Robin America EH035V Bedienungsanleitung

PARTS

MANUAL

EH035V

ENGINE

Models

PUB-EP

Rev. 09/04

940 Lively Blvd. • Wood Dale, IL 60191 • Phone: 630-350-8200 • Fax: 630-350-8212

e-mail: [email protected] • www.robinamerica.com

EH035V - 3 - 04-04

HOW TO USE THIS MANUAL

Robin engines are identiﬁed by MODEL, SPECIFICATION, and CODE NUMBER. For each

model there may be many different versions called speciﬁcations. Each speciﬁcation will be

unique in some way. The difference may only be the paint color or it may have a different type

of PTO or some other signiﬁcant difference.

In order the identify the correct service part number, it is important to conﬁrm the speciﬁca-

tion and code numbers for your engine. The speciﬁcation and code number together are

know as the PRODUCT NUMBER.

All Robin 4 cycle engines have a Product Number label similar to the label illustrated below.

The Product Number Label has a 15 digit alphanumeric string that consists of the

SPECIFICATION (SPEC) number (11 digits) and the CODE number (4 digits). Please

note the illustration below:

X X X X

SPEC NO. (11 digits) CODE NO. (4 digits)

PRODUCT NO. (15 digits)

E H 0 3 5

EH035V - 4 - 04-04

MANUAL LAYOUT

1. SECTION NAME Parts are broadly classiﬁed according to their functions.

Refer to the Group Index (table of contents) for respective section name.

2. FIG. No. The FIG. number indexes the reference and part numbers to the illustration. Figure numbers

that vary only in the tens place (i.e..: 700 and 710) are in a group of the same section

(i.e..:Electrical Device Group).

3. REF. No . The Reference number identiﬁes the part illustration with the corresponding part number in the

part list.

4. SUBASSEMBLY SUBASSEMBLY parts of part assembly are listed below the assembly part. The subassembly

part reference number is indicated by the number led by "-" such as "-1", "-2".

5. PART NUMBER It is the number assigned for sales unit. Use the PART No. when making an order.

6. DESCRIPTION It is designation of the part.

7. QTY. Quantity of each part used for each product.

8. REMARKS This gives a distinctive feature and/or a supplementary comment for the type, the speciﬁcation,

and the part concerned. It also shows part number(s) interchangeable for the part.

9. FROM-TO This section shows the CODE No. to indicate the history of progress in which improved parts

have been introduced in the product. The FROM-TO CODE No. helps to identify PART No.

being employed in the product concerned. See the examples below:

- The part is used in the product irrespective of CODE No.

2101- The part is used in the products with CODE No. of 2101 and after this number.

- 2100 The part is used in the products with CODE No. of 2100 and before this number.

16792

EH035V - 5 - 04-04

GROUP INDEX

Group Name Page

CRANKCASE GROUP............................................................................... 6

CRANKSHAFT, PISTON GROUP .............................................................. 8

INTAKE and EXHAUST GROUP.............................................................. 10

COOLING and STARTING GROUP......................................................... 12

FUEL, LUBRICANT GROUP.................................................................... 14

ELECTRIC DEVICE GROUP ................................................................... 16

CLUTCH GROUP .................................................................................... 18

ACCESSORY GROUP............................................................................. 20

SYMBOL DESCRIPTION

AY ...........................ASSEMBLY

CP...........................COMPLETE

EX........................... EXPORT (from Japan)

FIG..........................FIGURE

FR........................... FRONT

" ..............................INCH

INCL. ......................INCLUDE

~L............................LITER

L= ...........................LENGTH (in. mm)

L.H. (LH).................LEFT-HAND SIDE

MECH.....................MECHANICAL

NO (NON)............... NONE

OPT......................... OPTIONAL

O.S. ........................OVER SIZE

SYMBOL DESCRIPTION

P= ........................... PITCH (in mm)

P.T.O. (PTO) ...........POWER TAKE OFF

REF......................... REFERENCE

R.H. (RH)................ RIGHT HAND SIDE

RR. .........................REAR

STD. .......................STANDARD

SW.......................... SWITCH

T= ...........................THICKNESS (in mm)

UN ..........................UNIT

U.S..........................UNDER SIZE

~V ........................... VOLTAGE

~W .......................... WATT

W/ ...........................WITH

W/O ........................WITHOUT

INDEX OF DESCRIPTION SYMBOLS

EH035V - 6 - 04-04

SECTION 1 CRANKCASE GROUP

FIG. 100

EH035V - 7 - 04-04

SECTION 1 CRANKCASE GROUP

REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.

1 593-10110-00 CYLINDER BLOCK SET 1 100

4 593-15014-00 ROCKER COVER 1 100

5 593-15016-00 GASKET, rocker cover 1 100

6 593-15015-00 CAMGEAR COVER 1 100

7 593-15017-00 GASKET, camgear cover 1 100

8 592-15018-00 CHECK VALVE 2 100

10 592-15010-00 LEAD VALVE 1 100

11 593-15013-00 RETAINER PLATE 1 100

12 593-65005-00 OIL CASE 1 100

13 593-65004-00 GASKET, case 1 100

14 593-65006-00 OIL TUBE 1 100

15 592-65003-00 OIL WEIGHT 1 100

17 593-55002-00-1 BLOWER HOUSING 1 100

18 011-90595-31 SOCKET HEAD BOLT 4 100

19 004-31060-80 SCREW, panhead 1 100

20 003-71060-00 GASKET, ﬁber 1 100

21 011-90499-60 SOCKET HEAD BOLT 1 100

22 004-36051-60 SCREW AY 13 100

23 011-90594-70 SOCKET HEAD BOLT 4 100

24 011-90598-60 SOCKET HEAD BOLT 4 100

26 592-65006-00 OIL GAUGE 1 100

27 021-31699-90 GASKET 1 100

28 065-01099-50 SPARK PLUG 1 100

EH035V - 8 - 04-04

SECTION 2 CRANKSHAFT, PISTON GROUP

FIG. 200

EH035V - 9 - 04-04

SECTION 2 CRANKSHAFT, PISTON GROUP

REF. PART NO. DESCRIPTION QTY. REMARKS FROM-TO FIG.

1 593-20060-00 CRANKSHAFT 1 200

3 044-01299-50 OIL SEAL, L 1 200

4 044-01299-40 OIL SEAL, S 1 200

5 593-25010-00 CLIP 1 200

7 541-25013-00 NEEDLE ROLLER BEARING 1 200

8 593-25004-00 PISTON 1 200

9 593-20040-00 PISTON RING SET 1 200

11 056-50999-90 CLIP 2 200

12 593-25009-00 PISTON PIN 1 200

EH035V - 10 - 04-04

SECTION 3 CAMSHAFT GROUP

FIG. 300
