................................................................................................................... 6

Wiring Fault Alarm............................................................................................................................. 7

Wiring Digital Inputs .......................................................................................................................... 7

Double-Secure Power Input Fault Alarm........................................................................................... 7

Mounting............................................................................................................................................. 8

Installation Steps ............................................................................................................................... 9

Specification .......................................................................................................................................... 10

QP-748MI User Manual

Version 1.0

Overview

This user manual is for QP-748MI is an industrial managed gigabit Ethernet switch with the following hardware

features:

Interface

▪MDI/MDI-X function supported on all copper ports

▪Embedded 8x Gigabit Ethernet ports + 4x 1000 SFP Slot

▪Store-and-forward switching architecture

Switch Properties

▪Up to 16K MAC Address Table supported

▪Up to 16000bytes Jumbo Frame supported

▪Up to 12Mbits Packet Buffer supported

Power Input

▪Redundant 12-48VDC power

Temperature

▪Standard operating temperature: -10°C ~ 60°C (14°F ~ 140°F)

▪Extended operating temperature: -40°C ~ 75°C (-40°F ~ 167°F)

▪Storage temperature: -40°C ~ 85°C (40°F ~ 185°F)

Mechanical Construction

▪Class IP30 protection

▪DIN-Rail Mounting, Optional Wall Mounting

PACKAGE CHECK LIST

The QP-748MI is shipped with the following items. Ensure that all the items are in the box. If any item

is missing or damaged, contact us for assistance.

▪QP-748MI switch x 1

▪Protective caps for 8x copper ports, 4x SFP slots, 1x USB port, and 1x RJ45 console port

▪User manual CD x 1

▪Wall mount brackets and screws (Optional)

▪RJ45 to RS232 Serial console cable x 1

QP-748MI User Manual

Version 1.0

Hardware Description

FRONT PANEL INSTRUCTION

The following picture is the front panel for "QP-748MI".

DIMENSIONS

WxHxD: 72x145x118 mm

QP-748MI User Manual

Version 1.0

TOP VIEW

This is the top view of the QP-748MI containing the

ground, power inputs, and fault alarm relay.

LED INSTRUCTION

System LEDs

LED

Color

Status

Description

PWR1

Green

Power is supplied on the power input 1.

Off

Power is not supplied on the power input 1.

PWR2

Green

Power is supplied on the power input 2.

Off

Power is not supplied on the power input 2.

Fault

Green

The system boots up and in normal operation.

Off

The system is powered off or during booting.

Red

The configured event of failure is triggered.

Green

This device has the Ring Master.

Off

The Ring Master is not on the device.

Ring

Green

The Ring protocol is enabled and works normally.

Flickering

The Ring protocol is enabled, but works abnormally.

Off

The Ring protocol is disabled.

QP-748MI User Manual

Version 1.0

Interface Status LEDs

LED

Color

Status

Description

SFP Slot

P9 to P12

(1000M)

Green

The 1000Mbps link of the fiber port is active.

Flickering

Data is transmitted on the fiber port at 1000Mbps.

Off

The 1000Mbps link of the fiber port is inactive.

LAN Port

P1 to P8

(1000M)

Green

The 1000Mbps link of the port is active.

Flickering

Data is transmitted on the port at 1000Mbps.

Off

The 1000Mbps link of the port is inactive.

LAN Port

P1 to P8

(10/100M)

Green

The 10/100Mbps link of the port is active.

Flickering

Data is transmitted on the port at 10/100Mbps.

Off

The 10/100Mbps link of the port is inactive.

RESET BUTTON

A multifunctional reset button is provided. Use a pointed object such as toothpick or paper clip

(straightened) to press the reset button.

Continuous

Seconds

Action

Save the running configuration to the USB device named "running-config".

Reboot the system.

More than 7

Reset the system to factory default and reboot it.

