Rocket Fish RF-ACU9025 Bedienungsanleitung

User Guide

Rocketfish Laptop AC Power

Adapter with USB

RF-ACU9025

RF-ACU9025 11-1020_MAN_V1.fm Page 1 Monday, October 3, 2011 2:27 PM

Rocketfish RF-ACU9025

Laptop AC Power Adapter

with USB 2.1A port

Contents

Introduction............................................................................2

Safety information................................................................3

Features ....................................................................................4

Using the AC power adapter.............................................5

FAQ for Rocketfish Adapters .............................................8

Specifications ...................................................................... 11

Legal notices........................................................................ 11

Three-year limited warranty........................................... 13

Introduction

Thank you for purchasing a Rocketfish universal laptop power

adapter with USB. This adapter plugs into any AC power outlet

anywhere in the world, and provides a reliable power source to

run your laptop computer and charge its internal battery.

Rocketfish adapters are made using the highest quality

components and feature all of the necessary voltage and heat

protection circuits to ensure maximum levels of safety and

efficiency.

NOTE: A physical adapter plug may be necessary to plug into

some AC power outlets outside of the United States, but no

voltage converter is needed anywhere in the world.

This adapter comes with a variety of numbered tips which

connect to the output cable of the adapter and control the

output voltage. To make sure that the proper voltage is

RF-ACU9025 11-1020_MAN_V1.fm Page 2 Monday, October 3, 2011 2:27 PM

RF-ACU9025

delivered to your laptop, you must always make sure that you

are using the correct tip for your specific laptop model. Read the

following instructions and refer to the Tip Compatibility Guide

included with this adapter to make sure you select the correct

tip for your laptop. You can also go to the Tip Wizard at

www.rocketfishproducts.com for a complete listing of

compatible models.

This AC power adapter also has the added convenience of a

built-in USB port. You can use this USB port to charge popular

USB devices such as cell phones, MP3 players, and even

higher-powered devices such as tablets and newer

smartphones, at the same time the adapter powers and charges

the laptop. Rocketfish adapters are made using the highest

quality components and feature all of the necessary voltage and

heat protection circuits to ensure maximum levels of safety and

efficiency.

CAUTION: This AC power adapter is not compatible with Mac

computers or laptops requiring more than 90 watts of power.

Safety information

• Do not expose the power adapter to rain, moisture, or

excessive dust. It may cause shock hazards.

• Do not operate the adapter in direct sunlight.

• Operate the adapter in a well ventilated area. Maximum

ambient temperature around the power adapter must not

exceed 105° Fahrenheit (40° Celsius).

• Do not open the power adapter under any circumstances.

The power adapter is not intended to be repaired in case of

failure or component defect. There are no internal

serviceable parts.

• Discontinue use and contact our toll free help line for

assistance (800) 620-2790 if any of the following should

occur:

• The adapter shuts down when it is plugged into the

device (LED turns off).

RF-ACU9025 11-1020_MAN_V1.fm Page 3 Monday, October 3, 2011 2:27 PM

• The adapter's LED light blinks when the adapter is

plugged into an AC power outlet.

• A cord or plug is damaged or frayed.

• Do not use with laptops that require more than 90 watts of

power.

• Make sure to use the correct tip for your laptop listed in the

Tip Compatibility Guide. You can also go to the Tip Wizard at

www.rocketfishproducts.com for a complete listing of

compatible models. Do not use a tip that is not listed for

your laptop.

• Keep away from children.

Features

•Providesupto90wattsofpower

• Includes over-voltage, over-temperature, and short circuit

protection

• Powers laptops using a standard AC wall outlet

• Includes a 2.1A USB port to charge additional mobile

devices, such as MP3 players, tablets, e-readers, and

smartphones, as well as more traditional devices, such as

cell phones and PDAs.

• Can be used anywhere in the world - no voltage converter

needed (an adapter plug may be necessary)

Package contents

• 90 Watt universal laptop power adapter with USB port

•Eighttips

•ACpowercord

• Tip Compatibility Guide

• User Guide

RF-ACU9025 11-1020_MAN_V1.fm Page 4 Monday, October 3, 2011 2:27 PM

RF-ACU9025

Using the AC power adapter

To use the AC power adapter:

1Locate your laptop manufacturer and model from the Tip

Compatibility Guide, or go to www.rocketfishproducts.com

and go to RF-ACU9025 to find the Tip Wizard.

2Identify the correct tip number for your laptop model.

CAUTION: The use of an incorrect tip may damage your laptop.

Do not use this product if you cannot locate your laptop model

in the Tip Compatibility Guide included with this AC adapter or

by using the Tip Wizard at www.rocketfishproducts.com. If you

still have questions, contact our toll-free help line for assistance

at (800) 620-2790.

