RENAULT

recommends

QXBIUDB*T[G 3DJH 

nu654-6 - CLIO II C:\Documentum\Checkout\nu654-6_eng_T1.WIN 4/11/2002 13:44 -page3

0.01

Welcome to your new RENAULT

This driver’s handbook contains all the information you will need:

• to get to know your Renault, to use it to the best advantage and to benefit from all the latest technical developments

which are incorporated in it.

• to ensure that it is always running well by following the simple, but strict, advice concerning regular maintenance.

• to enable you to deal quickly with minor faults which do not require specialist attention.

The few minutes you spend reading this handbook will be amply rewarded by the information which it provides and the

technical innovations it will bring to your attention. If certain points are still unclear, the technicians in our Network will

be happy to provide you with any additional information you may require.

The following symbols are used in this handbook to help you while you are reading it:

To indicate a risk, danger or safety advice.

The description of the models given in this handbook is based on the technical specifications known at the date this

document was produced. The handbook covers all equipment (standard or optional) which is available for these

models, but their presence on the vehicle depends on the version, options selected and country of marketing.

Certain equipment which is due to be made available during the year may also be included in this handbook.

Enjoy driving your new Renault.

Copying or translation, in part or in full, is forbidden without written permission from Renault, 92100 Billancourt 2002.

QXBIUDB*T[G 3DJH 

nu654-6 - CLIO II C:\Documentum\Checkout\nu654-6_eng_T1.WIN 4/11/2002 13:44 - page 4

0.02

Brief overview

• Tyre pressures .............................................................................................. 0.04 - 0.05

• Adjusting the seats and driving position ............................................... 1.11 ¬1.14

• Child restraints ........................................................................................... 1.24 ¬1.36

• Warning lights ............................................................................................ 1.42 ¬1.52

• Horn and headlamp flash ............................................................. 1.55 ¬1.57 - 1.62

• De-icing .................................................................................................................... 1.61

• Running in, driving ................................................................................... 2.02 ¬2.30

• Heating/air conditioning ........................................................................... 3.04 ¬3.22

• Opening the bonnet ............................................................................................... 4.02

• Levels (engine oil, windscreen washer, etc.) .......................................... 4.03 ¬4.11

• Emergency spare wheel ............................................................................ 5.02 ¬5.05

• Practical advice (changing the bulbs, fuses, repairs, operating

incidents) .................................................................................................... 5.02 ¬5.34

QXBIUDB*T[G 3DJH 

nu654-6 - CLIO II C:\Documentum\Checkout\nu654-6_eng_T1.WIN 4/11/2002 13:44 - page 5

0.03

CONTENTS

Sections

Getting to know your car .....................................................................

Driving ...............................................................................................................

Your comfort .................................................................................................

Maintenance ..................................................................................................

Practical advice ...........................................................................................

Technical specifications ........................................................................

Alphabetical index ....................................................................................

QXBIUDB*T[G 3DJH 

nu654-6 - CLIO II C:\Documentum\Checkout\nu654-6_eng_T1.WIN 4/11/2002 13:44 - page 6

0.04

Tyre inflation pressures when cold (in bar)

Versions 1.2

1.2 16V

1.4 16V

1.6 16V 2.0 16V 1.5 dCi

1.9 dCi

Tyre sizes 175/65 R14 T

185/55 R15 H

175/65 R14 T

185/55 R15 H

195/45 R16 195/50 R15 175/65 R14 T

185/55 R15 H

Normal use (2)

• Front 1.9 2.2(1) 2.3 2.3 2.2

•Rear 1.822.12.12

Motorway use (2)

• Front 2 2.3(1) 2.7 2.5 2.3

• Rear 2 2.1(1) 2.2 2.2 2.1

Wheel sizes 5.5 J 14

6.0 J 15

7 J 16 7 J 16 5.5 J 14

6.0 J 15

Tyre safety and use of chains

Refer to the information on tyres in Section 5 for information on maintenance and, depending on the version, the

conditions under which snow chains may be fitted to the vehicle.

Special features of the 2.0 16V version

The tyres on this vehicle cannot be fitted with chains. If you wish to fit snow chains, you must use special equipment.

Consult your Renault Dealer.

(1) Vehicle with automatic transmission: add 0.1 bar.

(2) Special note concerning vehicles used under full load (maximum permissible all-up weight) and towing a trailer:

Maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 0.2 bar (or 3PSI).

Refer to the information on weights in Section 6 for more details.

