RCA F27550 Bedienungsanleitung

Television

User’s Guide

Changing Entertainment. Again.

Please read this manual before

operating this product for the

first time.

TOCOM 16068120

Models: F27550, F32550

This symbol indicates

"dangerous voltage" inside

the product that presents

a risk of electric shock or

personal injury.

Caution: To reduce the risk of electric

shock, do not remove cover (or back).

No user serviceable parts inside. Refer

servicing to qualified service personnel.

This symbol indicates

important instructions

accompanying the

product.

CAUTION

RISK OF ELECTRIC SHOCK DO

NOT OPEN

Caution: To prevent electric shock, match wide blade of plug to wide slot,

fully insert.

Power Consumption: 120V ~ 60 Hz A.C. 128W (model F27550),

142W (model F32550)

Attention: Pour éviter les chocs électriques, introduire la lame la plus large de

la fiche dans la borne correspondante de la prise et pousser jusqú au fond.

Refer to the identification/rating label located on the back panel of your product for its proper

operating voltage.

FCC Regulations state that unauthorized changes or modifications to this equipment may void

the user’s authority to operate it.

Caution: Using video games or any external accessory with fixed images for extended periods

of time can cause them to be permanently imprinted on the picture tube (or projection TV

picture tubes). ALSO, some network/program logos, phone numbers, etc. may cause similar

damage. This damage is not covered by your warranty.

Cable TV Installer: This reminder is provided to call your attention to Article 820-40 of the

National Electrical Code (Section 54 of the Canadian Electrical Code, Part 1) which provides

guidelines for proper grounding and, in particular, specifies that the cable ground shall be

connected to the grounding system of the building as close to the point of cable entry as

practical.

WARNING

To reduce the risk

of fire or electric

shock, do not

expose this

product to rain or

moisture.

Important Information

Product Registration

Please fill out the product registration card (packed separately) and return it immediately, or

Product Information

Keep your sales receipt to obtain warranty parts and service and for proof of purchase. Attach it

here and record the serial and model numbers in case you need them. These numbers are located

on the product.

Model No. ______________________________________________________________

Serial No. _______________________________________________________________

Purchase Date: ___________________________________________________________

Dealer/Address/Phone: _____________________________________________________

Table of Contents

Chapter 1: Connections & Setup

Things to Consider Before You

Connect .................................................. 2

Connecting Components to Your TV .... 3

TV + VCR + DVD Player ....................... 3

Using the VPORT Jack ........................... 4

Jacks on the Back of the TV ................. 5

Put Batteries in the Remote ................. 6

Complete the Interactive Setup ............ 6

Set the Menu Language...................... 6

Complete Auto Channel Search........ 6

Chapter 2: Using the Remote

Control

The Buttons on the Remote Control .... 7

Using the WHO•INPUT Button ......... 8

Programming the Remote to Operate

Other Components ................................. 8

Find Out If You Need to Program

the Remote ............................................ 8

How to Program the Remote ............ 9

How to Use the Remote After You’ve

Programmed It ....................................... 9

Remote Codes....................................... 10

Chapter 3: Using the TV’s

Features

Channel Banner .................................... 12

Why You Should Use the Auto

Tuning Feature ..................................... 13

How to Set Up the Auto

Tuning Feature ..................................... 13

Parental Controls and V-Chip ............. 14

How V-Chip Works ............................. 14

V-Chip TV Rating Limit ..................... 15

Blocking Age-Based Ratings ...... 16

Viewing Age-Based Ratings ....... 16

Blocking Specific Content

Themes .......................................... 16

Viewing Specific Content

Themes .......................................... 17

V-Chip Movie Rating Limit .............. 17

V-Chip Unrated Program Block ...... 17

Channel Block ...................................... 17

Front Panel Block ................................ 18

Lock/Unlock Parental Controls ........ 18

Chapter 4: Using the TV’s Menu

System

How to Use Your TV’s Menu System .. 19

Audio Menu ......................................... 19

Picture Quality Menu .......................... 20

Screen Menu ........................................ 21

Using Closed Captioning ..................... 21

Channel Menu ...................................... 22

Time Menu ........................................... 23

Chapter 5: Other Information

Troubleshooting ................................... 24

Limited Warranty ................................. 26

Care and Cleaning................................ 28

The Front of Your TV ........................... 28

Accessories ........................................... 29

Illustrations contained in this document are for representation only.

Chapter 1: Connections & Setup

2 Chapter 1

Things to Consider Before You Connect

Protect Against Power Surges

• Connect all components before you plug any of their power cords into the wall outlet.

