Race Navigator RN PRO Bedienungsanleitung

Thank you for choosing RN PRO!

Please read this manual before using the device for the first

time.

Visit the website for more information:

www.race-navigator.com

Updated 05-09-18

Release date: 11/05/2016

TABLE OF CONTENTS

DELIVERY SCOPE......................................................................................................................................................... 9

RACE NAVIGATOR PRO ............................................................................................................................................... 9

RN PRO MAIN UNIT INSTALLATION ...........................................................................................................................10

TURNING ON THE RN PRO MAIN UNIT.......................................................................................................................10

RN PRO MAIN UNIT ..................................................................................................................................................11

RN PRO DISPLAY........................................................................................................................................................13

RN PRO WITH DISPLAY AND CAMERAS......................................................................................................................15

RN PRO CLAMP..........................................................................................................................................................17

RN ANALYZER APP.....................................................................................................................................................20

1HOME................................................................................................................................................................23

2STATUS BAR ......................................................................................................................................................24

3DASHBOARD .....................................................................................................................................................25

3.1 DASHBOARD ·PANEL 1...................................................................................................................................... 25

3.2 DASHBOARD ·PANEL 2...................................................................................................................................... 26

3.3 DASHBOARD ·PANEL 3...................................................................................................................................... 26

3.4 DASHBOARD ·PANEL 4...................................................................................................................................... 27

3.5 DASHBOARD ·PANEL 5...................................................................................................................................... 27

3.6 DASHBOARD ·MIRROR VIEW DASHBOARD ............................................................................................................ 28

4MANUAL RECORDING .......................................................................................................................................29

5RECORDING WITH OBD-II DIAGNOSTIC DATA....................................................................................................30

6LAPS HISTORY (LAPS).........................................................................................................................................31

6.1 LAP DETAILS..................................................................................................................................................... 32

6.2 REVIEW DRIVE ................................................................................................................................................. 32

6.3 VIDEO PLAYER..................................................................................................................................................33

7EVENTS..............................................................................................................................................................33

8ANALYSIS...........................................................................................................................................................34

9SETTINGS...........................................................................................................................................................35

10 DRIVER..............................................................................................................................................................36

10.1 DRIVER ·ADD .................................................................................................................................................... 36

11 CAR ...................................................................................................................................................................38

11.1 CAR ·ADD .........................................................................................................................................................38

11.2 CAR ·CONFIGURE CANBUS..................................................................................................................................40

12 TRACK ...............................................................................................................................................................49

12.1 TRACK VARIANTS ............................................................................................................................................. 52

12.2 TRACK VARIANTS ·EDIT ....................................................................................................................................52

12.3 TRACK VARIANTS ·ADD ....................................................................................................................................53

13 EVENT ...............................................................................................................................................................54

13.1 EVENT ·TRACKDAY ............................................................................................................................................. 55

13.2 EVENT ·ENDURANCE...........................................................................................................................................56

13.3 EVENT ·TAXI ..................................................................................................................................................... 57

13.4 EVENT ·STREET MODE ........................................................................................................................................ 58

13.5 EVENT ·RCN MODE ........................................................................................................................................... 63

13.6 EVENT ·RALLY ................................................................................................................................................... 67

13.7 EVENT AUTO MANAGED .................................................................................................................................... 71

13.8 EVENT AUTO MANAGED REC LIMIT.....................................................................................................................72

14 NETWORK .........................................................................................................................................................73

15 CAMERA............................................................................................................................................................75

16 DEVICE ..............................................................................................................................................................76

16.1 DEVICE ·STATUS ................................................................................................................................................ 77

16.2 DEVICE ·CLOCK.................................................................................................................................................. 78

16.3 DEVICE ·UPDATE ............................................................................................................................................... 79

16.4 DEVICE ·DIAGNOSTICS ........................................................................................................................................ 82

16.5 DEVICE ·RN RESET............................................................................................................................................. 83

16.6 RN RESET ·RESET EVENT DATA ..............................................................................................................................83

