PT3002 Flow SensorTransmitter

Installation and Programming Instructions

Instrucciones de instalación y programación

2PT3002 Flow SensorTransmitter • Installation and Programming Instructions

ENG

Contents

Wiring Instructions............................................3

For Use As A High Flow Shut O Device With A

Stand Alone Controller......................................4

Using a Normally Closed Master Valve .................4

Using a Normally Open Master Valve ..................4

For Output to Maxicom®....................................5

Initial Powerup ................................................6

Display and Key Pad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6

General Programming ........................................6

Step 1 .......................................................6

Step 2a......................................................9

Step 2b.....................................................11

Resetting the 3002 After a High Flow Occurrence..........13

Resetting the 3002To ZeroTotal Flow Readings ...........13

Appendix A .....................................................

Appendix B .....................................................

ESP

page 14

PT3002 Flow SensorTransmitter • Installation and Programming Instructions 3

Wiring Instructions

NOTE: Refer to the PT3002 Flow Monitor and NEMACAB Installation sheet for more detailed instructions.

Wire red wire from ow sensor to terminal four on

terminal block with seven terminals. Wire black wire from

ow sensor to terminal ve on terminal block with seven

terminals. See wiring diagram label on side of PT3002.

Wire the red lead (+) from the PT Power Supply to the

terrminal one on the three port terminal block. Wire the

black / white (-) wire to terminal two of the three port

terminal block.

Flow

Sensor

PT3002

red

black

blue

red

black

blue/white

PT3002

Controller

Master

Valve

COM

COM MV

PT3002

24 Volt

Power Supply

Master

Valve

COM

COM LINE

PT3002

Link MIB Board

Site Satellite

SENSOR PORT

(-)(+)

PT3002

Pulse Decoder

Power

Supply

(-) (+)

Flow

Sensor

PT3002

red

black

blue

red

black

blue/white

PT3002

Controller

Master

Valve

COM

COM MV

PT3002

24 Volt

Power Supply

Master

Valve

COM

COM LINE

PT3002

Link MIB Board

Site Satellite

SENSOR PORT

(-)(+)

PT3002

Pulse Decoder

Power

Supply

(-) (+)

4PT3002 Flow SensorTransmitter • Installation and Programming Instructions

Wiring Instructions (cont.)

Using a Normally Closed MasterValve

Wire one leg of the master valve solenoid wire to the

Relay 1 NC 2 terminal. Wire the Relay 1 COM 3 terminal to

the master valve terminal in the controller.

Note: Wire master valve common to controller common

as in any normal installation.

Flow

Sensor

PT3002

red

black

blue

red

black

blue/white

PT3002

Controller

Master

Valve

COM

COM MV

PT3002

24 Volt

Power Supply

Master

Valve

COM

COM LINE

PT3002

Link MIB Board

Site Satellite

SENSOR PORT

(-)(+)

PT3002

Pulse Decoder

Power

Supply

(-) (+)

For Use As A High Flow Shut O Device With A Stand Alone Controller

Using a Normally Open MasterValve

Wire one leg of the master valve solenoid wire to the Relay

1 NO 1 terminal. Wire the second leg of the solenoid to an

auxiliary 24 volt power supply. Wire the Relay 1 COM 3 to

the other leg of the auxiliary power supply. When a high

ow condition occurs the internal relay closes, powering

the normally open master valve and closing it.

Flow

Sensor

PT3002

red

black

blue

red

black

blue/white

PT3002

Controller

Master

Valve

COM

COM MV

PT3002

24 Volt

Power Supply

Master

Valve

COM

COM LINE

PT3002

Link MIB Board

Site Satellite

SENSOR PORT

(-)(+)

PT3002

Pulse Decoder

Power

Supply

(-) (+)

PT3002 Flow SensorTransmitter • Installation and Programming Instructions 5

Wire the Pulse 1 Out terminal four to the positive (+)

terminal of the sensor port on a link MIB board or Site

Satellite. Wire Pulse 2 Out terminal ve to the negative

(–) terminal of the sensor port on a link MIB board or Site

Satellite.

Wire the Pulse 1 Out terminal four to the blue wire of a

pulse decoder if using two wire communications between

CCU and satellite Controller. Wire Pulse 2 Out terminal ve

to the blue / white wire of a pulse decoder.