• Turn off the TV and/or component before you connect or disconnect any cables.

• Make sure all antennas and cables are properly grounded. Refer to the Important Safeguards sheet

packed with your TV.

Protect Components from Overheating

• Don’t block ventilation holes on any of the components. Arrange the components so that air can

circulate freely.

• Don’t stack components.

• When you place components in a stand, make sure you allow adequate ventilation.

• If you connect an audio receiver or amplifier, place it on the top shelf so the heated air from it won’t

flow around other components.

Position Cables Properly to Avoid Audio Interference

• Insert each cable firmly into the designated jack.

• If you place components above the TV, route all cables down the side of the back of the TV instead of

straight down the middle of the back of the TV.

• If your antenna uses 300-ohm twin lead cables, do not coil the cables. Also, keep the twin lead cables

away from audio/video cables.

Important Stand and Base Safety Information

Choose the location for your TV carefully. Place the TV on a stand or base that is of adequate size and

strength to prevent the TV from being accidentally tipped over, pushed off, or pulled off. This could cause

personal injury and/or damage the TV. Refer to the Important Safeguards sheet packed with your TV.

Use Indirect Light

Don’t place the TV where sunlight or room lighting will be directed toward the screen. Use soft or indirect

lighting.

Connection Pictures

Audio/video cables are usually bundled together. For better visibility, the connection pictures in this book

show each cable separately (audio left, audio right, and video).

Cables Needed to Connect Components to Your TV

The pictures below show the cables needed for the connections represented in this book.

Notes: Audio/Video cables (A/V cables for short) are usually sold as a bundled set, but the connection pictures

in this book show each cable separately for better visibility.

Audio/Video

cables

Component video

(Y, P

, P

) cables

Component video

to VPORT cable

Coaxial cable S-Video cable

Xbox to VPORT

cable

Chapter 1 3

Connections and Setup

Illustrations contained in this document are for representation only.

Connecting Components

to Your TV

For information on using the

different jacks on the back of your

TV to hook up other components

not listed below, see the following

pages.

Note: If you prefer, we can provide you

with the name of an Authorized

Service Representative who will visit

your home for a fee to install your

electronic entertainment system and

to instruct you in its operation. For

details about this service, call 1-888-

206-3359 or visit www.rca.com.

* If you connect an S-Video cable, you

must connect the audio cables to the

INPUT1 AUDIO R and L jacks on the back

of the TV, not the INPUT2 AUDIO jacks.

TV + VCR + DVD Player

1. Connect your TV to your DVD player

A. Connect the audio cables (white and red) to the INPUT2 AUDIO R and L jacks on the back of the

TV and to the Audio Output Jacks on the DVD player.

B. If your DVD player has Component Output Jacks (Y, PB, PR), connect three video grade cables to

the Y, PB, PRjacks on the DVD player and to the Y, PB, PRjacks on the back of the TV. If your DVD

player doesn’t have Y, PB, PRjacks, go to C.

-OR-

C. If your DVD player has an S-Video jack, connect an S-Video cable to the S-Video jack on the DVD

player and the S-VIDEO jack on the back of the TV. If your DVD player doesn’t have an S-Video

jack, go to D.

-OR-

D. Connect a video cable (yellow) to the Video Output Jack on the DVD player and to the INPUT2

VIDEO jack on the back of the TV.

2. Connect your TV to your VCR

Connect a coaxial cable to the CABLE/ANTENNA jack on your TV and to the Output Jack on your VCR

(sometimes labeled OUT TO TV).

3. Connect cable or antenna to your VCR

Connect the coaxial cable from your cable outlet or antenna to the Input Jack on your VCR (sometimes

labeled IN FROM ANTENNA or IN FROM ANT).

INPUT2

TV (back panel)

R-AUDIO-L

VIDEO

S-VIDEO

R-AUDIO-L

VIDEO

INPUT1

AUDIO

OUT

CABLE/

ANTENNA

DVD

S-VIDEO

VIDEO

OUT

IN FROM ANT

OUT TO TV

CH3

CH4

VCR

VIDEO

OUT

AUDIO

From Cable

or Antenna

VPORT

4 Chapter 1

Connections and Setup

Illustrations contained in this document are for representation only.

Using the VPORT Jack

The VPORT jack lets you connect an Xbox video game console to the TV using an Xbox to VPORT cable (not

provided). Go to the Accessory Order Form on page 29 to purchase the Xbox to VPORT cable. You can also

connect a component, such as a DVD player, that has component video jacks (Y, PB, PR) using a Component

video to VPORT cable (not provided). When using the Component video to VPORT cable, make sure to

connect the left and right audio cables to the component in order for the TV to receive sound.