16.7 RN RESET ·FACTORY SETTINGS...............................................................................................................................84

16.8 RN RESET ·RN RECOVERY.....................................................................................................................................84

16.9 DEVICE ·HELP ................................................................................................................................................... 85

16.10 DEVICE ·LOGO ..............................................................................................................................................85

16.11 DEVICE ·VIDEO,SOUND ..................................................................................................................................86

16.12 DEVICE ·UNITS.............................................................................................................................................. 87

16.13 DEVICE ·ADDITIONAL SETTINGS ·PIT LANE MONITOR.......................................................................................88

16.14 DEVICE ·G-FORCE........................................................................................................................................ 95

16.15 DEVICE ADDITIONAL SETTINGS POWER MANAGEMENT ........................................................................................97

16.16 DEVICE ADDITIONAL SETTINGS AUTO REMOVE................................................................................................... 98

16.17 DEVICE ADDITIONAL SETTINGS TIME ................................................................................................................98

16.18 DEVICE ·NON-RECORDING ZONE................................................................................................................99

17 AUTOSTART.....................................................................................................................................................101

18 LAYOUT...........................................................................................................................................................102

19 EXPORT IMPORT .............................................................................................................................................104

20 EXPORT VIDEO ................................................................................................................................................105

21 IMPORT VIDEO................................................................................................................................................106

22 RN WI-FI DASHBOARD MODES........................................................................................................................107

22.1 RN MIRROR DISPLAY..........................................................................................................................................107

22.2 RN REMOTE DASHBOARD....................................................................................................................................108

23 MORE INFORMATION AND SAFETY PRECAUTIONS..........................................................................................110

24 REGULATORY INFORMATION ..........................................................................................................................112

Delivery scope

Take the Race Navigator PRO out of the box and

check the content:

•Race Navigator PRO Main Unit,

•External GPS antenna,

•12 V caradapter cable and240 V charger,

•Front Cover.

Additional components can vary depending on

ordered package. Please charge the battery with

the external charger before the firstuse.

Race Navigator PRO

The RN PRO is an autonomous modularly built system which largely functions

wirelessly. The system is highly flexible and easy to use and sets the standard for

video and data analysis.

A number of functions are available including:

•Full HD video recording (1080p/30fps) or HD (720p/30fps),

•Cameras withwide-angle lensand image stabilizer,

•Night vision camera with HDresolution works up to0,01 lux,

•Composite video and data upto 4 cameras simultaneously,

•HDMI video output,

•High dynamic range microphone,

•Recording starts and ends automatically, depending on the

speed,

•GPS position and speed(10 Hz),

•Acceleration sensor (20 Hz),

•Gyro sensor (roll/yaw/pitch) and compass,

•Engine speed, throttle position and more car-specific data via

OBD2 or CAN connectors,

•Wireless (Wi-Fi) data/video transfer,

•Export of data/video to USB stick (USB 3.0).

RN PRO Main Unit Installation

A. Connect the RN Clampto the RN PRO (page 14). Take the holder and screw it to

the device with the clamp. In the vehicle, put the sucker ofthe holder below the

rear-view mirror and fasten it tight to the windscreen with the clamping lever.

Make sure that the mounted RN PRO can record videos properly. In general, the

best position is about 5−10 cm above the dashboard.

Adjust the RN PRO so that the top is approximately in balance. Check the

position by recording a test video.

NOTE: Before every ride, check the adherence of the holder. An incorrectly

installed device might get detached from the windscreen and get damaged,

causing damageto the car or serious injuries to the driver.

B. RN PRO can be also installed using the car chassis mounting screws. You can

directly mount the main unit on the floor or to the rollcage in your racing car.

Turning on the RN PRO Main Unit

Turn the RN PRO on by pressing the Power button

for at least three seconds.

Turning off

Turn the RN PRO or RN PRO Wi-Fi Dashboard off

by pressing the Power button for a brief moment.

Wait for powering off the device.

Holes for car chassis mounting screws
