USER'S

GUIDE

COLOR TV

Important Information

Cautions

WARNING

To reduce the risk of fire or shock

hazard, do not expose this TV to rain

or moisture. This symbol indicates

“dangerous voltage” inside

the product that presents a

risk of electric shock or

personal injury.

CAUTION:

To reduce the risk of electric shock, match wide blade of plug to

wide slot, fully insert.

ATTENTION:

Pour éviter les chocs électriques, introduire la lame la plus large

de la fiche dans la borne correspondante de la prise et pousser

jusqú au fond.

Product

Registration

Please fill out the product registration card and return it immediately. Returning this

card allows us to contact you if needed.

Keep your sales receipt to obtain warranty parts and service and for proof of pur-

chase. Attach it here and record the serial and model numbers in case you ever need

them. The numbers are located on the back of the TV.

Model No _________________________________________________________

Serial No __________________________________________________________

Purchase Date: _____________________________________________________

Dealer/Address/Phone _______________________________________________

__________________________________________________________________

Note To Cable TV Installer This reminder is provided to call your attention to Article 820-40 of the National

Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides

guidelines for proper grounding and, in particular, specifies that the cable ground shall

be connected to the grounding system of the building as close to the point of cable entry

as practical.

Operate TV only on 120 volts, 60 Hz AC power (normal house power).

FCC Regulations state that unauthorized changes or modifications to this equipment

may void the user’s authority to operate it.

This symbol indicates

important instructions

accompanying the

product.

RISK OF ELECTRIC SHOCK

DO NOT OPEN

WARNING TO REDUCE THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING

TO QUALIFIED SERVICE PERSONNEL.

Introduction

Thank you for choosing RCA

Your television is designed for long

life and superior operation. Despite its

sophistication, your new TV is

amazingly simple to operate because it

has so many automatic features.

Table of Contents

Getting Started

First-Time Operation .................................................................. 2-3

Controlling Your TV

Front Panel..................................................................................... 4

On-Screen Displays ....................................................................... 5

Remote Operation.......................................................................... 6

Operating Features

VIDEO Menu................................................................................. 7

Languages (English, French, Spanish) .......................................... 8

Closed Captioning ......................................................................... 9

SETUP Menu............................................................................... 10

Sleep Timer Operation................................................................. 11

Alarm Timer Operation ............................................................... 12

Autoprogramming Channel Memory .......................................... 13

Editing Channel Memory ............................................................. 13

Connecting Your TV

Antenna/Cable Information ......................................................... 14

Dipole Antenna Connection......................................................... 15

Home Antenna Connections ........................................................ 16

Cable-TV Connections ................................................................ 17

Cable-TV Operation .................................................................... 18

Using Optional DC Power Cord................................................... 19

Caring for Your TV

Cleaning & Care .......................................................................... 20

Accessories

Accessories .................................................................................. 21

Order Form ............................................................................. 21-22

Trouble Checks......................................................................... 23

Limited Warranty.................................................................... 24

Getting Started

First-Time Operation

The steps below will help you get your TV connected and working quickly.

Page numbers are also listed for more details.

1. Unpack TV and accessories.

Shown below are the accessories that

came packed with your TV.

2. Place batteries in remote.

1. Turn the remote control face down.

2. Press down on the ridged area of the

battery cover and slide it off.

3. Place two “AAA” batteries as shown

matching the + and – end of each

battery in the compartment.

4. Replace the cover.

3. Connect antenna or cable-TV

system.

Most antenna or cable-TV systems can

be connected as shown here.

• Details for connecting a home antenna

to your TV are on pages 14-15.

• Details for connecting a cable-TV

system to your TV are on pages 16-17.

4. Plug in the TV.

First attach the flat end of the power cord

completely into the connector on the back

of your TV, and then plug the other end

into a wall outlet.

ANTENNA

Incoming Cable fromAntenna or

Cable-TV System

Back of

ANTENNA

POWER CORD

Back of TV

2nd

1st

Insert Plug

Completely

Do This Not This

AC Power Cord 



DC Car Cord

Antenna Adapter

Replace adapter only with

stock #193983.

Dipole Antenna

+_+_

emote Control and 

Two Batteries

DISPLAY

MUTE

INPUT SKIP

VOL VOL

CHAN

MENUCLEAR RESET

PREV CH

POWER

132

465

798

VIDEO

CAPTION OFF

- SETUP +

ENGLISH

ANTENNA:CABLE

LIST FEATURES

– AUTOPROGRAM +

EDIT CHANNELS

Getting Started

First-Time Operation

5. Turn on TV and place channels

in memory.

Your TV is designed to place active

channels into your TV’s memory the first

time you turn it on.

• Press POWER on the TV or remote to

turn on the TV.

• The TV automatically cycles through all

channel numbers and places active

channels into the channel memory.

When your TV is finished, it tunes to

the lowest channel number in its

channel memory.