DC input

jack

Tip

Output

cable

AC adapter AC cord

power

outlet

LED

USB port

RF-ACU9025 11-1020_MAN_V1.fm Page 5 Monday, October 3, 2011 2:27 PM

This AC power adapter is not compatible with Mac computers

or laptops requiring more than 90 watts of power.

NOTE: If the compatible tip for your laptop is not included in

the adapter package, one free tip can be ordered through the

Tip Wizard at www.rocketfishproducts.com. Use the Tip Wizard

to locate the manufacturer and model and you can order your

complementary tip. If you are unable to locate your laptop on

the Tip Wizard or need assistance please contact Rocketfish

customer service at (800) 620-2790.

3Locate the specified tip from the tip bundle provided. Each

tip is clearly numbered.

4Connect the selected tip to the end of the output cable,

making sure that the pins on the tip are aligned with the

holes in the cable. The ridge on the inside of the tip should

align with the groove in the output cable connector. Make

sure that the tip is pushed all the way into the output

cable's connector.

RF-ACU9025 11-1020_MAN_V1.fm Page 6 Monday, October 3, 2011 2:27 PM

RF-ACU9025

5Connect the AC cord to the socket on the AC adapter.

6Plug the AC cord into an AC power outlet. The LED on the

adapter turns on, indicating that the adapter is powered and

ready.

IMPORTANT: If the adapter's LED does not turn on, or if it

blinks, discontinue use and contact our toll free help line for

assistance

(800) 620-2790.

7Plug the tip connected to the output cable into the DC input

jack on the side or back of your laptop. The adapter powers

the laptop and charges its battery.

Charging additional USB devices

The AC power adapter features a convenient 2.1A USB port. This

port lets you charge any USB-enabled device, such as a cell

phone, handheld game, MP3 player, tablet, smartphone, and

others, while you use the AC adapter to power and charge your

laptop.

To charge additional USB devices:

1Plug a standard USB cable (not included) into the USB port

on the output end of the AC power adapter.

2Connect the other end of the USB cable to your device. For

best results, we recommend that you use the USB cable that

came with your device.

RF-ACU9025 11-1020_MAN_V1.fm Page 7 Monday, October 3, 2011 2:27 PM

3Connect the AC power cord to the socket on the AC power

adapter, and then plug the AC power cord into an AC power

outlet or power strip.

FAQ for Rocketfish Adapters

What tip should I use for my laptop?

You can determine the correct tip for your laptop by referencing

the Tip Compatibility Guide included with the adapter or by

visiting the Tip Wizard at www.rocketfishproducts.com. Locate

your laptop manufacturer and model and the correct tip will be

listed.

If you cannot find your specific laptop model please contact

Rocketfish customer service at (800) 620-2790 for additional

assistance.

My tip is not included, how do I order a new one?

First review the included Tip Compatibility Guide to locate the

correct tip for your specific laptop. You can also go to the Tip

Wizard at www.rocketfishproducts.com for a complete listing of

compatible models. If the compatible tip for your laptop is not

included in the adapter package, one free tip can be ordered

through the Tip Wizard at www.rocketfishproducts.com. Use

the Tip Wizard to locate your laptop manufacturer and model

and you can order your complimentary tip. If you are unable to

locate your laptop in the Tip Wizard please contact Rocketfish

customer service at (800) 620-2790.

How do I connect the tip to the adapter cable?

After you have selected the correct tip for your laptop, connect

the tip to the output cable, making sure that the ridge on the

inside of the tip aligns properly with the groove in the output

cable connector. Additionally, the pins on the inside of the tip

should be in line with the holes in the output cable. The tip

should be pushed firmly onto the cable until the tip and cable

meet and there is no gap.

RF-ACU9025 11-1020_MAN_V1.fm Page 8 Monday, October 3, 2011 2:27 PM

RF-ACU9025

What other laptops can I use this adapter for?

The Rocketfish Universal Power Adapter is compatible with

thousands of laptop models. A complete list of compatible

laptops can be viewed through the Tip Wizard at

www.rocketfishproducts.com.

Why doesn't the tip fit into my laptop?

If the tip does not appear to fit into your laptop you may have

selected the incorrect tip for your laptop. The tip should fit

snugly inside the DC input jack on the side or back of your

laptop. If the tip does not fit into the jack, do not force the tip.

Confirm you have selected the correct tip for your laptop by

referencing the included Tip Compatibility Guide or visiting the

Tip Wizard at www.rocketfishproducts.com. If you need

additional assistance please contact Rocketfish customer

service at (800) 620-2790.

Will using an incorrect tip damage my laptop?

The tips are designed to be used with specific laptops and so

you should only use the tip that is designated specifically for

your laptop. The correct tip can be identified by using the online

Tip Wizard at www.rocketfishproducts.com or by locating your

specific laptop in the included Tip Compatibility Guide.