Note: The VPORT jack cannot be used for game consoles other than the Xbox video game console.

OUT

Pb Pr

VPORT

TV (back panel)

DVD

Xbox

R-AUDIO-L

VIDEO

CABLE/

ANTENNA

S-VIDEO

From Cable

Cable Box

r An

enn

INPUT2

R-AUDIO-L

VIDEO

INPUT1AUDIO

OUT

Xbox to VPORT cable

(not supplied)

Component video

to VPORT cable

(not supplied)

1. Connect your TV to a DVD player

Use a Component video to VPORT cable (not provided) to connect your TV to

another component, such as a DVD player, that has Y, PB, PRjacks. Connect the

Component video to VPORT cable to the VPORT jack on the back of the TV.

Connect the other ends of the Component video to VPORT cable to the Y, PB, PR

and the Audio Output Jacks on the back of the DVD.

-OR-

2. Connect your TV to an Xbox video game console

Connect the end of an Xbox to VPORT cable (not provided) labeled TV to the

VPORT jack on the back of the TV and the other end to the corresponding jack

on the back of the Xbox video game console.

Note: If you have an audio receiver, you might be able to connect a digital audio cable

to the digital audio jack that’s on the VPORT cable.

Chapter 1 5

Connections and Setup

Illustrations contained in this document are for representation only.

R-AUDIO-L

VIDEO

INPUT2

S-VIDEO

R-AUDIO-L

VIDEO

INPUT1

AUDIO

OUT

Jacks on the Back of the TV

This section describes each of the jacks on the back of the TV. When connecting A/V cables, be sure to

connect corresponding outputs to inputs (video to video, right audio to right audio, etc.)

VPORT Go to page 4 for VPORT explanation.

CABLE/ANTENNA Lets you connect a coaxial cable to receive the signal from the antenna, cable or cable

box.

INPUT1 Lets you connect a component such as a VCR, DVD

player, satellite receiver or laserdisc player.

• VIDEO provides composite video connection. The video

connector is usually yellow.

• R AUDIO provides right audio connection. The right audio

connector is usually red.

• L AUDIO provides left audio connection. The left audio

connector is usually white.

• S-VIDEO provides better picture quality than the regular

video jacks (INPUT1 and INPUT 2 VIDEO) because the color

part of the signal is separated from the black and white

part of the picture. When using S-Video, make sure to

connect left and right audio cables to the R-AUDIO-L

INPUT1 jacks.

INPUT2 Lets you connect a second component such as a VCR,

internet access device, DVD player, or laserdisc player. Its AUDIO

and VIDEO jacks are the same as described for INPUT1 above.

•Y,P

B, PR(Component Video) provides optimum picture

quality because the video is separated into three signals.

Use three video-grade cables for the connection. When

using Y, PB, PR, make sure to connect left and right audio

cables to the R-AUDIO-L INPUT2 jacks.

AUDIO OUT R/L Lets you connect an amplifier or audio

receiver for improved sound quality.

Note: You might want to turn off the TV’s speakers from the

Audio Menu. Go to page 19 for more information.

6 Chapter 1

Connections and Setup

Illustrations contained in this document are for representation only.

Set the Menu Language

1. Use the arrow buttons on the remote to highlight your

preferred language for the menu system.

2. Press OK to select that language.

SETUP

Select the language to be used

in these menus.

1 English

2 Español

3 Français

SETUP

Would you like the TV to search

for all available channels?

1 Search for channels

2 Skip this step

Use the arrow buttons on the remote to

highlight an option.

Press OK to select.

Put Batteries in the Remote

1. Remove the battery compartment cover on the remote.

2. Insert new batteries. Match the polarities (+ and -) on the batteries with the diagram on the remote.

3. Put the battery compartment cover back on the remote.

Turn on the TV

Press the TV button on the remote control or the POWER button on the TV (the first screen of the

Interactive Setup appears). The menu screens “time out” after a period of time if you don’t make a

selection. The tips in this section tell you how to access the Setup menu screens manually.

Note: Pressing the TV button not only turns on the TV, but puts the remote into TV mode. “TV mode” means

that the buttons on the remote control operate the TV’s functions.

Complete the Interactive Setup

The menu system in your TV allows the TV’s features to work properly. The first time you turn on your TV,

the setup screens appear automatically. The TV will prompt you, you answer, and the TV makes the

appropriate adjustments.