6. Edit the channel memory.

You can add and erase channels from

memory as desired.

• Press MENU repeatedly to highlight

SETUP. Then press +to select the

SETUP menu.

• Press MENU repeatedly to highlight

EDIT CHANNELS.

• Press +to select EDIT CHANNELS.

• Select the desired channel number by

pressing the CHANNEL up or down

button or by pressing two number

buttons.

• Then press +to add a channel, or

press –to erase a channel. Details

are on page 13.

• Press CLEAR to remove the menu from

the screen.

7. Set the clock.

• Press MENU repeatedly until SETUP is

highlighted. Then press +to select the

SETUP menu.

• Repeatedly press MENU to select

CLOCK.

• Press and hold –to set the correct hour.

Then press and hold +to set the correct

minutes.

• Press CLEAR to remove the menu from

the screen.

– CLOCK 12:00PM +

(MORE)

SLEEP -:--

ALARM 6:30AM

ALARM: OFF

– ERASE / ADD +

–

Press

repeatedly to

see 2nd setup

menu.

ANTENNA:CABLE



– AUTOPROGRAM +

EDIT CHANNELS

DISPLAY

MUTE

INPUT SKIP

VOL VOL

CHAN

MENUCLEAR RESET

PREV CH

POWER

132

465

798

VIDEO

CAPTION OFF

- SETUP +

ENGLISH



chan

vol

–

power

Front Panel

Shown here are the front-panel buttons.

Controlling Your TV

Remote Sensor

• When using the remote control, point it toward this sensor.

Headphone Jack

• You can plug an optional set of headphones into this jack for

private listening. When headphones are attached, the sound

comes through the headphones instead of the TV speaker.

• If the plug on your headphones does not fit the jack, adapters

are available at your local electronics supply store

MENU Button

• Press repeatedly until the item you want is highlighted, then

press +or –to enter the menu.

• Press repeatedly to move down each menu screen and then

press +or –to adjust each setting.

• To mute the TV, press once and then press +.

CH 11

1and 22

2Buttons (Channel Up and Down)

• Press Channel up to see the next higher channel in memory.

• Press Channel down to see the next lower channel in memory.

• You can add or erase channels in memory as desired. Details

are on page 13.

VOL Buttons (Volume Up and Down)

(Also + and – Buttons)

• Press VOL +to increase volume, or press VOL –to decrease

volume.

• Press +or – to adjust the setting of an item that is highlighted

in the menu.

• The volume display will automatically appear on the screen

when you press the VOL buttons.

POWER Button

• Press to turn the TV on or off.

Headphone Jack

Remote Sensor

Controlling Your TV

On-Screen Displays



13

SLP ALM 7:17PM

MUTE 



Sleep Timer

Alarm Timer

3MUTE

Channel Number

Time

Sleep Timer

This display appears when the sleep timer has been set.

Details are on page 11.

Alarm Timer

This display appears when the alarm timer has been set.

Details are on page 12.

MUTE

This display appears when the TV’s sound is muted. Press

MUTE on the remote. Details are on page 6.

Time

This display appears after the clock is set whenever you

change channels or press DISPLAY.

Channel Number

This display appears whenever you change channels or press

DISPLAY.

Remote Operation

When operating the remote, point it

directly at the front of the TV.

Objects between the remote and the

remote sensor can block the signal to

the TV.

Controlling Your TV

MENU Button

• Press repeatedly until the item you want

is highlighted, then press +or –to enter

the menu.

• Press repeatedly to move down each

menu screen and then press +or –to

adjust each setting.

RESET Button

• Press to return all video settings (color,

tint, contrast, brightness, and sharpness)

back to the original settings.

CLEAR Button

• Press to clear the screen of all on-screen

displays except MUTE.

Number Buttons (0-9)

• Press to access any channel number.

• To select a channel, press two number

buttons. For example, press 0 then 6 for

channel 6.

• To select a 3-digit number, press and

hold number button 1 until 1— appears

on the screen. Then press the other two

numbers.

INPUT Button

• Switches the TV to channel 03. This is

useful if you have a VCR connected to

your TV.

SKIP Button (Commercial Skip)

• Allows you to look at other channels

during commercials using the

CHANNEL buttons.

• Each press adds 30 seconds. The TV

switches back to original channel when

time runs out.

POWER Button

• Press to turn the TV on or off.

PREV CH

Button (Previous Channel)

• Pressing this button switches the TV

back to the last tuned channel. This is

useful if you want to watch two

channels.

• Select the first channel you wish to

watch. Then select the other channel by

pressing two number buttons.

• The TV changes back and forth be-

tween the two channels each time you

press this button.

DISPLAY Button

• Press to display the time and channel

number on the screen.

• Press to see if the Sleep Timer and/or

Alarm Timer is set.

• Press to quickly remove menus from the

screen.

MUTE Button

• Press to quickly reduce sound to

minimum level. Closed captioning (C1)

automatically appears on the screen

when you press MUTE.