The use of an incorrect tip may cause performance issues,

including the inability to charge the internal battery or power

the laptop, or the display of an error message on the laptop

screen. It is also possible that the use of an incorrect tip could

damage your laptop. For these reasons, it is necessary to use the

tip designed specifically for your laptop.

My laptop is less than 90 watts (e.g., 65 watts). Will

this adapter damage my laptop?

No, using this power adapter will not damage your laptop. This

adapter only supplies as much power as required by the laptop,

up to a maximum of 90 watts.

RF-ACU9025 11-1020_MAN_V1.fm Page 9 Monday, October 3, 2011 2:27 PM

My laptop is more than 90 watts (e.g., 120 watts). Will

this adapter damage my laptop?

This is a 90 watt adapter and it should NOT be used with laptops

that require more than 90 watts of power.

The label on my Rocketfish adapter says DC OUTPUT:

15-20V but my laptop is only 19V. Will the adapter

damage my laptop?

The 15-20V rating refers to the capability of the adapter and it

signifies that it can safely provide power to laptops with

voltages within this range. After you select the correct tip, the

laptop and tip combination will output the appropriate voltage

for your laptop. Please refer to the included Tip Compatibility

Guide or online Tip Wizard at www.rocketfishproducts.com to

find the correct tip for your laptop.

I notice that the adapter is warm when I use it. Is this a

problem?

During standard operation the adapter body may feel warm,

and this is normal. The adapter should always be placed in a

ventilated area in order to prevent over-heating.

How can I use the USB port to charge my other

devices?

The AC power adapter can charge one device through the USB

port at the same time that it powers or charges your laptop. See

"Charging additional USB devices" on page 8.

Does the USB port charge all USB compatible

devices?

The USB port (with 2.1A maximum output current) can charge

most USB compatible devices that are currently available,

including tablets and smartphones with higher power

requirements. For best results, we recommend that you use the

USB cable that came with your device.

RF-ACU9025 11-1020_MAN_V1.fm Page 10 Monday, October 3, 2011 2:27 PM

Andere Handbücher für RF-ACU9025

Inhaltsverzeichnis

Andere Rocket Fish Adapter Handbücher

Rocket Fish

Rocket Fish RF-AC9021 Kurzanleitung

Rocket Fish

Rocket Fish RF-GWII012 Stücklistenhandbuch

Rocket Fish

Rocket Fish RF-MRBTAD Bedienungsanleitung

Rocket Fish

Rocket Fish RF-BPRAC4 Kurzanleitung

Rocket Fish

Rocket Fish RF-BPRAC3 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-ACU12002 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-GDS010A Bedienungsanleitung

Rocket Fish

Rocket Fish RF-GUV1124 Gebrauchs- und Wartungshandbuch

Rocket Fish

Rocket Fish RF-MRBTAD Kurzanleitung

Rocket Fish

Rocket Fish RF-BCDM4 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-BCDM4 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-G1175 Installations- und Betriebshandbuch

Rocket Fish

Rocket Fish RF-G1175 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-BPRAC2 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-GWII008 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-G1179 Stücklistenhandbuch

Rocket Fish

Rocket Fish RF-ACU9025 Kurzanleitung

Rocket Fish

Rocket Fish RF-G4100 Bedienungsanleitung

Rocket Fish

Rocket Fish ND-GDS1207 Betriebsanleitung

Rocket Fish

Rocket Fish RF-WHD100 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-GUV1124 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-GUV1124 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-BCDM4 Bedienungsanleitung

Rocket Fish

Rocket Fish RF-MRBTAD Bedienungsanleitung

Beliebte Adapter Handbücher anderer Marken

PCB Piezotronics

PCB Piezotronics 090B274 Bedienungsanleitung

Auvidea

Auvidea J20 Produkthandbuch

Gossen MetraWatt

Gossen MetraWatt AT3-III E Bedienungsanleitung

Akribis

Akribis ITF-21-BISS-MIT Bedienungsanleitung

Tenda

Tenda W54U Bedienungsanleitung

ROHO

ROHO AGILITY Bedienungsanleitung

PROLiNK

PROLiNK WN2001 Bedienungsanleitung

Hawking

Hawking HUF2 Bedienungsanleitung

Airlink101

Airlink101 AWLC4030 Bedienungsanleitung

NETGEAR

NETGEAR XAV101v1 - Powerline AV Ethernet Adapter Bedienungsanleitung

Philips

Philips SWA4554S/10 Bedienungsanleitung

JVC

JVC TS-C9D2B Gebrauchsanweisung

NETGEAR

NETGEAR A6100 Bedienungsanleitung

D-Link

D-Link DWA-121 Bedienungsanleitung

Philips

Philips SWA2037 Bedienungsanleitung

Basalte

Basalte 0610-20 Bedienungsanleitung

Yealink

Yealink EHS40 Bedienungsanleitung

Balluff

Balluff BIC 1B0-IT1A7-Q40KFU-SM4A4A Bedienungsanleitung
