MD9612FP USER’S GUIDE
0049-1237-XXX Page i REV. A
Myriad MD9612FP Flash Poll
Rack-Mount Modem
User’s Guide
MD9612FP USER’S GUIDE
0049-1237-XXX Page ii REV. A
The products and programs described in this User’s Guide are licensed
products of Raymar Information Technology, Inc. This User’s Guide
contains proprietary information protected by copyright, and this User’s
Guide and all accompanying hardware and documentation are
copyrighted.
Raymar Information Technology, Inc. does not warrant that the hardware
will work properly in all environments and applications, and makes no
warranty and representation, either implied or expressed, with respect to
the quality, performance, merchantability, or fitness for a particular
purpose.
Information in this User’s Guide is subject to change without notice and
does not represent a commitment on the part of Raymar Information
Technology, Inc. Raymar Information Technology, Inc. assumes no
responsibility for any inaccuracies that may be contained in this User’s
Guide.
Raymar Information Technology, Inc. makes no commitment to update or
keep current the information in this User’s Guide, and reserves the right
to make changes to this User’s Guide and/or product without notice.
No part of this manual may be reproduced or transmitted in any form or
by any means, electronic or mechanical, including photocopying,
recording, or information storage and retrieval systems, for any purpose
other than the purchaser's personal use, without the express written
permission of Raymar Information Technology, Inc.
©Copyright 2012
Raymar Information Technology, Inc.
7325 Roseville Road
Sacramento, California 95842
Tel: 800-695-1951
Direct: (916) 783-1951
Fax: (916) 783-1952
MD9612FP USER’S GUIDE
0049-1237-XXX Page iii REV. A
Compliances
This device complies with Part 15A of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to Part 15A of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment to an outlet on a circuit other than the one
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
If none of these actions resolves the problem, consult your distributor or
an experienced radio/television technician for additional suggestions.
Additionally, Section 15.838, paragraph d), of the FCC Rules and
Regulations states: “Where special accessories, such as shielded cables,
are required in order to meet FCC regulations, shielded cables must be
used with this equipment. Operation with non-approved equipment or
unshielded cables is likely to result in interference to radio and TV
reception. The user is cautioned that changes and modifications to this
equipment without the approval of the manufacturer could void the user’s
authority to operate this equipment.
MD9612FP USER’S GUIDE
0049-1237-XXX Page iv REV. A
Contents
CHAPTER 1 INTRODUCTION.............................1
FEATURES ...............................................................2
APPLICATIONS ..........................................................2
CHAPTER 2 INSTALLATION.........................4
UNPACKING YOUR HARDWARE.......................................4
ADDITIONAL ITEMS YOU NEED ......................................4
HARDWARE OVERVIEW................................................4
Front View..........................................................4
Component View.................................................5
INSTALLATION SUMMARY .............................................7
CONFIGURING THE MODEM...........................................7
SW1 DIP Switch Settings.....................................8
SW2 DIP Switch Settings................................... 11
SW3 DIP Switch Settings................................... 14
INSTALLING THE MODEM ........................................... 18
CONNECTING TO A TRANSMISSION LINE ......................... 19
Modular Jack Connectors................................... 19
CONNECTING AN RS-232 DEVICE ................................ 20
LEDS................................................................... 21
LOOPBACK CONTROL SWITCH...................................... 21
APPENDIX A TROUBLESHOOTING..................23
PROBLEM SOLVING................................................... 23
APPENDIX B SPECIFICATIONS.......................24
GENERAL SPECIFICATIONS.......................................... 24
MECHANICAL SPECIFICATIONS..................................... 25
BACK-TO-BACK CONNECTIONS TO A SECOND MODEM......... 26
RS-232 (RTU) Interface..................................... 26
ENVIRONMENTAL SPECIFICATIONS ................................ 27
APPENDIX C LIMITED PRODUCT WARRANTY 28
APPENDIX D RMA PROCEDURE ......................29
MD9612FP USER’S GUIDE
0049-1237-XXX Page 1 REV. A
Chapter 1
Introduction
Congratulations for purchasing the finest industrial-grade fast-poll rack-
mount modem available.
The Raymar-Telenetics MD9612FP (Flash Poll) modem is a 9600/4800/0-
1800 bps rack-mount modem designed for 4-wire, full-duplex or 2-wire,
half-duplex operation over a voice-band leased line. The modem is
designed utilizing the latest digital-signal processing (DSP) technology to
achieve high performance. The modem employs Raymar-Telenetics’
proprietary modulation and encoding scheme to achieve fast modem
training time. It is also backward compatible with Bell 202 modems.
The modem can be installed in an Myriad Rack (18 slots, 3U) from
Raymar-Telenetics. The modem occupies only one rack slot, eliminating
the hassle of equipment trays and power bricks required for “Stand Alone”
modems. The modem is powered from the modem rack.
The MD9612FP modem is ideally suited for multi-point communication
systems that require fast response time, short training time, and low
throughput delay. The modem is the most technologically advanced rack-
mount modem on the market.
