Probe Stand Quick Start Guide
1
2
3
4
5
6
1
2
3
4
5
6
Assembly
1. First place/slide the longest 80 cm into the foot of the stand.
2. Then use the connector pieces to connect the remaining three tubes of 50
cm and end with the lid.
3. Place the probe holder over the tubes and tighten it with the screw at the
back.
Stand Parts
The Probe stand consist of the following
parts:
• 1 x Stand foot
• 1 x Probe holder
• 3 x Tube connector pieces
• 1 x Top tube lid
• 1 x 80cm tube
• 3 x 50cm tube
Probe Stand Quick Start Guide
80CM
130CM
180CM
230CM
50CM
50CM
50CM
80CM
Tip
The probe holder can be either, moved over the
completed tube to match te desired height.
Or can be attached at the last top tube and when
height adjustment is need the seperate tubes are
added. This way the adjustment of the probe holder
is only changed once.