Flow

Sensor

PT3002

red

black

blue

red

black

blue/white

PT3002

Controller

Master

Valve

COM

COM MV

PT3002

24 Volt

Power Supply

Master

Valve

COM

COM LINE

PT3002

Link MIB Board

Site Satellite

SENSOR PORT

(-)(+)

PT3002

Pulse Decoder

Power

Supply

(-) (+)

Flow

Sensor

PT3002

red

black

blue

red

black

blue/white

PT3002

Controller

Master

Valve

COM

COM MV

PT3002

24 Volt

Power Supply

Master

Valve

COM

COM LINE

PT3002

Link MIB Board

Site Satellite

SENSOR PORT

(-)(+)

PT3002

Pulse Decoder

Power

Supply

(-) (+)

For Output to Maxicom® or Site Control

(complete step

on pages 6 to 8 and step

on pages 11 to 12)

6PT3002 Flow SensorTransmitter • Installation and Programming Instructions

General Programming

Step 1

3. At the Setup

menu, press u to

go to the Flow 1

Setup Screen.

4. Press p to go to

the Flow 1 Rate

Screen.

1. Press MENU

to enter

Programming

Mode. Press

q to go to the

Password Screen.

2. Use the arrow

keys to enter a 4

digit password

then press ENTER

OR press ENTER

to bypass using a

password.

When the PT3002 is rst powered up, it runs through

internal self checks, while displaying “PT3002 DIC

Initializing." At the end of this cycle its normal display

will appear.

Plug the PT3002 Flow Monitor

power supply into a 120 VAC

electrical outlet.

Menu Enter

TX RX

Relay 1 Pulse Out

Model 3002

Enter

1-Switch to main menu

2-Backward/Previous menu

1-Save value

2-Forward/Next menu

1-Select Menu option

2-Increase numerical value

1-Select Menu option

2-Decrease numerical value

1-Select Menu option

2-Move cursor to the right

Display and Key Pad

Initial Powerup

Rain Bird

PTPWRSUPP

Menu Enter

RESET SETUP DIAG

Menu Enter

0000

Enter password

Menu Enter

PWORD DSPY FLOW1

RATE TOTAL SENSR

SETUP

Flow 1 Setup





5. Press pto Set

Units.

Menu Enter

UNITS #.DIG CUST

Flow 1 rate

PT3002 Flow SensorTransmitter • Installation and Programming Instructions 7

7. Press MENU once

to go to the Flow

1 Setup Screen.

11. Press MENU twice

to go to the Flow

1 Setup Screen.

8. Press q to Set

TOTAL.

12. Press u to Set

SENSOR.

9. Press p to Set

UNITS.

13. Press p to Set

TYPE.

10. Set UNITS for gal

by using p or q

then press ENTER

(the PT3002 saves

the setting)

14. Press p or q

until "Pulse –DI"

appears, then

press ENTER. The

PT3002 saves the

setting and brings

you back to the

screen below

15. Press u to Set

DICAL.

6. Set UNITS for

GPM* by using p

or q then press

ENTER (the PT3002

saves the setting).

(Note: GPM used

as an example

throughout this

manual.)

Menu Enter

GPM

UNITS #.DIG CUST

Flow 1 rate

Flow 1 total

Menu Enter

UNITS #.DIG CUST

Pulse–DI

Flow 1 total

Sensor 1 type

Menu Enter

gal

Total 1 units

Menu Enter

RATE TOTAL SENSR

TYPE AVG DICAL

Flow 1 Setup

Flow 1 sensor









8PT3002 Flow SensorTransmitter • Installation and Programming Instructions

Follow Step

or Step

to complete setup.

16. Press p to

Set SENSOR K

FACTOR.

20. Press MENU until

you arrive at

the GPM / Total

Screen.

21. The screen will

look as to the

right.

17. Use the pqu

keys to enter the K

FACTOR then press

ENTER (the PT3002

saves the setting

and returns to the

Sensor Calibration

Screen)

18. Press q to Set

SENSOR OFFSET.

Note: See instructions pages 26 - 29 for Rain Bird Flow

Sensor K & Oset information or instruction sheet

included with Rain Bird Flow Sensors.

Note: See instructions pages 26 - 29 for Rain Bird Flow

Sensor K & Oset information or instruction sheet

included with Rain Bird Flow Sensors.

19. Use the pqu

keys to enter the

OFFSET then press

ENTER (the PT3002

saves the setting

and returns to the

Sensor Calibration

Screen)

Menu Enter Menu Enter

Menu Enter

KNUM OFFSET KNUM OFFSET

0.0 gal

KNUM OFFSET

1.00000000

+0.00000001

DI Sensor Cal. DI Sensor Cal.