Complete Auto Channel Search

The TV will search for all channels viewable through your

antenna or cable TV system. This is called “auto programming.”

1. Press OK to tell the TV to begin searching for channels. A

progress report appears on the screen.

2. When the screen tells you the search is complete, press

OK.

Chapter 2 7

Illustrations contained in this document are for representation only.

Chapter 2: Using the Remote Control

STOP PAUSE

ON OFF

AUX

DVD SAT CABLE

PLAY FORWARDREVERSE

SOUND GO BACK

SKIPMUTE

INFO

CLEAR

GUIDE

ANTENNA

123

456

789

WHO•INPUT

VCR

RECORD

VPORT

L.E.D. The Buttons on the Remote Control

0-9 (Number buttons) Enter channel numbers and time settings directly

through the remote control.

To enter a two-digit channel, press the two digits. To enter a three-digit

channel, press and hold the first digit for two seconds until two dashes appear

to the right of the number, then add the second two. Example: to tune to

channel 123, press and hold 1 for two seconds, press 2, then press 3.

Arrow buttons (up, down, left, right) Move through the on-screen menu

system.

ANTENNA Functions as TV/VCR button in VCR mode and TV/receiver button in

SAT•CABLE mode.

AUX (auxiliary) Puts the remote in auxiliary mode to operate the component

you’ve programmed the remote to operate with this button. You can program

this button to control a cable box, audio components, a VCR, DVD player or

satellite receiver. If you set up the Auto Tuning feature (Chapter 3), pressing the

AUX button automatically tunes the TV to the correct channel.

CH (up and down) buttons Scan up or down through the current channel list.

Press once to change the channel up or down; press and hold to continue

changing channels.

CLEAR Removes any menu or display from the screen and returns you to

TV viewing.

DVD Puts the remote in DVD mode. If you set up the Auto Tuning feature (Chapter 3), pressing the DVD

button automatically tunes the TV to the correct channel.

FORWARD If you’re operating a VCR or DVD player with the remote control, press FORWARD to advance a

videotape or disc.

GO BACK Returns you to the previous channel.

GUIDE If you’re operating another component that has a guide, this button access the on-screen guide.

INFO Displays channel information.

L.E.D. (light-emitting diode) The little light on the remote that lights when you are programming the

remote. It also lights when you press a valid button on the remote.

MENU Displays the TV’s Main menu.

MUTE Lowers the volume to its minimum level. Press again to restore volume.

OK When a menu is on the screen, press OK to select the item that is highlighted.

ON•OFF Turns the TV on and off. When the remote is in another mode (VCR, DVD, Satellite, etc.) and the

remote is programmed to operate that component, you can press ON•OFF to turn the component on and

off.

PAUSE If you’re operating a VCR or DVD player with the remote control, press PAUSE when the videotape

or disc is playing to pause playback.

PLAY If you’re operating a VCR or DVD player, plays the videotape or disc.

RECORD If the remote is in VCR mode, press REC•VCR+ to start recording.

REVERSE If you’re operating a VCR or DVD player, press REVERSE to go backwards on a videotape or disc.

SAT•CABLE Puts the remote in SAT•CABLE mode. If you set up the Auto Tuning feature (Chapter 3),

pressing the SAT•CABLE button automatically tunes the TV to the correct channel.

Using the Remote Control

8 Chapter 2

Illustrations contained in this document are for representation only.

SKIP If you press this button before you change the channel, the TV waits 30 seconds and goes back to the

original channel. Each time you press SKIP, you add 30 seconds (i.e, if you press SKIP two times, the TV waits

60 seconds and turns back to the original channel). Press CLEAR to cancel skip timer.

SOUND Displays the AUDIO PROCESSOR menu.

STOP If you’re operating a VCR or DVD player, stops playing the videotape or disc.

TV Turns on the TV and puts the remote in TV mode. Also displays channel information.

VCR Puts the remote in VCR mode. If you set up the Auto Tuning feature (Chapter 3), pressing the VCR

button automatically tunes the TV to the correct channel.

VPORT Tunes the TV to the VPORT input channel. Program this button to control a cable box, audio

components, a VCR, DVD or satellite receiver. When programmed, changes the mode of the remote when the

button is pressed. To restore the VPORT button to factory default mode (unprogrammed), press and hold

VPORT, then press 1, 0, 0, and 0.

VOL (up and down) buttons Decrease or increase the TV’s volume.

WHO•INPUT In TV mode, press WHO•INPUT to toggle through the available Video Input channels (FRNT,

VID1/SVID1, VID2/CVID2, VPORT and the current channel). In SAT mode, press to select available channel lists.

