USER MANUAL
Please read and keep these instrucons
FOLDING
WALKING
FRAME
B4070WS
redgumbrand.com.au
BASICS by Redgum owns the copyright to the Folding Walking Frame user manual.
Any informaon contained in this user manual shall not be photocopied, reproduced or
translated into any other languages without the prior wrien consent of BASICS by Redgum.
BASICS by Redgum strives to provide the highest quality products possible.
Product is subject to change without noce.
© Copyright BASICS by Redgum 2021
BASICS by Redgum is part of FOR-DE Group Pty Ltd
redgumbrand.com.au
CONTENTS
1. INTRODUCTION - INTENDED USE
2. PRODUCT OVERVIEW - FEATURES / SPECIFICATIONS
3. SET UP - UNPACK and INSPECT SUPPLIED PARTS
4. SET UP - UNFOLD FRAME
5. ASSEMBLY - FIT REAR GLIDES
6. ASSEMBLY - FIT FRONT WHEELS
7. SET UP - WALKING FRAME HEIGHT ADJUSTMENT
8. USAGE - FOLDING WALKING FRAME
9. USAGE GUIDELINES - DO’s + DON’Ts
10. PRODUCT CARE - INSPECTIONS / CLEANING
11. WARRANTY
12. BASICS by Redgum - PRODUCT RANGE
redgumbrand.com.au
INTRODUCTION
Thank you for purchasing this quality BASICS by Redgum product.
If you have any issues or quesons about the Folding Walking Frame
please contact your supplier or BASICS by Redgum direct:
T: +61 8 9248 4180
E: sales@for-de.com.au
A: 1 Business Way, Malaga Western Australia 6090
INTENDED USE
This product has limitaons and should be used in accordance
to these guidelines. Failure to follow these guidelines may result
in damage to the product and injury to the user. It is the
responsibility of the user to ensure the suitability of this product
for its intended use. The user should consult their appropriate
healthcare professional if unsure of the correct product usage
for their unique circumstances.
Only use the Folding Walking Frame
for its intended purpose which is as a
stability aid on which to lean on for
support to maintain balance
whilst standing or walking.
Refer to usage guideline page for informaon
on how to use the Folding Walking Frame in
a safe manner.
IMPORTANT NOTE
This equipment MUST
be assembled for use
by a competent person.
1.
redgumbrand.com.au
PRODUCT OVERVIEW
FEATURES
Stable standing / walking frame
Great independent living aid
Adjustable height
Ø125mm front wheels / rear glides
Folds up for transit or storage
Strong lightweight construcon
Comfortable hand grips
SPECIFICATIONS (All dimensions shown are nominal)
Overall:
595mm (W) - 440mm Internal (W)
530mm (D)
825 - 1000mm (H) - 8 height sengs
Overall - Folded:
625mm (W)
100mm (D)
860mm (H) at lowest seng
Wheels:
Ø125 (5”) x 20mm - Grey PVC tyre / Black PP rim (replacements available)
Glides:
80 x 30mm - White PP (replacements available)
Product Weight: 2.6kg
Maximum User Weight: 136kg
Please contact BASICS by Redgum if you would like any further informaon
on the Folding Walking Frame .
2.
redgumbrand.com.au
SET UP- UNPACK and INSPECT SUPPLIED PARTS
Ensure you have been supplied with the following parts:
We recommend that you visually inspect the Folding Walking Frame parts
prior to assembly:
3.
IMPORTANT NOTE:
If you see any damage
suspect a fault
or are missing parts
DO NOT ASSEMBLE
THE PRODUCT and
contact your supplier
for support.
LEG
WITH
GLIDE
(x2)
LEG
WITH
WHEEL
(1 x LEFT)
(1 x RIGHT)
FRAME
(x1)
redgumbrand.com.au
4.
SET UP- UNFOLD FRAME
The Folding Walking Frame needs to be unfolded out of the box.
Please follow these steps
to unfold the frame:
1. Rotate out the side
frame that is on the
outside of frame.
2. Rotate out the
other side frame.
A loud ‘click’ will be
heard when the side
frames have been locked
into posion.
The adjustable legs are now
ready to t.
Loud ‘CLICK’
will be hear when
frame is locked into
posion.
redgumbrand.com.au
ASSEMBLY- FIT REAR GLIDES
Please follow these steps to t rear glides to frame:
1. Put the unfolded frame on its side.
2. Oer up leg with glide to REAR LEG of side frame.
Align holes in leg with press buon on frame.
3. Slide leg onto frame.
4. Push in press buon and connue to slide leg onto frame unl press buon pops
out of hole in leg. (Refer to page 7 for walking frame height adjustment)
5. Repeat process to t other leg with glide onto frame.
5.
1. Push in press buon
Locate tube with glides onto
REAR leg on frame
2. Slide leg onto frame unl press
buon pops out of hole in leg.
IMPORTANT NOTE
Press buon MUST protrude
3mm out from tube when
properly located in place.
redgumbrand.com.au
6.
ASSEMBLY- FIT FRONT WHEELS
Please follow these steps to t front wheels to frame:
1. Put the unfolded frame on its side.
2. Oer up leg with wheel to FRONT LEG of side frame.
Ensure wheel is facing toward OUTSIDE of frame.
Align holes in leg with press buon on frame.
3. Slide leg onto frame.
4. Push in press buon and connue to slide leg onto frame unl press buon pops
out of hole in leg. (Refer to page 7 for walking frame height adjustment)
5. Repeat process to t other
leg with wheel onto frame.
1. Push in press buon
2. Slide leg onto frame unl press
buon pops out of hole in leg.
IMPORTANT NOTE
Press buon MUST protrude
3mm out from tube when
properly located in place.
redgumbrand.com.au
Straight arm
when holding
walking frame
SET UP- WALKING FRAME HEIGHT ADJUSTMENT
We recommend that the
Folding Walking Frame be set at
the correct height for the user.
The user should be able to hold
onto the hand grip with a straight
arm when using the walking frame.
To adjust the height of the frame:
- Push in press buon and slide leg
onto frame unl press buon pops
out of required hole in leg.
- Repeat process to adjust other
legs onto walking frame.
Use numbers on leg tube to ensure
all legs are set at the same height.
7.
IMPORTANT NOTE
Press buon MUST protrude
3mm out from tube when
properly located in place.