QXBIUDB*T[G 3DJH 

nu654-6 - CLIO II C:\Documentum\Checkout\nu654-6_eng_T1.WIN 4/11/2002 13:44 -page7

0.05

Tyre pressures when cold (in PSI) (continued)

Versions 1.2

1.2 16V

1.4 16V

1.6 16V 2.0 16V 1.5 dCi

1.9 dCi

Tyre sizes 175/65 R14 T

185/55 R15 H

175/65 R14 T

185/55 R15 H

195/45 R16 195/50 R15 175/65 R14 T

185/55 R15 H

Normal use

•Front 28 32(1) 33 33 32

•Rear 2629303029

Motorway use (2)

• Front 29 33 (1) 39 36 33

• Rear 28 30(1) 32 32 30

Wheel sizes 5.5 J 14

6.0 J 15

7 J 16 7 J 16 5.5 J 14

6.0 J 15

Tyre safety and use of chains

Refer to the information on tyres in Section 5 for information on maintenance and, depending on the version, the

conditions under which snow chains may be fitted to the vehicle.

Special features of the 2.0 16V version

The tyres on this vehicle cannot be fitted with chains. If you wish to fit snow chains, you must use special equipment.

Consult your Renault Dealer.

(1) Vehicle with automatic transmission: add 3PSI.

(2) Special note concerning vehicles used under full load (maximum permissible all-up weight) and towing a trailer:

Maximum speed must be limited to 60 mph (100 km/h) and the tyre pressure increased by 0.2 bar (or 3PSI).

Refer to the information on weights in Section 6 for more details.

QXBIUDB*T[G 3DJH 

nu654-6 - CLIO II C:\Documentum\Checkout\nu654-6_eng_T1.WIN 4/11/2002 13:44 -page8

0.06

QXBIUDB*T[G 3DJH 

nu654-6 - CLIO II C:\Documentum\Checkout\nu654-6_eng_T1.WIN 4/11/2002 13:44 -page9

1.01

Section 1: Getting to know your car

Keys - plip remote control unit ............................................................................................................ 1.02 - 1.03

Doors ....................................................................................................................................................... 1.04 - 1.05

Automatic locking of doors when driving ..................................................................................................... 1.06

Engine immobiliser system ................................................................................................................... 1.07 - 1.08

Head restraints - Seats ......................................................................................................................... 1.09 ¬1.12

Seat belts/Methods of restraint in addition to the front seat belts ................................................. 1.13 ¬1.23

Child safety ........................................................................................................................................... 1.24 ¬1.36

Clock and external temperature ...................................................................................................................... 1.37

Driving position ................................................................................................................................... 1.38 ¬1.41

Instruments ........................................................................................................................................... 1.42 ¬1.49

On-board computer .......................................................................................................................... 1.50 ¬1.52

Rear-view mirrors .................................................................................................................................. 1.53 - 1.54

Steering wheel .................................................................................................................................................. 1.54

Lighting and external signals ............................................................................................................... 1.55 - 1.56

Headlight beam adjustment ............................................................................................................................. 1.57

Wipers ................................................................................................................................................... 1.58 ¬1.60

De-icing .............................................................................................................................................................. 1.61

Visible and audible warning signals ............................................................................................................... 1.62

Fuel tank (filling with fuel) .................................................................................................................. 1.63 - 1.64

QXBIUDB*T[G 3DJH 

nu654-6 - CLIO II C:\Documentum\Checkout\nu654-6_eng_T1.WIN 4/11/2002 13:44 -page10

1.02

KEYS / RADIO FREQUENCY REMOTE CONTROL

1Remote control coded ignition

key, key for doors and fuel filler

cap.

The plip remote control 1locks and

unlocks the doors.

It is supplied with power by a

battery which has to be replaced

when the battery tell-tale light 2no

longer comes on. (Refer to the

information on the radio frequency

remote control batteries.)

If there is a child (or

animal) in the car, never

leave it unattended with

the key in the ignition.

With the key in the ignition it

would be possible to operate

electrical equipment such as the

window risers and there is a risk

that the child may be seriously

injured (by trapping his or her

neck, arm, hand, etc.).

Locking/unlocking the doors

Press the remote control for

approximately one second to lock or

unlock the doors. (Tell-tale light 2

will switch on.)

- The hazard warning lights flash

twice to indicate that the doors

have been locked.

Note: Depending on the vehicle, if

eitheradoorortailgateisopenor

not properly closed or if a rear

interior light remains in the

“continuous lighting” position

(see information on interior lights

in section 3), the hazard warning

lights will not flash.

- The hazard warning lights flash

once to indicate that the doors

have been unlocked.