Using the WHO•INPUT Button

Use the WHO•INPUT button to toggle through the available input sources (FRNT, VID1/SVID1, VID2/CVID2,

VPORT and the current channel) and view the content from the component you have connected to the TV.

1. Press TV to place the remote in TV mode. Make sure that the content from the component is turned ON.

2. Press WHO•INPUT to tune to the available input source and view the component.

3. Press WHO•INPUT again to tune back to the channel you were previously watching.

Programming the Remote to Operate Other

Components

The universal remote can be programmed to operate most brands of remote

controllable VCRs, DVD players, audio receivers, satellite receivers and cable boxes.

The remote is already programmed to operate most RCA, GE and Proscan VCRs, DVD

players, audio receivers and satellite receivers. The TV button cannot be programmed.

Find Out If You Need to Program the Remote

To determine whether the universal remote needs to be programmed, turn a

component ON, such as a VCR, point the remote at the VCR, and press the VCR

button. Then press ON•OFF or channel up or channel down to see if the VCR

responds to the remote commands. If not, the remote needs to be programmed.

How to Program the Remote

There are two ways to program the remote control: automatic code search and direct

entry. Instructions for both ways follow.

Use these buttons

when you

program the

remote to operate

another

component.

The remote may

not operate all

models of all

brands.

STOP

ON OFF

AUX

DVD SAT CABLE

PLAYREVERSE

VCR

VPORT

CLEAR

Andere Handbücher für F27550

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere RCA Fernseher Handbücher

RCA

RCA F27683GYJX1AK2 Bedienungsanleitung

RCA

RCA RLDED2952A Bedienungsanleitung

RCA

RCA F25432 Bedienungsanleitung

RCA

RCA F20640BC Bedienungsanleitung

RCA

RCA color tv Bedienungsanleitung

RCA

RCA G27669YX2AX1 Bedienungsanleitung

RCA

RCA MR32575YX0CY1 Bedienungsanleitung

RCA

RCA 14M041 Bedienungsanleitung

RCA

RCA MR13401, M14300, M19401, M2030 Bedienungsanleitung

RCA

RCA 5inch BLACK & WHITE TVwith CD Player and AM/FM... Bedienungsanleitung

RCA

RCA F19265 Bedienungsanleitung

RCA

RCA F32690 Bedienungsanleitung

RCA

RCA 35V432T Bedienungsanleitung

RCA

RCA J13804CL Bedienungsanleitung

RCA

RCA M21500 Bedienungsanleitung

RCA

RCA P46728 Bedienungsanleitung

RCA

RCA F27703 Bedienungsanleitung

RCA

RCA G32705 Bedienungsanleitung

RCA

RCA TruFlat F20TF10 Bedienungsanleitung

RCA

RCA Roku TV RTR4060-U-US Bedienungsanleitung

RCA

RCA 24V412T Bedienungsanleitung

RCA

RCA IB-F20551WN Bedienungsanleitung

RCA

RCA F25653 Bedienungsanleitung

RCA

RCA 27F554T Bedienungsanleitung

Beliebte Fernseher Handbücher anderer Marken

Philips

Philips Colour Television Bedienungsanleitung

Toshiba

Toshiba 27A10 Bedienungsanleitung

Philips

Philips 42PF9630A/37 Bedienungsanleitung

Hitachi

Hitachi 32FX48B Bedienungsanleitung

DAEWOO ELECTRONICS

DAEWOO ELECTRONICS DTQ-14V1FC Bedienungsanleitung

Changhong Electric

Changhong Electric uhd55b6000is Bedienungsanleitung

Philips

Philips Matchline 21CE7551 Bedienungsanleitung

Panasonic

Panasonic Genus TX-G10 Bedienungsanleitung

Toshiba

Toshiba 19A20 Bedienungsanleitung

Philips

Philips 25PT4523-16 Bedienungsanleitung

Sony

Sony XBR-100Z9D Bedienungsanleitung

Philips

Philips PR0930X3 Bedienungsanleitung

Philips

Philips Brilliance 231P4QPY Bedienungsanleitung

Samsung

Samsung 55S9 B Series Bedienungsanleitung

Philips

Philips 32HF9385D Fehlerbehebungshandbuch

Sharp

Sharp LC-40FI5012E Bedienungsanleitung

Loewe

Loewe Table Stand Reference 55 Bedienungsanleitung

Philips

Philips 32PFH5300 Bedienungsanleitung