• To restore sound and normal picture,

press MUTE again or press VOL up.

CHAN 11

1/22

2Buttons (Channel Up and

Down)

• Press to select the next higher or lower

channel in memory.

• You can add or erase channels in

memory as desired.

Details are on page 13.

VOL Buttons (Volume Up and Down)

(Also – and + Buttons)

• Press VOL +to increase volume, or

press VOL –to decrease volume.

• Press +or –to adjust the setting of an

item that is highlighted in a menu.

• The volume display appears on the

screen when you press the VOL buttons.

DISPLAY

MUTE

INPUT SKIP

VOL VOL

CHAN

MENUCLEAR RESET

PREV CH

POWER

132

465

798

Operating Features

VIDEO Menu

Press MENU until VIDEO is highlighted. Then press +to select the

VIDEO menu. Press MENU to move down the menu and +and –to

adjust each function.

Press

MENU to

select

VIDEO

Press +

for 1st

VIDEO

Screen

– VIDEO RESET +

(MORE)

The VIDEO RESET function changes all the video functions (color, tint,

contrast, brightness, sharpness) back to the factory settings. Press +or –to

reset the video functions. RESET appears on the TV screen momentarily

while the functions are being adjusted.

Press

until the

second

VIDEO

appears

COLOR

–.......I.......+

TINT

CONTRAST

BRIGHTNESS

SHARPNESS

R......I.......G

–.......I.......+

– COLOR +

TINT

CONTRAST

BRIGHTNESS

SHARPNESS

The SHARPNESS function adjusts picture sharpness. Press +or –to

select SHARPNESS. Press +to increase or press –to decrease.

The BRIGHTNESS function adjusts the brightness of the dark portions

of the picture. Press +or –to select BRIGHTNESS. Press +to increase

or press –to decrease brightness.

The CONTRAST function adjusts the overall brightness and contrast of

the picture. Press +or –to select CONTRAST. Press +to increase or

press –to decrease contrast.

The TINT function adjusts the color of flesh tones. Press +or –to select

TINT. Press +to add more green tint or press –to add more red tint.

The COLOR function adjusts the amount of color in the picture. Press +or –

to select COLOR, then press +to increase or press –to decrease color.

These functions are displayed individually at the bottom of the screen

once they have been selected. The setting can be adjusted at that time by

pressing either the +or –button.

Adjustment

Displays

Caution: When using TV games,

computers, and similar products with

your TV, keep the brightness and

contrast functions at low settings. If a

fixed (non-moving) pattern is left on the

screen for long periods of time at a high

brightness or contrast setting, the image

can be permanently imprinted onto the

screen. These types of imprints are not

covered by your warranty because they

are the result of misuse.

– VIDEO +

CAPTION OFF

SETUP

ENGLISH

Operating Features

The on-screen displays in this TV can be displayed in three languages: English,

French, and Spanish. When you select a language, most of the displays will be

shown on the screen in your preferred language.

Languages

VIDEO

CAPTION OFF

SETUP

- ENGLISH +

Selecting a Language

1. Press MENU once to bring up the

main menu and highlight ENGLISH.


SOUS-TITR – –

REGLAGES

- FRANCAIS +

2. Press +or –to select FRANCAIS

(French), ESPANOL (Spanish),

or ENGLISH.

Andere Handbücher für E13335

Inhaltsverzeichnis

Andere RCA Fernseher Handbücher

RCA

RCA ColorView E13700 Bedienungsanleitung

RCA

RCA J32BE220 Bedienungsanleitung

RCA

RCA RTDVD1900 Bedienungsanleitung

RCA

RCA HDTV Monitor Bedienungsanleitung

RCA

RCA F27677 Bedienungsanleitung

RCA

RCA RLED1945A Bedienungsanleitung

RCA

RCA E13309 Bedienungsanleitung

RCA

RCA J20542 Bedienungsanleitung

RCA

RCA TruFlat F20TF20 Bedienungsanleitung

RCA

RCA RTU4300-E Bedienungsanleitung

RCA

RCA E13710 colorView Bedienungsanleitung

RCA

RCA F19253BCFJ1 Bedienungsanleitung

RCA

RCA Victor 730TV1 Bedienungsanleitung

RCA

RCA P60100 Bedienungsanleitung

RCA

RCA 27V412T Bedienungsanleitung

RCA

RCA M20303BL Bedienungsanleitung

RCA

RCA VPORT F36650 Bedienungsanleitung

RCA

RCA G27648YX1 Bedienungsanleitung

RCA

RCA RLC4283A Bedienungsanleitung

RCA

RCA F38310 - 38" 16:9 HDTV Bedienungsanleitung

RCA

RCA G32665 Bedienungsanleitung

RCA

RCA P46811 Bedienungsanleitung

RCA

RCA F20645YX1B1 Bedienungsanleitung

RCA

RCA F19262 Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