USB PORT

A USB port is available on the switch that is located between the Console port and Reset

button. This USB port provides the following features:

▪Backup/Restore Configurations

▪Auto-Load configuration from USB

▪Auto-Backup configuration to USB

▪Save system logs to USB

QP-748MI User Manual

Version 1.0

Hardware Installation

SFP CABLING

There are 4x 1000 SFP Slot SFP Slots on the QP-748MIswitch. The 100Tx SFP module is not supported

in this model. The following table is the SFP modules that is recommend to the users.

Part No.

Wave

(nm)

Media

Power

(dBm)

Sen.

(dBm)

Code

Dist.

Temp.

1.25Gbps (Gigabit Ethernet/ 1000Base-X/ Fiber Channel SFP)

QPCOM-1000Base-X1

850

MMF

-9.5~-4

-17

550m

0~70°C

QPCOM-1000Base-X2 (DDM)

1310

SMF

-9.5~-3

-20

10km

0~70°C

QPCOM-1000Base-X3

1310

SMF

-9.5~-3

-20

10km

-40~85°C

QPCOM-1000Base-X4 (DDM)

1310

SMF

-9.5~-3

-20

10km

-40~85°C

1.25Gbps (1000Base-BX, Single Fiber Bi-Directional SFP)

QPCOM-1000Base-BX1 Dual-Rate

T1310

R1490

SMF

-9~-3

-20

1000BX10-U4

10km

0~70°C

QPCOM-1000Base-BX2 (DDM)

T1310

R1490

SMF

-9~-3

-20

1000BX10-U4

10km

-40~85°C

QPCOM-1000Base-BX3 Dual-Rate

T1490

R1310

SMF

-9~-3

-20

1000BX10-U4

10km

0~70°C

QPCOM-1000Base-BX4 (DDM)

T1490

R1310

SMF

-9~-3

-20

1000BX10-U4

10km

-40~85°C

Copper SFP (Gigabit Ethernet/1000BaseT)

QPCOM-1000Base-T

1.25Gbps

Copper

SFP-1000T-LOS

AutoNeg: On

100m

0~70°C

Insert SFP Module

1. Insert the SFP module. A triangle is available on the switch and SFP module.

QP-748MI User Manual

Version 1.0

2. Push the SFP module down.

Remove SFP Module

1. Press and remove the SFP cable.

2. Open the SFP module and remove it.

WIRING POWER INPUTS

1. Insert the positive and negative wires into the PWR1 (+,-) and PWR2

(+,-) on the 4-contact terminal block connector.

2. Tighten the screws to prevent the wires from loosening.

QP-748MI User Manual

Version 1.0

WIRING FAULT ALARM

1. Insert the wires into the left two contacts of the 4-contact terminal

block (Fault Alarm Relay).

2. Tighten the screws to prevent the wires from loosening.

3. The relay will detect the power and link failure.

4. Users can connect the relay to an alarm and buzzer so that when

the relay forms an open circuit, the users will be notified.

WIRING DIGITAL INPUTS

1. Insert the positive and negative wires into the right two contacts

(+,-) of the 4-contact terminal block (DI).

2. Tighten the screws to prevent the wires from loosening.

3. The system will detect the voltage go through the DI.

▪+13 to +30V for state "1"

▪-30 to +3V for state "0"

▪Max. input current: 8mA

DOUBLE-SECURE POWER INPUT FAULT ALARM

The power inputs are designed as a "common

negative", which implies that the negative input is

connected, but "double-secure" is supported to

prevent the unnotified failure of power from one of the

negative inputs. If one of the negative power input

fails, the system will detect it and the system will

trigger the event if the users set the fault alarm or

event log for powers.

QP-748MI User Manual

Version 1.0

MOUNTING

Din-Rail Mounting

a. Screw the DIN-Rail bracket to the switch.

b. Insert the top of the DIN-Rail bracket to the DIN-

Rail track.

c. Pull down the DIN-Rail bracket to the DIN-Rail track and check if it is mounted tightly on the DIN-Rail

track.