0.00 GPM

DI Sensor Cal.

DI Sensor K Num

DI Sensor Oset





Step 1cont.

PT3002 Flow SensorTransmitter • Installation and Programming Instructions 9

Step

Set Up as a High Flow Shut O Device

With a Stand Alone Controller

Be Sure Unit is Set Up Through Step 1

Above Before Continuing

3. At the Setup

screen, press

ENTER.

5. Press p for

FUNC.

8. Press ENTER.

9. Press p.

6. Press p for

MANUAL.

7. Press p or q

until ALARM

appears. Press

ENTER to SAVE.

4. Press p for RLY1.

1. Press MENU

to enter

Programming

Mode. Press

q to go to the

Password Screen.

2. Use the arrow

keys to enter a 4

digit password

then press ENTER

OR press ENTER

to bypass using a

password.

Menu Enter

RESET SETUP DIAG

Menu Enter

0000

Enter password

Menu Enter

PWORD DSPY FLOW1

FUNC MANUAL

FUNC INPUT UNITS

LATCH SETPT RELP

Manual Control

Alarm

RLY1 PULSE AOUT1

SETUP

Relay 1

Relay 1 function

SETUP









10 PT3002 Flow Sensor Transmitter • Installation and Programming Instructions

10. Press p or q

until brackets are

around "ON" then

press ENTER.

14. Press p.

11. Press q for SET

POINT.

13. Press ENTER.

12. Use the pqu

keys to set the

Flow Threshold

Amount. (This

amount, once

exceeded, will

cause the PT3002

to break the

common and

close the master

valve, stopping

ow.) Press ENTER

when done.

15. Use the pqu

keys to set the

number of desired

seconds for the

PT3002 to wait

before breaking

the valve common

and closing the

Master Valve

once a High Flow

occurs. Press

ENTER to SAVE.

Menu Enter Menu Enter

Menu Enter

(ON) OFF SDLY

SDLY

LATCH SETPT RELP

Relay 1 latch Relay 1

Relay 1





+1.00000000

+0.00000000 s

Set Point

Trigger delay









16. Press MENU until

you arrive at

the GPM / Total

Screen.

17. The screen will

look as to the

right.

Menu Enter

0.0 gal

0.00 GPM

Step

cont.

Andere Handbücher für PT3002

Inhaltsverzeichnis

Sprachen:

Andere Rain Bird Sender Handbücher

Rain Bird

Rain Bird TBOS Bedienungsanleitung

Rain Bird

Rain Bird TBOS SYSTEM 6LR61 Bedienungsanleitung

Rain Bird

Rain Bird CYCLIK Micro Betriebsanleitung

Rain Bird

Rain Bird TBOS 635098 Bedienungsanleitung

Rain Bird

Rain Bird TBOS-II Bedienungsanleitung

Rain Bird

Rain Bird RMX-1T Bedienungsanleitung

Rain Bird

Rain Bird TBOS-II Bedienungsanleitung

Rain Bird

Rain Bird TBOS-II Bedienungsanleitung

Rain Bird

Rain Bird TBOS-II Bedienungsanleitung

Rain Bird

Rain Bird UNIK Field Transmitter Merkblatt

Beliebte Sender Handbücher anderer Marken

NIVELCO

NIVELCO EasyTREK SCA-300 Series Betriebsanleitung

Honeywell

Honeywell 5816WMBR Bedienungsanleitung

Kamstrup

Kamstrup READy MTU Betriebsanleitung

Omega

Omega ZW Series Bedienungsanleitung

ABB

ABB Field 264H Leitfaden

Alinco

Alinco DJ-V17T Bedienungsanleitung

Dejero

Dejero EnGo 3x Bedienungsanleitung

Rosemount

Rosemount 4600 Bedienungsanleitung

Speaka Professional

Speaka Professional 2342740 Bedienungsanleitung

trubomat

trubomat GAB 1000 Bedienungsanleitung

Teledyne Analytical Instruments

Teledyne Analytical Instruments LXT-380 Bedienungsanleitung

Rondish

Rondish UT-11 Bedienungsanleitung

MG 10JRE Bedienungsanleitung

Burkert

Burkert 8177 Bedienungsanleitung

Firetide

Firetide HotPort 3203 Handbuch

Tele Radio

Tele Radio T9-02 Bedienungsanleitung

Rotronic

Rotronic HygroFlex HF3 Series Bedienungsanleitung

Jamara

Jamara FCX6 Pro Tel Bedienungsanleitung