This User’s Guide is designed to let you get your modem “up and running”
as quickly as possible. It contains all the information you need to install
and configure your modem. It also contains troubleshooting information
in the unlikely event you encounter a problem with your modem.
MD9612FP USER’S GUIDE
0049-1237-XXX Page 2 REV. A
Features
Though functionally similar to commercial modems, the MD9612FP
provides the following unique features that make it well suited for utility
and industrial applications.
Requires only one rack slot.
Operates over voice-band conditioned or unconditioned leased line
and pilot wires.
Operates without human intervention, making it ideal for
unmanned locations.
Works within an extended temperature range of -40ºC to +85ºC.
Designed with coupling transformers for high-voltage isolation and
common mode noise rejection in industrial and commercial
environments.
Asynchronous data rates (selectable) of 9600, 4800, and 0-1800
bps.
Easily accessible DIP switches for user configuration and option
selection.
Local analog, local digital, and remote digital loopback diagnostics.
Applications
The MD9612FP modem is designed for point-to-point and multipoint data
communications. Figure 1-1 shows a typical multipoint configuration.
Figure 1-1. Network of Multipoint Configuration
Host Modem
(Rack Mount or MD9612FP)
MD9612FP USER’S GUIDE
0049-1237-XXX Page 3 REV. A
There are a number of factors that can affect the network’s and modem’s
operation and performance. These include:
Operating speed
2-wire or 4-wire configuration
Transmission line characteristics, noise, and line impairments
Network configuration (point-to-point or multipoint)
Number of nodes on the network
MD9612FP USER’S GUIDE
0049-1237-XXX Page 4 REV. A
Chapter 2
Installation
This chapter describes how to install the modem.
Unpacking Your Hardware
Your package should include:
At least one MD9612FP modem
This User’s Guide (on CD)
If your package contents are damaged or missing, please contact your
place of purchase immediately.
Additional Items You Need
To use your modem, you need the following additional items:
An Myriad (MDR) Rack from Raymar-Telenetics
A two- or four-wire transmission line or leased line
Hardware Overview
Front View
Figure 2-1 shows a front view of the MD9612FP modem. Starting from the
top, this view shows:
A loopback test switch. See page 21.
A set of eight LEDs. See page 21.
MD9612FP USER’S GUIDE
0049-1237-XXX Page 5 REV. A
Figure 2-1. Front View of Modem
Component View
Figure 2-2 shows the component view of the modem. This view shows:
Three configuration switch blocks, designated SW1, SW2, and
SW3. See page 7.
Jumpers located in various positions on the modem. Do not
change or remove the straps from these jumpers.
Edge connectors at the back of the modem, which plug into the
backplane of an MDR Rack from Raymar-Telenetics.
MD9612FP USER’S GUIDE
0049-1237-XXX Page 6 REV. A
Figure 2-2. Component View of Modem
Switch Block SW1 Switch Block
SW2 Switch Block SW3
Edge Connectors
Configuration
Switch Blocks
Inhaltsverzeichnis
Andere Raymar Modem Handbücher
Raymar
Raymar 2.4 MIU/PowerPort Series Bedienungsanleitung
Raymar
Raymar 326X V.34 Series Bedienungsanleitung
Raymar
Raymar Myriad MD202T Bedienungsanleitung
Raymar
Raymar BBI-14.4 Betriebsanleitung
Raymar
Raymar 3460 Bedienungsanleitung
Raymar
Raymar DSP9612RM Bedienungsanleitung
Raymar
Raymar Telenetics MIU9.6FPD Bedienungsanleitung
Raymar
Raymar Telenetics MIU14.4L Bedienungsanleitung
Raymar
Raymar RMX-2 Betriebsanleitung
Raymar
Raymar DSP9612 Bedienungsanleitung
Raymar
Raymar Hidex HXII Bedienungsanleitung
Raymar
Raymar MIU202T Bedienungsanleitung
Raymar
Raymar Alliance V.34M Bedienungsanleitung
Raymar
Raymar HIDEX Bedienungsanleitung
Raymar
Raymar MOT202TSA Bedienungsanleitung
Raymar
Raymar V.32M/14.4 Bedienungsanleitung
Raymar
Raymar ASTRO 25 Analog Modem II Bedienungsanleitung
Beliebte Modem Handbücher anderer Marken
Davicom
Davicom DM562AP Bedienungsanleitung
EpiValley
EpiValley TATA indicom SXC-1080 Bedienungsanleitung
Zte
Zte WiMAX Bedienungsanleitung
Intelimax
Intelimax MA-2060 Bedienungsanleitung
SMC Networks
SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch
Telstra
Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung
US Robotics
US Robotics 3453C Bedienungsanleitung
MaxTech
MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung
Zte
Zte MF823 Bedienungsanleitung
Four-Faith
Four-Faith F1403 Bedienungsanleitung
Sierra Wireless
Sierra Wireless AIRLINK MP595W Bedienungsanleitung
Gemtek
Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
