Range Master IGNEOUS Bedienungsanleitung

Instructions for:

Andesite and Scoria sinks

IGNEOUS GRANITE SINKS

Installation Instructions

Aftercare Information

U110645-01

Due to our policy of continual improvement, we reserve the right to change specications without prior notice.

INSTALLATION

Installer

Please leave this leaet with the user, as it contains valuable

after care advice.

Tools Required

Ruler/Tape Measure Pencil

Masking Tape Safety Glasses

Kitchen Silicone Sealant Screwdriver

Hammer 35mm Hole Saw

(for cutting tap hole)

Drill Jigsaw & Suitable Blade (if

work top cutout is required)

Notes

 During installation, take care to protect the sink

from scus and scratches.

 Do not stand on the sink.

 During installation, do not stand the sink on its

edges or corners. This may cause damage.

 Avoid straining and over tightening of all plumbing

xtures connected to the sink.

 Carefully check that the moulding and edges of the

sink are dead level so that water will ow o the

drainer.

 The clamping brackets are suitable for worktops

of between 30–40 mm thickness (Fig. 1.1). If your

worktop is a dierent size then it may require

packing under the clamps or rebating (Fig. 1.2).

Preparing the Worktop

Marking Out the Opening

We recommend that you t the sink to the worktop before

permanently xing the worktop to the cabinet.

1. Place the sink upside down on the worktop. Position

the sink on the worktop as required. Make sure the

cabinet framework will clear all parts of the sink. Using a

soft, sharp pencil draw around the sink as accurately as

possible (Fig. 1.3). Remove the sink.

2. Draw another line 10mm inside the sink top outline –

this is the cutting line for the opening (Fig. 1.4).

3. Drill as large a hole as possible inside the cutting line.

Using a pad saw, jigsaw or similar, cut out the opening

up to the cutting line.

Sealing the Edges of the Opening.

We recommend that porous edges around the cut-out are

sealed using a waterproof sealant such as varnish, paint or

wood glue . This will prevent swelling of the worktop should

any small leaks occur (Fig. 1.5).

Worktop

Final position

of sink

Cutting line for opening

10 mm

Less than

Fig. 1.1

Fig. 1.2

Fig. 1.3

Fig. 1.4

Fig. 1.5

Preparing the Sink

Tap Hole Preparation

Drilling a pre-marked hole for taps

 Before drilling please read safety instructions

supplied with hole saw.

 The front face must be fully supported to prevent

cracking when drilling or cutting.

 WARNING!

Any machining operation will produce ne particles

of dust. Drilling or cutting MUST be carried out in a

well-ventilated area.

1. Identify which pre marked tap hole(s) you will require.

2. Using a hole saw, drill out the tap hole part way from

the underside of the sink Fig. 1.6. Finish drilling the hole

from the upper surface of the sink to ensure a clean

hole.

3. It may be necessary to cool the tip of the drill with water

to prevent burning. For this reason we recommend the

use of a rechargeable drill. Take special care if using a

mains electric drill around water.

4. Attach the tap, waste and overow (where required) to

the sink according to the manufacturer’s Instructions.

Applying the Silicon Sealant

 DO NOT use Epoxi sealant or Epoxi adhesive.

Apply a bead of “Silicone sealant”(not included) to the

underside of the sink ange. For nal t, make sure each sink

clip is pulled back as shown in Fig. 1.7. Position the sink into

the work top opening.

Secure the sink by pivoting the sink clips into the position

Fig. 1.8 and tighten screws in the front, then tighten rear and

side screws.

Waste Fittings

Fit the waste ttings to the sink using the instructions

supplied with them. Apply a uniform bead of silicone onto

the underside of the rim of the sink, 1/4 inch from the outer

edges of the rim.

Fitting the Sink

1. Turn the sink upside down and lay the worktop over

the sink. Swing each clip into place – this is the most

eective method, although if the worktop has been

tted to the cabinet the sink can be placed in the

opening and xed in position from underneath.

2. Centre the sink. Tighten the xing screws in the

sequence shown in Fig. 1.9.

 DO NOT TIGHTEN FULLY AT FIRST ATTEMPT.

3. Remove any surplus sealing material or wipe away any

excess sealant.

Check for Leaks:

• Supply user tubes to faucet

• Supply riser tubes to shut o valves or lower connections

• Fill sink with water and check for leak around drain

• Release water from sink and check for possible leaks

• Tighten a s needed

Drill starter hole from bottom.

Finish drilling hole from top.

Fig. 1.6

SinkWorktop

1 2 3

Fig. 1.7

Fig. 1.8

Fig. 1.9

25 Year Guarantee

We guarantee to replace any igneous granite sink that

breaks due to material or manufacturing defects within

25years from the date of purchase.

The guarantee does not cover normal wear and tear

occurring through use of the product.

For the guarantee to apply the owner must follow the use,

care and cleaning instructions provided.

Accessories and waste ttings are not included in this

guarantee.

Meadow Lane, Long Eaton,

Nottingham, NG10 2GD, England

Tel: +44 (0) 115 946 4000 Fax: +44 (0) 115 973 6602

E-mail: consumers@rangemaster.co.uk

www.rangemaster.co.uk

DOP Reference BEF024

CA - DA

EN 13310 : 2015

Preparation of food, washing of dishes and

discharge of domestic waste water

Kitchen sink made of: Granite Composite

After Care

Day-to-day care

Although your sink is made from extremely durable materials

and will withstand a great deal of hard use, it can be

scratched by hard or sharp objects. If the surfaces are to be

kept in a blemish free condition reasonable care should be

taken when handling such items.

 DO NOT USE THE DRAINER AS A CHOPPING BOARD.

Cleaning

Wash your sink using warm water, a soft cloth or non‐

abrasive woven nylon pad and a non‐ abrasive liquid cleaner

or detergent. This can be done as often as the sink is used.

Metallic Abrasions or Heavy Stains:

Wipe the sink using a soft cloth or non –abrasive woven nylon

pad and a liquid scouring product. Apply the liquid scouring

product sparingly and rub lightly. Repeat as necessary until

sink is clean.

Hard Water, Calcium and Lime Deposits:

Wipe with a non‐ Abrasive woven nylon pad and white

vinegar. Rinse after 20 minutes.

Please refer to www.rangemaster.co.uk for a full guide to

cleaning your sink.

 Do not use abrasive cleaning creams or powders,

scrub pads or alkali cleaners such as ammonia,

concentrated caustic soda, formic acid or anything

highly corrosive.
